Sangean FMT-02 User manual
Version 1
FMT-02
中文
GB
01
GB
F
E
NL
D
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by SANGEAN ELECTRONICS INC. is under license.
Important safety instructions
1. Follow the operating instructions provided and take note of any warnings.
2. If you do not follow the operating instructions provided, it may compromise the safety of your
product and this may invalidate the warranty.
3. Only use the supplied 5V cigarette type car power adaptor with your product.
4. Do not install your product in a way that may interfere with the safe operation of the vehicle, or
affect the deployment of air bags or other safety items. Do not install cables and wires near the
steering wheel.
5. Do not place your product on or near sources of your vehicle's heat or ventilation.
6. Do not use your product in a way that may cause careless driving or improper control of your
vehicle.
7. Keep your product dry and only clean with a dry cloth.
8. Donotexposeyourproducttonakedames.
9. Do not use your product in extremely hot or cold temperature.
10. If you need to connect your product to the rear of your vehicle's head unit, remove any power before
you start to install your product. When you have safely installed your product, you can reconnect the
power. See your vehicle's owner's manual for more information.
11. Do not use the product if it is damaged.
12. Product repairs should only be carried out by authorized personnel.
13. For your driving safety, do not operate your product while driving.
14. SANGEAN is not reliable for any damage caused by usage of the product while driving.
02
GB
F
E
NL
D
4
5
6
3
2
1
9
10
11
8 7
12
1LCD display
2Info / Menu button
3Back / Auto tune / SF(Service following)
button
4Tuning control / Next / Previous knob /
Select / Play / Pause / Call button
5Bluetooth pairing / Preset button
6Mode / Power On / Off button
7Sliding slot
8Micro USB socket
9External antenna socket
10 Auxiliary input socket
11 Line out socket
12 Microphone
Controls and connections
03
GB
F
E
NL
D
Supplied accessories
Car mount (Suction cup holder)
USB cable
5V cigarette type car power adaptor
External DAB / DAB+ antenna
Getting started
Installing your GoTune
Before you can start using your GoTune, you need to do the following:
1. Position the antenna in your vehicle.
2. Connect the antenna to GoTune.
3. Install the Car mount and GoTune.
4. Power your GoTune.
5. Connect the GoTune to your vehicle’s audio system with an auxiliary cable or by FM radio.
Vehicle requirements
1. Fitted audio system with auxiliary (3.5mm) port or FM receiver.
2. Standard 12V negative earth power supply. GoTune is not suitable for use with a 24V power
supply.
04
GB
F
E
NL
D
When the GoTune is installed in your car, you should
be able to reach the device easily without leaning or
stretching. The diagram shows where you can safely
install the car mount and Gotune.
Getting the best DAB signal
As with FM radio, DAB signal coverage changes depending on your location. As you use the GoTune
in your vehicle, you may travel through areas where DAB signal coverage is poor. To help get the
best DAB signal when coverage is poor or there is a weak signal:
– Follow the installation instructions carefully.
– Ensure the antenna is attached to GoTune.
– Use the supplied 5V cigarette type car power adaptor, as other third-party adapters can cause
interference.
– Switch off other devices in your vehicle that aren't in use. Devices such as satellite navigation
systems and dashboard cameras can cause interference.
Where to install your GoTune
It'simportanttoinstallyourGoTuneinasafelocationinyourvehicle.Donottanycomponents
in locations that may interfere with safe operation of the vehicle, or affect the deployment of air bags
or other safety products. Keep cables and wires away from the steering wheel.
Consider carefully where to install the GoTune in your car.
The GoTune should not block or interfere with any of the following:
●Your view of the road
●Any of the controls in your car
●Any of your mirrors
●The airbag
05
GB
F
E
NL
D
Where to install the DAB antenna
We recommend you install the DAB antenna for your
GoTune in the top corner of the windscreen, on the
passenger's side of your vehicle.
Install the DAB antenna so that it is not within the
swept area of the windscreen. Make sure the DAB
antenna and GoTune do not obstruct the view of the
driver.
Ifyouhaveaheatedwindscreeninyourvehicle,orthewindscreencontainsmetallicUVlters,it
can cause interference for the DAB signal. Install the DAB antenna on a part of the windscreen
thatdoesnotcontainheatingelementsorUVlters.
