Samsung WW9 J5 6 Series User manual

Washing Machine
User manual
WW9*J5**5**/WW8*J5**5**/WW7*J5**5**
Untitled-2 1 2017-03-13  5:17:10

English26
Before you start
Initial settings
Run Calibration (recommended)
Calibration ensures accurate weight detection by the washing machine. Make sure the
drum is empty before running Calibration.
1. Power off, and then power on the washing machine.
2. Hold down Temp. and Delay End simultaneously for 3 seconds to enter
Calibration mode. The “Cb” message appears.
3. Press Start/Pause to run the Calibration cycle.
4. The drum will rotate clockwise and counter-clockwise for about 3 minutes.
5. When the cycle is complete, “0” appears on the display and the washing machine will
turn off automatically.
6. The washing machine is now ready for use.
Laundry guidelines
STEP 1 Sort
Sort the laundry according to these criteria:
• Care Label: Sort the laundry into cottons, mixed bres, synthetics, silks, wools, and
rayon.
• Colour: Separate whites from colours.
• Size: Mixing different sized items together in the drum improves the washing
performance.
• Sensitivity: Wash delicate items separately for pure, new woollen items, curtains, and
silk items. Check the labels on the items.
NOTE
Make sure to check the care label on the clothing, and sort them accordingly before
starting the wash.
Before you start
Untitled-2 26 2017-03-13  5:17:14

English 27
Before you start
STEP 2 Empty pockets
Empty all the pockets of your laundry items
• Metal objects such as coins, pins, and buckles on clothing may damage other laundry
items as well as the drum.
Turn clothing with buttons and embroideries inside out
• If trousers or jacket zippers are open while washing, the drum may be damaged.
Zippers should be closed and xed with a string.
• Clothing with long strings may become entangled with other clothes. Make sure to tie
the strings before starting the wash.
STEP 3 Use a laundry net
• Brassieres (machine washable) must be placed in a laundry net. Metal parts of the
brassieres may break through and tear other laundry items.
• Small, light clothing such as socks, gloves, stockings, and handkerchiefs may become
caught around the door. Place them inside a ne laundry net.
• Do not wash the laundry net by itself without other laundry. This may cause abnormal
vibrations that could move the washing machine and result in injury.
STEP 4 Prewash (if necessary)
Select the Prewash option for the selected cycle if the laundry is heavily soiled. When
selecting the Prewash option, make sure to put powder-type detergent into the main wash
compartment.
STEP 5 Determine the load capacity
Do not overload the washing machine. Overloading may cause the washing machine to
not wash properly. For the load capacity for the type of clothing, see page 36.
NOTE
When washing bedding or bedding covers, the wash time may be lengthened or the spin
efciency may be reduced. For bedding or bedding covers, the recommended maximum
spin cycle speed is 800 rpm, and the load capacity is 2.0 kg or less.
CAUTION
If the laundry is unbalanced and the “Ub” information code is displayed, redistribute the
load. Unbalanced laundry may reduce the spinning performance.
Untitled-2 27 2017-03-13  5:17:14

Before you start
English28
Before you start
STEP 6 Apply a proper detergent type
The type of detergent depends on the type of fabric (cotton, synthetic, delicate items,
wool), colour, wash temperature, and degree of soiling. Make sure to use the laundry
detergent that is designed for automatic washing machines.
NOTE
• Follow the detergent manufacturer’s recommendations based on the weight of the
laundry, the degree of soiling, and the hardness of the water in your local area. If you
are not sure about the water hardness, contact a local water authority.
• Do not use detergent that tends to be hardened or solidied. This detergent may
remain after the rinse cycle, blocking the drain outlet.
CAUTION
When washing wool using the WOOL cycle, use only a neutral liquid detergent. If used
with the WOOL cycle, powder detergent may remain on the laundry and discolour the
laundry.
Laundry capsules
To get the best results from using laundry capsules, please follow these instructions.
1. Put the capsule in the bottom of the
empty drum towards the rear.
Untitled-2 28 2017-03-13  5:17:14

English 29
Before you start
2. Put the laundry in the drum on top of
the capsule.
CAUTION
For cycles using cold water or cycles that complete in less than one hour, it is
recommended to use a liquid detergent. Otherwise, the capsule may not dissolve
completely.
Detergent drawer guidelines
The washing machine provides a three-compartment dispenser: the left compartment for
the main wash, the front-right for fabric softeners, and the rear-right for the preliminary
wash.
A
1. Prewash compartment: Apply
prewash detergent.
2. Main-wash compartment: Apply
main-wash detergent, water softener,
soaking detergent, bleach, and/or stain
removers.
3. Softener compartment: Apply
additives such as fabric softener. Do not
exceed the max line (A).
Untitled-2 29 2017-03-13  5:17:15

