S&C PureWave User manual

May 22, 2017
© S&C Electric Company 2007-2017, all rights reserved Instruction Sheet 653-502
S&C PureWave® UPS System
250 kW, 500 kW, 750 kW, and 1000 kW; 208-600 Volts
Operation and Maintenance
Table of Contents
Section Page Section Page
Introduction
Qualified Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this Instruction Sheet. . . . . . . . . . . . . . . . . . . . . . . 2
Retain this Instruction Sheet. . . . . . . . . . . . . . . . . . . . . . 2
Proper Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warranty Qualifications. . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Information
Understanding Safety-Alert Messages . . . . . . . . . . . . . . 3
Following Safety Instructions . . . . . . . . . . . . . . . . . . . . . 3
Replacement Instructions and Labels. . . . . . . . . . . . . . . 3
Hazardous Voltages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Securing the Enclosure. . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Equipment, Precautions, and Practices . . . . . . . . 4
Emergency Procedures and Equipment . . . . . . . . . . . . . 4
Additional Safety Instructions . . . . . . . . . . . . . . . . . . . . . 4
Location of Safety Labels . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Shipping and Handling. . . . . . . . . . . . . . . . . . . . . . . . 13
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Components and Controls
Enclosure Configurations . . . . . . . . . . . . . . . . . . . . . . . 14
Enclosure Bays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
LCD Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Air Control and Ventilation. . . . . . . . . . . . . . . . . . . . . . . 20
Operating Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Service Personnel Controls . . . . . . . . . . . . . . . . . . . . . 23
Monitoring Computer . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Remote Disable (optional) . . . . . . . . . . . . . . . . . . . . . . 25
Operation
System Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Transition States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Alarms List and Troubleshooting Tips . . . . . . . . . . . . . . 28
Warning Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Inhibit Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Bypass Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Bypass Isolate Alarms . . . . . . . . . . . . . . . . . . . . . . . . . 30
Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Maintenance Bypass Procedure . . . . . . . . . . . . . . . . . . 31
Returning the PureWave UPS System
to the Ready State . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Bypass Isolation Procedure . . . . . . . . . . . . . . . . . . . . . 31
Battery Charging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Generator Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Monitoring
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Monitoring Software Security . . . . . . . . . . . . . . . . . . . . 33
Monitoring Software . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Maintenance
Maintenance Checklist Overview . . . . . . . . . . . . . . . . . 37
Quarterly Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 38
Annual Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 42

2S&C Instruction Sheet 653-502
Qualified Persons WARNING
The equipment covered by this publication must be installed, operated, and maintained by
qualified persons who are knowledgeable in the installation, operation, and maintenance
of electric power distribution equipment and the associated hazards.
A qualified person is one who is trained and competent in:
• The skills and techniques necessary to distinguish exposed live parts from nonlive
parts of electrical equipment
• The skills and techniques necessary to determine the proper approach distances
corresponding to the voltage to which the qualified person will be exposed
• The proper use of the special precautionary techniques, personal protective equip-
ment, insulating and shielding materials, and insulated tools for working on or near
exposed energized parts of electrical equipment
These instructions are intended only for such qualified persons. They are not intended to
be a substitute for adequate training and experience in safety procedures for this type of
equipment. Failure to comply can result in personal injury or even death.
Read this
Instruction Sheet NOTICE
Read this instruction sheet thoroughly and carefully before installing or operating your
S&C PureWave UPS System. Familiarize yourself with the Safety Information and
Safety Precautions on pages 3 through 5.The latest version of this publication is available
online in PDF format at sandc.com/Support/Product-Literature.asp.
Retain this
Instruction Sheet
This instruction sheet is a permanent part of your S&C PureWave UPS System. Designate
a location where you can easily retrieve and refer to it.
Proper Application WARNING
The equipment in this publication must be selected for a specific application. The
application must be within the ratings furnished for the selected equipment.
Warranty The warranty and/or obligations described in S&C’s standard conditions of sale, as
set forth in Price Sheet 150, plus any special warranty provisions, as set forth in the
applicable product-line specication bulletin, are exclusive. The remedies provided in
the former for breach of these warranties shall constitute the immediate purchaser’s
or end user’s exclusive remedy and a fulllment of all the seller’s liability. In no event
shall the seller’s liability to the immediate purchaser or end user exceed the price of
the specic product that gives rise to immediate purchaser’s or end user’s claim. All
other warranties, whether express or implied or arising by operation of law, course
of dealing, usage of trade or otherwise, are excluded. The only warranties are those
stated in Price Sheet 150, and THERE ARE NO EXPRESS OR IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. ANY EXPRESS
WARRANTY OR OTHER OBLIGATION PROVIDED IN PRICE SHEET 150 IS GRANTED
ONLY TO THE IMMEDIATE PURCHASER AND END USER, AS DEFINED THEREIN.
OTHER THAN AN END USER, NO REMOTE PURCHASER MAY RELY ON ANY
AFFIRMATION OF FACT OR PROMISE THAT RELATES TO THE GOODS DESCRIBED
HEREIN, ANY DESCRIPTION THAT RELATES TO THE GOODS, OR ANY REMEDIAL
PROMISE INCLUDED IN PRICE SHEET 150.
Warranty
Qualifications
The seller’s warranties are contingent upon the installation and adjustment of the S&C
PureWave UPS System in accordance with S&C’s applicable instruction sheets, data
sheets, and/or data bulletins
Safety Information

