Sandstorm SDW60B10 User manual

Instruction Manual
Dishwasher
SDW60B10

Contents
Unpacking...............................................................................................................................................................................................3
Product Overview................................................................................................................................................................................4
Internal View...........................................................................................................................................................................4
Rear View .................................................................................................................................................................................4
Control Overview ................................................................................................................................................................................5
Installation..............................................................................................................................................................................................6
Location....................................................................................................................................................................................6
Before Operating..................................................................................................................................................................................6
To open the door ..................................................................................................................................................................6
To close the door...................................................................................................................................................................6
Adding the Detergent Powder and Tablet..................................................................................................................7
Adding of Rinse Aid..............................................................................................................................................................8
Adjusting Rinse Aid Reservoir..........................................................................................................................................8
Adding of Salt.........................................................................................................................................................................9
Adjusting of Salt Consumption .......................................................................................................................................9
Loading the Dishwasher..................................................................................................................................................................10
Before loading the dishwasher......................................................................................................................................10
Upper Basket ........................................................................................................................................................................10
Adjusting the Upper Basket............................................................................................................................................10
Hinged Cup Rack.................................................................................................................................................................11
Loading the Upper Basket for 8 Place Settings .......................................................................................................11
Lower Basket.........................................................................................................................................................................11
Hinged Spikes .....................................................................................................................................................................11
Loading the Lower Basket for 8 Place Settings........................................................................................................12
Cutlery Basket ......................................................................................................................................................................12
Wash Cycle Table ................................................................................................................................................................................13
Starting a Wash Cycle .......................................................................................................................................................................14
Changing a Programme ..................................................................................................................................................................14
At the End of a Programme............................................................................................................................................................14
Switching off the Dishwasher........................................................................................................................................................15
Unloading the Dishwasher.............................................................................................................................................................15
Delay Start ............................................................................................................................................................................................16
Half Load ...............................................................................................................................................................................................16
Cleaning After Use.............................................................................................................................................................................16
External Care ........................................................................................................................................................................16
Frost Precaution..................................................................................................................................................................................18
Maintenance After Prolonged Period of Non-Operation ...................................................................................................18
Moving the Dishwasher...................................................................................................................................................................19
Helpful Tips and Guides ................................................................................................................................................................. 20
Fault Code............................................................................................................................................................................. 20
Technical Problems ........................................................................................................................................................... 20
Specification ....................................................................................................................................................................................... 22
Safety Warnings................................................................................................................................................................................. 23
Disposal of Dishwasher................................................................................................................................................................... 25
Disposal of Packing Material......................................................................................................................................................... 25

GB-3
Before UseOperationSpecificationSafety Warnings Cleaning and Maintenance
Accessories
part number 673005400045
Congratulations on the purchase of your new Sandstrøm Dishwasher.
We recommend that you spend some time to read this Instruction Manual in order to fully
understand how to install and operate it.
Read all the safety instructions carefully before use and keep this instruction manual for future
reference.
Unpacking
Remove all packaging from the dishwasher. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Measuring cup X 1
60ml (approx)
part number 673006200004
Detergent measuring spoon x 1
1 full spoon = 20g (approx.)
part number 673002200079
Water supply
hose X 1
U-shape hose holder X 1
part number 673006200003
Upper Basket x 1
Cutlery Basket x 1
part number 673002200099
The Main Unit - Front View
Instruction
manual X 1
part number
675000608529-V2
Installation guide
X 1
part number
675000608540
• This product has been wet tested to
ensure correct operation. As a result
some water may remain inside the
unit. This is normal and safe. Remove
any water droplets from the exterior
if necessary.
Lower Basket x 1
20ml
1
2

GB-4
Before Use Cleaning and Maintenance Specification
Operation Safety Warnings
Product Overview
Internal View
Rear View
Water Inlet
Mains Cable
Drain Hose
Drain Oulet
Upper
Basket
Lower
Basket
Rinse Aid
Reservoir
Detergent
Dispenser
Salt Reservoir
Cup Rack
Filtering
System
Spray Arms

GB-5
Before UseOperationSpecificationSafety Warnings Cleaning and Maintenance
On
Off
PROG
Control Panel Overview
1. On/O Button
• To turn the dishwasher on and o.
Power on light
• Illuminates when On/O button is pressed.
3. Display Window
• Shows the selected programme time, time delay and error codes.
2. Delay Start Button
• Press to preset the wash timer and delay the starting time by up to 24 hours.
• Each press of this button increases the delay start time by 1 hour intervals.
4. Programme Button
• Press to select your required washing programme.
5. Half Load Button
• Press to button to select the half load washing cycle.
Half load indicator light
• Illuminates when the half load washing cycle is selected.
• Only the upper spray arm will be in function.
• Load the soiled dishes in the upper basket.
1 2 3 4 5
1
2
6
6. Exterior Display Window
• Shows the selected programme, programme time, time delay and error codes.