Before you start
English30
Before you start
NOTE
The actual appearance of the softener
guide may differ with the model.
CAUTION
• Do not open the detergent drawer while the washing machine is operating.
• Do not use the following types of detergent in the drawer:
- Tablet or capsule types
- Ball or net types
• To prevent the compartment from clogging, concentrated or highly-enriched agents
(fabric softener or detergent) must be diluted with water before being applied.
• When Delay End is selected, do not apply detergent directly into the drum. Otherwise,
this may discolour the laundry. Use the detergent drawer when Delay End is selected.
To apply washing agents to the detergent drawer
1. Slide open the detergent drawer.
2. Apply laundry detergent to the
main-wash compartment as
instructed or recommended by the
manufacturer. To use liquid detergent,
see page 32.
Untitled-2 30 2017-03-13  5:17:15

English 31
Before you start
A
3. Apply fabric softener to the softener
compartment. Do not exceed the max
line (A).
Softener is dispensed into the wash
during the nal rinse.
4. If you want to prewash, apply
prewash detergent to the prewash
compartment as instructed or
recommended by the manufacturer.
5. Close the detergent drawer.
CAUTION
• Do not apply powder detergent to the
liquid detergent guide.
• Concentrated fabric softener must be
diluted with water before applied.
• Do not apply main-wash detergent to
the softener compartment.
Untitled-2 31 2017-03-13  5:17:16

Before you start
English32
Before you start
To use liquid detergent (applicable models only)
A
First insert the provided liquid detergent
guide in the main-wash compartment.
Then, apply liquid detergent to the guide
below the marked max line (A).
NOTE
• Insert the liquid detergent guide only
after you remove the detergent drawer
from the washing machine by pressing
release lever (A).
• After a wash, some liquid detergent
may remain in the detergent drawer.
CAUTION
• Do not use the Prewash function when
you use liquid detergent.
• Remove the liquid detergent guide
when you use powder detergent.
Untitled-2 32 2017-03-13  5:17:16

English 33
Operations
Control panel
WW9*J5**5**
01
02
03 04 05 06 07
08
09
11
10
WW8*J5**5**, WW7*J5**5**
01
02
03 04 05 06 07
08
09
11
10
01 Cycle Selector Turn the dial to select a cycle.
02 Display The display shows current cycle information and estimated time
remaining, or an information code when a problem occurs.
03 Temp. Press to change the water temperature for the current cycle.
04 Rinse Press to change the rinse count for the current cycle. You can set
the rinse count to a max of 5, depending on the cycle.
Operations
Untitled-2 33 2017-03-13  5:17:16

Operations
English34
Operations
05 Spin
Press to change the spinning speed for the current cycle. The
revolutions per minute (RPM) differs with the model.
• Rinse Hold : The nal rinse process is suspended so that the
laundry remains in the water. To unload the laundry, run a
drain or spin process.
• No Spin : The drum does not rotate after the nal drain
process.
• Spin Only : To run the Spin Only cycle, press Spin for
3 seconds. When the cycle time and spinning speed appear,
press Spin repeatedly until a desired spinning speed
is selected. Then, press Start/Pause to start the cycle. The
spinning time depends on the selected cycle.
06 Options
Press to select an option from Intensive, and Pre Wash. Press
again to deselect.
• Availability of the options depends on the cycle.
07 Bubble Soak
Press to activate/deactivate the Bubble Soak function. This
function helps remove a wide variety of stubborn stains.
• Bubble Soak helps remove a variety of stubborn stains.
• With Bubble Soak selected, laundry is thoroughly soaked in
water bubbles for effective washing.
• Bubble Soak is available with and adds up to 30 minutes to 5
cycles: COTTON, SYNTHETICS, BEDDING, DAILY WASH, BABY
CARE, and DENIM (9 kg-models only).
08 Delay End
Delay End lets you set the end time of the current cycle. Based
on your settings, the start time of the cycle will be determined
by the machine’s internal logic. For example, this setting is useful
for programming your machine to nish a wash at the time you
normally return home from work.
• Press to choose a preset unit of hours.
09 Easy Iron
Press to prepare your laundry so that it can be easily ironed by
reducing the wrinkles during the spin cycle.
• Easy Iron is only available for the following wash cycles:
COTTON, COTTON, SYNTHETICS, DENIM (9 kg-models
only), SUPER ECO WASH, BEDDING, DAILY WASH, BABY CARE,
and DARK GARMENT.
10 Power Press to turn on/off the washing machine.
11 Start/Pause Press to start or stop operation.
Untitled-2 34 2017-03-13  5:17:17

