S&T kontron KSwitch D3 User manual


USER GUIDE
www.kontron.com
KSwitch D3 Unmanaged Fast Ethernet
Switch
Doc. Preliminary User Guide, Rev. 0.9
Doc. ID: 1068-1422

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 2
This page has been intentionally left blank

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 3

KSWITCH D3 UNMANAGED
FAST ETHERNET SWITCH – USER
GUIDE
Disclaimer
Kontron would like to point out that the information contained in this user guide may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee
on the part of Kontron with respect to technical processes described in the user guide or any product characteristics
set out in the user guide. Kontron assumes no responsibility or liability for the use of the described product(s),
conveys no license or title under any patent, copyright or mask work rights to these products and makes no
representations or warranties that these products are free from patent, copyright or mask work right infringement
unless otherwise specified. Applications that are described in this user guide are for illustration purposes only.
Kontron makes no representation or warranty that such application will be suitable for the specified use without
further testing or modification. Kontron expressly informs the user that this user guide only contains a general
description of processes and instructions which may not be applicable in every individual case. In cases of doubt,
please contact Kontron.
This user guide is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this user guide is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products
and thus this user guide only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2021 by Kontron Europe GmbH
Kontron Europe GmbH
Gutenbergstraße 2
85737 Ismaning
Germany
www.kontron.com

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 4
Intended Use
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE
OR RESALE FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR
COMMUNICATION SYSTEMS FOR AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE
SUPPORT OR LIFE SUSTAINING APPLICATIONS, WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A
HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE PERFORMANCE, OR IN WHICH THE FAILURE OF
PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR SEVERE PHYSICAL OR
ENVIRONMENTAL DAMAGE (COLLECTIVELY, “HIGH RISK APPLICATIONS”).
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless otherwise
stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities and cannot
therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or for resale as
device in High Risk Applications. All application and safety related information in this document (including application
descriptions, suggested safety measures, suggested Kontron products, and other materials) is provided for reference
only.

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 5
Revision History
Revision Brief Description of Changes Date of Issue Author/
Editor
0.9 Preliminary version 2021-April-21 CW
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order
Terms & Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.
Customer Support
Find Kontron contacts by visiting: https://www.kontron.com/support-and-services/kontron-europe-and-
asia/support/contact-support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths into
a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product
expertise coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace of
mind to build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron
training academy, and more visit https://www.kontron.com/support-and-services/kontron-europe-and-
asia/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron Support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 6
Symbols
The following symbols may be used in this user guide
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
NOTICE indicates a property damage message.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60
V) when touching
products or parts of products
. Failure to observe the precautions indicated and/or
prescribed by the law may endanger your life/health and/or result in damage to your
material.
ESD Sensitive Device!
This symbol and title informs
that the electronic boards and their components are sensitive
to static electricity. Care must therefore
be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
HOT Surface!
Do NOT touch! Allow to cool before servicing.
Laser!
This symbol informs of the risk of exposure to laser beam and light emitting devices (LEDs)
from an electrical device. Eye protection per manufacturer notice shall review before
servicing.
This symbol indicates general information about the product and the user guide.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

KSwitch D3 Unmanaged Fast Ethernet Switch – Preliminary User Guide, Rev. 0.9
www.kontron.com
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its
compliance with electrical safety requirements. It was also designed for a long fault-free life. However, the life
expectancy of your product can be drastically reduced by improper treatment during unpacking and installation.
Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are
requested to conform with the following guidelines.
High Voltage Safety Instructions
As a precaution and in case of danger, the power connector must be easily accessible. The power connector is the
product’s main disconnect device.
Warning
All operations on this product must be carried out by sufficiently skilled personnel only.
Electric Shock!
Before installing a non hot-swappable Kontron product into a system always ensure that
your mains power is switched off. This also applies to the installation of piggybacks. Serious
electrical shock hazards can exist during all installation, repair, and maintenance operations
on this product. Therefore, always unplug the power cable and any other cables which
provide external voltages before performing any work on this product.
Earth ground connection to vehicle’s chassis or a central grounding point shall remain
connected. The earth ground cable shall be the last cable to be disconnected or the first
cable to be connected when performing installation or removal procedures on this product.
Optical Safety Instructions
Laser!
This symbol inform of the risk of exposure to laser beam and light emitting devices (LEDs)
from an electrical device. Eye protection per manufacturer notice shall review before
servicing.
When a connector is removed during installation, testing, or servicing, or when an energized fiber is broken, a risk of
ocular exposure to optical energy that may be potentially hazardous occurs, depending on the laser output power.
The primary hazards of exposure to laser radiation from an optical-fiber communication system are:
Damage to the eye by accidental exposure to a beam emitted by a laser source
Damage to the eye from viewing a connector attached to a broken fiber or an energized fiber

