Samsung UN40JU6500F User manual

UHD TV
SERVICEManual
UHD TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN**JU6500F
Chassis : UWJ51
Model : UN40JU6500F
UN48JU6500F
UN50JU6500F
UN55JU6500F
UN60JU6500F
UN65JU6500F
UN75JU6500F

Contents
1. Precautions...................................................................................................................1-1
1-1. Safety Precautions ..............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Product specication ..........................................................................................................2-3
2-2-1. Feature & Specications...........................................................................................2-3
2-2-2. Detailed Specications .............................................................................................2-5
2-3. Accessories .........................................................................................................................2-9
2-4. Viewing the Functions .......................................................................................................2-10
2-5. NEW Key Features............................................................................................................ 2-11
2-5-1. 15" New UI.............................................................................................................. 2-11
2-5-2. Multi Screen............................................................................................................2-12
2-5-3. Instant On ...............................................................................................................2-13
2-6. HDMI 60P Mode................................................................................................................2-14
2-7. Supported Formats............................................................................................................2-15
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
3-1-1. TV Disassembly........................................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Troubleshooting...................................................................................................................4-1
4-1-1. Previous Check ........................................................................................................4-1
4-2. How to Check Fault Symptom.............................................................................................4-2
4-2-1. Video.........................................................................................................................4-2
4-2-2. Bluetooth / WIFI Module ...........................................................................................4-4
4-2-3. Apps / Photos, Videos & Music.................................................................................4-8
4-3. Factory Mode Adjustments..................................................................................................4-9
4-3-1. Detail Factory Option................................................................................................4-9
4-3-2. Entering Factory Mode ........................................................................................... 4-11
4-3-3. Factory Data ...........................................................................................................4-12
4-4. White Balance ...................................................................................................................4-20
4-4-1. Calibration ..............................................................................................................4-20

4-4-2. Service Adjustment.................................................................................................4-20
4-4-3. Adjustment..............................................................................................................4-22
4-5. RS-232C............................................................................................................................4-23
4-6. AV Control Tabe.................................................................................................................4-24
