Samsung WW8 T3 Series User manual

Washing Machine
User manual
WW8*T3*****/WW7*T3*****
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 1WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 1 2021-01-15  4:04:402021-01-15  4:04:40

2 English
Contents
Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols 4
Important safety precautions 5
Critical installation warnings 6
Installation cautions 8
Critical usage warnings 8
Usage cautions 10
Critical cleaning warnings 13
Instructions about the WEEE 14
Installation 15
What’s included 15
Installation requirements 17
Step-by-step installation 19
Before you start 27
Initial settings 27
Laundry guidelines 27
Detergent drawer guidelines 31
Operations 34
Control panel 34
Simple steps to start 35
Cycle overview 36
Settings 39
Maintenance 40
Emergency drain 40
Cleaning 41
Recovery from freezing 44
Care against an extended time of disuse 44
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 2WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 2 2021-01-15  4:04:542021-01-15  4:04:54

English 3
Contents
Troubleshooting 45
Checkpoints 45
Information codes 49
Specifications 51
Fabric care chart 51
Protecting the environment 52
Specification sheet 53
Information of main washing programmes 55
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 3WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 3 2021-01-15  4:04:542021-01-15  4:04:54

4 English
Safety information
Safety information
Congratulations on your new Samsung washing machine. This manual contains important information
on the installation, use and care of your appliance. Please take some time to read this manual to take
full advantage of yourwashing machine’s many benefits and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efficiently operate the
extensive features and functions of your new appliance. Please store the manual in a safe location
close to the appliance for future reference. Use this appliance only for its intended purpose as
described in this instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution and care when
installing, maintaining and operating your washing machine.
Because the following operating instructions covervarious models, the characteristics of yourwashing
machine may differ slightly from those described in this manual and not all warning signs may be
applicable. If you have any questions or concerns, contact your nearest service centre orfind help and
information online at www.samsung.com.
Important safety symbols
What the icons and signs in this usermanual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Indicates that a risk of personal injury or material damage exists.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 4WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 4 2021-01-15  4:04:542021-01-15  4:04:54

English 5
Safety information
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place forfuture reference.
Read all instructions before using the appliance.
As with any equipment that uses electricity and moving parts, potential hazards exist. To safely
operate this appliance, familiarize yourself with its operation and exercise care when using it.
Important safety precautions
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using your
appliance, follow basic precautions, including the following:
1. This appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
2. For use in Europe: This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
3. Children should be supervised to ensure that they do not play with the appliance.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
5. The new hose-sets supplied with the appliance are to be used and old hose-sets
should not be reused.
6. For appliances with ventilation openings in the base, a carpet must not obstruct
the openings.
7. For use in Europe: Children of less than 3 years should be kept away unless
continuously supervised.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 5WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 5 2021-01-15  4:04:542021-01-15  4:04:54

6 English
Safety information
Safety information
8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal
cut-out, this appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly switched on and
off by the utility.
9. This appliance is intended to be used in household only and it is not intended to
be used such as:
– staff kitchen areas in shops, offices and otherworking environments;
– farm houses;
– by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– areas for communal use in blocks of flats or in launderettes.
Critical installation warnings
WARNING
The installation of this appliance must be performed by a qualified technician or service company.
• Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury.
The appliance is heavy, therefore take care when lifting it.
Plug the power cord into a wall socket that meets local electrical specifications. Use the socket for this
appliance only, and do not use an extension cord.
• Sharing a wall socket with other appliances using a power strip or extending the power cord may
result in electric shock orfire.
• Ensure that the powervoltage, frequency, and current are the same as those of the product
specifications. Failure to do so may result in electric shock or fire. Plug the power plug into the wall
socket firmly.
Remove all foreign substances such as dust orwaterfrom the power plug terminals and contact points
using a dry cloth on a regular basis.
• Unplug the power plug and clean it with a dry cloth.
• Failure to do so may result in electric shock or fire.
Plug the power plug into the wall socket so that the cord is running towards the floor.
• If you plug the power plug into the socket in the opposite direction, the electric wires within the
cable may be damaged and this may result in electric shock or fire.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 6WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 6 2021-01-15  4:04:542021-01-15  4:04:54

