Sangfor IAM11.2 User manual

IAM 11.2 User Manual
www.sangfor.com
1
SANGFOR IAM11.2
User Manual
2016 January

IAM 11.2 User Manual
www.sangfor.com
2

IAM 11.2 User Manual
www.sangfor.com
3
Table of Content
Table of Content.........................................................................................................................................3
Declaration................................................................................................................................................. 8
About This Document................................................................................................................................ 9
Organization....................................................................................................................................... 9
Conventions....................................................................................................................................... 9
Symbol Conventions........................................................................................................................ 10
Technical Support.............................................................................................................................10
Acknowledgment............................................................................................................................. 10
Chapter 1 IAM Installation.......................................................................................................................11
1.1 Environment Requirement........................................................................................................ 11
1.2 Power......................................................................................................................................... 11
1.3 Product Appearance.................................................................................................................. 11
1.4 Configuration and Management............................................................................................... 13
1.5 Wiring Method of Standalone................................................................................................... 13
1.6 Wiring Method of Redundant System....................................................................................... 16
Chapter 2 IAM Console............................................................................................................................ 17
2.1 Web UI Login..............................................................................................................................17
2.1.1 Log into the Web Console...............................................................................................17
2.1.2 Remove the Certificate Alert Dialog............................................................................... 18
2.2 Configuration............................................................................................................................. 20
Chapter 3 Functions.................................................................................................................................22
3.1 System........................................................................................................................................ 22
3.1.1 Status.............................................................................................................................. 22
3.1.1.1 Dashboard............................................................................................................22
3.1.1.2 Online users......................................................................................................... 29
3.1.1.3 Connection Quality..............................................................................................32
3.1.1.4 Traffic Statistics.................................................................................................... 40
3.1.1.5 Internet Activities................................................................................................ 47
3.1.1.6 Locked Users........................................................................................................ 49
3.1.1.7 DHCP Status......................................................................................................... 50
3.1.1.8 Security Events.....................................................................................................51
3.1.2 Firewall............................................................................................................................51
3.1.2.1 Firewall Rules....................................................................................................... 51
3.1.2.2 IPv4 SNAT............................................................................................................. 53
3.1.2.3 IPv4 DNAT............................................................................................................ 59
3.1.2.4 IPv6 NAT............................................................................................................... 63
3.1.3 Network.......................................................................................................................... 65
3.1.3.1 Deployment......................................................................................................... 65
3.1.3.2 Network Interface Configuration........................................................................ 92
3.1.3.3 Static Routes........................................................................................................ 99
3.1.3.4 Policy-Based Routing......................................................................................... 101
3.1.3.5 High Availability................................................................................................. 106
3.1.3.6 HOSTS.................................................................................................................115
3.1.3.7 DHCP.................................................................................................................. 116