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 8
Special Handling and Unpacking Instruction
ESD Sensitive Device!
Electronic boards and their components are sensitive to static electricity. Therefore, care
must be taken during all handling operations and inspections of this product, in order to
ensure product integrity at all times.
Handling and operation of the product is permitted only for trained personnel within a work
place that is access controlled. Follow the “General Safety Instructions” supplied with the
product.
Do not handle this product out of its protective enclosure while it is not used for operational purposes unless it is
otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where a safe work station is not
guaranteed, it is important for the user to be electrically discharged before touching the product with his/her hands
or tools. This is most easily done by touching a metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggybacks, ROM devices,
jumper settings etc. If the product contains batteries for RTC or memory backup, ensure that the product is not placed
on conductive surfaces, including anti-static plastics or sponges. They can cause short circuits and damage the
batteries or conductive circuits on the product.
Lithium Battery Precautions
If your product is equipped with a lithium battery, take the following precautions when replacing the battery.
Danger of explosion if the battery is replaced incorrectly.
Replace only with same or equivalent battery type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or
modifications to the product, that are not explicitly approved by Kontron and described in this user guide or received
from Kontron Support as a special handling instruction, will void your warranty.
This product should only be installed in or connected to systems that fulfill all necessary technical and specific
environmental requirements. This also applies to the operational temperature range of the specific board version
that must not be exceeded. If batteries are present, their temperature restrictions must be taken into account.
In performing all necessary installation and application operations, only follow the instructions supplied by the
present user guide.
Keep all the original packaging material for future storage or warranty shipments. If it is necessary to store or ship
the product then re-pack it in the same manner as it was delivered.
Special care is necessary when handling or unpacking the product. See Special Handling and Unpacking Instruction.

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 9
Quality and Environmental Management
Kontron aims to deliver reliable high-end products designed and built for quality, and aims to complying with
environmental laws, regulations, and other environmentally oriented requirements. For more information regarding
Kontron’s quality and environmental responsibilities, visit http://www.kontron.com/about-kontron/corporate-
responsibility/quality-management.
Disposal and Recycling
Kontron’s products are manufactured to satisfy environmental protection requirements where possible. Many of the
components used are capable of being recycled. Final disposal of this product after its service life must be
accomplished in accordance with applicable country, state, or local laws or regulations.
WEEE Compliance
The Waste Electrical and Electronic Equipment (WEEE) Directive aims to:
Reduce waste arising from electrical and electronic equipment (EEE)
Make producers of EEE responsible for the environmental impact of their products, especially when the product
become waste
Encourage separate collection and subsequent treatment, reuse, recovery, recycling and sound environmental
disposal of EEE
Improve the environmental performance of all those involved during the lifecycle of EEE
Environmental protection is a high priority with Kontron.
Kontron follows the WEEE directive
You are encouraged to return our products for proper disposal.