GB-6
Before Use Cleaning and Maintenance Specification
Operation Safety Warnings
Installation
Location
When selecting a position for your freestanding dishwasher you should make sure the installation surface
is flat and firm, and the room is well ventilated. Avoid locating your dishwasher near a heat source, eg.
cooker, boiler or radiator. Extreme cold ambient temperatures may also cause the appliance not to perform
properly. This dishwasher is not designed for use in a garage or outdoor installation.
Do not drape the dishwasher with any covering. When installing, ensure that free space is left at the sides.
Please refer to the seperate Installation Guide for detail installation requirements and process.
• We recommend that you contact a qualified technician for the installation. You should
only try to install the dishwasher yourself if you believe that you are qualified to do so.
• All parts removed must be saved to do the reinstallation in the future. Ensure the
dishwasher is unplugged and empty. We recommend that 2 people handle the
dishwasher during assembly.
Before Operating
To open the door
• Pull the door handle to open the door.
• If the door is opened during operation, all functions are automatically interruped.
To close the door
• After loading the dishes, push the baskets fully into the dishwasher.
• Life the door upwards and push until it clicks into position.
• Do not slam the dishwasher door.
• When purchasing new crockery and cutlery, please make sure they are dishwasher-proof.
Some items are not suitable for dishwashers, for examples:
• Wooden cutlery and crockery or items with wooden parts may discolour and
fade. The glue used in these items is not dishwasher-proof either, and the
wooden handles may come loose after being washed in a dishwasher.
• Craft items, antiques, valuables vases and decorative glassware are also not
suitable for dishwashers.
• Plastic items (e.g. tupperware) which are not heat resistant may melt or lose
shape due to the high temperatures in the dishwasher.
• Copper, brass, tin and aluminium items may discolour or become matt.

GB-7
Before UseOperationSpecificationSafety Warnings Cleaning and Maintenance
• Clouding may occur on glasses and delicate glassware after frequent washing. Do not
wash delicate glassware, or glassware containing lead crystal in a dishwasher. Please wash
delicate glassware by hand instead.
• Silver and aluminium parts have a tendancy to discolour during washing. Residues
like egg white, egg yolk and mustartd often cause discolouring and staining on silver.
Therefore, please clean the residues from silver immediately after use.
Adding the Detergent Powder and Tablet
Only use detergents specifically designed for use in dishwashers. To be more environmentally friendly,
please use no more than the correct amount of detergent. Fill the detergent dispenser with detergent
power or tablet.
Please follow the steps below to fill the detergent dispenser.
1. Push the button on the lid of the detergent dispenser in
the direction of the arrow until the flap springs open.
2. Fill the detergent dispenser with detergent powder to both
main wash detergent chamber and pre-wash detergent
chamber, or insert the detergent tablet to the main
detergent chamber. The marking indicates the filling level.
TIP: All programmes with pre-wash need an additional
detergent dosage that myst be placed in the pre-wash
detergent chamber. Please refer to the the wash cycle table.
This detergent will take effect during the pre-wash phase.
3. Close the lid firmly so that it clicks into place.
• WARNING! Keep out of the reach of children.
• Irritating to eyes. Avoid contact with eyes.
• In case of contact with eyes, rinse immediately with plenty of water and
seek medical advice.
• If swallowed, seek medical advice immediately.
Irritant

GB-8
Before Use Cleaning and Maintenance Specification
Operation Safety Warnings
Adjusting Rinse Aid Reservoir
The rinse aid reservoir has six settings. Both the recommended setting and the factory setting is "4". If the
dishes are not drying properly or are spotted, adjust the dial to the next higher number until your dishes
are spot-free.
• If the water hardness in your area is soft, you may not need rinse aid as it may cause white
film to develop on your dishes.
• If there are some rinse aid residue left in the washing compartment or your dishes, please
turn the rinse aid dispenser dial to 1.
• If you select to use detergent tablet, you do not need to add rinse aid into the rinse aid
reservoir.
Adding of Rinse Aid
Rinse aid helps to ensure water does not cling and leave marks on crockery during the drying phase and
helps crockery dry faster after it has been washed. Only pour rinse aid that is for domestic dishwashers into
the reservoir. This model is designed to use liquid rinse aid only.
Please follow the steps below to pour the rinse aid into the storage reservoir, and the amount will dispense
automatically.
1. Turn the cap and open. When the cap open marking
is aligned, you may lift the cap up.
2. Pour the rinse aid until the rinse aid indicator turns
completely black in colour and close the cap.
3. Be careful not to overfill the reservoir. Wipe up any
spills.
• Rinse aid warning light will illuminate when the reservoir is running out of rinse aid and
requires refilling.
• Alternatively, you can judge the amount of rinse aid by checking the rinse aid indicator
light next to the reservoirs cap when the indicator is black, it means it is full. When it is
clear, it means it is almost empty.