IAM 11.2 User Manual
www.sangfor.com
4
3.1.3.8 Protocol Extension.............................................................................................118
3.1.3.9 Optical Bypass Module...................................................................................... 120
3.1.4 General..........................................................................................................................122
3.1.4.1 Licensing............................................................................................................ 122
3.1.4.2 Administrator.....................................................................................................123
3.1.4.3 Date/Time.......................................................................................................... 134
3.1.4.4 Update............................................................................................................... 135
3.1.4.5 Alarm Options....................................................................................................137
3.1.4.6 Global Exclusion.................................................................................................141
3.1.4.7 Backup/Restore................................................................................................. 143
3.1.4.8 Custom Webpage.............................................................................................. 144
3.1.4.9 Report Center.................................................................................................... 146
3.1.4.10 Advanced Settings........................................................................................... 148
3.1.5 Diagnostics....................................................................................................................157
3.1.5.1 System Logs....................................................................................................... 157
3.1.5.2 Capture Packets................................................................................................. 158
3.1.5.3 Web Console......................................................................................................160
3.1.5.4 Troubleshooting.................................................................................................161
3.1.5.5 Shutdown...........................................................................................................163
3.2 Proxy .......................................................................................................................................164
3.2.1 Proxy Services............................................................................................................... 164
3.2.2 Proxies...........................................................................................................................166
3.2.2.1 HTTP Proxy.........................................................................................................166
3.2.2.2 SOCKS4 Proxy.....................................................................................................169
3.2.2.3 SOCKS5 Proxy.....................................................................................................170
3.2.3 ICAP Server Groups.......................................................................................................171
3.2.4 Cascading Proxy Servers............................................................................................... 174
3.2.5 Forward......................................................................................................................... 175
3.3 Object.......................................................................................................................................177
3.3.1 Application Signature....................................................................................................178
3.3.1.1 Viewing the Application Signature.................................................................... 179
3.3.1.2 Enabling/Disabling Application Identification Rules.........................................182
3.3.2 Advanced App Signature.............................................................................................. 183
3.3.2.1 Enabling/Disabling Advanced App Signature....................................................184
3.3.2.2 Editing P2P Behavior Identification Rules......................................................... 184
3.3.2.3 Editing Ultrasurf/Freegate Identification Rules................................................ 186
3.3.2.4 Editing Web Online Proxy Identification Rules..................................................187
3.3.3 Custom Application.......................................................................................................188
3.3.3.1 Adding Custom Application Rules..................................................................... 188
3.3.3.2 Enabling, Disabling, and Deleting Custom Application Rules........................... 190
3.3.3.3 Importing and Exporting Custom Application Rules.........................................190
3.3.4 URL Database................................................................................................................190
3.3.4.1 URL Database List.............................................................................................. 191
3.3.5 Ingress Rule Database...................................................................................................195
3.3.5.1 Ingress Rules...................................................................................................... 195
3.3.5.2 Combined Ingress Rule...................................................................................... 206
3.3.6 Service...........................................................................................................................210
3.3.7 IP Group........................................................................................................................ 212
3.3.8 ISP..................................................................................................................................213
3.3.9 Schedule........................................................................................................................215

IAM 11.2 User Manual
www.sangfor.com
5
3.3.10 Keyword Group........................................................................................................... 217
3.3.11 File Type Group...........................................................................................................218
3.3.12 Location.......................................................................................................................219
3.4 Users.........................................................................................................................................222
3.4.1 Working Principle..........................................................................................................222
3.4.1.1 Users Type..........................................................................................................222
3.4.1.2 User Authentication.......................................................................................... 224
3.4.2 Authentication.............................................................................................................. 225
3.4.2.1 Authentication Policy.........................................................................................225
3.4.2.2 External Auth Server..........................................................................................240
3.4.2.3 Single Sign-On....................................................................................................260
3.4.2.4 Custom Webpage.............................................................................................. 273
3.4.3 Users............................................................................................................................. 278
3.4.3.1 Local Users......................................................................................................... 278
3.4.3.2 User Import........................................................................................................302
3.4.3.3 User Binding.......................................................................................................306
3.4.3.4 IP&MAC Binding................................................................................................ 310
3.4.4 Advanced...................................................................................................................... 312
3.4.4.1 Authentication Options..................................................................................... 313
3.4.4.2 USB Key User..................................................................................................... 316
3.4.4.3 Custom Attributes..............................................................................................319
3.4.4.4 MAC Filtering Across L3 Switch......................................................................... 321
3.5 Access Mgt............................................................................................................................... 324
3.5.1 Policies.......................................................................................................................... 324
3.5.1.1 Introduction to Policies......................................................................................325
3.5.1.2 Adding Object for Access Control......................................................................330
3.5.1.3 Viewing Network Access Policies of Users........................................................ 336
3.5.1.4 Matching Network Access Policies....................................................................339
3.5.1.5 Adding Policies...................................................................................................340
3.5.1.6 Adding a Policy Using a Template......................................................................390
3.5.1.7 Deleting an Ingress Policy..................................................................................392
3.5.1.8 Editing Policies in Batches................................................................................. 392
3.5.1.9 Enabling or Disabling a Policy............................................................................393
3.5.1.10 Changing the Policy Order...............................................................................394
3.5.1.11 Importing/Exporting a Policy.......................................................................... 395
3.5.2 Advanced Policy Options.............................................................................................. 397
3.5.2.1 Logging...............................................................................................................397
3.5.2.2 Web Access Options.......................................................................................... 399
3.5.2.3 Policy Troubleshooting...................................................................................... 400
3.5.2.4 Excluded Application......................................................................................... 400
3.6 Traffic Management.................................................................................................................402
3.6.1 Overview.......................................................................................................................402
3.6.2 Bandwidth Management..............................................................................................403
3.6.3 Bandwidth Channel Configuration............................................................................... 403
3.6.3.1 Line Bandwidth..................................................................................................404
3.6.3.2 Limited Channel.................................................................................................412
3.6.3.3 Traffic Sub-Channel............................................................................................421
3.6.3.4 Penalty Channel................................................................................................. 428
3.6.3.5 Adding a Channel Using a Template..................................................................438
3.6.3.6 Exclusion Policy..................................................................................................438

