Samung RH25H5611 Series User manual

Refrigerator
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
Free Standing Appliance
RH25H5611**
DA68-02981J-07.indb 1 2018. 7. 4. �� 1:59

English - 2
Safety information
Contents
SAFETY INFORMATION……………………………………………………………… 2
SETTING UP YOUR SIDE-BY-SIDE REFRIGERATOR …………………………… 9
OPERATING THE SAMSUNG SIDE-BY-SIDE REFRIGERATOR………………… 21
TROUBLESHOOTING………………………………………………………………… 32
SAFETY INFORMATION
• Before using your new Samsung Refrigerator,
please read this manual thoroughly to ensure
that you know how to operate the features and
functions that your new appliance offers safely
and efficiently.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with
the appliance.
• Because the following instructions cover
various models, the characteristics of your
refrigerator may differ slightly from the
refrigerator described in this manual.
• If you have any question, contact us at
1-800-SAMSUNG or find help and information
online at www.samsung.com.
• R-600a or R-134a is used as a refrigerant.
Check the compressor label on the rear of
the appliance or the rating label inside the
fridge to see which refrigerant is used for your
refrigerator. If this product contains flammable
gas (Refrigerant R-600a), contact your local
authority in regard to safe disposal of this
product.
• It is hazardous for anyone other than an
Authorized Service Person to service this
appliance.
Warning; Risk of
fire / flammable
materials
Important safety symbols and
precautions:
WARNING
Hazards or unsafe practices that may result in
severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in
minor personal injury or property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
DA68-02981J-07.indb 2 2018. 7. 4. �� 1:59

English - 3
SAFETY INFORMATION
Unplug the power plug from the wall
socket.
Make sure the refrigerator is grounded to
prevent electric shock.
Call the contact center for help.
Note.
These warning symbols are here to prevent
injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe
place for future reference.
WARNING
STATE OF CALIFORNIA
PROPOSITION 65 WARNING (US
ONLY)
• Cancer and Reproductive Harm - www.
P65Warnings.ca.gov.
WARNING
CRITICAL INSTALLATION
WARNINGS
• Do not install the refrigerator in a damp
location or place where it may come in
contact with water.
- Deteriorated insulation on electrical parts may
cause an electric shock or fire.
• Do not place this refrigerator in direct sunlight
or expose it to the heat from stoves, room
heaters, or other appliances.
• Do not plug several appliances into the same
multiple power strip.
The refrigerator should always be plugged into
its own individual electrical outlet which has a
voltage rating that matches the voltage listed
on the refrigerator’s rating plate.
- This provides the best performance and
also prevents overloading of house wiring
circuits, which could cause a fire hazard from
overheated wires.
• If the wall socket is loose, do not insert the
power plug.
- There is a risk of electric shock of fire.
• Do not use a power cord that has cracks or
abrasion damage along its length or at either
end.
• Do not bend the power cord excessively or
place heavy objects on it.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal
object, place a heavy object on the power
cord, insert the power cord between objects, or
push the power cord into the space behind the
appliance.
• When moving the refrigerator, be careful not to
roll over or damage the power cord.
- This may result in an electric shock or fire.
• Never unplug your refrigerator by pulling on the
power cord.
Always grip the plug firmly and pull straight out
from the outlet.
- Damage to the cord may cause a short-circuit,
fire, and/or electric shock.
• Do not use aerosols near the refrigerator.
- Using aerosols near the refrigerator may cause
an explosion or fire.
• Do not install this appliance near a heater or
inflammable material.
• Do not install this appliance in a humid, oily,
or dusty location , or in a location exposed to
direct sunlight or water (rain, etc.).
• Do not install this appliance in a location where
gas may leak.
- This may result in an electric shock or fire.
• This refrigerator must be properly
located and installed in accordance
with the instructions in this manual
before you use it.
• Connect the power plug in the proper position
with the cord hanging down.
- If you connect the power plug upside down, the
wire can get cut off and cause a fire or electric
shock.
• When moving the refrigerator, be careful not to
roll over or damage the power cord.
- This constitutes a fire hazard.
• Make sure that the power plug is not crushed
or damaged by the back of the refrigerator.
DA68-02981J-07.indb 3 2018. 7. 4. �� 1:59