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 10
Table of Contents
Symbols.................................................................................................................................................................................................................6
For Your Safety ...................................................................................................................................................................................................7
High Voltage Safety Instructions ..................................................................................................................................................................7
Optical Safety Instructions..............................................................................................................................................................................7
Special Handling and Unpacking Instruction ........................................................................................................................................... 8
Lithium Battery Precautions.......................................................................................................................................................................... 8
General Instructions on Usage..................................................................................................................................................................... 8
Quality and Environmental Management.................................................................................................................................................9
Disposal and Recycling.....................................................................................................................................................................................9
WEEE Compliance...............................................................................................................................................................................................9
Table of Contents.............................................................................................................................................................................................10
List of Tables ......................................................................................................................................................................................................11
List of Figures.....................................................................................................................................................................................................11
1/ Introduction .........................................................................................................................................................................................12
2/ General Safety Instructions ...........................................................................................................................................................13
2.1. Laser ..............................................................................................................................................................................................................14
2.2. Electrostatic Discharge (ESD) ..............................................................................................................................................................14
2.3. Grounding Methods .................................................................................................................................................................................14
3/ Shipment and Packaging.................................................................................................................................................................15
3.1. Packaging.....................................................................................................................................................................................................15
3.2. Unpacking....................................................................................................................................................................................................15
3.3. Scope of Delivery......................................................................................................................................................................................15
3.4. Accessories ................................................................................................................................................................................................15
3.5. Product Identification Type Label .......................................................................................................................................................17
4/ Features ................................................................................................................................................................................................18
4.1. Faceplate Features...................................................................................................................................................................................19
4.1.1. RJ45 Copper Ethernet Ports................................................................................................................................................................19
4.1.2. SFP Fiber Ethernet Ports....................................................................................................................................................................20
4.1.3. Indicator LEDs (P1, P2, ALM and Ethernet)....................................................................................................................................21
4.1.4. DC Terminal Block (16-port) ............................................................................................................................................................. 22
4.1.5. DC Terminal Block Alarm Relay Contacts (16-port) ..................................................................................................................23
4.1.6. Ground Connector (16-port).............................................................................................................................................................. 23
4.2. Bottom Side Features ............................................................................................................................................................................24
4.2.1. DC Terminal Block Power Contacts (10-port) .............................................................................................................................24
4.2.2. DC Terminal Block Alarm Relay Contacts (10-port) ................................................................................................................. 25
4.2.3. Ground Connector (10-port).............................................................................................................................................................26
4.3. Rear Side Features.................................................................................................................................................................................. 27
5/ Mounting..............................................................................................................................................................................................28
5.1. DIN-Rail Mounting....................................................................................................................................................................................28
5.2. DIN-Rail Removal ....................................................................................................................................................................................28
5.3. Wall Mounting ..........................................................................................................................................................................................29
6/ Starting Up...........................................................................................................................................................................................30
7/ Technical Specification....................................................................................................................................................................31
7.1. Hardware Specification...........................................................................................................................................................................31
7.2. Environmental Specification................................................................................................................................................................ 32
7.3. Certifications.............................................................................................................................................................................................32

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 11
7.4. Mechanical Specification ......................................................................................................................................................................32
7.5. Power Specification ................................................................................................................................................................................34
8/ Maintenance ....................................................................................................................................................................................... 35
9/ Technical Support.............................................................................................................................................................................36
9.1. Returning Defective Merchandise......................................................................................................................................................36
10/ Warranty.............................................................................................................................................................................................. 37
10.1. Limitation/Exemption from Warranty Obligation....................................................................................................................... 37
List of Acronyms .............................................................................................................................................................................................38
About Kontron ..................................................................................................................................................................................................39
List of Tables
Table 1: Scope of Delivery ..............................................................................................................................................................................15
Table 2: List of Accessories...........................................................................................................................................................................15
Table 3: Ethernet Ports (RJ45 copper) Connector Pin Assignment .................................................................................................19
Table 4: Indicator LEDs...................................................................................................................................................................................21
Table 5: Wall Mount Plates ..........................................................................................................................................................................29
Table 6: Hardware Specification .................................................................................................................................................................31
Table 7: Environmental Specification ....................................................................................................................................................... 32
Table 8: Certification Compliance ..............................................................................................................................................................32
Table 9: Mechanical Specification .............................................................................................................................................................32
Table 10: Electrical Specification................................................................................................................................................................34
Table 11: List of Acronyms ............................................................................................................................................................................38
List of Figures
Figure 1: KSwitch Type Label.........................................................................................................................................................................17
Figure 2: KSwitch D3 UF Unmanaged Fast Ethernet Switch ..............................................................................................................18
Figure 3: RJ45 Copper (10/100 Mbps) Ethernet ports (10-port and 16-port) ...............................................................................19
Figure 4: SFP Ports (10-port).......................................................................................................................................................................20
Figure 5: Indicator LED (10-port and 16-port).........................................................................................................................................21
Figure 6: Power Contacts (16-port)...........................................................................................................................................................22
Figure 7: Alarm Relay Contacts (16-port)................................................................................................................................................23
Figure 8: Ground Connector (16-port) ......................................................................................................................................................23
Figure 9: Power Contacts (10-port)...........................................................................................................................................................24
Figure 10: Alarm Relay Contacts (10-port).............................................................................................................................................. 25
Figure 11: Ground Connector (10-port) .....................................................................................................................................................26
Figure 12: Rear Side View (10-port and 16-port) ................................................................................................................................... 27
Figure 13: DIN-Rail Clip...................................................................................................................................................................................28
Figure 14: Wall Mount Plate.........................................................................................................................................................................29
Figure 15: Mechanical Dimensions 10-port.............................................................................................................................................32
Figure 16: Mechanical Dimensions 16-port............................................................................................................................................. 33