IAM 11.2 User Manual
www.sangfor.com
6
3.6.4 Line Bandwidth Configuration......................................................................................440
3.6.5 Virtual Line Configuration.............................................................................................441
3.7 Endpoint Device Connection Management............................................................................ 445
3.7.1 Shared Connection Management.................................................................................445
3.7.2 Mobile Endpoint Management.................................................................................... 449
3.8 Security Protection.................................................................................................................. 452
3.8.1 Anti-DoS Attack............................................................................................................. 453
3.8.2 ARP Protection..............................................................................................................454
3.8.3 Antivirus........................................................................................................................456
3.9 VPN Configuration................................................................................................................... 458
3.9.1 DLAN Operating Status................................................................................................. 458
3.9.2 Basic Settings................................................................................................................ 459
3.9.3 User Management........................................................................................................ 461
3.9.4 Connection Management.............................................................................................469
3.9.5 Virtual IP Address Pool................................................................................................. 471
3.9.6 Multi-Line Settings........................................................................................................477
3.9.7 Multi-Line Route Selection Policy.................................................................................479
3.9.8 Local Subnet List........................................................................................................... 481
3.9.9 Inter-channel Routing Settings..................................................................................... 482
3.9.10 Third party connection............................................................................................... 485
3.9.10.1 Phase I..............................................................................................................485
3.9.10.2 Phase II.............................................................................................................491
3.9.10.3 Security Options.............................................................................................. 495
3.9.11 Object..........................................................................................................................497
3.9.11.1 Schedule.......................................................................................................... 497
3.9.11.2 Algorithm List Settings.....................................................................................498
3.9.12 Advanced Settings...................................................................................................... 498
3.9.12.1 Intranet Service Settings..................................................................................498
3.9.12.2 VPN Interface Settings.....................................................................................501
3.9.12.3 Multicast Service............................................................................................. 503
3.9.12.4 LDAP Server Settings....................................................................................... 505
3.9.12.5 Radius Server Settings..................................................................................... 506
3.9.12.6 Dynamic Routing Settings................................................................................507
Chapter 4 Use Cases.............................................................................................................................. 508
4.1 SSO Configuration.................................................................................................................... 508
4.1.1 SSO Configuration for the AD Domain......................................................................... 508
4.1.1.1 SSO Implemented by Delivering a Login Script Through Domains................... 508
4.1.1.2 Obtaining Login Information Using a Program (SSO Without a Plug-in).......... 521
4.1.1.3 SSO Implemented Using IWA............................................................................ 535
4.1.1.4 SSO Implemented in Monitoring Mode............................................................ 535
4.1.2 Proxy SSO Configuration...............................................................................................539
4.1.2.1 4 SSO in Monitoring Mode................................................................................ 539
4.1.2.2 SSO in ISA Mode................................................................................................ 543
4.1.3 POP3 SSO Configuration............................................................................................... 547
4.1.4 Web SSO Configuration................................................................................................ 551
4.1.5 Configuration of SSO Implemented with Third-Party Devices.....................................555
4.1.5.1 SSO Implemented with Ruijie SAM................................................................... 555
4.1.5.2 SSO Implemented with Devices Supporting the HTTP SSO Interface...............563
4.1.5.3 SSO Implemented with H3C CAMS................................................................... 565
4.1.5.4 SSO Implemented with Dr. COM....................................................................... 566