English 7
Safety information
Keep all packaging materials out of the reach of children as these may be dangerous.
• If a child places a bag over its head, it may suffocate.
When the appliance, power plug or power cord is damaged, contact your nearest service centre.
This appliance must be properly grounded.
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
• This may result in electric shock, fire, an explosion, or problems with the product.
• Never plug the power cord into a socket that is not grounded correctly and make sure that it is in
accordance with local and national regulations.
Do not install this appliance near a heater or any inflammable material.
Do not install this appliance in a humid, oily or dusty location, or in a location exposed to direct
sunlight or water (rain drops).
Do not install this appliance in a location exposed to low temperatures.
• Frost may cause the tubes to burst.
Do not install this appliance in a location where gas may leak.
• This may result in electric shock orfire.
Do not use an electric transformer.
• This may result in electric shock orfire.
Do not use a damaged power plug, damaged power cord, or loose wall socket.
• This may result in electric shock orfire.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the
power cord between objects, or push the power cord into the space behind the appliance.
• This may result in electric shock orfire.
Do not pull the power cord when unplugging the powerplug.
• Unplug the power plug by holding the plug.
• Failure to do so may result in electric shock or fire.
This appliance should be positioned so that the power plug, the water supply taps, and the drain pipes
are accessible.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 7WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 7 2021-01-15  4:04:542021-01-15  4:04:54

8 English
Safety information
Safety information
Installation cautions
CAUTION
This appliance should be positioned in such a way that the power plug is easily accessible.
• Failure to do so may result in electric shock or fire due to electric leakage.
Install your appliance on a solid, level floorthat can support its weight.
• Failure to do so may result in abnormal vibrations, movement, noise, or problems with the product.
Critical usage warnings
WARNING
If the appliance is flooded, turn off the water & power supplies immediately and contact your nearest
service centre.
• Do not touch the power plug with wet hands.
• Failure to do so may result in electric shock.
If the appliance generates a strange noise, a burning smell, or smoke, unplug the power plug
immediately and contact your nearest service centre.
• Failure to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching
the power plug. Do not touch the appliance or power cord.
• Do not use a ventilating fan.
• A spark may result in an explosion orfire.
Do not let children play in or on the washing machine. In addition, when disposing of the appliance,
remove the washing machine door lever.
• If trapped inside the product, children may suffocate to death.
Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the washing
machine before using it.
Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or other
inflammable or explosive substances.
• This may result in electric shock, fire, or an explosion.
Do not open the washing machine door by force while it is operating (high-temperature washing/
drying/spinning).
• Water flowing out of the washing machine may result in burns or cause the floor to be slippery.
This may result in injury.
• Opening the door by force may result in damage to the product or injury.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 8WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 8 2021-01-15  4:04:542021-01-15  4:04:54

English 9
Safety information
Do not insert your hand under the washing machine while an operation is in progress.
• This may result in injury.
Do not touch the power plug with wet hands.
• This may result in electric shock.
Do not turn the appliance off by unplugging the power plug while an operation is in progress.
• Plugging the power plug into the wall socket again may cause a spark and result in electric shock
or fire.
Do not let children or the infirm use this washing machine without proper supervision. Do not let
children climb in or onto the appliance.
• This may result in electric shock, burns or injury.
Do not insert your hand or a metal object under the washing machine while it is operating.
• This may result in injury.
Do not unplug the appliance by pulling the power cord. Always grip the plug firmly and pull it straight
out of the outlet.
• Damage to the power cord may cause a short-circuit, fire and/or electric shock.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use a fuse (such as copper, steel wire, etc.) other than a standard fuse.
• When the appliance needs to be repaired or reinstalled, contact your nearest service centre.
• Failure to do so may result in electric shock, fire, problems with the product, or injury.
If the water supply hose comes loose from the water tap and floods the appliance, unplug the power
plug.
• Failure to do so may result in electric shock or fire.
Unplug the power plug when the appliance is not being used for long periods of time or during a
thunder or lightning storm.
• Failure to do so may result in electric shock or fire.
If any foreign substance enters into the appliance, unplug the power plug and contact your nearest
Samsung Customer Service.
• This may result in electric shock orfire.
Do not let children (or pets) play in or on yourwashing machine. The washing machine door does not
open easily from the inside and children may be seriously injured if trapped inside.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 9WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 9 2021-01-15  4:04:552021-01-15  4:04:55