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 12
1/ Introduction
This user guide focuses on describing the special features of the Kontron KSwitch D3 UF Unmanaged Fast Industrial
Switch series referred to as switch within this user guide. To ensure you have the latest version of this user guide,
visit Kontron’s KSwitch Industrial Ethernet Switches, at https://www.kontron.com/products/systems/ethernet-
solutions/.
This user guide provides an overview of the switch’s features and available accessories, to help users set up, mount,
operate and trouble shoot the switch properly.
For safety reasons Kontron recommends new users to study the instructions within this user guide before switching
on the power.
This preliminary version of the user guide may contain information that is subject to change.

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 13
2/ General Safety Instructions
Please read this passage carefully and take careful note of the instructions, which have been compiled for your safety
and to ensure to apply in accordance with intended regulations. If the following general safety instructions are not
observed, it could lead to injuries to the operator and/or damage of the product; in cases of non-observance of the
instructions Kontron Europe is exempt from accident liability, this also applies during the warranty period.
The product has been built and tested according to the basic safety requirements for low voltage (LVD) applications
and has left the manufacturer in safety-related, flawless condition. To maintain this condition and to also ensure safe
operation, the operator must not only observe the correct operating conditions for the product but also the following
general safety instructions:
The product must be used as specified in the product documentation, in which the instructions for safety for the
product and for the operator are described. These contain guidelines for setting up, installation and assembly,
maintenance, transport or storage.
The on-site electrical installation must meet the requirements of the country's specific local regulations.
If a power cable comes with the product, only this cable should be used. Do not use an extension cable to connect
the product.
To guarantee that sufficient air circulation is available to cool the product, please ensure that the ventilation
openings are not covered or blocked. If a filter mat is provided, this should be cleaned regularly. Do not place the
product close to heat sources or damp places. Make sure the product is well ventilated.
Only connect the product to an external power supply providing the voltage type (AC or DC) and the input power
(max. current) specified on the Kontron Product Label and meeting the requirements of the Limited Power Source
(LPS) and Power Source (PS2) of UL/IEC 62368-1 .
Only products or parts that meet the requirements for Power Source (PS1) of UL/IEC 62368-1 may be connected
to the product’s available interfaces (I/O).
Before opening the product, make sure that the product is disconnected from the mains.
Switching off the product by its power button does not disconnect it from the mains. Complete disconnection is
only possible if the power cable is removed from the wall plug or from the product. Ensure that there is free and
easy access to enable disconnection.
The product may only be opened for the insertion or removal of add-on cards (depending on the configuration of
the product). This may only be carried out by qualified operators.
If extensions are being carried out, the following must be observed:
all effective legal regulations and all technical data are adhered to
the power consumption of any add-on card does not exceed the specified limitations
the current consumption of the product does not exceed the value stated on the product label.
Only original accessories that have been approved by Kontron Europe can be used.
Please note: safe operation is no longer possible when any of the following applies:
the product has visible damages or
the product is no longer functioning
In this case the product must be switched off and it must be ensured that the product can no longer be
operated.
Handling and operation of the product is permitted only for trained personnel within a work place that is access
controlled.
CAUTION: Risk of explosion if the battery is replaced incorrectly (short-circuited, reverse-poled, wrong battery
type). Dispose of used batteries according to the manufacturer’s instructions.
This product is not suitable for use in locations where children are likely to be present
Additional Safety Instructions for DC Power Supply Circuits
To guarantee safe operation, please observe that:
the external DC power supply must meet the criteria for LPS and PS2 (UL/IEC 62368-1)
no cables or parts without insulation in electrical circuits with dangerous voltage or power should be
touched directly or indirectly
a reliable protective earthing connection is provided