English 35
Operations
Simple steps to start
WW9*J5**5**
2
1
6
4 5
3
WW8*J5**5**, WW7*J5**5**
1
6
4 5
3
2
1. Press Power to turn on the washing machine.
2. Turn the Cycle Selector to select a cycle.
3. Change the cycle settings ( Temp., Rinse, and Spin) as necessary.
4. To add an option, press Options. Use the button again to choose a preferred item.
5. The machine provides 3 respective buttons for Bubble Soak, Easy Iron and
Delay End for easy access. If you want to use one of these options, press the
corresponding button.
6. Press Start/Pause.
To change the cycle during operation
1. Press Start/Pause to stop operation.
2. Select a different cycle.
3. Press Start/Pause again to start the new cycle.
Untitled-2 35 2017-03-13  5:17:17

Operations
English36
Operations
Cycle overview
Standard cycles
Cycle Description & Max load (kg)
COTTON
• For cottons, bed linens, table linens, underwear,
towels, or shirts. The washing time and the rinse
count are automatically adjusted according to the
load.
MAX
COTTON
• Optimal performance with lower energy for cotton
fabrics, bed linens, table linens, underwear, towels,
or shirts. For energy saving, the actual washing
temperature may be lower than specied.
MAX
SYNTHETICS
• For blouses or shirts that are made of polyester
(diolen, trevira), polyamide (perlon, nylon), or the
like.
4
WOOL
• Specic for machine-washable wool for loads less
than 2.0 kg.
• The WOOL cycle features gentle cradling and
soaking to protect the wool bres from shrinkage/
distortion.
• A neutral detergent is recommended.
2
SPIN (7, 8 kg-models
only)
• Featuring an additional spin process to effectively
remove moisture from laundry. MAX
DENIM (9 kg-models
only)
• Featuring a higher water level in the main wash
and an extra rinse cycle to ensure that no powder
detergent remains.
3
RINSE+SPIN • Featuring an additional rinse process after
applying fabric softener to the laundry. MAX
ECO DRUM CLEAN
• Cleans the drum by removing dirt and bacteria
from the drum.
• Perform once every 40 washes with no detergent
or bleach applied.
• Make sure the drum is empty.
• Do not use any cleaning agents for cleaning the
drum.
—
SUPER ECO WASH • Low temperature ecobubble cycle helps reduce
power consumption. 4
Untitled-2 36 2017-03-13  5:17:18

English 37
Operations
Cycle Description & Max load (kg)
15' QUICK WASH
• For lightly soiled garments in less than 2.0 kg that
you want to wash quickly.
• Use less than 20 g of detergent. Using more than
20 g of detergent may leave detergent residue.
• For liquid detergent, use a max of 20 ml of liquid
detergent.
2
DAILY WASH • For everyday items such as underwear and shirts. 4
DELICATES
• For sheer fabrics, bras, lingerie (silk), and other
handwash-only fabrics.
• For best performance, use liquid detergent.
2
DARK GARMENT
• Featuring additional rinses and reduced spinning
to ensure that the laundry is washed gently and
rinsed thoroughly.
4
BEDDING
• For bed spreads, bed sheets, bedding covers, etc.
• For best results, wash only 1 type of bedding and
make sure the load weighs less than 2.0 kg.
2
BABY CARE
• Featuring a high-temperature wash and extra
rinses to help remove the remaining detergent
effectively.
4
Untitled-2 37 2017-03-13  5:17:18

Operations
English38
Operations
Options
Option Description
Pre Wash • This will add a preliminary washing cycle before the main
wash cycle.
Intensive • For badly soiled laundry. The operation time for each cycle is
longer than normal.
Untitled-2 38 2017-03-13  5:17:18

English 39
Operations
Delay End
You can set the washing machine to nish your wash automatically at a later time,
choosing a delay of between 1 to 24 hours (in 1 hour increments). The hour displayed
indicates the time the wash will nish.
1. Select a cycle. Then change the cycle settings if necessary.
2. Press Delay End repeatedly until a desired end time is set.
3. Press Start/Pause.
The Delay End indicator blinks and the washing machine tumbles the drum to sense
the weight of the load if you have selected the COTTON or COTTON cycle. Load
sensing is preset and enabled only in these 2 cycles. When complete, the machine
displays your set time and the timer starts ticking.
4. To cancel the Delay End, restart the washing machine by pressing Power.
Real-life case
You want to nish a two-hour cycle 3 hours later from now. For this, you add the Delay
End option to the current cycle with the 3-hour setting, and press Start/Pause at 2:00 p.m.
Then, what happens? The washing machine starts operating at 3:00 p.m., and ends at 5:00
p.m. Provided below is the time line for this example.
2:00 pm
Set the Delay End to 3 hours
3:00 pm
Start
5:00 pm
End
Untitled-2 39 2017-03-13  5:17:18