English - 4
• Keep the packing materials out of reach of
children.
- There is a risk of death from suffocation if a
child puts the packing materials on his or her
head.
• The appliance must be positioned so that the
plug is accessible after installation.
- Failing to do so may result in an electric shock
or fire due to electric leakage.
• You need to remove all the protective plastic
film before you initially plug the product in.
• The refrigerator must be safely
grounded.
- Always make sure that you have grounded the
refrigerator before attempting to investigate or
repair any part of the appliance.
Power leakages can cause severe electric
shock.
• Never use gas pipes, telephone lines, or other
potential lightning attractors as an electrical
ground.
- Improper use of the grounding plug can result
in a risk of electric shock.
If it is necessary to use an extension cord, use
only a 3-wire extension cord that has a 3-blade
grounding plug and a 3-slot receptacle that will
accept the plug on the appliance.
The marked rating of the extension cord should
be AC 115-120 V, 10 A, or more.
If a grounding adapter is used, make sure the
receptacle box is fully grounded.
• Plug the power plug into the wall socket firmly.
Do not use a damaged power plug, damaged
power cord, or loose wall socket.
- This may result in an electric shock or fire.
• If the power cord is damaged,
have it replaced immediately by the
manufacturer or one of its service
agent.
• The wall socket must be easily accessible so
that the appliance can be quickly disconnected
from the wall socket in an emergency.
• It must be outside the area of the rear of the
appliance.
• When positioning the appliance, ensure the
power cord is not trapped or damaged.
• Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the
appliance.
• Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
• Connect to potable water supply only.
• Do not store explosive substances such as
aerosol cans with a flammable propellant in this
appliance.
CAUTION
INSTALLATION CAUTIONS
• Allow sufficient space around the
refrigerator and install it on a flat
surface.
- If your refrigerator is not level, the internal
cooling system may not work correctly.
- Keep the ventilation space in the appliance
enclosure or mounting structure clear of
obstructions.
• Allow the appliance to stand for 2 hours after
installation.
• We strongly recommend you have a qualified
technician or service company install the
refrigerator.
- Failing to do so may result in an electric shock,
fire, explosion, problems with the product, or
injury.
WARNING
CRITICAL USAGE WARNINGS
• Do not insert the power plug into a wall
socket with wet hands.
• Do not store articles on the top of the
appliance.
- When you open or close the door, the articles
may fall and cause personal injury and/or
material damage.
• Do not insert hands, feet or metal objects (such
as knives, etc.) into the bottom or the back of
the refrigerator.
- This may result in an electric shock or injury.
- Any sharp edges may cause a personal injury
• Do not put a container filled with water on the
refrigerator.
DA68-02981J-07.indb 4 2018. 7. 4. �� 1:59

English - 5
- If spilled, there is a risk of fire or electric shock.
• Children should be supervised to ensure that
they do not play with the appliance.
- Keep fingers out of “pinch point” areas.
Clearances between the doors and cabinet are
necessarily small. Be careful when you open
the doors if children are in the area.
• Do not let children hang on the door.
A serious injury may occur.
• Do not let children go inside the refrigerator.
They could become trapped.
• Do not insert your hands into the bottom area
under the appliance.
- Any sharp edges may cause personal injury.
• Do not let children step on a drawer cover.
- The drawer may break and cause them to slip.
• Do not overfill the refrigerator with food.
- When you open the door, an item may fall out
and cause personal injury or material damage.
• Do not touch the inside walls of the freezer or
products stored in the freezer with wet hands.
- This may cause frostbite.
• Never put fingers or other objects into the water
dispenser hole, ice chute, or ice maker bucket.
- It may cause personal injury or material
damage.
• Do not use or place any substances sensitive
to temperature such as inflammable sprays,
inflammable objects, dry ice, medicine, or
chemicals near or inside of the refrigerator.
• Do not keep volatile or inflammable objects
or substances (benzene, thinner, propane
gas, alcohol, ether, LP gas, and other such
products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in fire or explosion.
• Do not store pharmaceutical products, scientific
materials, or temperature sensitive products in
the refrigerator.
- Products that require strict temperature
controls must not be stored in the refrigerator.
• Do not place or use an electrical appliance
inside the refrigerator, unless it is of a type
recommended by the manufacturer.
• Do not stand on top of the appliance or place
objects (such as laundry, lighted candles,
lighted cigarettes, dishes, chemicals, metal
objects, etc.) on the appliance.
This may result in an electric shock, fire,
problems with the product, or injury.
Do not put a container filled with water on the
appliance.
- If spilled, there is a risk of fire or electric shock.
• Do not use mechanical devices or any other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.
• Do not damage the refrigerant circuit.
• Do not spray volatile material such as
insecticide onto the surface of the appliance.
- As well as being harmful to humans, it may also
result in an electric shock, fire, or problems with
the product.
• Never stare directly at the UV LED lamp for long
periods of time.
- This may result in eye strain due to the
ultraviolet rays.
• Do not attempt to repair, disassemble,
or modify the appliance yourself.
• Do not use any fuse (such as cooper, steel wire,
etc.) other than a standard fuse.
• If your appliance needs to be repaired or
reinstalled, contact your nearest service center.
- Failing to do so may result in an electric shock,
fire, problems with the product, or injury.
• If the interior or exterior LED lamp has gone
out, please contact your nearest service center.
• Children should be supervised to
ensure that they do not play with the
appliance.
- Keep fingers out of “pinch point” areas. :
Clearances between the doors and cabinet are
necessarily small. Be careful when you open
the doors if children are in the area.
• Do not let children hang on the door.
A serious injury may occur.
• Do not let children go inside the refrigerator.
They could become trapped.
• Bottles should be stored tightly together so that
they do not fall out.
• This product is intended only for the storage of
food in a domestic environment.
• If a gas leak is detected, avoid any naked
flames or potential sources of ignition, and air
the room in which the appliance is standing for
several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or fire.
• Use only the LED Lamps provided by the
manufacturer or its service agents.
DA68-02981J-07.indb 5 2018. 7. 4. �� 1:59