10 English
Safety information
Safety information
Usage cautions
CAUTION
When the washing machine is contaminated by a foreign substance such as detergent, dirt, food
waste, etc., unplug the power plug and clean the washing machine using a damp, soft cloth.
• Failure to do so may result in discolouration, deformation, damage, or rust.
The front glass may be broken by a strong impact. Take care when using the washing machine.
• If the glass is broken, it may result in injury.
After a water supply failure or when reconnecting the water supply hose, open the water tap slowly.
Open the water tap slowly after a long period of non-use.
• The air pressure in the water supply hose or the water pipe may damage a product part or result in
a water leak.
If a draining error occurs during an operation, check if there is a draining problem.
• If the washing machine is used when it is flooded because of a draining problem, it may result in
electric shock or fire.
Insert the laundry into the washing machine completely so that the laundry does not get caught in the
door.
• If laundry gets caught in the door, it may result in damage to the laundry or the washing machine,
or result in a water leak.
Turn the water supply off when the washing machine is not being used.
• Ensure that the screws on the water supply hose connector are properly tightened.
Ensure that the rubber seal and front door glass are not contaminated by a foreign substance (e.g.
waste, thread, hair, etc.).
• If a foreign substance is caught in the door or the door is not completely closed, it may cause a
water leak.
Open the water tap and check if the water supply hose connector is firmly tightened and that there is
no water leak before using the product.
• If the screws on the water supply hose connector are loose, it may result in a water leak.
The product you have purchased is designed for domestic use only.
Using the product for business purposes qualifies as a product misuse. In this case, the product will not
be covered by the standard warranty provided by Samsung and no responsibility can be attributed to
Samsung for malfunctions or damages resulting from such misuse.
Do not stand on the appliance or place objects (such as laundry, lighted candles, lighted cigarettes,
dishes, chemicals, metal objects, etc.) on the appliance.
• This may result in electric shock, fire, problems with the product, or injury.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 10WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 10 2021-01-15  4:04:552021-01-15  4:04:55

English 11
Safety information
Do not spray volatile material such as insecticide onto the surface of the appliance.
• As well as being harmful to humans, this may result in electric shock, fire or problems with the
product.
Do not place objects that generate electromagnetic fields near the washing machine.
• This may result in injury due to a malfunction.
Water drained during a high-temperature wash or drying cycle is hot. Do not touch the water.
• This may result in burns or injury.
If the water temperature is high before drain, it take time until the temperature goes down, and it can
be different depending on internal temperature.
Do not wash, spin, or dry water-proof seats, mats, or clothing (*) unless your appliance has a special
cycle forwashing these items.
(*): Woollen bedding, rain covers, fishing vests, ski pants, sleeping bags, diaper covers, sweat suits, and
bicycle, motor cycle and car covers, etc.
• Do not wash thick or hard mats even if the washing machine mark is on the care label. This may
result in injury or damage to the washing machine, walls, floor, or clothing due to abnormal
vibrations.
• Do not wash throw rugs or doormats with rubber backing. The rubber backing may come off and
stick to inside the drum, and this may result in malfunction such as a drainage error.
Do not operate the washing machine when the detergent drawer is removed.
• This may result in electric shock or injury due to a water leak.
Do not touch the insides of the drum during or just after drying as it is hot.
• This may result in burns.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 11WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 11 2021-01-15  4:04:552021-01-15  4:04:55