4-7. Updating the TV’s Software...............................................................................................4-30
5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-2
ANNEX. Exploded View & Part List [UN40JU6500FXZA TD01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN48JU6500FXZA TH01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN50JU6500FXZA IH01]........................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN55JU6500FXZA TH01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN60JU6500FXZA HD01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN65JU6500FXZA TD01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2
ANNEX. Exploded View & Part List [UN75JU6500FXZA TD01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2015 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

1-1-1. Parts List
No. Code No. Description & Specification Q’ty SA/SNA Remark
1 BN95-01992A PRODUCT LCD-AMLCD; CY-GJ040HGLV1V,JU6400, 1 SA
1-1 BN96-35593A ASSY CHASSIS TOP P; Y15_JU6.4K_40,PC+ABS 1 SA
2 BN96-35007D ASSY SPEAKER P; 6ohm,4pin,10W,JU6400 40" 1 SA
3 BN94-08476A ASSY PCB MAIN; UN40JU6500FXZC 1 SA
4 BN44-00806A DC VSS-LED TV PD BD; L40S6_FDY,L40S6_FDY, 1 SA
5 BN61-11587A HOLDER-SIDE AV; JU6400,HIPS,1 TUNNER 1 SNA
6 BN96-35345B ASSY BOARD P-FUNCTION_SW; JU7500,Function 1 SA
7 BN96-35346D ASSY BOARD P-FUNCTION ASSY; JU6400,Functi 1 SA
8 BN59-01194F NETWORK; 11ac Combo,Internal WiFi,USB 2.0 1 SA
9 BN95-01936A ASSY T CON; LSF400FN01-K,40U60Hz Flat 1 SA
10 BN96-35541G ASSY COVER P-REAR; 40JU6400,USA,HIPS V0,B 1 SA
11 BN96-35974A ASSY GUIDE P-STAND; JU6400,40"~55" 1 SA
12 BN96-35977A ASSY STAND P-BASE; JU6400,40" 1 SA
ANNEX. Exploded View & Part List [UN40JU6500FXZA TD01]
1-1. Exploded View
ANNEX-1
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
UN40JU6500FXZA (TD01)
1 BN90-06530A ASSY W/I;LED_J6000 1 SNA
0.2 BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC 1 SNA
0.2 BN81-09501V A/S PART SET-MECH W/I;UJ6P,U40JP* 1 SNA
1 S001A BN90-06543A ASSY STAND;LED_J6K,UJP6 40 6500 1 SNA
0.2 SG01A BN96-35974A ASSY GUIDE P-STAND;JU6400,40"~55" 1 SA
..3 6902-002055 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W300,L30 1 SNA
..3 SG01 BN61-11878A GUIDE-STAND NECK;JU6400_55,PC+GF20%,BLK 1 SNA
..3 AH089 BN61-11933A HOLDER-CABLE;JU6300, 6400,ABS,BLK,HB 1 SNA
..3 BN63-13705A COVER-NECK;JU6400_55,ABS,BK 1 SNA
..3 BN63-13706A COVER-NECK SUB;JU6400_55,ABS,BK 1 SNA
..3 BN96-35528A ASSY ACCESSORY-SCREW;JU7500,40 1 SNA
...4 6902-002474 BAG SCREW;LDPE,T0.05*,W70,L90,TRP,RECYCL 1 SNA
...4 HOLDER-BOLT BN61-09494D HOLDER-BOLT;BH+,SWRCH18A,L14,M4,B TYPE 8 SA
0.2 SB04A BN96-35977A ASSY STAND P-BASE;JU6400,40" 1 SA
..3 SCREW 6003-001010 SCREW-TAPTYPE;FH,+,B,M3,L6,ZPC(WHT),SWRC 6 SA
..3 6902-002205 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W400,L20 1 SNA
..3 6902-002473 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W700,L15 1 SNA
..3 BN60-00162E SPACER-FOAM;FOAM,50000mm,DARK GRAY,0.5T, 1 SNA
..3 BN61-11500A BRACKET-STAND BASE;JU6400_40,HGI,T2.0 1 SNA
..3 AS080 BN63-04755Q SHEET-COVER;32UD6500,PE,T0.05,W850mm,200 0 SNA
..3 BN63-07556B SHEET-COVER;TOC,PO,T0.07,W45mm,100M,ST-6 1 SNA
..3 BN63-13300A COVER-STAND BASE;JU6300_40,ABS,BLK 1 SNA
..3 BN64-02814A BADGE-INLET;HU7200,Ni,0.08,20,silver chr 1 SNA
..3 BN67-00327M RUBBER-FOOT;STAND,SILICON,10*10,T1.5,GRA 7 SNA
..3 BN68-05381A LABEL-BASE;Art Paper 100G,T0.08,20mmX50m 1 SNA
1 R001A BN90-07060A ASSY COVER REAR;LED_UJ6K,40 6500 1 SNA
0.2 SCREW 6001-002755 SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 14 SA
0.2 R001A BN96-35541G ASSY COVER P-REAR;40JU6400,USA,HIPS V0,B 1 SA
..3 R001 BN63-13229E COVER-REAR;JU6400_40",HIPS,BLK, BK0020,V 1 SNA
..3 T0071 BN64-02929B INLAY-TERMINAL;JU6400,PC,T0.25,W114.7,L9 1 SNA
..3 BN68-06900B LABEL-TERMINAL SIDE;JU6400,PET,T0.125,15 1 SNA
1 BN91-13789A ASSY LCM-AMLCD;BN95-01992A,CY-GJ040HGLV1 1 SNA
0.2 PANEL BN95-01992A PRODUCT LCD-AMLCD;CY-GJ040HGLV1V,JU6400, 1 SA
..3 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 8 SA
..3 BN68-05595A LABEL-STICKER;Art Paper 100G,T0.2,80mmX2 1 SNA
..3 BN90-06335A ASSY MISC-BLU;CY-GJ040HGLV1V 1 SNA