NOTE
For more information on where to safely and legally install your GoTune in your vehicle, contact your
localtransportofceifneeded.
Positioning and Connecting the DAB antenna
1Choose a position for the DAB antenna, so that it's as high as possible on the windscreen and
at least 4cm from the side of the windscreen.
NOTE
Make sure the DAB antenna does not obstruct the view of the driver.
2Clean the chosen area of the windscreen with a cleaning cloth and wait for it to dry.
3Unpeel the backing from the antenna and stick the
antenna onto your windscreen.
4Place the antenna cable so that it follows a path to
GoTune. If possible, tuck the cable behind the trim
down the side of your windscreen. Alternatively,
secure the cable to your windscreen and dashboard
with selfadhesive clips.
06
GB
F
E
NL
D
5Insert the antenna cable into the external antenna
socket of GoTune.
Installing the car mount and GoTune
1Choose an area on your vehicle's windscreen where you want to install the car mount and
GoTune. Clean the surface with a cleaning cloth and wait for it to dry.
NOTE
Make sure the car mount and GoTune does not obstruct the view of the driver.
2Pullopentheleveronthecarmountrst.Pressthesuctioncuprmlyagainstthewindscreen
on the chosen area, and then push back the lever to lock the suction cup that allows it to hold
securely to the windscreen.
3Insert the car mount to the slot on the rear of the GoTune, and then slide GoTune until you
hear it click into position.
Rotate the nut in a anti-clockwise direction to loosen the swivel, so that the ball head allows
360 degree rotation and easy adjustment for optimal viewing and then rotate the nut in a
clockwise direction to fasten the GoTune.
2
1
FASTEN LOOSEN
07
GB
F
E
NL
D
Using your GoTune for the rst time
1Insert the USB power cable into the micro USB socket on the rear of GoTune and insert the
other end to the supplied 5V cigarette type car power adaptor, then insert the power adaptor
into your vehicle's power socket. The display will show “Welcome to Digital Radio” for a few
seconds. Your GoTune will perform a scan of the Band III DAB channels and will normally
update the clock automatically using the DAB signal. If no signals are found, it may be
necessary to relocate the antenna to a position giving better reception. After a power failure the
GoTune will then set its clock the next time that you turn on the unit in DAB mode.
2Choose how to connect your GoTune to your vehicle's audio system.
●If connecting your GoTune with an auxiliary cable, choose Line out .
●If connecting your GoTune by FM radio, choose ‘FM TX’(FM transmitter)mode and then
choose an FM frequency. Ensure a radio station isn't using the frequency you choose. Tune
yourvehicle’saudiosystemtothesameFMfrequencyyourGoTune.ToeasilyndtheFM
frequency in the future, save it as a preset on your vehicle’s audio system.
Line out socket
A 3.5mm Line out socket located on the rear of your GoTune is provided for connecting the audio
signaltoanexternalamplier.Insertanaudiocableintothissocketandinserttheotherendintothe
vehicle's auxiliary socket.
Adjust the Volume control on the vehicle's audio system to the required level.
When selecting Line out to connect your GoTune to your vehicle's audio system, there may be
interference noises due to different vehicles.
NOTE
FM transmitter (FM TX mode)
1. Press the Power On / Off button to switch on your GoTune.
2. Press the Mode button to select FM TX mode.
3. Press the Autotune button to scan the FM frequency. The frequency of 10 unused radio stations
will be automatically stored in the preset list.
08
GB
F
E
NL
D
4. Press and release the Preset button to display the ‘Preset Recall’ menu. Rotate the Tuning
Control knob to select the desired preset frequency. Press and release the Tuning Control knob.
5. Tune your vehicle’s audio system to the same FM frequency your GoTune. Your vehicle’s audio
system will connect to GoTune. Press the Mode button to select your desired play mode (DAB /
Bluetooth / Auxiliary Input).
6. Adjust the Volume control on the vehicle's audio system to the required level.
7. To switch off your GoTune, press and hold the Power On / Off button.
Manual tuning – FM transmitter
1. Press the Power On / Off button to switch on your GoTune.
2. Press the Mode button to select FM TX mode.
3. Rotate the Tuning control knob to tune to a frequency. The frequency will change in steps of
100kHz. Ensure a radio station isn't using the frequency you choose.