12 English
Safety information
Safety information
The door glass becomes hot during washing and drying. Therefore, do not touch the doorglass.
Also, do not allow children to play around the washing machine or touch the door glass.
• This may result in burns.
Do not insert your hand into the detergent drawer.
• This may result in injury as your hand may be caught by the detergent input device.
• The liquid detergent guide (applicable models only) is not used for powder detergent. Remove the
guide when using powder detergent.
Do not place any objects (such as shoes, food waste, animals) other than laundry into the washing
machine.
• This may result in damage to the washing machine, or injury and death in the case of pets due to
the abnormal vibrations.
Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.
• This may result in electric shock or injury.
Do not wash laundry contaminated by oils, creams or lotions usually found in skincare shops or
massage clinics.
• This may cause the rubber seal to become deformed and result in a water leak.
Do not leave metal objects such as safety pins, hair pins or bleach in the drum for long periods of time.
• This may cause the drum to rust.
• If rust starts appearing on the surface of the drum, apply a (neutral) cleansing agent to the surface
and use a sponge to clean it. Never use a metal brush.
Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry contaminated by dry
cleaning detergent.
• This may result in spontaneous combustion or ignition due to the heat from the oxidation of the
oil.
Do not use water from water cooling/heating devices.
• This may result in problems with the washing machine.
Do not use natural hand-washing soap for the washing machine.
• If it hardens and accumulates inside the washing machine, it may result in problems with the
product, discolouration, rust, or bad odours.
Place socks and brassieres in a washing net and wash them with the other laundry.
Do not wash large laundry items such as bedding in the washing net.
• Failure to do so may result in injury due to abnormal vibrations.
Do not use hardened detergent.
• If it accumulates inside the washing machine, it may result in a water leak.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 12WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 12 2021-01-15  4:04:552021-01-15  4:04:55

English 13
Safety information
Make sure that the pockets of all the clothing items to be washed are empty.
• Hard, sharp objects such as coins, safety pins, nails, screws, or stones can cause extensive damage
to the appliance.
Do not wash clothing with large buckles, buttons or other heavy metal objects.
Sort the laundry by colour on the basis of its colorfastness and select the recommended cycle, water
temperature and additional functions.
• This may result in discolouration or fabric damage.
Take care that children’s fingers are not caught in the doorwhen you close it.
• Failure to do so may result in injury.
Critical cleaning warnings
WARNING
Do not clean the appliance by spraying water directly onto it.
Do not use a strong acidic cleaning agent.
Do not use benzene, thinner or alcohol to clean the appliance.
• This may result in discolouration, deformation, damage, electric shock orfire.
Before cleaning or performing maintenance, unplug the appliance from the wall socket.
• Failure to do so may result in electric shock or fire.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 13WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 13 2021-01-15  4:04:552021-01-15  4:04:55

14 English
Safety information
Safety information
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items from other
types of waste and recycle them responsibly to promote the sustainable
reuse of material resources.
Household users should contact eitherthe retailerwhere they purchased
this product, or their local government office, for details of where and how
they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product regulatory obligations, e.g.
REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 14WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 14 2021-01-15  4:04:552021-01-15  4:04:55

English 15
Installation
Installation
Follow these instructions carefully to ensure proper installation of the washing machine and to
prevent accidents when doing laundry.
What’s included
Make sure all the parts are included in the product package. If you have a problem with the washing
machine or the parts, contact a local Samsung customer centre or the retailer.
01 Release lever 02 Detergent drawer 03 Control panel
04 Door 05 Drum 06 Debris filter
07 Emergency drain tube 08 Filter cover 09 Worktop
10 Power plug 11 Drain hose 12 Levelling feet
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 15WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 15 2021-01-15  4:04:552021-01-15  4:04:55

16 English
Installation
Installation
Spanner Bolt caps Hose guide
Cold water hose Hot water hose
NOTE
• Spanner is needed for adjusting the levelling feet, and removing the shipping bolts on the back of
the washing machine.
• 4 bolt caps are provided for covering the shipping bolt holes.
• Use the hose guide to loop the end of the drain hose.
• Connect the cold and hot water hoses to the inlets at the back of the washing machine to supply
cold and hot water.
• Some models may just have one water supply inlet which is for cold water. If yourwashing machine
has one water supply inlet, make sure you connect the cold water hose to the cold watertap.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 16WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 16 2021-01-15  4:04:552021-01-15  4:04:55