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 14
a suitable, easily accessible disconnecting device is used in the application (e.g. overcurrent protective
device), if the product itself is not disconnectable
a disconnect device, if provided in or as part of the product, shall disconnect both poles simultaneously
interconnecting power circuits of different products cause no electrical hazards
A sufficient dimensioning of the power cable wires must be selected – according to the maximum electrical
specifications on the product label – as stipulated by EN62368-1 or VDE0100 or EN60204 or UL61010-1
regulations.
2.1. Laser
Laser!
When a connector is removed, or when an energized fiber is broken, a risk of ocular exposure
to optical energy that may be potentially hazardous occurs, depending on the laser output
power.
Primary hazards of exposure to laser radiation from an optical-fiber communication system are:
•damage to the eye by accidental exposure to a beam emitted by a laser source
•damage to the eye from viewing a connector attached to a broken fiber or an energized
fiber
2.2. Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can destroy static-sensitive devices or micro-
circuitry.
Therefore, proper packaging and grounding techniques are necessary precautions to prevent damage. Always take
the following precautions:
1. Transport ESD sensitive parts in ESD safe containers such as boxes or bags, until they arrive at an ESD safe
workplace.
2. Always be properly grounded when touching sensitive components, or assembly.
3. Store ESD sensitive components in protective packaging or on antistatic mats.
2.3. Grounding Methods
By adhering to the guidelines below, electrostatic damage to the switch may be avoided:
1. Cover workstations with approved antistatic material/mat. Always wear a wrist strap connected to workplace or
heel straps, and use properly grounded tools and equipment.
2. Use properly grounded tools and equipment such as field service tools that are conductive
3. Always handle ESD sensitive components by their edge or by their casing.
4. Avoid contact with pins, leads, or circuitry.
5. Switch off power and input signals before inserting and removing connectors or connecting test equipment.
6. Keep work area free of non-conductive materials such as ordinary plastic assembly aids and Styrofoam.

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 15
3/ Shipment and Packaging
3.1. Packaging
All parts are delivered together in a switch specific cardboard package designed to provide adequate protection to
absorb shock. Kontron recommends keeping the packaging to store or transport the switch.
3.2. Unpacking
To unpack the switch, perform the following:
1. Remove packaging.
2. Do not discard the original packaging. Keep the original packaging for future transportation or storage.
3. Check the delivery for completeness by comparing the delivery with the original order.
4. Keep the associated paperwork. It contains important information for handling the switch.
5. Check the contents for visible shipping damage.
If you notice any shipping damage or inconsistencies between the contents and the original order, contact Kontron for
help and information.
3.3. Scope of Delivery
Check that your delivery is complete, and contains the items listed below. If you discover damaged or missing items,
contact your dealer.
Table 1: Scope of Delivery
Delivery Quantity Description
KSwitch D3 UF Ethernet Switch 1 Unmanaged, Fast industrial Ethernet switch
DC Terminal Block 1 Power connector
DIN-Rail Kit 1 DIN-Rail clip, 3x screws
General Safety Instructions Sheet 1 General safety instructions for set up and operation
3.4. Accessories
Table 2: List of Accessories
Product Name / Product Group Description
Mounting Kits
RK2U 19” Rack Mount Kit 2U
Enables DIN-Rail Switch to be installed in a 2U rack