English - 6
• If the refrigerator emits a burning smell
or smoke, unplug the refrigerator
immediately and contact your
Samsung Electronics service center.
• If you experience difficulty changing a non-LED
light, contact a Samsung service center.
• If the product is equipped with LED Lamps, do
not disassemble the Lamp Covers and LED
Lamps yourself.
- Please contact your service agents.
• If dust or water enters the refrigerator, unplug
the refrigerator and contact your Samsung
Electronics service center.
- There is a risk of fire.
CAUTION
USAGE CAUTIONS
• Do not re-freeze frozen foods that have
thawed completely.
Do not place carbonated or fizzy drinks
in the freezer compartment.
Do not put bottles or glass containers
in the freezer.
- When the contents freeze, the glass may break
and cause personal injury.
• Use only the ice maker provided with the
refrigerator.
• Have the refrigerator’s water supply installed by
a suitably qualified person and connected only
to a potable water supply. To operate the ice
maker properly, water pressure of 20 ~ 125psi
(138 ~ 862kPa) is required.
If you will be away from home for a long period
of time (on vacation, for example) and won’t
be using the water or ice dispensers, close the
water valve.
- Otherwise, water leakage may occur.
• If you won’t be using the refrigerator for a very
long period of time, (3 weeks or more) empty
the refrigerator, unplug it, close the water valve,
wipe excess moisture from the inside walls,
and leave the doors open to prevent odors and
mold.
• Service Warranty and Modification.
• Any changes or modifications
performed by a 3rd party on this
finished appliance are not covered
under Samsung warranty service, nor is
Samsung responsible for safety issues
that result from 3rd party modifications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a
plastic bag, the refrigerator can be over cooled.
If this cooling period lasts too long, the water
filter may break and cause water leakage.
• If the refrigerator is disconnected from the
power supply, you should wait for at least five
minutes before plugging it back in.
• If you have a long vacation planned or do not
intend to use the refrigerator for a long period of
time, (3 weeks or more) empty the refrigerator,
pull out the power plug, close the water valve,
wipe excess moisture from the inside walls,
and leave the doors open to prevent odors and
mold.
- Letting the refrigerator run long periods of time
without using it can cause the insulation to
deteriorate and may cause a fire.
• To get the best performance from the product:
- Do not place food too close to the vents at the
rear of the appliance as it can obstruct free air
circulation in the refrigerator compartment.
- Wrap food up properly or place it in airtight
containers before putting it into the refrigerator.
- Do not place glass bottles or carbonated
beverages into the freezer.
They can freeze and break.
Broken beverage containers can cause injury.
- Please observe maximum storage times and
expiration dates of frozen goods.
- There is no need to disconnect the refrigerator
from the power supply if you will be away for
less than three weeks.
However, if you will be away for more than
three weeks, remove all the food, unplug the
refrigerator, close the water valve, wipe excess
moisture from the inside walls, and leave the
doors open to prevent odors and mold.
• Fill the water tank and ice cube trays with
potable water only (tap water, mineral water, or
purified water).
- Do not fill the tank with tea or a Sports drink.
This may damage the refrigerator.
• Do not strike or apply excessive force to any
glass surface.
- Broken glass may result in a personal injury
and/or property damage.
DA68-02981J-07.indb 6 2018. 7. 4. �� 1:59