...4 BN61-11508A SUPPORT-PLATE;Y15 LED,PC,V2,CLEAR,OD-19m 8 SNA
...4 BN61-11748A LGP-DIFFUSESR PLATE;40inch Flat, Diffuse 1 SNA
...4 BN63-13496A SHEET-DBEF;DLF250,PET,0.25,895.6,510.1,W 1 SNA
...4 BN63-13497A SHEET-PRISM;PTM358Z,PET,0.295,895.6,512. 1 SNA
...4 BN63-13498A SHEET-REFLECTOR;SY95S,PET,0.188,875.65,4 1 SNA
...4 BN96-34791A ASSY LED BAR P-LED BAR;40" UHD_L_SDC,4ea 5 SNA
ANNEX-2
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
...4 BN96-34792A ASSY LED BAR P-LED BAR;40" UHD_R_SDC,5ea 5 SNA
...4 BN96-35043A ASSY FRAME P-MOLD MIDDLE;Y15 FLAT, 55,BN 1 SNA
....5 BN60-00735R SPACER-MIDDLE;Y14 VNB 48,PET,L420,NTR,T0 4 SNA
....5 BN60-00735S SPACER-MIDDLE;Y14 VNB 65,PET,L485,NTR,T0 2 SNA
....5 BN60-00744A SPACER-RUBBER;Y13 F-LED SLIM,SH-0140U+AT 2 SNA
....5 BN60-01120A SPACER-PANEL(UD);Y15 UHD Flat 40",SI,890 2 SNA
....5 BN60-01120L SPACER-PANEL(LR);Y15 UHD Flat 40",SI,493 2 SNA
....5 BN61-11432A FRAME-MOLD MIDDLE;Y15 JU7K 40",PC+GF10%, 1 SNA
...4 BN96-35397A ASSY CHASSIS BOTTOM P;JU6300 40 1 SNA
....5 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 1 SA
....5 BN02-00040C TAPE DOUBLE FACE-D-PLATE;F-LED ALL,MKT50 2 SNA
....5 BN02-00173C TAPE PET;JU7K,PET,0.05,40,BLK 0 SNA
....5 BN02-00352E TAPE PET-ROLL;Y12 F-LED,PET,T0.05,W15,L5 0 SNA
....5 BN61-11435A HOLDER-MIDDLE U;Y15 JU7K 40",PC+GF10%,WT 1 SNA
....5 BN61-11475A HOLDER-MIDDLE D;Y15 JU7K 40",PC+GF10%,WT 1 SNA
....5 BN61-11476A HOLDER-MIDDLE LR;Y15 JU7K 40",PC+GF10%,W 2 SNA
....5 BN61-11477A HOLDER-SOURCE PCB;Y15 JU7K SDC,ABS,BLK,H 4 SNA
....5 BN61-11982A HOLDER-WALL RIVET;Y15 F-LED,CR-SPCC,L15. 4 SNA
....5 BN62-00690A INSULATOR-PD-BOARD;JU7500,PC,0.45,222.0, 1 SNA
....5 BN63-14290A SPONGE-BOTTOM;JU7K,EVA,7,10,50,BLUE,low 2 SNA
....5 CC02 BN64-02881A CHASSIS-BOTTOM;Y15 JU7K 40",EGI-SECC AG, 1 SNA
....5 BN96-34707A ASSY BOARD P-LED INTERFACE BOARD;8pin 40 1 SNA
....5 BP63-00024A GASKET-RECT,H/S;SVP-50L2H,Conductive Fab 2 SNA
....5 GK63-00070A GASKET;ID-45BNKH-10-8-5-23-C,Conductive 2 SNA
..3 TCON BN95-01936A ASSY T CON;LSF400FN01-K,40U60Hz Flat 1 SA
...4 BN62-00704A HEAT SINK-PS;JU 6.4K,A1050,BLACK,115*88. 1 SNA
...4 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),BLACK, 1 SNA
...4 BN97-09207A ASSY SMD;BN95-01936A 1 SNA
....5 0202-001899 SOLDER-CREAM;M705-GRN360-K2-VT,20-38um,S 1 SNA
....5 0403-001164 DIODE-ZENER;MMSZ5232B,5.32-5.88V,500MW,S 1 SA
....5 0403-001831 DIODE-ZENER;KDZ12B,12/13.5V,1000mW,SOD-1 2 SA
....5 0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,SO 1 SA
....5 0404-001643 DIODE-SCHOTTKY;B360A,60V,3000mA,SMA,TP 1 SA
....5 0406-001643 DIODE-TVS;1SMA33AT3G,36.7/38.65/40.6V,40 1 SNA
....5 0406-001689 DIODE-TVS;SMH14A,15.6V,17.9V,1MAV,40A,TP 1 SA
....5 0406-001691 DIODE-TVS;5.5V,7.0V,8.5V,0.5MAV,TP 2 SA
....5 0501-000465 TR-SMALL SIGNAL;MMBT3904,NPN,350mW,SOT-2 1 SA
....5 0502-001346 TR-POWER;FCX591A,PNP,1000mW,SOT89,TR,30/ 1 SA
....5 0505-002660 FET-SILICON;Si2308BDS,N,60V,2.3A,0.156oh 1 SNA
....5 0505-003224 FET-SILICON;AO6405,P,-30V,-5A,0.052ohm,2 1 SA
....5 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 4 SA
....5 EL02 0601-002037 LED;SMD(TOP VIEW),BLUE,1.6x0.8mm,465/470 2 SA
....5 0801-002345 IC-CMOS LOGIC;7S04,INVERTER,SOT-353,5P,2 1 SA
....5 0801-003580 IC-CMOS LOGIC;TC7WB66CFK,SSOP,8P,2.0X2.3 3 SA
....5 1105-002274 IC-DDR3 SDRAM;K4B1G1646G-BCMA,DDR3 1866, 2 SNA
....5 1203-006130 IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8 1 SA
ANNEX-3
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....5 1203-007957 IC-DC/DC CONVERTER;SM4158,QFN,48P,6x6x0. 1 SNA
....5 1203-008118 IC-DC/DC CONVERTER;AOZ3013PI,SO-8,8P,4.9 2 SA
....5 1203-008316 IC-DC/DC CONVERTER;SM4183,QFN,32P,5x5mm, 1 SNA
....5 1203-008391 IC-DC/DC CONVERTER;AOZ1269QI-02,QFN-23L, 1 SA
....5 1204-003585 IC-VIDEO PROCESS;SDP1409,FCBGA,1023P,31X 1 SA
....5 IS01 1209-002183 IC-SENSOR;S-5851AAA-M6T1U,SOT,6Z30,2.9x1 1 SA
....5 1405-001381 VARISTOR;11V,8VDC,30A,1.6x0.8x0.9mm,TP,2 4 SA
....5 2007-000039 R-CHIP;0ohm,1%,1/10W,TP,1608 7 SA
....5 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 3 SA
....5 2007-000066 R-CHIP;20Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 2 SNA
....5 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 6 SA