4. Tune your vehicle’s audio system to the same FM frequency your GoTune. Your vehicle’s audio
system will connect to GoTune. Press the Mode button to select your desired play mode (DAB /
Bluetooth / Auxiliary Input).
5. Adjust the Volume control on the vehicle's audio system to the required level.
Disabling / Enabling FM transmitter
1. Press the Power On / Off button to switch on your GoTune.
2. Press and hold the Info / Menu button to access the menu for the current mode.
3. Rotate the Tuning control knob to select “Fm Tx Disable” and press the Tuning control knob to
enter the setting.
4. Rotate the Tuning control knob to select “Fm Tx On” or “Fm Tx Off”. To activate the FM transmitter
function,select“FmTxOn”andpresstheTuningcontrolknobtoconrmthesetting.Todisable
theFMtransmitterfunction,select“FmTxOff”andpresstheTuningcontrolknobtoconrmthe
setting.
When there is not any audio signal input into Gotune, the transmission will be turned off within 30
seconds. When the audio signal is input again, the transmission will be restarted within 3 seconds.
NOTE
Operating your GoTune – DAB
1. Press the Power On / Off button to switch on your GoTune.
2. Choose the way that you have connected GoTune to your vehicle's audio system as previously
described.
3. Press the Mode button to select DAB mode.
09
GB
F
E
NL
D
4. IfthisisthersttimetheGoTuneisused,aquickscanofBandIIIDABchannelswillbecarried
out. If the GoTune has been used before, the last used station will be selected.
5. During Autotune, as new stations are detected, the station counter on the right hand side of
the display will increase and stations will be added to the list. The display shows a bar graph
indicating progress of autotune.
6. WhentheAutotune is completed,therststation(innumeric-alphaorder0…9…A…Z)willbe
selected.
7. If the station list is still empty after the Autotune, your GoTune will display “No Station Found”.
8. If no signals are found, it may be necessary to relocate the antenna to a position giving better
reception.
Selecting a station – DAB
1. Press the Power On / Off button to switch on your GoTune.
2. Press and release the Mode button until the DAB mode is selected. The display will show the
name of the radio station currently selected.
3. Rotate the Tuning control knob to scroll through the list of available stations.
4. Press and release the Tuning control knob to select the station. The display may show
“Connecting…”whileyourGoTunendsthenewstation.
5. Adjust the Volume control on the vehicle's audio system to the required level.
If after selecting a station, the station is not found it may be necessary to relocate the antenna to a
position giving better reception.
NOTE
Secondary service – DAB
1. Certain radio stations have one or more secondary services associated with them. If a station has
a secondary service associated with it, the display will show “>>” next to the station name on the
station list. The secondary service will then appear immediately after the primary service as you
rotate the Tuning control knob.
2. Press and release the Tuning control knob to select the station. Most secondary services do
not broadcast continually and if the selected service is not available, the radio will re-tune to the
associated primary service.
Display mode – DAB
Your GoTune has a range of display options when in DAB mode:
1. Press and release the Info / Menu button to cycle through the various modes.
10
GB
F
E
NL
D
a. Scrolling text (DLS) displays scrolling text messages such as artist / track name,
phone in number, etc.
b. Signal strength
displaysthesignalstrengthofradioreception.Theclearunlled
rectangle indicates minimum signal level required for satisfactory
reception.
c. Program type displays type of station being listened to e.g. Pop, Classic, News
etc.
d. Multiplex name displays name of multiplex to which current station belongs.
e. Channel & frequency displays current channel and frequency.
f. Bit rate / audio type displays the digital bit rate and the audio type for the currently
tuned DAB station.
g. Time displays the current time.
h. Date displays the current date.
Finding new stations – DAB
Astimepassesnewstationsmaybecomeavailable.Tondnewstationsproceedasfollows:
1. When in DAB mode, to carry out a full scan of the entire DAB Band III frequencies, press and
hold the Autotune button.
2. As new stations are found, the station counter on the right hand side of the display will increase
and stations will be added to the list.
Manual Tuning – DAB
Manual tuning allows you to tune directly to the various DAB band III channels.
1. When in DAB mode press and hold the Info / Menu button to enter the DAB menu list.
2. Rotate the Tuning control knob to select “Manual Tune”. Press and release the Tuning control
knob to enter manual tune mode.