English - 7
• If the product is flooded, make sure to
contact your nearest service center.
- There is a risk of electric shock or fire.
• Do not keep vegetable oil in your refrigerator’s
door bins. The oil can solidify, making it foul-
tasting and difficult to use. In addition, the
open container can leak and the leaked oil can
cause the door bin to crack. After opening an
oil container, it is best to keep the container in
a cool and shaded place such as a cupboard
or pantry.
- Examples of vegetable oil: olive oil, corn oil,
grape-seed oil, etc.
CAUTION
CLEANING CAUTIONS
• Do not spray water directly on the
inside or outside the refrigerator.
- There is a risk of fire or electric shock.
• Do not use a hair dryer to dry the inside of the
refrigerator.
• Do not place a lighted candle in the refrigerator
to remove bad odors.
- This may result in an electric shock or fire.
• Use a clean, dry cloth to remove any
foreign matter or dust from the power
plug blades.
Do not use a wet or damp cloth when
cleaning the plug.
- Otherwise, there is a risk of fire or electric
shock.
• Before cleaning or performing
maintenance, unplug the appliance
from the wall socket.
- Failing to do so may result in an electric shock
or fire.
• Use a clean sponge or soft cloth and a
mild detergent in warm water to clean the
refrigerator.
• Do not use abrasive or harsh cleansers
such as window sprays, scouring cleansers,
flammable fluids, muriatic acid, cleaning
waxes, concentrated detergents, bleaches, or
cleansers containing petroleum products on
exterior surfaces (doors and cabinet), plastic
parts, door and interior liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with
warm water when they are cold. Glass shelves
and covers may break if exposed to sudden
temperature changes or impacts such as
bumping or dropping.
WARNING
CRITICAL DISPOSAL WARNINGS
• DANGER : Risk of child entrapment.
Before you throw away your old
refrigerator or freezer:
- Take off the doors and door latch.
- Leave the shelves in place so that children may
not easily climb inside.
- Children trapped inside a refrigerator can hurt
themselves or suffocate to death.
• Please dispose of the packaging material from
this product in an environmentally friendly
manner.
• Ensure that none of the pipes on the back of
the appliance are damaged prior to disposal.
• R-600a or R-134a is used as a refrigerant.
Check the compressor label on the rear of
the appliance or the rating label inside the
fridge to see which refrigerant is used for your
refrigerator.
If this product contains flammable gas
(Refrigerant R-600a), contact your local
authority in regard to safe disposal of this
product.
• When disposing of this refrigerator, remove the
door/door seals and door latch so that small
children or animals cannot become trapped
inside.
Children should be supervised to ensure that
they do not play with the appliance.
If trapped inside, the child may get hurt or
suffocate to death.
• Cyclopentane is used in the insulation.
The gases in the insulation material require a
special disposal procedure.
Please contact your local authorities in regard
to the environmentally safe disposal of this
product.
• Keep all packaging materials well out of the
DA68-02981J-07.indb 7 2018. 7. 4. �� 1:59

English - 8
reach of children, as packaging materials can
be dangerous to children.
- If a child places a bag over his or her head, the
child could suffocate.
ADDITIONAL TIPS FOR
PROPER USAGE
• In the event of a power failure, call the local
office of your Electricity Company and ask how
long it is going to last.
- Most power failures that are corrected in an
hour or two will not affect your refrigerator
temperatures. However, you should minimize
the number of door openings while the power
is off.
- Should the power failure last more than 24
hours, remove and discard all frozen food.
• If a key is provided with refrigerator, the keys
should be kept out of the reach of children and
not be kept in the vicinity of the appliance.
• The appliance might not operate consistently
(frozen contents can thaw or temperatures
can become too warm in the frozen food
compartment) when sited for an extended
period of time in a location where ambient
air temperatures are constantly below the
temperatures for which the appliance is
designed.
• Do not store food which goes bad easily at low
temperature, such as bananas and melons.
• Your appliance is frost free, which means there
is no need to manually defrost your appliance.
This will be carried out automatically.
• Temperature rise during defrosting complies
with ISO requirements.
But If you want to prevent an undue rise in the
temperature of frozen food while the appliance
defrosts, wrap the frozen food in several layers
of newspaper.
• Any increase in the temperature of frozen food
during defrosting can shorten its storage life.
• Do not re-freeze frozen foods that have thawed
completely.
THIS APPLIANCE IS INTENDED
TO BE USED IN HOUSEHOLD
AND SIMILAR APPLICATIONS
SUCH AS
• staff kitchen areas in shops, offices and other
working environments;
• farm houses and by clients in hotels, motels
and other residential type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.
DA68-02981J-07.indb 8 2018. 7. 4. �� 1:59