....5 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 3 SA
....5 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 2 SA
....5 2007-000109 R-CHIP;1Mohm,5%,1/10W,TP,1608 1 SA
....5 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 6 SNA
....5 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 10 SA
....5 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 3 SA
....5 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 34 SA
....5 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 12 SA
....5 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 SNA
....5 2007-000165 R-CHIP;200Kohm,5%,1/16W,TP,1005 4 SNA
....5 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 13 SA
....5 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 2 SNA
....5 2007-000239 R-CHIP;1.5Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000265 R-CHIP;1.8Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000336 R-CHIP;120Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000509 R-CHIP;2.4Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000516 R-CHIP;2.7Kohm,1%,1/10W,TP,1608 3 SA
....5 2007-000536 R-CHIP;200ohm,1%,1/10W,TP,1608 3 SA
....5 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000651 R-CHIP;27Kohm,1%,1/10W,TP,1608 2 SA
....5 2007-000669 R-CHIP;2Kohm,1%,1/10W,TP,1608 2 SNA
....5 2007-000708 R-CHIP;3.9Kohm,1%,1/10W,TP,1608 1 SNA
....5 2007-000828 R-CHIP;39Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-000869 R-CHIP;4.7Kohm,1%,1/10W,TP,1608 3 SNA
....5 2007-000962 R-CHIP;5.1Kohm,1%,1/10W,TP,1608 3 SA
....5 2007-000999 R-CHIP;510ohm,1%,1/10W,TP,1608 1 SA
....5 2007-001090 R-CHIP;620ohm,1%,1/10W,TP,1608 2 SA
....5 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 6 SNA
....5 2007-001433 R-CHIP;12Kohm,1%,1/10W,TP,1608 1 SA
....5 2007-002437 R-CHIP;2ohm,5%,1/10W,TP,1608 1 SNA
....5 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 2 SNA
....5 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005 3 SA
....5 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 3 SA
ANNEX-4
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....5 2007-007229 R-CHIP;360ohm,1%,1/10W,TP,1608 1 SA
....5 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 8 SNA
....5 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,0.35T 3 SA
....5 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 3 SA
....5 2007-007315 R-CHIP;3.9Kohm,1%,1/16W,TP,1005 1 SNA
....5 2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 1 SNA
....5 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 12 SA
....5 2007-007488 R-CHIP;75Kohm,1%,1/16W,TP,1005 1 SNA
....5 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 7 SNA
....5 2007-007538 R-CHIP;56Kohm,1%,1/16W,TP,1005 2 SA
....5 2007-007590 R-CHIP;82Kohm,1%,1/16W,TP,1005 2 SNA
....5 2007-007627 R-CHIP;16Kohm,1%,1/16W,TP,1005 2 SA
....5 2007-007768 R-CHIP;13Kohm,1%,1/10W,TP,1608 2 SA
....5 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 1 SNA
....5 2007-008136 R-CHIP;36Kohm,1%,1/16W,TP,1005 1 SA
....5 2007-008332 R-CHIP;11.5Kohm,1%,1/16W,TP,1005 1 SA
....5 2007-008596 R-CHIP;0.1ohm,1%,1/4W,TP,3216 1 SC
....5 2007-008779 R-CHIP;0ohm,1%,1/16W,TP,1005 4 SA
....5 2007-009777 R-CHIP;4.99Kohm,1%,1/16W,TP,1005 1 SA
....5 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 16 SNA
....5 AD480 2203-000332 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1608 2 SA
....5 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 2 SA
....5 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 2 SA
....5 AD480 2203-000715 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1608 2 SNA
....5 AD480 2203-000888 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1608 2 SA
....5 AD480 2203-002711 C-CER,CHIP;100nF,10%,25V,X7R,TP,1608 4 SA
....5 AD480 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 6 SA
....5 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,0.5T 10 SNA
....5 AD480 2203-005918 C-CER,CHIP;1000nF,10%,6.3V,X7R,TP,1608 4 SNA
....5 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 2 SNA
....5 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 2 SA
....5 AD480 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,0.5 115 SA