3. Rotate the Tuning control knob to select the required DAB channel. Press and release the Tuning
control knob to cause the GoTune to tune to the chosen channel.
4. Press the Back button to return to manual tune mode and then choose a different DAB channel.
Dynamic Range Control (DRC) setting – DAB
DRC can make quieter sound easier to hear when your GoTune is used in a noisy environment.
1. When in DAB mode press and hold the Info / Menu button to enter the DAB menu list.
2. RotatetheTuningcontrolknobtond“DRC”.PressandreleasetheTuningcontrolknobtoenter
the adjustment mode.
11
GB
F
E
NL
D
3. Rotate the Tuning control knob to select required DRC setting (default is off).
Off DRC is switched off. Broadcast DRC will be ignored.
High DRC is set as sent by broadcaster.
Low DRC level is set to 1/2 that sent by broadcaster.
4. PressandreleasetheTuningcontrolknobtoconrmthesetting.
Not all DAB broadcasts are able to use the DRC function. If the broadcast does not support DRC,
then the DRC setting in the radio will have no effect.
NOTE
Prune stations
If you move to a different part of the country, some of the stations which were listed may no longer
be available.
Also from time to time, some DAB services may stop broadcasting, or may change location or
frequency.
Stations which cannot be found, or which have not been received for a very long time are shown in
the station list with a question mark. The prune stations function will delete the marked DAB stations
from your station list.
1. When in DAB mode press and hold the Info / Menu button to enter the DAB menu list.
2. RotatetheTuningcontrolknobtond“PruneStation”.PressandreleasetheTuningcontrolknob
to enter the adjustment mode. Then rotate the Tuning control knob to select “Yes” or “No”. To
activatethePrunefunctionselect“Yes”,andpressandreleasetheTuningcontrolknobtoconrm
the setting.
3. If you do not wish to prune stations, select “No” and then press and release the Tuning control
knobtoconrmthesetting.
If you have moved your GoTune to a different part of the country you should also carry out a
search for new stations (please see the section 'Finding new stations').
NOTE
Trafc announcement On / Off setting
Wheneveratrafcannouncement(TA)isbroadcast,theGotunecanbesettoswitchautomatically
fromastationthatdoesnotprovidetrafcreportstotheappropriatetrafcinformationstationwithin
the broadcasting network that does.
Oncethetrafcreporthasbeenplayed,theGotunewillswitchbacktotheprogrammethatyouwere
listening to before.
1. When in DAB mode press and hold the Info / Menu button to enter the DAB menu list.
2. RotatetheTuningcontrolknobtond“Announcement”.PresstheTuningcontrolknobtoenter
the setting.
12
GB
F
E
NL
D
3. Rotate the Tuning control knob to select “On” or “Off”. To activate the traffic announcement
function,select“On”.PresstheTuningcontrolknobtoconrmthesetting.Todisablethisfunction,
select“Off”.PresstheTuningcontrolknobtoconrmthesetting.
DAB service following function
If the reception quality of the programme being received decreases, the Gotune can automatically
tune to the programme in another ensemble (if available). For this feature to work, the service
following function must be activated.
Press the SF button to switch service following on / off. The “S/F” symbol on the display shows that
the service following function is activated.
Alternative you can set it in the DAB menu.
1. When in DAB mode press and hold the Info / Menu button to enter the DAB menu list.
2. RotatetheTuningcontrolknobtond“ServiceFollowing”.PresstheTuningcontrolknobtoenter
the setting.
3. Rotate the Tuning control knob to select “On” or “Off”. To activate service following, select “On”.
Press the Tuning control knob to confirm the setting. The “S/F” will appear on the display. To
disablethisfunction,select“Off”.PresstheTuningcontrolknobtoconrmthesetting.The“S/F”
will disappear on the display.
Presets in DAB and FM Tx modes
There are 10 memory presets each for DAB radio and FM transmitter. They are used in the same
way for each operating mode.
1. Press the Power On / Off button to switch on your GoTune.
2. Tune to the required radio station / frequency as previously described.
3. Press and hold the Preset button to enter the “Preset Store” menu. Rotate the Tuning Control
knob to scroll through the preset list until you reach an unused preset or a preset that you wish
to change. Press and release the Tuning Control knob to store the preset. “Preset 1 Stored” (for
example) will be shown on the display. The corresponding preset number e.g.“P1” will show on
the display. Repeat this procedure for the remaining presets.