S&C Instruction Sheet 653- 502 3
Safety Information
Understanding
Safety-Alert
Messages
Several types of safety-alert messages may appear throughout this instruction sheet and
on labels attached to the containers and power conversion system (PCS) enclosures.
Familiarize yourself with these types of messages and the importance of these various
signal words:
DANGER
“DANGER” identifies the most serious and immediate hazards that will likely result in
serious personal injury or death if instructions, including recommended precautions, are
not followed.
WARNING
“WARNING” identifies hazards or unsafe practices that can result in serious personal injury
or death if instructions, including recommended precautions, are not followed.
CAUTION
“CAUTION” identifies hazards or unsafe practices that can result in minor personal injury
if instructions, including recommended precautions, are not followed.
NOTICE
“NOTICE” identifies important procedures or requirements that can result in product or
property damage if instructions are not followed.
Following Safety
Instructions NOTICE
Read this instruction sheet thoroughly and carefully before
operating your PureWave UPS System.
If you do not understand any portion of this instruction sheet and need assistance, contact
your nearest S&C Sales Office or S&C Authorized Distributor. Their telephone numbers
are listed on S&C’s website, sandc.com. Or call S&C Headquarters at [phone].
Replacement
Instructions
and Labels
If you need additional copies of this instruction sheet, contact your nearest S&C Sales
Ofce, S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.
It is important that any missing, damaged, or faded labels on the equipment be replaced
immediately. Replacement labels are available by contacting your nearest S&C Sales
Office, S&C Authorized Distributor, S&C Headquarters, or S&C Electric Canada Ltd.

4S&C Instruction Sheet 653-502
Safety Information
Hazardous Voltages DANGER
Potentially lethal voltages are present inside the PureWave UPS System. Dc voltage
is present even without utility power connected. Hazardous voltages should also be
expected in all interconnecting components and lines.
Securing the
Enclosure
To maintain safety, the user should use padlocks on each enclosure door. The doors and
the use of the padlocks provide protection against inadvertent contact with high-voltage
circuits.
Safety Equipment,
Precautions, and
Practices
S&C PureWave UPS System and battery instruction sheets must be available to all
operators and other employees. If doors to the electrical controllers or panels to the
system enclosure must be opened, refer to the instruction sheet for procedures for
guarding against electric shock. Lockout and tagout procedures should be developed
and implemented in accordance with 29 CFR 1910.147.
WARNING
Insulated hand tools are required when working on or around any energized equipment.
Use only properly rated tools for the energy present. Tool inventories should be kept
to ensure all tools that enter the system enclosure are removed before energizing the
system.
Emergency
Procedures and
Equipment
The owner should develop policies and procedures for handling emergency situations.
It is the responsibility of the owner to develop site-specic emergency action plans for
response to such situations.
Additional Safety
Instructions
Consult the supplier of the batteries for additional safety instructions and procedures.
Location of Safety
Labels NOTICE
For safety labels, contact S&C Electric Company for the following:
• Exact location of the standard safety labels
• Project-specific safety labels
• Replacement of labels (reference the label part numbers as shown below)
Reorder Information for Safety Information
Location Safety Alert Message Description Part Number
AWARNING Keep out. Risk of electric shock… PE-70314
BDANGER Hazardous voltage… PE-70315
CDANGER Keep out. Risk of electric shock… PE-70323
DCAUTION Do not remove power conversion… PE-70321
EDANGER Hazardous voltage inside… PE-70319
FDANGER Risk of electric shock… PE-70316
GWARNING To reduce risk of fire... PE-70324
HCAUTION Always follow the instructions... PE-70325