....5 AD480 2203-006320 C-CER,CHIP;2200nF,10%,16V,X7R,TP,2012 2 SNA
....5 AD480 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,TP,1608 1 SA
....5 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 2 SA
....5 AD480 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,2012 8 SA
....5 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 1 SNA
....5 AD480 2203-006698 C-CER,CHIP;1000nF,10%,25V,X7R,TP,1608,0. 6 SA
....5 AD480 2203-006741 C-CER,CHIP;470nF,10%,25V,X5R,TP,1608,0.8 3 SNA
....5 AD480 2203-006841 C-CER,CHIP;1000nF,10%,16V,X5R,TP,1005 1 SNA
....5 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 2 SNA
....5 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 40 SNA
....5 AD480 2203-007193 C-CER,CHIP;10000nF,10%,6.3V,X7R,TP,2012 7 SA
....5 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 13 SA
....5 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 6 SA
....5 AD480 2203-007306 C-CER,CHIP;10000nF,10%,25V,X5R,TP,2012,1 9 SNA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....5 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 48 SA
....5 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 4 SA
....5 2703-003747 INDUCTOR-SMD;22uH,20%,6060,0.135ohm,1300 3 SA
....5 2703-003862 INDUCTOR-SMD;10uH,20%,6060,0.065ohm,1900 1 SA
....5 2703-003913 INDUCTOR-SMD;2.2uH,20%,2520,1.2T,0.116Oh 1 SNA
....5 2703-003937 INDUCTOR-SMD;1uH,20%,7.0x6.47x3.0mm,0.00 1 SA
....5 2703-004199 INDUCTOR-SMD;10uH,20%,6.6x7.0mm,2.2mm,0. 1 SNA
....5 2703-004589 INDUCTOR-SMD;2.2uH,20%,5050,2T,0.048Ohm, 2 SA
....5 2801-005324 CRYSTAL-SMD;27MHz,30ppm,Ceramic SMD(4pin 1 SA
....5 3301-002039 BEAD-SMD;26ohm,1608,TP 15 SA
....5 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,Hi 2 SNA
....5 3601-001386 FUSE-SURFACE MOUNT;125V,5A,FAST-ACTING,C 1 SA
....5 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N 1 SA
....5 3708-003241 CONNECTOR-FPC/FFC/PIC;96P,0.5mm,SMD-A,AU 2 SNA
....5 3711-007839 CONNECTOR-HEADER;BOX,15P,1R,1.25mm,SMD-A 1 SA
....5 3711-007975 CONNECTOR-HEADER;BOX,10P,1R,1.25mm,SMD-A 1 SA
....5 6302-001290 GASKET;SMR-TS-4-4.5-3,4.0mm,Ni+Au+SUS+Mg 4 SNA
....5 BN41-02297A PCB MAIN;2015 SDC UHD,FR-4,4,1.6T,160*14 1 SNA
....5 BN68-04746A LABEL-SMD;all model,POLY*,25.4mm x 9.53m 1 SNA
....5 BN97-09423A ASSY MICOM;BN95-01936A,1107-002265,BN41- 1 SNA
.....6 IC 1107-002265 IC-NOR FLASH;W25Q32FVSSIG,32Mbit,SOP,8P, 1 SA
..3 BN96-34887A ASSY OPEN CELL;LSF400FN01-K,8bit,40INCH, 1 SNA
...4 BN81-07437A A/S-ADHESIVE-A.C.F;ADHESIVE-A.C.F,4-ADHE 1 SNA
...4 BN81-07943A A/S-ADHESIVE-A.C.F(TP500B);ADHESIVE-A.C. 1 SNA
...4 BN82-01519A A/S ASSY-IC DRIVER GATE;IC DRIVER GATE,L 1 SNA
...4 BN82-01532A A/S ASSY-POLARIZER TFT;POLARIZER TFT,LJ0 1 SNA
...4 BN82-01536A A/S ASSY-POLARIZER C/F;POLARIZER C/F,LJ0 1 SNA
...4 BN82-01583A A/S ASSY-POLARIZER C/F;POLARIZER C/F,LJ0 1 SNA
...4 BN82-01584A A/S ASSY-ASSY PCB-SOURCE(L);ASSY PCB-SOU 1 SNA
...4 BN82-01585A A/S ASSY-ASSY PCB-SOURCE(R);ASSY PCB-SOU 1 SNA
..3 FL06 BN96-34970A ASSY CABLE P-FFC;UHD,FFC,NH,57mm짹1.0,96 2 SNA
..3 BN96-35015A ASSY COVER P-SOURCE PCB;Y15 FLAT, 55,BN6 1 SNA
...4 BN62-00537E INSULATION-S-COVER-R;Y15 JU7K 40",PET,0. 1 SNA
...4 BN62-00537F INSULATION-S-COVER-L;Y15 JU7K 40",PET,0. 1 SNA
...4 BN63-13239A COVER-SOURCE PCB;Y15 JU7K 40",EGI-SECC A 1 SNA
..3 TC01A BN96-35593A ASSY CHASSIS TOP P;Y15_JU6.4K_40,PC+ABS 1 SA
...4 BN02-00381A TAPE CONDUCTIVE-PTC(UD);Y15 UHD Flat 40" 2 SNA
...4 BN02-00381B TAPE CONDUCTIVE-PTC(LR);Y15 UHD Flat 40" 2 SNA
...4 BN60-00715A SPACER-TOP,CORNER;Y13 Slim F-LED,GASKET* 2 SNA
...4 BN60-01115A SPACER-TOP LINK;Y15 JU7K,CONDUCTIVE FABR 4 SNA
...4 BN63-10886E SHEET-COVER;U28D590,PET+SI,0.052,W30mm,1 4 SNA
...4 AC157 BN64-02893A CHASSIS-TOP;JU6400_40,PC+ABS+MF15%,BK000 1 SNA
...4 BN96-36205A ASSY COVER P-DECORATION;JU6400 40,Chrome 1 SNA
....5 BN63-10886D SHEET-COVER;U28D590,PET+SI,0.052,W35mm,1 1 SNA
....5 FD01 BN63-13304A COVER-DECORATION;JU6400_40,PC+ABS+MF17% 1 SNA
.....6 BN63-10877A FILM HOT STAMPING;UF6500, UF6600, UF6700 1 SNA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
1 M0017 BN91-14193L ASSY CHASSIS;LED_J6K 1 SNA
0.2 M0014 BN94-08476A ASSY PCB MAIN;UN40JU6500FXZC 1 SA
..3 BN61-11587A HOLDER-SIDE AV;JU6400,HIPS,1 TUNNER 1 SNA