English 17
Installation
Installation requirements
Electrical supply and grounding
• AC 220-240 V / 50 Hz fuse or circuit breaker
is required
• Use an individual branch circuit specific to
the washing machine
To ensure proper grounding, the washing
machine comes with a power cord featuring a
three-prong grounding plug for use in a properly
installed and grounded outlet.
Check with a qualified electrician or
serviceperson if you are not sure about the
grounding.
Do not modify the provided plug. If it does not fit
the outlet, call a qualified electrician to install a
proper outlet.
WARNING
• Do NOT use an extension cord.
• Use only the power cord that comes with the
washing machine.
• Do NOT connect the ground wire to plastic
plumbing, gas lines, or hot water pipes.
• Improperly connected grounding conductors
may cause electric shock.
Water supply
A proper water pressure for this washing
machine is between 50 kPa and 800 kPa. Water
pressure less than 50 kPa may cause the water
valve not to close completely. Or, it may take
longer to fill the drum, causing the washing
machine to turn off. Water taps must be within
120 cm from the rear of the washing machine so
that the provided inlet hoses reach the washing
machine.
To reduce the risk of leaks:
• Make sure water taps are easily accessible.
• Turn off the taps when the washing machine
is not in use.
• Check for any leaks at the water inlet hose
fittings on a regular basis.
CAUTION
Before using the washing machine forthe first
time, check all connections at the watervalve
and taps for any leaks.
Drain
Samsung recommends a standpipe in height of
60-90 cm. The drain hose must be connected
through the hose clip to the standpipe, and the
standpipe must fully cover the drain hose.
Flooring
For best performance, the washing machine
must be installed on a solid floor. Wood floors
may need to be reinforced to minimize vibration
and/or unbalanced loads. Carpeting and soft tile
surfaces are not a good resistance to vibrations
and may cause the washing machine to move
slightly during the spin cycle.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 17WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 17 2021-01-15  4:04:562021-01-15  4:04:56

18 English
Installation
Installation
CAUTION
Do NOT install the washing machine on a
platform or a poorly supported structure.
Water temperature
Do not install the washing machine in areas
where water may freeze as the washing machine
always retains some water in its watervalves,
pumps, and/or hoses. Frozen water left in the
connection parts may cause damage to belts,
the pump, and other components of the washing
machine.
Alcove or closet installation
Minimum clearance for stable operation:
Sides 25 mm Rear 50 mm
Top 25 mm Front 550 mm
If both the washing machine and a dryer are
installed in the same location, the front of the
alcove or closet must have at least a 550 mm
unobstructed air opening. Your washing machine
alone does not require a specific air opening.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 18WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 18 2021-01-15  4:04:562021-01-15  4:04:56

English 19
Installation
Step-by-step installation
STEP1 Select a location
Location requirements:
• Solid, level surface without carpeting or flooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room forventilation and wiring
• The ambient temperature is always higher than the freezing point (0 ˚C)
• Away from a heat source
STEP 2 Remove the shipping bolts
Unpack the product package and remove all shipping bolts.
NOTE
Number of shipping bolts may differ depending on the model.
WARNING
Packaging materials can be dangerous to children. Dispose all packaging material (plastic bags,
polystyrene, etc.) out of children’s reach.
A
1. Locate the shipping bolts (marked with
circle in the figure) on the rear side of the
washing machine.
CAUTION
Do not remove the screw (A) that fixes the hose
clip.
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 19WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 19 2021-01-15  4:04:562021-01-15  4:04:56

20 English
Installation
Installation
2. Using the supplied spanner, loosen
all the shipping bolts by turning them
counterclockwise.
NOTE
You must keep the shipping bolts forfuture use.
B
3. Insert the bolt caps (B) to the holes (marked
with circle in the figure).
WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 20WW3000TM_7-8KG_Jordan_8C104-000584_EN.indd 20 2021-01-15  4:04:562021-01-15  4:04:56