4. Stations which are already stored in the presets may be over written by following the above procedure.
Recall a preset in DAB and FM Tx modes
1. Press the Power On / Off button to switch on your GoTune.
2. Press the Mode button to select the required operating mode.
3. Press and release the Preset button to display the ‘Preset Recall’ menu. Rotate the Tuning Control
knob to select the desired preset station / frequency. Press and release the Tuning Control knob.
Your GoTune will then tune to the station / frequency stored in the selected preset memory.
13
GB
F
E
NL
D
Listening to music via Bluetooth streaming
You need to pair your Bluetooth device with your GoTune before you can auto-link to play / stream
Bluetooth music through your GoTune. Pairing creates a ‘bond’ so two devices can recognize each
other.
Pairing and playing your Bluetooth device for the rst time
1. Press the Power On / Off button to switch on your GoTune. Choose the way that you have
connected GoTune to your vehicle's audio system as previously described. Press the Mode
buttontoselectBluetoothmode.“Pairing”willshowandashonthedisplayoftheGoTune.
2. Activate Bluetooth on your device according to the device’s user manual to link to the GoTune.
Locate the Bluetooth device list and select the device named ‘FMT-02’ (With some Smartphone’s
that are equipped with earlier versions than BT2.1 Bluetooth device, you may need to input the
pass code “0000”).
3. Once connected, the name of your connected Bluetooth device will be shown on the display.
You can simply select and play any music from your source device. The volume control can be
adjusted from your source device, or directly from the vehicle's audio system.
4. Use the controls on your Bluetooth-enabled device or on the GoTune to play / pause and navigate
tracks.
1. If2Bluetoothdevicesarepairingforthersttime,bothmustsearchforyourGoTune,itwill
showitsavailabilityonbothdevices.However,ifonedevicelinkswith thisunitrst,thenthe
other Bluetooth device will not be found on the list.
2. If you take your source device out of range, the connection will be temporarily disconnected to
your GoTune. Your GoTune will automatically reconnect if the source device is brought back in
range. Be aware that during the period of disconnection, no other Bluetooth device can pair or
link with your radio.
3. If ‘FMT-02’ shows in your Bluetooth device list but your device cannot connect with it, please
delete the item from your list and pair the device with the GoTune again following the steps
described previously.
4. The effective operation range between the system and the paired device is approximately 10
meters (30 feet). Any obstacle between the system and the device can reduce the operational
range.z
5. Bluetooth connectivity performance may vary depending on the connected Bluetooth devices.
Please refer to the Bluetooth capabilities of your device before connecting to your GoTune. All
features may not be supported on some paired Bluetooth devices.
6. With some mobile phones, making / receiving calls, text messages, e-mails or any other
activities unrelated to audio streaming may mute the Bluetooth audio streaming or even
temporarily disconnect from your device. Such behavior is a function of the connected device
and does not indicate a fault with your GoTune.
NOTE
14
GB
F
E
NL
D
Playing audio les in Bluetooth mode
When you have successfully connected your GoTune with the chosen Bluetooth device you can start
to play your music using the controls on your connected Bluetooth device.
1. Once playing has started adjust the volume to the required setting using the volume control on
your vehicle's audio system or on your enabled Bluetooth device.
When in Bluetooth mode, if the input signal is too large, the output sound of vehicles audio system
may be unstable. It is recommended to turn down the volume of your Bluetooth device.
NOTE
2. Use the controls on your Bluetooth source device to play / pause and navigate tracks.
3. Alternatively, control the playback using Tuning control knob on the GoTune.
To Pause or Play the current track, press the Tuning control knob.
To play the next track, rotate the Tuning control knob in a clockwise direction.
To play the previous track, rotate the Tuning control knob in a anti-clockwise direction.
Not all player applications or devices may respond to all of these controls.
NOTE
4. If your connected device is able to provide information from the track being played, you may
press and release the Info / Menu button to display the Track status, Track name, Artist, Album,
Time and Date details on the display. Note that the availability of information depends on the
specicmediaformat.