..3 AH020 BN62-00726A HEAT SINK;Y15 UHD 6K (Main),A1050,BLACK 1 SNA
..3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),BLACK, 1 SNA
..3 BN97-09265A ASSY SMD;J6,UJ6P,40 ~ 65 USA,BN41 1 SNA
...4 0202-001899 SOLDER-CREAM;M705-GRN360-K2-VT,20-38um,S 5 SNA
...4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO 4 SNA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 4 SA
...4 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 2 SA
...4 0406-001573 DIODE-TVS;AOZ8806DI-05,6 1 SA
...4 0406-001628 DIODE-TVS;AOZ8804ADI,6/-/-V,150W,SLP2510 1 SA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V, 6.7V, 7V,200W,SM 6 SA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 3 SC
...4 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7Koh 1 SA
...4 0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,-30V,-11. 1 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,-20V,-4.2A,0.052o 1 SA
...4 0505-002893 FET-SILICON;AO4801AS,P,-30V,-5A,2W,SOIC- 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,380mA,1.19ohm, 2 SA
...4 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 4 SA
...4 1001-001860 IC-ANALOG SWITCH;NX5L2750CGU,QFN,10P,1.4 1 SNA
...4 1001-001934 IC-VIDEO SWITCH;SiI9777,LQFP,208P,28X28m 1 SNA
...4 1006-001576 IC-DRIVER/RECEIVER;MAX3221ECPWR,TSSOP,16 1 SA
...4 1103-001564 IC-EEPROM;S-24C512CI-J800,512Kbit,64Kx8, 1 SA
...4 1105-002528 IC-DDR3 SDRAM;K4B4G1646D-BCMA,DDR3 1866, 4 SA
...4 1105-002534 IC-DDR3 SDRAM;K4B2G1646Q-BCMA,DDR3 SDRA 2 SA
...4 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
...4 1201-003891 IC-AUDIO AMP;NTP7415,MLF,48P,7x7mm,DUAL, 1 SA
...4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
...4 1203-006330 IC-POWER SUPERVISOR;TPS2065DBV,SOT-23,5P 2 SA
...4 1203-007018 IC-DC/DC CONVERTER;TPS54821RHL,QFN,14P,3 1 SA
...4 1203-007238 IC-PWM CONTROLLER;TPS54427,DDA,8P,4.8x3. 2 SNA
...4 1203-008023 IC-POSI.ADJUST REG.;AOZ2003PI,SO-8,8P,4. 1 SA
...4 1203-008082 IC-DC/DC CONVERTER;TPS54627DDAR,SOP 8P,8 1 SA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E8001,HSOP, 2 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E8001,HSOP, 1 SNA
...4 1203-008112 IC-POSI.ADJUST REG.;AOZ2002PI,SO-8,8P,4. 1 SA
...4 1203-008183 IC-DC/DC CONVERTER;AOZ3015PI-1,EPAD SO-8 1 SA
...4 1203-008392 IC-VOL. DETECTOR;S-6414AAB-L800X,TSOT-23 1 SA
...4 1203-008393 IC-DDR TERMINATION REG.;AP2303MTR-G1-89, 1 SA
...4 1203-008405 IC-DC/DC CONVERTER;AOZ3103DI,DFN3X3,8P,3 1 SA
...4 1203-008454 IC-DC/DC CONVERTER;TPS56528,HSOP8,8P,4,8 1 SA
...4 1204-003587 IC-DECODER;SDP1406,PBGA,1053P,31x31mm,PL 1 SA
...4 1205-004983 IC-SWITCH;BD82032FVJ,TSSOP-B8J,8P,3.0x4. 3 SA
...4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5x0.6mm,TP,1 14 SA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 42 SA
...4 2007-000145 R-CHIP;6.2Kohm,5%,1/16W,TP,1005 1 SA
...4 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 2 SNA
...4 2007-000166 R-CHIP;300Kohm,5%,1/16W,TP,1005 1 SA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 66 SA
...4 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 4 SNA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 11 SA
...4 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 50 SA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 5 SA
...4 2007-000999 R-CHIP;510ohm,1%,1/10W,TP,1608 1 SA
...4 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 4 SA
...4 2007-001284 R-CHIP;4.7ohm,5%,1/16W,TP,1005 16 SNA
...4 2007-001285 R-CHIP;5.6ohm,5%,1/16W,TP,1005 16 SA
...4 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 11 SA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 9 SNA
...4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007134 R-CHIP;39Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007137 R-CHIP;1.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005 20 SA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 26 SA
...4 2007-007197 R-CHIP;3.3ohm,5%,1/16W,TP,1005 4 SNA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 16 SNA
...4 2007-007308 R-CHIP;33Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007310 R-CHIP;8.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007311 R-CHIP;22Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007314 R-CHIP;5.6Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007317 R-CHIP;2.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 25 SA