S&C Instruction Sheet 653- 502 5
Location of Safety Labels − continued
For 750-kW and 1000-kW PureWave UPS Systems (1000-kW system pictured)
Safety Information
A
A
A
A
B
B
D
F
ABDF

6S&C Instruction Sheet 653-502
Safety Information
Location of Safety Labels − continued
For 750-kW and 1000-kW PureWave UPS Systems (1000-kW system pictured)
ABD
F
C
A
A
B
D
F
B
B
C
C

S&C Instruction Sheet 653- 502 7
Safety Information
Location of Safety Labels − continued
For 750-kW and 1000-kW PureWave UPS Systems (1000-kW system pictured)
ABDC
G
E
Inside wall of the circuit breaker section of the switchgear bay
A
A
B
C
D
E
E
E
G

8S&C Instruction Sheet 653-502
Safety Information
Location of Safety Labels − continued
For 750-kW and 1000-kW PureWave UPS Systems
View of the back side of the circuit breaker
section door of the switchgear bay
View of the back side of the swing-out control
panel inside the control bay.
B E H
H
B
E

S&C Instruction Sheet 653- 502 9
Safety Information
Location of Safety Labels − continued
For 250-kW and 500-kW PureWave UPS Systems (500-kW system pictured)
A
A
A
A
A

10 S&C Instruction Sheet 653-502
Safety Information
Location of Safety Labels − continued
For 250-kW and 500-kW PureWave UPS Systems (500-kW system pictured)
BE
C
B
C
B
B
E
E

S&C Instruction Sheet 653- 502 11
Safety Information
Location of Safety Labels − continued
For 250-kW and 500-kW PureWave UPS Systems
E
E
E
Views of the control bay (with the door open showing the dead-front panels).

12 S&C Instruction Sheet 653-502
Safety Information
Location of Safety Labels − continued
For 250-kW and 500-kW PureWave UPS Systems
EHG
E
E
E
E
H
G
View of the switchgear bay with door open.
G

S&C Instruction Sheet 653- 502 13
Safety Precautions
1. QUALIFIED PERSONS. Access to the PureWave UPS
System must be restricted only to qualified persons. See
“Qualified Persons” on page 2.
2. SAFETY PROCEDURES. Always follow safe operating
procedures and rules.
3. PERSONAL PROTECTIVE EQUIPMENT. Always use
suitable protective equipment, such as rubber gloves,
rubber mats, hard hats, safety glasses, and flash
clothing, in accordance with safe operating procedures
and rules.
4. SAFETY LABELS. Do not remove or obscure any of
the “DANGER,” “WARNING,” “CAUTION,” or “NOTICE”
labels.
5. OPERATING MECHANISM AND BASE. The PureWave
UPS System contains fast-moving parts that can
severely injure fingers. Do not remove or disassemble
operating mechanism or circuit breakers or remove
access panels on the PureWave UPS System unless
directed by S&C Electric Company.
6. ENERGIZED COMPONENTS. Always consider all parts
live until de-energized, tested, and grounded.
7. GROUNDING.
For grounding purposes, the proceeding must be
followed:
• The PureWave UPS System PCS base must be
connected to a suitable earth ground or to a suitable
building ground for testing before energizing the unit
and at all times when energized.
8. MAINTAINING PROPER CLEARANCE. Always
maintain proper clearance from energized components.
DANGER
The S&C PureWave UPS System operates at high ac and dc voltages. Failure to
observe these precautions will result in serious personal injury or death.
Some of these precautions may differ from your company’s operating procedures and
rules. Where a discrepancy exists, follow your company’s operating procedures and rules.
Inspection After the PureWave UPS System is commissioned and the unit is online, inspection and
maintenance should be scheduled on a regular basis to ensure proper system operation.
Shipping and Handling

14 S&C Instruction Sheet 653-502
Enclosure
Configurations DANGER
Do not enter the system enclosure unless trained, certified, and authorized to do so by
S&C Electric Company. Physical entry into the PureWave UPS System should never be
attempted while the system is enabled or when the modules are online. Voltages up to
800 Vdc and 600 Vac should be expected under normal operating conditions. Dc voltage
is present even without the utility power connected.
The enclosure is meant to provide access for field troubleshooting purposes only when
the unit is properly grounded. Never, under any circumstances, open the enclosure doors
while it is online or has not been fully discharged and grounded. Failure to do this can
result in equipment damage, personal injury, or even death.
Figures 1 through 4 show the different enclosure congurations for the 250-kW, 500-kW,
750-kW, and 1000-kW PureWave UPS System enclosures, respectively
Components and Controls
Battery bay Control bay
Air conditioner Air-outlet vent hood
Air-inlet vent
Switchgear bay
LCD
Figure 1. Front and side view of the 250-kW PureWave UPS System.
Figure 2. Front and side view of the 500-kW PureWave UPS System.
Battery bay Control bayBattery bay
Air conditioner Air-outlet vent hood
Air-inlet vent
Switchgear bay
LCD