Playing a previously-paired Bluetooth source device
The GoTune can memorize up to 8 paired Bluetooth source devices, when the memory exceeds
this amount, the earliest paring device will be over written from the device. If your Bluetooth source
device already paired with the GoTune previously, the unit will memorize your Bluetooth Source
device and will attempt to reconnect with a Bluetooth source device in the memory that was last
connected. If the last connected Bluetooth source device is not available, the GoTune will try to
connect to the second last Bluetooth source device.
Disconnecting your Bluetooth device
Press and hold the Bluetooth pairing button to disconnect with your Bluetooth device.
You can also press the Mode button to select any mode other than Bluetooth mode or turn off
Bluetooth on your Bluetooth source device to disable the connection.
If you disconnect the Bluetooth device when you are in Bluetooth mode, the “Pairing” will show and
ashonthedisplay,indicatingBluetoothisavailableagainforpairing.
Using your hands-free call feature
Your unit can be used as a hands-free accessory for your phone. When music is playing through
your GoTune and vehicle's audio system, if you receive a call on your phone it can pause the music
automatically to allow you to answer your phone.
15
GB
F
E
NL
D
1. When there is an incoming call, press the Call button on the Gotune to answer your phone call.
2. Speak in direction of the built-in microphone. Note that a very high volume setting may decrease
sound quality.
3. Press the Call button to end the phone call.
Auxiliary input socket
A 3.5mm stereo Auxiliary Input socket is provided on the rear of your GoTune to permit an audio
signal to be fed into the unit from an external audio device such as iPod, MP3 or CD player.
1. Press the Power On / Off button to switch on your GoTune.
2. Choose the way that you have connected GoTune to your vehicle's audio system as previously
described.
3. Press the Mode button to select Auxiliary Input mode.
4. Connect an external audio source (for example, iPod, MP3 or CD player) to the Auxiliary Input
socket.
5. Adjust the volume setting on your iPod, MP3 or CD player to ensure an adequate signal level
from the player, and then use the volume control on the vehicle's audio system as needed for
comfortable listening.
When in Auxiliary Input mode, if the input signal is too large, the output sound of vehicles audio
system may be unstable. It is recommended to turn down the volume of your external audio device.
NOTE
Sleep timer
Your radio can be set to turn off after a preset time has elapsed. The sleep timer setting can be
adjusted between 15 and 180 minutes.
1. Press the Power On / Off button to switch on your GoTune.
2. Press and hold the Info / Menu button to access the menu for the current mode.
3. Rotate the Tuning control knob to select “System” and press the Tuning control knob to enter the
system settings menu.
4. Rotate the Tuning control knob to select “Sleep” and press the Tuning control knob to enter the
setting.
5. Rotate the Tuning control knob to select the desired sleep time (15,30,60,90,120,180). Select the
“Sleep Off” to cancel the sleep function.
6. Press the Tuning control knob to confirm the setting. An active sleep timer is shown using a
symbol “S” on the playing display. Your radio will switch into power off mode after the preset time
has elapsed.
7. To view the remaining time of an active sleep timer setting, go back to steps 2-4.The remaining
time will show on the display.
16
GB
F
E
NL
D
8. To cancel the sleep timer before the preset time has elapsed and to turn off the radio, press the
Power button to turn the unit off manually.
Language selection
By default your GoTune will display all menus and messages in English. You can choose your
preferred language.
1. Press the Power On / Off button to switch on your GoTune.
2. Press and hold the Info / Menu button to access the menu for the current mode.
3. Rotate the Tuning control knob to select “System” and press the Tuning control knob to enter the
system settings menu.
4. Rotate the Tuning control knob to select “Language” and press the Tuning control knob to enter
the language adjustment menu.
5. Rotate the Tuning control knob until your desired language appears on the display. Press the
Tuningcontrolknobtoconrmyourchoice.Thedisplaywillchangetothechosenlanguage.The
chosen language will be marked with an asterisk.
Dimmer
The brightness of the display can be adjusted when the GoTune is in use.
1. Press the Power On / Off button to switch on your GoTune.
2. Press and hold the Info / Menu button to access the menu for the current mode.
3. Rotate the Tuning control knob to select “System” and press the Tuning control knob to enter the
system settings menu.
4. Rotate the Tuning control knob to select “Dimmer” and press the Tuning control knob to enter the
setting.