...4 2007-007470 R-CHIP;7.5Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007488 R-CHIP;75Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 9 SNA
...4 2007-007528 R-CHIP;1.5Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007538 R-CHIP;56Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007698 R-CHIP;5.1Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 25 SA
...4 2007-007767 R-CHIP;200ohm,1%,1/16W,TP,1005 6 SA
...4 2007-007861 R-CHIP;62Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 2 SNA
...4 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 11 SA
...4 2007-008137 R-CHIP;24Kohm,1%,1/16W,TP,1005 3 SNA
...4 2007-008213 R-CHIP;4.3Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 4 SA
ANNEX-8
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
...4 2007-009117 R-CHIP;49.9Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-009777 R-CHIP;4.99Kohm,1%,1/16W,TP,1005 3 SA
...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 5 SA
...4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP 4 SA
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 6 SA
...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 4 SA
...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 3 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 18 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 2 SA
...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 3 SA
...4 AD480 2203-000627 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1005 5 SNA
...4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000714 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1005 6 SA
...4 AD480 2203-000812 C-CER,CHIP;0.033nF,5%,50V,C0G,TP,1005 5 SA
...4 AD480 2203-000854 C-CER,CHIP;0.039nF,5%,50V,C0G,TP,1005 1 SA
...4 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-001124 C-CER,CHIP;0.68nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 10 SNA
...4 AD480 2203-003019 C-CER,CHIP;8.2nF,10%,50V,X7R,TP,1005 3 SNA
...4 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 1 SNA
...4 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 331 SA
...4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,TP,1005 2 SNA
...4 AD480 2203-006257 C-CER,CHIP;470nF,10%,6.3V,X5R,TP,1005,0. 2 SNA
...4 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 7 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 54 SNA
...4 AD480 2203-006636 C-CER,CHIP;220nF,10%,25V,X7R,TP,1608 2 SA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 6 SNA
...4 AD480 2203-006838 C-CER,CHIP;2200nF,10%,6.3V,X5R,TP,1005 13 SA
...4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 1 SNA
...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 4 SNA
...4 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 37 SA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 15 SA
...4 AD480 2203-007486 C-CER,CHIP;1000nF,10%,50V,X5R,TP,1608 2 SA
...4 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 107 SA
...4 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 20 SA
...4 2409-001338 C-POLYMER ,CHIP;47uF,20%,6.3V,TP,3.2x1.6 1 SA
...4 2503-001051 C-NETWORK;100nFx4,20%,16V,2012 1 SA
...4 2703-000158 INDUCTOR-SMD;1uH,10%,2012,.4Ohm,50mA,45, 1 SA
...4 2703-000213 INDUCTOR-SMD;470nH,10%,1608,1.35Ohm,35mA 1 SA
...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 3 SA
...4 2703-003135 INDUCTOR-SMD;4.7uH,20%,6965,0.04Ohm,7000 1 SNA
...4 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366,0.015ohm,700 4 SA
...4 2703-004724 INDUCTOR-SMD;8.2uH,20%,5050,4mm,0.072Ohm 4 SA
...4 2703-005193 INDUCTOR-SMD;2.2uH,20%,6060,4.5,0.024ohm 1 SA
...4 2703-005194 INDUCTOR-SMD;3.3uH,20%,6060,4.5,0.03ohm, 1 SA
ANNEX-9
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
...4 2801-003954 CRYSTAL-SMD;27MHz,30ppm,28-AAN,16pF,50oh 1 SA
...4 2801-004477 CRYSTAL-SMD;24.576MHz,20ppm,SMD,18pF,20o 1 SA
...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz 6 SNA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 53 SA
...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL 2 SA