GB-9
Before UseOperationSpecificationSafety Warnings Cleaning and Maintenance
Adding of Salt
If the water in your area is hard, deposits will form on your dishes and
utensils. As such, this appliance contains a salt reservoir for you to reduce
the hardness of the water.
Please follow the steps below to pour the salt into the salt reservoir and to
correspond to the water hardness level in your area.
1. Remove the lower basket and unscrew the reservoir cap.
2. Fill the reservoir with approximately 500ml of water (first use only).
3. Place the funnel provided over the salt reservoir. Pour in approximately
1.2kg of dishwasher salt depending on the brand used.
4. Clean any excess salt from around the reservoir opening and then
screw the cap on again firmly.
5. Run the "Rapid" wash programme immediately (without any crockery
in the dishwasher) to remove any traces of salt from the compartment.
• The salt refill warning indicator on the control panel will illuminate
when the reservoir is running out of sale and requires refilling.
• The salt refill warning indicator will cease to illuminate within a
few days, depending on how quickly the salt dissolves.
• If you select to use detergent tablet, you do not need to add rinse
aid into the rinse aid reservoir.
Adjusting of Salt Consumption
To optimise and customise the level of salt consumption, please follow the
steps below to adjust the salt consumption.
1. Remove the lower basket and unscrew the reservoir cap.
2. There is an arrow-shaped indicator in the reservoir, which allows you
to turn. You may turn it to the "-" or "+" settings based on the water
hardness in your area.
It is recommended that adjustments should be made in accordance with
the following chart.
WATER HARDNESS Selector
Position
Salt Consumption
(gram/cycle)
Auto nomy
(cycle/1.2kg)
˚dh ˚fh ˚Clark mmol/l
0-8 0-14 0-10 0-1.4 / 0 /
8-22 14-39 10-28 1.4-3.9 - 20 60
22-45 39-80 28-56 3.9-8 Mid 40 30
>45 >80 >56 >8 + 60 20
• 1 ˚dh (German degree) = 1.25mmol/l
• 1 ˚fh (French degree) = 0.178mmol/l
• 1 ˚Clark (British degree) = 1.78mmol/l
OPEN
Turn

GB-10
Before Use Cleaning and Maintenance Specification
Operation Safety Warnings
• For safety reasons, do not operate the dishwasher without the dishwasher basket in
place.
Upper Basket
We recommend using the upper basket for small and lightweight items such as
cups saucers, glasses, dessert bowls, etc. Shallow pans or casserole dishes can
aslo be placed in the dishwasher basket. Long items such as soup ladles, mixing
spoons and long knives should be placed lying down across the front of the
upper basket.
Adjusting the Upper Basket
More space can be created for large items on the upper or lower baskets by adjusting the height of the
upper basket. Ensure that the rail stop is placed back properly after the height adjustment.
Loading the Dishwasher
Before loading the dishwasher
In general, please observe the following notes before loading your cutlery and crockery in the basket.
• Remove lipstick stains and any food residues from crockery and dishes. Rinse if necessary.
• Dishes and cutlery must not lay inside one another or cover each other.
• Loading your cutlery and crockery so that water can access all surfaces.
• Ensure all items are securely positioned.
• Hollow items such as cups, glasses, pans, etc. must be placed upside down in the basket.
• Wide based items should be placed at an angle so that water can run off them freely. The
spray arms must not be blocked by items which are too tall or hang through the baskets.
If in doubt, test for free movement by manually torating the spray arm.
• Ensure that small items cannot fall through the holders in the basket.
• CAUTION: Do not wash items soiled with ash, sand, wax, lubricating grease or paint in the
dishwasher. These items can cause damage to the dishwasher. Ash does not dissolve and
can distibute in the dishwasher.
Lift
Remove the Stop
Slide the Basket out from
the Rail