IAM 11.2 User Manual
www.sangfor.com
7
4.1.5.5 SSO Implemented with H3C IMC.......................................................................568
4.1.6 SSO Implemented with Another SANGFOR Device......................................................569
4.1.7 SSO Implemented with a Database System................................................................. 571
4.2 Configuration That Requires No User Authentication............................................................ 574
4.3 Configuration That Requires Password Authentication.......................................................... 580
4.3.1 SMS Authentication...................................................................................................... 580
4.3.1.1 Sending SMS Messages Through an SMS Modem............................................580
4.3.1.2 Sending an SMS Message Using an SMS Modem Installed on an External Server585
4.3.2 WeChat and QR Code Authentication..........................................................................592
4.3.3 Password Authentication..............................................................................................603
4.4 Other Configuration Cases.......................................................................................................611
4.5 CAS Server Authentication Case..............................................................................................624
4.6 Policy Configuration Cases.......................................................................................................628
4.6.1 Configuring a Policy for Blocking P2P and P2P Streaming Media Data for a User Group628
4.6.2 Configuring an IM Monitoring Policy for a User Group............................................... 632
4.6.3 Enabling the Audit Function for a User Group............................................................. 636
4.7 Endpoint Device Management Configuration Cases...............................................................639
4.7.1 Configuring the Sharing Prevention Function.............................................................. 639
4.7.2 Mobile Endpoint Management Configuration Cases...................................................641
4.8 Comprehensive Configuration Cases.......................................................................................642
4.8.1 Customer Network Environment and Requirement.................................................... 642
4.8.2 Configuration Idea........................................................................................................ 643
4.8.3 Configuration Process...................................................................................................644
Appendix: Usage of SANGFOR Device Upgrade System........................................................................665
Product Upgrade Procedure.......................................................................................................... 668

IAM 11.2 User Manual
www.sangfor.com
8
Declaration
Copyright © SANGFOR Technologies Co.Ltd. All rights reserved.
No part of the information contained in this document shall be extracted,
reproduced or transmitted in any form or by any means, without prior written
permission of SANGFOR.
SANGFOR, SANGFOR Technologies and the SANGFOR logo are the trademarks
or registered trademarks of SANGFOR Technologies Co. Ltd. All other trademarks used
or mentioned herein belong to their respective owners.
This manual shall only be used as usage guide, and no statement, information, or
suggestion in it shall be considered as implied or express warranties of any kind, unless
otherwise stated. This manual is subject to change without notice. To obtain the latest
version of this manual, please contact the Customer Service of SANGFOR Technologies
CO. Ltd

IAM 11.2 User Manual
www.sangfor.com
9
About This Document
Organization
Part I Describe the hardware server and software server requirement in order to install External
Data Center. Step of Installation included.
Part II Describe the interface and each of the function such as generate report, check online
behavior and system management. Justify overall configuration, setting and precaution.
This document takes SANGFOR IAM M5100 as an example. Equipment of different models
differs in both hardware and software specifications. Therefore, confirm with SANGFOR about
problems involving product specifications.
Conventions
GUI Conventions
Item
Sign
Example
Button
Frame+shadow+
shading
The OK button can be simplified as OK.
Menu item
{}
The menu item System Setup can be simplified as
System Setup.
Choose cascading menu
items
→
Choose System Setup > Interface Configuration.
Drop-down list, option
button, check box
[ ]
The Enable User check box can be simplified as
Enable User.
Window name
Bold Font
Open the New User window.
Prompt
“”
The prompt “Succeed in saving configuration. The
configuration is modified. You need to restart the
DLAN service for the modification to take effect.
Restart the service now?” is displayed.