English - 9
SETTING UP
GETTING READY TO INSTALL
THE REFRIGERATOR
Congratulations on the purchase of your Samsung
Side-By-Side Refrigerator.
We hope you will enjoy the many state-of-the-art
features and efficiencies that this new appliance
has to offer.
Selecting the best location for the
refrigerator
Choose:
• A location with easy access to a water supply.
• A location without direct exposure to sunlight.
• A location with level (or nearly level) flooring.
• A location with enough space for the
refrigerator doors to open easily.
• A location that allows sufficient space to the
right, left, back, and top for air circulation.
If the refrigerator does not have enough space,
it will run less efficiently and increase its power
consumption.
• A location that allows you to move the
refrigerator easily if it needs maintenance or
service.
• Do not install the refrigerator in locations where
the temperature is over 110°F (43°C) or below
50°F (10°C ).
BB
C
CDD
AA
E
E
Depth “A” 34" (864 mm)
Width “B” 35 3/4" (908 mm)
Height “C” 68 1/2" (1740 mm)
Overall Height “D” 70" (1778 mm)
Depth “E” 36 5/8" (930 mm)
62 1/4" (1581 mm)
16 3/4" (427 mm)
135°135°
2 "
(50.8 mm)
35 3/4" (908 mm)
29 5/8"
(751 mm)
50 3/4" (1291 mm)
1" (26 mm)
2" (53 mm)
Each measurement based on the design
dimension, so it may differ depending on
the measuring method.
Setting up your side-by-side
refrigerator
DA68-02981J-07.indb 9 2018. 7. 4. �� 1:59

English - 10
When moving your refrigerator
To prevent floor damage, be sure the front leveling
legs are in the up position (above the floor).
See “Leveling the Refrigerator” on page 15 for
instructions.
SCREW DRIVER(-)
CONTROL LEVER
Flooring
For proper installation, you must place this
refrigerator on a level, hard surface that is the
same height as the rest of the floor.
This surface should be strong enough to support a
fully loaded refrigerator.
To protect the finish of the flooring during
installation, cut a large section of the cardboard
carton and place it under the refrigerator where
you are working.
When moving the refrigerator, you need to pull and
push it straight forwards or back.
Do not wiggle it from side to side.
CAUTION
When installing, servicing, or cleaning behind the
refrigerator, be sure to pull the unit straight out and
push it back in straight after finishing.
Important: Make sure that you can easily move
your refrigerator to its final location by measuring
doorways (both width and height), thresholds,
ceilings, stairways, etc.
• Make sure you disconnect the water supply line
BEFORE removing the freezer door.
To avoid damage, refer to ‘Separating the water
line from the refrigerator’ on page 12.
SETTING UP THE REFRIGERATOR
Installing the handles
Important : If you need to remove the refrigerator’s
doors to move it into place, install the handles after
you put the doors back on.
To remove the doors, see “Removing the
Refrigerator Doors” on page 11.
Take the handles out of the right side door.
(Only RH25* models)
Unpack the handles and locate the door
installation packet with the fixer screws
and hex wrench.
DA68-02981J-07.indb 10 2018. 7. 4. �� 1:59

English - 11
SETTING UP
How to install the handles
Using a Philips head screwdriver, attach fixer
screws to the screw holes on each door.
If your refrigerator already has the fixer screws
installed, skip this step.
Orient each handle so that the end with the sticker
attached is at the top and the holes for the screws
are facing the screw holes on the refrigerator door.
Place a handle over the fixer screws on one door,
and then slide the handle down firmly.
Repeat with the second handle on the other door.
For Models with a lever attached to the right
handle, push the lever button on the handle in,
hold it in place, and then slide the bottom of the
handle down over the fixer screw.
Fix the handles to the doors
by sliding them down firmly.
( 1 )
( 3 )( 2 )
L
S
Using the include hex wrench, tighten the set
screw on the top inside section of each handle.
Use the longer part of the hex wrench to begin
tightening, and then the shorter part to tighten the
screw fully, as shown in the diagram below.
( 4 ) ( 5 )
LS
REMOVING THE REFRIGERATOR
DOORS
If your entrance won’t allow the refrigerator to pass
through it easily, you can remove the refrigerator
doors.
To remove the doors, follow the steps below.
If you do not need to remove the doors, go to
“Leveling the Refrigerator” on page 15.
Tools You’ll Need
Philips
Screwdriver
Flat-blade
Screwdriver
10mm Socket
Wrench
1. Remove the Front Leg Cover
Open both the freezer and refrigerator doors.
Unscrew the three screws holding the front leg
cover in place by turning them counter-clockwise.
When the screws are loose, remove the front leg
cover.
Screw
Front leg cover
CAUTION
When disassembling, make sure the unit is turned
off.
DA68-02981J-07.indb 11 2018. 7. 4. �� 1:59

