Sanat SVC-5061 User manual

VACUUM CLEANER
Instruction Manual
Model No.: SVC-5061
Please read carefully before using for the first time.

1 Parts
Please assemble vacuum cleaner as follows
Handle
Hose
Telescope tube
Insert tube
Cord rewind button
Speed button
On/off Button
Power Cord
Rear wheel
Front cover
Square brush
Flat brush
Floor brush

2 Attention:
1. Please don’t suck in liquids such as water, oil, oil paint to
the vacuum cleaner. Avoid liquids from getting into the
motor as this may cause motor failure.
2. Please don’t suck in hair agglomerate, big paper
agglomerate etc as this will easily block the tube and hose.
This may cause motor failure. Please pull out power cord
while cleaning the vacuum cleaner if it gets blocked.
3. Please don’t keep it too close to heater or other high
temperature equipments.
4. Please make sure that you assemble the dust cup
correctly. Don’t use the vacuum cleaner without the filter.
5. Please don’t bend, trample or pull the hose. Don’t use the
hose if it is broken.
6. . Please don’t suck in cement, calcimine granules etc... As
this may cause motor failure. Please clean the HYPA and
the filter.

7. Please remove the plug when you clean the vacuum
cleaner and when the vacuum cleaner is not in use. Do not
pull the power cord, but remove the plug from the socket.
8. Don’t use gasoline or Nitrocellulose lacquer thinner to
clean the vacuum cleaner, as this will cause the enclosure chap
to fade. Don’t use the vacuum cleaner after cleaning at once.
Wait for some time before using it after cleaning
3 Assemble
1. Connecting hose and vacuum cleaner
△ Insert the hose connection wand in to hose connection
inlet. Please check if it is locked with button.
△ After finishing, please pull out the hose connection wand.
2.Connecting handle and telescope tube.
△Please connect the handle to telescope tube. By slowly
pushing the handle into the tube.

3.Adjusting the length of telescope tube
Press the telescope tube button, and adjust the length.
4.Connecting telescope tube and floor brush
△ Insert the telescope tube to the floor brush.
4 Operation
Red
Yellow
△ Pull out power cord
Pull out power cord Pull out power cord
Pull out power cord
Pull out the power cord to the yellow mark,
Do not
pass the red mar
△ Rewind power cord
Rewind power cordRewind power cord
Rewind power cord
After working please pull out plugs.
△ ON/OFF
ON/OFF ON/OFF
ON/OFF
Insert the plug into socket, press the ON/OFF button
before working.
△ Speed control
Speed control Speed control
Speed control
Slip the speed button.

△ Suction control
Suction controlSuction control
Suction control
Slip the handle control button.
△ Finish working
Push back the telescope
tube and fix the floor
brush with the product parking position.
△ Cleaning the vacuum cleaner
Please pull out the accessory from the slot.
1. Small brush and narrow brush for cleaning the corners,
curtains and lights and so on.

2.Floor brush for cleaning room floor and carpet
3. When hose is blocked, please pull out the hose and
put the handle in the inlet to suck out the rubbish..
6 Maintenance
1. Pour the rubbish from dust bag
A、Press the front cover button, pull up the front
cover.
B、Poke the dust bag holder as arrowhead show, and
take out the dust bag.
C、Unhinge the dust bag nip, and pour the rubbish.
2. Cleaning outlet filter
Press outlet board button, pull out the outlet board, and
take out the HYOA for cleaning.
3. Cleaning inlet filter
Open the front cover, and do as in the picture.

Out
filter
4. Clean the HYPA and filter
Clean the filter
A、Put the filter in the water first.
B、Swish the filter in air to dry it, and don’t bend
Clean HYPA
C、A、Put the filter in the water first.
D、Swish the filter in air to dry it and don’t bend.
E、Notice：
：：
：Please air the filter and HYPA
. Do not
heat the HYPA and the filter
7 Possible problem and solution
Problem Cause Solution
Motor stops working Product has not been connected
with power supply
Connect the power suply
Filter jam Clean the filter
Dust bag full Empty or replace the dust bag
Outlet filter jam Clean the outlet filter
Suction weakened
Wind line jam Clean the wind line
Stops rewinding Cord departure rewinding cable slot
Product heated A little heat is normal
Attention: Please go to dealer or appointed service for the cord line replacing.
8 Specification
Rated Voltage ：
：：
：230V
Nom power :2000W
Max power :2200W
Frequency：
：：
：50Hz

Vacuum degree ：≥
：≥：≥
：≥26KPa
Noise：
：：
：≤
≤≤
≤91dB(A)
Max volume：
：：
：4L
Max working place radii：
：：
：7m
1.This appliance is not intended for use by persons (including children )with
reduced physical sensory or mental capabilities ,or lack of experience and
knowledge ,unless they have been given supervision orinstruction concerning use
of the appliance by a person responsible for their safety .
Children should be supervised to ensure that they do not play with the appliance .
2.If the supply cord is damaged ,it must be replaced by the manufacturer ,its service
agent or similarly qualified persons in order to avoid hazard .