S&C Instruction Sheet 653- 502 15
Components and Controls
Air conditioner Air-outlet vent hoodAir-inlet vent hood
Battery bay Control bayBattery bay Battery bay
Switchgear bay
LCD
Figure 3. Front view of the 750-kW PureWave UPS System.
Battery bay Control bayBattery bay Battery bay Battery bay
Air conditioner Air-outlet vent hoodAir-inlet vent hood
Switchgear bay
LCD
Figure 4. Front view of the 1000-kW PureWave UPS System.

16 S&C Instruction Sheet 653-502
Components and Controls
Enclosure Bays The enclosure of the PureWave UPS System consists of three types of bays:
Battery bay—Each battery bay contains a 250-kW battery module and a power conver-
sion module (PCM). The PCM is located in its own compartment in the battery bay and
is comprised of one inverter module consisting of power-conversion electronics and con-
trols. The PCM is panel-mounted and supported by a welded and bolted steel structural
base. See Figure 5 for a view of the battery bay.
Power conversion
module (PCM)
Battery
Figure 5. View of the battery bay (with the door open).

S&C Instruction Sheet 653- 502 17
Components and Controls
Enclosure Bays −
continued
Switchgear bay—The switchgear bay houses the bypass switchgear circuit breakers, the
ENABLE/DISABLE switch, the RESET pushbutton switch, and user connections. For the
250-kW and 500-kW systems, the switchgear bay is located on the side of the system. For
the 750-kW and 1000-kW systems, the switchgear bay is located at the front of the system.
See Figures 6 and 7.
Input circuit breaker
Output circuit breaker
Bypass circuit breaker
Figure 6. View of the switchgear bay for the 250-kW and 500-kW PureWave UPS system.
Input circuit breaker
Output circuit breaker
Bypass circuit breaker
Figure 7. View of the switchgear bay for the 750-kW and 1000-kW PureWave UPS system.

18 S&C Instruction Sheet 653-502
Enclosure Bays −
continued
Control bay—The control bay houses the monitoring computer, control system, power
electronic switch (PES), and ac lter capacitor. In addition, an EMERGENCY DISABLE
mushroom switch and a RESET pushbutton are located behind the door. See Figure 8 for
a view of the control bay.
Components and Controls
Figure 8. View of the control bay.

S&C Instruction Sheet 653- 502 19
Figure 9. Lock bar at the bottom of a bay door.
Components and Controls
Doors To open a bay door, remove the padlock from the security cover located over the
center bolt. Three bolts (top, center, and bottom) secure the door closed. Loosen the three
bolts so they detach from the enclosure (the bolt will not completely detach from the
door). The door will now open. Once the door is opened approximately 90 degrees or 135
degrees, engage the lock-bar at the bottom of the door to prevent the door accidentally
closing. See Figure 9. To close a door, disengage the lock-bar by lifting it and returning it
to its storage location. Swing the door closed. Tighten the three bolts to secure the door
and install the padlock.
Lock bar

20 S&C Instruction Sheet 653-502
LCD screen Next to the control bay is the LCD screen, which displays information regarding the state
of the PureWave UPS System. See Figure 10. The bottom line of the LCD screen displays
the general messages as stated in Table 1.
Components and Controls
LCD screen
Figure 10. Location of the LCD screen.
Message Description
S&C PUREWAVE UPS Indicates the type of PureWave product
FWVER PQ001VvvvRrrr Indicates the version of firmware in the PureWave UPS System
CNFG CcccRrrr Indicates the configuration revision of the firmware running in the PureWave UPS System
Test Run Request Indicates the PureWave UPS System has received a manual Run request
Table 1. General Messages on LCD Screen
Air Control
and Ventilation
Components such as air conditioners and air-inlet and -outlet vent/vent hoods are used
to regulate the air inside the enclosure. Periodic maintenance is required to ensure the
air conditioners, air-inlet lter, vents, and hoods are clear from debris or obstructions
that can restrict air owing in and out of the PureWave UPS System enclosure. Refer
to the maintenance instruction sheet for detailed instructions for proper air ventilation
maintenance.