English - 12
2. Separate the water supply line from
the refrigerator
1. Remove one or two water lines, depending on
the model, by pressing each coupler (1) and
pulling the water lines (2) away.
(1)
(2)
CAUTION
Do not cut the water line.
Gently separate it from the coupler.
3. Remove the freezer door
A few things to mention first.
• Make sure that you lift the door straight up so
the hinges are not bent or broken.
• Be careful not to pinch the water tubing and
wire harness on the door.
• Place doors on a protected surface to prevent
scratching or damage.
• Is necessary, have two people disassemble the
doors.
1. With the Freezer door closed, remove the
upper hinge cover (1) using a screwdriver,
and then disconnect the wires by gently pulling
them apart (2).
(2)
(1)
Pressing
Be careful not to damage the sensor
harness with the hinge cover.
2. Disconnect the electrical harness.
3. Gently lift the clamp.
To prevent damage to the clamp or
injuries, do not lift the clamp forcefully.
4. Pull the clamp to remove.
Remove the ground screw by turning it counter-
clockwise.
DA68-02981J-07.indb 12 2018. 7. 4. �� 1:59

English - 13
SETTING UP
5. Open the door by 90 degrees. While holding
the door, remove the hinge.
CAUTION
If you remove the hinge without holding the door,
the door may fall and cause injury.
6. Open the Freezer door, and then remove the
door from the lower hinge (3) by carefully lifting
it up (4).
(4)
(3)
7. Remove the lower hinge (5) from the lower
hinge bracket (6) by lifting the lower hinge up
in the direction of the arrow.
(5)
(6)
CAUTION
Make sure to put the water line through the lower
hinge before re-assembling it.
4. REMOVE THE FRIDGE
SHOWCASE
1. With the door closed, remove the upper hinge
cover (1) using a screwdriver.
(1)
2. Disconnect the wires.
Pressing
CAUTION
When disassembling, make sure the unit is turned
off.
3. Disassemble the three fastening screws on the
top hinge of the show case.
DA68-02981J-07.indb 13 2018. 7. 4. �� 1:59

English - 14
4. Disassemble the show case.
Lift the door straight up. 5. REMOVE THE FRIDGE DOOR
1. Disconnect the electrical harness.
2. Gently lift the clamp.
To prevent damage to the clamp or
injuries, do not lift the clamp forcefully.
3. Pull the clamp to remove.
4. Open the door by 90 degrees. While holding
the door, remove the hinge.
CAUTION
If you remove the hinge without holding the door,
the door may fall and cause injury.
DA68-02981J-07.indb 14 2018. 7. 4. �� 1:59

English - 15
SETTING UP
CAUTION
Do not remove the sensor assembly in the right
upper hinge cover.
Re-attaching the Fridge Door
To re-attach the fridge door, replace parts in
reverse order.
Re-attaching the Freezer Door
To re-attach the freezer door, replace parts in
reverse order.
CAUTION
Hook the wire on the Hinge Hook to prevent
damage to the wire when re-assembling.
Re-attaching the Water Supply Lines
1. The Water Lines must be fully Inserted into the
center of the transparent coupler to prevent
water leakage from the dispenser.
2. Insert the 2 clips in the install pack as shown
below, and then confirm that each clip holds
the line firmly.
Center of Transparent coupler
Clip A (1/4”)
(6.35mm)
CAUTION
Make sure the color of the water lines match.
LEVELING THE REFRIGERATOR
The refrigerator must be level before you can make
final adjustments.
Use a level to test if the refrigerator is level both
side to side and back to front.
If the refrigerator is not level, you will not be able
to get the doors perfectly even, which may cause
moisture condensation and increased energy bills.
The front of the refrigerator is also
adjustable.
Before levelling the refrigerator, remove
the front leg cover.
Open both the freezer and refrigerator doors.
Unscrew the three screws holding the front leg
cover in place by turning them counter-clockwise.
When the screws are loose, remove the front leg
cover.
DA68-02981J-07.indb 15 2018. 7. 4. �� 1:59