Operations
English40
Operations
Settings
Child Lock
To prevent accidents by children, Child
Lock locks all buttons except for Power.
• To set the Child Lock function,
hold down Temp. and Rinse
simultaneously for 3 seconds.
• To release the Child Lock function,
hold down Temp. and Rinse
simultaneously for 3 seconds.
NOTE
• In the Child Lock state, you must rst
release the Child Lock if you want to
add detergent or laundry.
• Your setting will be kept even after
restarting the machine.
Sound On/Off
You can turn on or off the sound from the
washing machine. Your setting will be kept
even after restarting the machine.
• To mute the sound, hold down
Rinse and Spin simultaneously for 3
seconds.
• To unmute the sound, hold down again
for 3 seconds.
Untitled-2 40 2017-03-13  5:17:18

English 41
Maintenance
Keep the washing machine clean to prevent deteriorated performance and to preserve its
life cycle.
Eco drum clean
Perform this cycle regularly to clean the drum and to remove bacteria.
1. Press Power to turn on the washing machine.
2. Turn the Cycle Selector to select ECO DRUM CLEAN.
3. Press Start/Pause.
NOTE
• The water temperature for ECO DRUM CLEAN is set to 70 °C, which cannot be changed.
• It is recommended to run the ECO DRUM CLEAN cycle once every 40 washes.
CAUTION
Do not use any cleaning agents for cleaning the drum. Chemical residue in the drum
deteriorates the washing performance.
ECO DRUM CLEAN reminder
• The ECO DRUM CLEAN reminder appears on the main screen once every 40 washes. It
is advisable to perform the ECO DRUM CLEAN regularly.
• When you rst see this reminder, you can ignore the reminder for 6 consecutive
washes. From the 7th wash, the reminder no longer appears. However, it appears again
on the next 40th wash.
Maintenance
Untitled-2 41 2017-03-13  5:17:18

Maintenance
English42
Maintenance
Smart Check
To enable this function, you must rst download the Samsung Smart Washer app at the
Play Store or the App Store, and install it on a mobile device featuring a camera function.
The Smart Check function has been optimized for Galaxy & iPhone series (applicable
models only).
1. When the washing machine detects an issue to check, an information code appears
on the display. To enter Smart Check mode, press and hold Spin and Options
simultaneously for 3 seconds.
2. The washing machine starts the self-diagnosis procedure and displays an information
code if a problem is detected.
3. Run the Samsung Smart Washer app on your mobile device, and tap Smart Check.
4. Put the mobile device close to the washing machine’s display so that the smartphone
camera and the washing machine face each other. Then, the information code will be
recognized automatically by the app.
5. When the information code is recognized correctly, the app provides detailed
information about the problem with applicable solutions.
NOTE
• The function name, Smart Check, may differ depending on the language.
• If there is strong reected light on the washing machine display, the app may fail to
recognize the information code.
• If the app fails to recognize the Smart Check code consecutively, enter the information
code manually onto the app screen.
Untitled-2 42 2017-03-13  5:17:18

English 43
Maintenance
Emergency drain
In case of a power failure, drain the water inside the drum before taking out the laundry.
A
1. Power off and unplug the washing
machine from the electrical outlet.
2. Gently press the top area of the lter
cover (A) to open.
B
3. Put an empty, spacious container
around the cover, and stretch the
emergency drain tube to the container
while holding the tube cap (B).
C
4. Open the tube cap and let water in the
emergency drain tube (C) ow into the
container.
5. When done, close the tube cap, and
reinsert the tube. Then, close the lter
cover.
NOTE
Use a spacious container because the
water in the drum may be more than
expected.
Untitled-2 43 2017-03-13  5:17:19

Maintenance
English44
Maintenance
Cleaning
Surface of the washing machine
Use a soft cloth with a nonabrasive household detergent. Do not spray water onto the
washing machine.
Mesh lter
Clean the mesh lter of the water hose once or twice a year.
1. Turn off the washing machine, and
unplug the power cord.
2. Close the water tap.
3. Loosen and disconnect the water hose
from the back of the washing machine.
Cover the hose with a cloth to prevent
water from gushing out.
4. Use pliers to pull out the mesh lter
from the inlet valve.
5. Submerge the mesh lter deeply in
water so that the threaded connector is
also submerged.
6. Dry the mesh lter completely in the
shade.
7. Reinsert the mesh lter into the inlet
valve, and reconnect the water hose to
the inlet valve.
8. Open the water tap.
NOTE
If the mesh lter is clogged, an information code of “4C” appears on the screen.
Untitled-2 44 2017-03-13  5:17:19