5. Rotate the Tuning control knob to adjust your required brightness level and press the Tuning
control knob to save the setting.
Factory reset
If your GoTune fails to operate or some digits on the display are missing or incomplete, carry out the
following procedure.
1. Press the Power On / Off button to switch on your GoTune.
2. Press and hold the Info / Menu button to access the menu for the current mode.
3. Rotate the Tuning control knob to select “System” and press the Tuning control knob to enter the
system settings menu.
4. Rotate the Tuning control knob to select “Factory Reset” and press the Tuning control knob to
enter the setting.
17
GB
F
E
NL
D
5. Rotate the Tuning control knob to select “Yes” or “No”. If you do not wish to carry out a system
reset,select“No”andthenpresstheTuningcontrolknobtoconrmthesetting.
6. With “Yes” selected, press the Tuning control knob. A full reset will be performed. All presets and
station lists will be erased. All settings will be set to their default values. After a system reset, the
GoTune will be restarted. The display will show “Welcome to Digital Radio” and a scan of the DAB
band III will be performed. In case of malfunction due to electrostatic discharge, reset the product
(reconnection of power source may be required) to resume normal operation.
Software upgrade
From time to time, new software features for your GoTune may be developed. Your GoTune has
therefore been designed to allow its internal software to be updated using your USB upgrade port.
You should not attempt to update your GoTune unless it is recommended to you by Sangean
Customer Services.
Updating the software may remove radio station presets and settings from your GoTune.
Software updates for your GoTune may be available in the future. As software updates become
available software and information on how to update your GoTune can be found at:
http://www.sangean.com
Formoreinformation,pleasecontactourHeadOfcebysendinganemailto[email protected]
1. Using the micro USB cable (supplied) to connect the USB socket on the rear of your GoTune and
your PC.
2. With your GoTune switched on, press and hold the Info / Menu button to access the menu for the
current mode.
3. Rotate the Tuning control knob to select “System” and press the Tuning control knob to enter the
system settings menu.
4. Rotate the Tuning control knob to select “Software Upgrade” and press the Tuning control knob to
enter the setting.
5. Rotate the Tuning control knob to select “Yes” or “No”. If you do not wish to carry out a software
upgrade,select“No”andpresstheTuningcontrolknobtoconrmthesetting.
6. With “Yes” selected, press the Tuning control knob. The display will show “Waiting for PC wizard”.
7. Go to the website above to download the latest software. Follow the on-screen instructions on
your PC provided with the upgrade software to complete the software upgrade.
Do not switch off the power to the GoTune until the update operation is complete and the GoTune
has restarted, otherwise the unit may become permanently damaged.
NOTE
18
GB
F
E
NL
D
Software version
The software display cannot be altered and is just for your reference.
1. With your GoTune switched on, press and hold the Info / Menu button to access the menu for the
current mode.
2. Rotate the Tuning control knob to select “System” and press the Tuning control knob to enter the
system settings menu.
3. Rotate the Tuning control knob until “SW Version” appears on the display and press the Tuning
control knob. The software version shows on the display.
4. Press the Back button to exit the software version display.
19
GB
F
E
NL
D
Specications
Power Requirement
Power supply DC 5V cigarette type car power adaptor
Frequency Range FM transmitter: 88.1 – 107.9 MHz
DAB: 174.928 – 239.200 MHz
Bluetooth
Bluetoothspecication Bluetooth®Ver 4.1
ProleSupport A2DP, AVRCP1.4, HFP1.6
Bluetooth Audio CODEC SBC, AAC
Transmitting Power Power Class 2
Line of sight range 10meters / 30feet
The frequency and maximum
transmitted power 2402MHz – 2480MHz: 3.25dBm (Bluetooth EDR)
Circuit features
Aux In socket 3.5mm diameter, stereo
Line Out socket 3.5mm diameter, stereo
Temperature range Operational temperature: 0°C to +65°C
Storage temperature: -40°C to +85°C
If at any time in the future you should need to dispose of this product please note that:
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice. (Waste
Electrical and Electronic Equipment Directive)
Thecompanyreservestherighttoamendthespecicationswithoutnotice.
※ The barcode label on the product is dened as below:
Serial number
Production month
Production year
Product code
Table of contents