English - 16
If the Freezer part is lower than the Fridge
part.
Insert a flat-blade screwdriver into a slot on the
Freezer Leg, then turn it clockwise.
If the Fridge part is lower than the Freezer
part.
Insert a flat-blade screwdriver into a slot on the
Fridge Leg, then turn it clockwise.
Screw Driver Leg
Refer to the next section for the best way
to make very minor adjustments to the
doors.
HOW TO ADJUST THE DOOR
HEIGHT
If one refrigerator door is lower than the
other:
• The door height levels can be adjusted using
the adjustment nut located at the bottom of
refrigerator door.
• Raising the door too high can cause the door to
interfere with the hinge cover when it is opened
or closed.
(A)
(B)
Before adjusting the doors, remove the
front leg cover.
Open both the freezer and refrigerator doors.
Unscrew the three screws holding the front leg
cover in place by turning them counter-clockwise.
When the screws are loose, remove the front leg
cover.
DA68-02981J-07.indb 16 2018. 7. 4. �� 1:59

English - 17
SETTING UP
1. Open the door that needs to be adjusted and
loosen the clamping nut (A) at the bottom of
the door by turning it clockwise ( ) using
the spanner included in the product package.
(Raise the lower of the two doors first.)
A
2. Adjust the height of the door by turning the
adjustment nut (B) counterclockwise ( )
with a spanner.
(Turn it counterclockwise ( ) to increase
the height of the door and clockwise ( ) to
decrease it.)
- Open the door and adjust it from the inside.
B
3. Once the doors are level, turn the clamping nut
(A) counterclockwise ( ) to tighten it.
A
Adjusting the level when the refrigerator
is empty can result in the refrigerator
becoming uneven again once items have
been placed inside.
If this occurs, adjust the level again.
WHEN THE FREEZER DOOR IS
LOWER THAN FRIDGE DOOR
A level refrigerator is necessary for getting the
doors perfectly even.
Make sure your refrigerator is level before you
begin.
If you need help leveling, review the previous
section on leveling the refrigerator.
Freezer door is lower than Fridge door
The process for adjusting each door is the same.
Open the doors and adjust them, one at a time, as
follows:
1. Unscrew the nut (1) from the lower hinge until
it reaches the upper end of the bolt (2).
(2) Bolt
(1) Nut
(3) Wrench
When you release the nut (1), make sure
that you use the hex wrench provided
(3) to loosen the bolt (2) in a counter-
clockwise ( ) direction.
You should then be able to unscrew the
nut (1) with your fingers.
DA68-02981J-07.indb 17 2018. 7. 4. �� 1:59

English - 18
2. Adjust the height difference between the doors
by turning the bolt (2) clockwise ( ) or
counter clockwise ( ).
(2) Bolt
(3) Wrench
When you turn clockwise ( ), the
door will move up.
3. After adjusting the doors, turn the nut (1)
clockwise ( ) until it reaches the lower
end of the bolt, then tighten the bolt again with
the wrench (3) to fix the nut in place (1).
(2) Bolt
(1) Nut
(3) Wrench
If you do not secure the nut firmly, the bolt
may release.
MAKING MINOR ADJUSTMENTS
BETWEEN THE SHOW CASE AND
INNER CASE OF THE FRIDGE
After raising the out door, insert the supplied SHIM
HINGE MIDDLE in the gap between the Show
case of fridge and the HINGE-SHAFT.
The SHIM HING MIDDLE is included with
the refrigerator. The thickness of the SHIM
is 1mm.
CAUTION
Don’t make the Show Case door higer than Inner
Case door.
- The Show Case can break away from
STOPPER (HINGE )
DA68-02981J-07.indb 18 2018. 7. 4. �� 1:59

