SAMWOO Desk Plus Series User manual

Enhance your
competitiveness
Upgrade your health
and work efficiency
www.shsdeskplus.com
Presenting
new changes
in your work
environment
User Manual
[ Add on Desk / Desk type ]

[ Add on Desk / Desk type ]
※ Please visit "www.shsdeskplus.com" for the newest installation manual.
Vertical height adjustment (up / down)
Smooth height Control with Gas Lift
Any Stop (freely fixed at desired height)
Eccentricity prevention design
(maintaining balance while leaning)
Adjusting the heightwith the lever
Anti-swaying
Stopper
Safety design
1·Take the desk out of the box.
·Two people should move it together.
·Possibilty of injury exists if moved alone.
3
Gather and hold the
cable to organize.
Wrap the cables by
the cable zip
Pull down the rest of
cable zip while
wrapping cables
※CableTiesand
CableZipsNOT
INCLUDED with
the desk.
4CAUTION
·
Orgnize cables at the maximum height position of a desk.
· Objects might fall during up and down operation if the cables
are organized at the Minimum position
2
CAUTION
·Place the objects in the center of a desk.
·If you don't comply with this, you may get injured,
or the objects could fall.
1. How to install "Add on Desk"
3/8
Lift the desk up to the maximum height
by pushing two levers together.
When adjusting the desk, it can be lifted up faster
or lowered because it is designed
for 11~24.3lbs of equipment(monitor or laptop)
weight.
※ In case of purchasing Add on type and legs
·Always two people together when assemble
the desk and leg.
·Possibility of injury exists if moved or assembled alone.
·Followtheassemblysequencefrom①to⑧asshownin
the right picture.
·Tighten the screws to prevent being loosened.
1) How to assemble "Add on Desk Type"
Assemble rubber
feet to both left
and right leg.
Lie down the right leg as
shown on the picture after
assembling rods.
Assemble coupling rod to
the right leg as shown in
the picture.
Assemble the left leg.
Assemble another coupling
rod to the right leg as shown
in the picture.
Place assembled legs as shown in
the picture, and tighten the
screws.
①
④
②
⑤
③
⑥
Material list
-Leg(L/R) : 1pc each
-Couplingrod:2pcs
-Rubber feet : 4pcs
-Screw(for legs) : 8pcs
-Screw(for add on desk) : 8pcs
·Take the desk out of the box.
·Checkthemateriallistafteropeningthebox.
·Assemble the legs two people together.
·Possibility of injury exists if moved or
assembled alone.
·Fasten the screws of the legs with a Philips
screwdriver.
2/8
Maximum height
Minimum height

[ Add on Desk / Desk type ]
2. Add on Desk Height Adjustment
(1)Adjust the height by squeezing the "left and right" lever at the same time as in the above picture.
Warning
·Adjust the cable arrangment of item(Laptop & Monitor) at the highest position.
·Item(Laptop & Monitor) may fall behind if cables are at lowest position.
✖WARNING
Checksettingconditiontobeabletodisplaytheitem(laptop&Monitor)safely.
✖WARNING : Do not put hands near the X white adjusting.
Hands may be pinched or trapped. Failure to comply with this
warnning may result in injury.
✖WARNING
·Damage to mechanism may occur under heavy impact.
·When Moving :
- shift desk to lowest position.
- with two people.
- do not grab adjusting levers.
※ If this warning is ignored, it can occur injury.
✖WARNING
·Do not access another body part when operates control
handle lever of desk height.
※ If this warning is ignored, it can occur injury.
✖WARNING
·Do not climb or run on the desk for child.
·Do not adjust desk height if child is on the desk top board.
※ If this warning is ignored, it can occur injury.
✖WARNING
·Do not lean or press the adjusted desk too hard for long time.
※ If this warning is ignored, it can occur injury.
WARNING
3. Safety
5/8
Handle Lever
※ Please visit "www.shsdeskplus.com" for the newest installation manual.4/8
* If you have to withstand a heavier working load, use the 'auxiliary spring'
(This description applies only to Quattro type models.)
* Two auxiliary springs are located on the side of the product's Styrofoam packaging.
(This description applies only to Quattro type models.)
How to install auxiliary springs
- After lifting the product up to the top, 'a. Ball
stud 'on 'B. Assemble the auxiliary spring 'in the
direction of the arrow.
- Make sure that the up and down direction is as
shown in the figure.
* Appearance of completed installation
a. Ballstud
b. Auxiliary spring
c. Socket
* Removed appearance
Auxiliary spring detachment method
- Raise the product up to the top and then 'c. Socket
'Press 'b' with your thumb. Remove auxiliary spring
in the direction of the arrow.
- Remove the opposite way in the same way.
Allowable load Average
Basic Mounting 6 ~ 16kg 11kg
Equipped with one auxiliary spring 9 ~ 19kg 14kg
Equipped with two auxiliary springs 12 ~ 22kg 17kg

[ Add on Desk / Desk type ]
4. Feature / Spec
7/8
4. Feature / Spec
MODEL S-TYPE E-TYPE M-TYPE B-TYPE G-TYPE
Width (inch)
Length(inch)
Height (inch)
Load (lbs)
Max Capacity
35.4 inch
31.9 inch
4.3~17.8 inch
11~33 lbs
44 lbs
37.4 inch
23.6 inch
4.3~17.8 inch
11~33 lbs
44 lbs
27.6 inch
23.6 inch
4.3~17.8 inch
6.6~28.6 lbs
44 lbs
35.4 inch
29.5 inch
4.3~17.8 inch
11~33 lbs
44 lbs
39 inch
25.6 inch
4.3~20 inch
11~33 lbs
44 lbs
Feature and function
WARNING
·Do not exceed the proper weight limit.
·If you do not follow the safty precautions in section 3, installed items (notebook & monitor) may fall and cause injury.
H(inch)
W(inch)
L(inch)
A+B : 11~24.3 lbs
MaxCapacity : 11~24.3 lbs
B
MaxCapacity : 6.6 lbs
A B
}
A
※Ifyoudo notputanythingonthe desk,itmaybe
somewhat hard to descend the product from the
max height, depending on user.
h(inch)
※ Please visit "www.shsdeskplus.com" for the newest installation manual.6/8
Vertical height adjustment
(up / down)
Smooth height Control
with Gas Lift
Any Stop
(freely fixed at desired height)
Eccentricity prevention design
(maintaining balance while leaning)
Adjusting the height
with the lever
Anti-swaying
Stopper
Safety design

Customer Service
Please contact our customer service center for product fails,
warranty and feedback about our product.
Tel : [phone]
Fax: [phone]
E-mail: [e-mail]