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 16
Product Name / Product Group Description
RK4U 19” Rack Mount Kit 4U
Enables DIN-Rail Switch to be installed in a 4U rack
WK25 Wall Mount kit
2x wall mount plates and screws
SFP Modules
EN-SFP-F-M002-T 100 Megabit SFP Modules 100BaseF(X)ps multi-mode transceiver 2km
(850nm), wide operating Temp. -40~85
℃
EN-SFP-F-M004-T 100 Megabit SFP Modules 100BaseF(X)ps multi-mode transceiver 5km
(1310nm), wide operating Temp. -40~85
℃
EN-SFP-F-S030-T 100 Megabit SFP Modules 100BaseF(X)ps single mode transceiver 30km
(1310nm), wide operating Temp. -40~85
℃
EN-SFP-F-S060-T 100 Megabit SFP Modules 100BaseF(X)ps single mode transceiver 60km
(1310nm), wide operating Temp. -40~85
℃
EN-SFP-F-S080-T 100 Megabit SFP Modules 100BaseF(X)ps single mode transceiver 80km
(1550nm), wide operating Temp. -40~85
℃
EN-SFP-F-S100-T 100 Megabit SFP Modules 100BaseF(X)ps single mode transceiver 100km
(1550nm), wide operating Temp. -40~85
℃
EN-SFP-F-S120-T 100 Megabit SFP Modules 100BaseF(X)ps single mode transceiver 120km
(1550nm), wide operating Temp. -40~85
℃
Power Supply/ Adapter
230 VAC to DC Power Adaptor

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 17
3.5. Product Identification Type Label
Figure 1: KSwitch Type Label
1 Model full name
2Series name
3Part Number(PN) with bar code
4Revision
5Serial Number (SN) with barcode
6 Production date
7Electrical Specification
8QI code
9Certification Information
1
7
3
4
5
6
8
2
9

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 18
4/ Features
Before working with the switch, Kontron recommends users to take a few minutes to learn about the switch’s various
features and to observe the instructions and warning notices within this user guide.
The Kontron KSwitch D3 UF unmanaged industrial Ethernet switch with up to 24 fast Ethernet ports providing easy to
use plug-n-play connectivity. Copper and fiber optics ports are available.
Figure 2: KSwitch D3 UF Unmanaged Fast Ethernet Switch
Key features are:
Up to 16-ports (option for 24-ports on request)
Copper and fiber connectivity
Layer 2 Line-speed switching fabric, non-blocking
2KV surge immunity on RJ45 copper port
Flexible mounting options:
DIN-Rail
Wall mount
IP 30 protection
Rugged fanless design
Dual power input (12 VDC to 58 VDC) and reverse power protection
-40 ºC to 75ºC operating temperature

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 19
4.1. Faceplate Features
4.1.1. RJ45 Copper Ethernet Ports
To connect to a PC use a straight-through or a cross-over Ethernet cable and when connecting to an Ethernet device
use UTP (Unshielded Twisted Pair) or STP (Shielded Twisted Pair) Ethernet cables.
The switch supports eight 10/100 Mbps copper RJ45 Ethernet ports and up to two 100 Base fiber SFP slots on the
10-port variant and 16 copper 10/100 Mbps RJ45 Ethernet ports on the 16-port variant.
Figure 3: RJ45 Copper (10/100 Mbps) Ethernet ports (10-port and 16-port)
Table 3: Ethernet Ports (RJ45 copper) Connector Pin Assignment
Pin Signal
1,2 T/Rx+,T/Rx-
3,6 R/Tx+,R/Tx-
For further copper/fiber port combination, see Chapter 7.1/: Hardware Specification.

KSwitch D3 Unmanaged Fast Ethernet Switch - Preliminary User Guide, Rev. 0.9
www.kontron.com // 20
4.1.2. SFP Fiber Ethernet Ports
Up to two 100 Base fiber SFP slots are available on the 10-port variant.
For each fiber port there is a transmit (TX) and receive (RX) signal. When making fiber optic connections ensure that
the transmit (TX) port of the switch connects to the receive (RX) port of the other device, and the receive (RX) port of
the switch connects to the transmit (TX) port of the other device.
Figure 4: SFP Ports (10-port)
Laser!
To avoid ocular exposure and a possible eye injury:
•Do not attempt to view optical connectors that might be emitting laser energy
•Do not power up the laser without connecting the laser to the optical fiber and
putting the cover in position, as laser outputs will emit infrared laser light at this
point.
For further copper/fiber port combination, see Chapter 7.1/: Hardware Specification.