English - 19
SETTING UP
INSTALLING THE WATER
DISPENSER LINE
A water dispenser is one of the helpful features on
your new Samsung Refrigerator.
To help promote better health, the Samsung water
filter removes unwanted particles from your water.
However, it does not sterilize or destroy
microorganisms.
You may need to purchase a water purifying
system to do that.
The water line also connects to the ice maker.
For the ice maker to operate properly, water
pressure of 20 ~ 125psi (138 ~ 862kPa) is
required.
If the refrigerator is installed in an area with low
water pressure (below 20psi), you can install a
booster pump to compensate for the low pressure.
After you have connected the water line, make
sure the water storage tank inside the refrigerator
is properly filled.
To do this, press the water dispenser lever until
water runs from the water dispenser.
• Water line installation kits are available at
extra cost from your dealer.
We recommend using a water supply kit
that contains copper tubing.
• Use the new hose-sets supplied with the
appliance only. Do not re-use an old hose set.
Connecting to the water supply line
1. First, shut off the main water supply line and
make sure the ice maker is turned off.
2. Locate the nearest cold water drinking water
line.
3. Install the pipe clamp and shut off valve.
4. Connect the water line installation kit to the
shut off valve.
Shut off valve
Pipe clamp
Cold water line
Water line installation kit
Connecting the water supply line to the
refrigerator
There are several items that you need to purchase
to complete this connection.
You may find these items sold as a kit at your local
hardware store.
Use Copper Tubing Use Plastic Tubing
• ¼” copper tubing
• ¼” compression nut
(1pc)
• Ferrule (2pc)
• ¼” plastic tubing
→Molded end (Bulb)
• ¼” compression nut
(1pc)
Compression Nut
(1/4”) (Assembled)
Ferrule
(Not supplied)
Plastic Tubing
(Supplied)
Compression
Fitting (Assembled)
Bulb
Compression
nut (B) (1/4”)
(Not supplied)
or
Copper tubing
(Not supplied)
Plastic tubing (B)
(Not supplied)
Household water line
Refrigerator
1. Connect the household water line to the
assembled compression fitting.
- If you are using copper tubing, slip the
compression nut (B) (not supplied) and
ferrule (not supplied) on the copper tubing (not
supplied) as shown.
- If you are using plastic tubing (B), insert the
molded end (Bulb) of the plastic tubing (B) into
the compression fitting.
CAUTION
Do not use plastic tubing (B) without the molded
end (Bulb).
DA68-02981J-07.indb 19 2018. 7. 4. �� 1:59

English - 20
2. Tighten the compression nut (B) onto the
compression fitting.
Do not over-tighten the compression nut (B).
3. Turn the water on and check for any leaks
inside the refrigerator, around the water filter,
and in any connection areas.
If you find water drops or leaks, turn off the
main water supply.
If the leaks are in the connection areas, check
the connections and, if necessary, tighten.
If there are leaks in the refrigerator, check
the water filter and confirm it is in the locked
position.
Turn on the water supply and check for leaks
again.
4. Plug in the refrigerator.
5. Flush 3 gallons of water through the filter before
drinking or using the water from the refrigerator.
(Flush approximately 6 minutes.)
This will clean the water supply system and
remove air from the lines.
To flush, press the Water button, and then press
a large glass or cup against the water dispenser
lever. Fill the glass, empty it into the kitchen sink
after it is filled, and then repeat.
Additional flushing may be required in
some households.
6. Open the refrigerator door and make sure there
are no water leaks coming from the water filter.
• After you turn on the refrigerator, let the
ice maker make ice for 1 to 2 days.
Over that period of time, throw out the
first 1 or 2 buckets of ice the ice maker
makes to ensure all impurities have been
removed from the water line.
• Only connect the water line to a drinkable water
source.
• If you have to repair or disassemble the water
line, cut off 1/4“ of the plastic tubing to make
sure you get a snug, leak-free connection.
• You can test the water line quickly using a
paper cup.
Under normal conditions, the water dispenser
can fill a 5.75oz. (170cc) cup in about 10
seconds.
COMPLETING THE SET UP
Now that you have your new refrigerator installed
in place, you are ready to set up and enjoy the
features and functions of the appliance.
By completing the following steps, your refrigerator
should be fully operational.
1. Make sure your refrigerator is in an appropriate
location with reasonable clearance between it
and the wall. Refer to installation instructions in
this manual.
2. Once the refrigerator is plugged in, make sure
the interior light comes on when you open the
doors.
3. Set the Temperature control to the coldest
temperature and wait for an hour.
The freezer will get slightly chilled and the motor
will run smoothly.
Reset the refrigerator and freezer to the
temperatures you want.
4. After you plug the refrigerator in, it will
take a few hours to reach the appropriate
temperature.
You can store food and drinks in the refrigerator
after the temperature is sufficiently cool.
If condensation or water drops appear
on both sides of the fridge door’s central
part, turn the Energy Saver mode off after
removing the condensation.
(See the explanation of the Energy Saver
button in “Control panel functions” on
page 21.)
Preventing Power Cord Damage
To prevent power cord damage, fix any excess
power cord to the top rear of the refrigerator as
shown in the illustration below.
DA68-02981J-07.indb 20 2018. 7. 4. �� 1:59