...4 3701-001861 CONNECTOR-HDMI;19P,FEMALE,AU,0.5mm,BLK,S 4 SA
...4 3707-001106 CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF 1 SA
...4 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N 1 SA
...4 EH01 3711-008131 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 SA
...4 EH01 3711-008422 HEADER-BOARD TO CABLE;BOX,9P,1R,1.25mm,S 1 SA
...4 EH01 3711-008659 HEADER-BOARD TO CABLE;BOX,16P,2R,2mm,ANG 1 SA
...4 EH01 3711-008859 HEADER-BOARD TO CABLE;BOX,12P,2R,2.0mm,A 1 SA
...4 3722-003229 JACK-MODULAR;8P/8C W/L,Y,STRAIGHT,N,Au,1 1 SA
...4 3722-003457 JACK-USB;4P/1C,NI,BLK,A 2 SA
...4 JACK PIN 3722-003546 JACK-PIN;5P+Screw hole,NI+SN,G,Y/BLU/RED 1 SA
...4 3722-003617 JACK-PHONE;14P/2C,SN,BLK,STRAIGHT,3.6PI, 1 SA
...4 JACK 3722-003837 JACK-USB;9P/1C,AU/SN/NI,BLU,SMD-A,A,3.0, 1 SA
...4 6302-001376 GASKET;D-Q43-14-180,6mm,SI 8 SNA
...4 ET01 BN40-00312B TUNER;GVTH-5B31,GVTH-5B31,VSB-half,75ohm 1 SA
...4 BN41-02344A PCB MAIN;HAWK-MU_JU6400_BOSTON,FR-4,4,A, 1 SNA
...4 BN68-04746A LABEL-SMD;all model,POLY*,25.4mm x 9.53m 1 SNA
...4 BN97-09407A ASSY MICOM-MAIN;T-HKMAKUC-XXXX,UWJ51,H26 1 SNA
....5 1107-002357 IC-EMMC;H26M41103HPR,8Gbyte,BGA,153P,11. 1 SA
...4 BN97-09410A ASSY MICOM-SPI;T-HAWAUSS3-XXXX,UWJ51,W25 1 SNA
....5 1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4Mbit,SOIC,8P, 1 SA
...4 BN97-09412A ASSY MICOM-SPI;X-XXXXXXXXX-XXXX,UWJ51,W2 1 SNA
....5 1107-002223 IC-NOR FLASH;W25Q16DVSSIG,16Mbit,2Mbitx8 1 SNA
..3 BN97-09484A ASSY DRM-KEY;JU7000,7500,HDCP, MAC 1 SNA
...4 BN46-00109H KEY CODE-CERTIFI;MAC,TV/AV,General 1 SNA
...4 BN46-00110P KEY CODE-CERTIFI;MIRACAST(HDCP2.2), TV 1 SNA
..3 M0131 MD63-00103A GASKET;GRANDSLAM,Conductive Fabric,1,10, 3 SNA
1 BN91-14215A ASSY SHIELD;UJP6 FLAT 1 SNA
0.2 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 9 SA
0.2 BN02-00102B TAPE FILAMENT;UE7000,#8917,0.15,25,50,WH 0 SNA
0.2 M-F BN39-01990A LEAD CONNECTOR-FUNCTION;JU7.5K,Lead Conn 1 SA
0.2 EC13 BN39-02017A LEAD CONNECTOR;FLAT CONNECTOR ASS'Y,Lea 1 SA
0.2 BN39-02025A LEAD CONNECTOR-POWER;UN40JU6400AFXZA,Fl 1 SA
0.2 BN39-02030E LEAD CONNECTOR-BLU;BLU,LEAD CONNECTOR, 1 SA
0.2 P001A BN44-00806A DC VSS-LED TV PD BD;L40S6_FDY,L40S6_FDY, 1 SA
0.2 NW01 BN59-01194F NETWORK;11ac Combo,Internal WiFi,USB 2.0 1 SA
0.2 SP01A BN96-35007D ASSY SPEAKER P;6ohm,4pin,10W,JU6400 40" 1 SA
0.2 BN96-35345B ASSY BOARD P-FUNCTION_SW;JU7500,Function 1 SA
0.2 FB01A BN96-35346D ASSY BOARD P-FUNCTION ASSY;JU6400,Functi 1 SA
0.2 FL06 BN96-36273E ASSY CABLE P;UN40JU7000,FFC,NH,250mm,51P 1 SA
1 BN92-16904A ASSY LABEL;J6 1 SNA
0.2 BN68-05050A LABEL RATING;ALL,SS,PET,T0.05,93,73,Dark 1 SNA
ANNEX-10
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
0.2 BN68-07042X LABEL ENERGY;UN40JU6500FXZA,ZA,PET,T0.1, 1 SNA
0.2 BN68-07054F LEAFLET-QSG;JU6500,Samsung,United States 1 SNA
0.2 BN74-00053G TAPE PAPER-PROTECTION;3M2307,PAPER,0.14T 0 SNA
1 ACCE1 BN92-16922A ASSY ACCESSORY;J6 1 SNA
0.2 BN96-35698A ASSY ACCESSORY MANUAL/CABLE;LED_J6K,650 1 SNA
..3 T0268 3903-000985 CBF-POWER CORD;DT,USA,LP-11L,125,7,BLK,1 1 SA
..3 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,LR03,10.2x4 2 SNA
..3 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP 1 SNA
..3 BN59-01223A REMOCON-REMOCON;TM1260C,52,3.0V,TM1260C 1 SA
..3 HOLDER-WIRE BN61-08370A HOLDER-WIRE STAND;26UE4000 GUIDE STAND,P 1 SA
..3 BN68-04972E LEAFLET-02,REGULATORY GUIDE;ALL,SAMSUNG, 1 SNA
..3 BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,0.2,20,7 1 SNA
..3 BN68-06965A MANUAL USERS;JU6400,Common,ENG,United St 1 SNA
1 BN92-16961A ASSY BOX;40 6500 1 SNA
0.2 BH68-00697A LABEL BOX-00;ALL MODEL,ART PAPER 90G,60, 1 SNA
0.2 BN69-11668B BOX-SET;40JU6500-TS,CB,A-01,SW2,W1120,D1 1 SNA
1 BN92-17135A ASSY P/MATERIAL;LED_J6K,40 6500 1 SNA
0.2 6902-002380 BAG ROLL;HDPE/PE FOAM+HDPE,T0.015/T0.5+T 2 SNA
0.2 6922-000013 BAND;PP,W18,L2300/L2900,TRP 1 SNA
0.2 BH69-00418A WRAP;762,1828M,SAMEX FACTORY 1123 SNA
0.2 BN02-00319B TAPE OPP;OPP,T0.05,W75,L800m,CLEAR 3 SNA
0.2 BN68-02422B LABEL-WARNING SHIPPING;ALL MODEL,A/P,T0. 1 SNA
0.2 BN69-00391E PAD-ANGLE;DI19PS,PAPER,T5,50,1500,YEL 1 SNA
0.2 BN69-11278A CUSHION-SET;JU6300_40,EPS,W/W 1 SNA
ANNEX-11
ANNEX. Exploded View & Part List