IAM 11.2 User Manual
www.sangfor.com
10
Symbol Conventions
The symbols that may be found in this document are defined as follows:
Caution: alerts you to a precaution to be observed during operation. Improper operation may
cause setting validation failure, data loss, or equipment damage.
Warning: alerts you to pay attention to the provided information. Improper operation may
cause bodily injuries.
Note or tip: provides additional information or a tip to operations.
Technical Support
Email: [e-mail]
International Service Centre: [phone] (7511) Malaysia: 1700817071
Website: www.sangfor.com
Acknowledgment
Thanks for choosing our product and user manual. For any suggestions on our product or user
manual, provide your feedback to us by phone or email.

IAM 11.2 User Manual
www.sangfor.com
11
Chapter 1 IAM Installation
This chapter mainly describes the appearance and installation of SANGFOR IAM hardware device.
After correct installation, you can configure and debug the system.
1.1 Environment Requirement
The SANGFOR IAM device requires the following working environment:
Input voltage: 110V-230V
Temperature: 0-45℃
Humidity: 5%-90%
To ensure long-term and stable running of the system, the power supply should be properly
grounded, dustproof measures taken, working environment well ventilated and indoor temperature
kept stable. This product conforms to the requirements on environment protection, and the
placement, usage and discard of the product should comply with relevant national law and
regulation.
1.2 Power
The SANGFOR IAM device uses 110 ~ 230V alternating current (IAM) as its power supply. Make sure it
is well-grounded before being provided with power supply.
1.3 Product Appearance
SANGFOR IAM Hardware Device
Above is the front panel of SANGFOR IAM hardware gateway device. The interfaces or indicators on

IAM 11.2 User Manual
www.sangfor.com
12
the front panel are described respectively in the following table.

IAM 11.2 User Manual
www.sangfor.com
13
Table 1 Interface Description
No.
Interface/Indicator
Usage
1
CONSOLE Interface
Used for high-availability function (redundant system)
2
WAN2 (eth3)
Network interface to be defined as WAN2 interface
3
DMZ (eth1)
Network interface to be defined as DMZ interface
4
WAN1 (eth2)
Network interface to be defined as WAN1 interface
5
LAN (eth0)
Network interface to be defined as LAN interface
6
POWER Indicator
Power indicator of IAM gateway device
7
ALARM Indicator
Alarm indicator of IAM gateway device
The CONSOLE interface is only for debugging by technical engineers. The end users connect to
the device via the network interfaces.
1.4 Configuration and Management
Before configuring the device, please prepare a computer and make sure the web browser (for
example, Internet Explorer browser) of the computer can be used normally. Then connect the
computer with the IAM device to a same local area network (LAN) and then configure the IAM device
on the computer over the established network.
The default IP address settings for the network interfaces are described below:
Interface
IP Address
eth0 (LAN)
10.251.251.251/24
eth1 (DMZ)
10.252.252.252/24
eth2 (WAN1)
200.200.20.61/24
1.5 Wiring Method of Standalone
Connect the power cable to the Power interface on the rear panel of the IAM device and switch on

IAM 11.2 User Manual
www.sangfor.com
14
the power supply. The POWER indicator (in green) and ALARM indicator (in red) on the front panel
will be lighted. The ALARM indicator will go out one or two minutes later, indicating the device runs
normally.
Follow the instructions below to wire the interfaces:
Use standard RJ-45 Ethernet cable to connect the LAN interface to the local area network
and then configure the IAM device.
Use standard RJ-45 Ethernet cable to connect the WAN1 interface with the networking
device, such as router, optical fiber transceiver, ADSL Modem, etc.
Use standard RJ-45 Ethernet cable to connect DMZ interface to the DMZ zone network.
Generally, the Web server and Mail server providing services to wide area network (WAN)
are placed at the DMZ zone. The IAM device provides secure protection for these servers.
When wiring the interfaces, please use the correct cables for connection as instructed below:
Use straight-through cable to connect a WAN interface with the Modem, and crossover
cable to connect a WAN interface with the router.
Use straight-through cable to connect the LAN interface with the switch, and crossover
cable to connect the LAN interface on the device with the network interface on the
computer.
If connections cannot be established while the corresponding indicator functions normally, please
check whether cables are correctly used for connections. The differences between straight-through
cable and crossover cable are the wire sequences at both ends, as shown below:

IAM 11.2 User Manual
www.sangfor.com
15
Wire Sequences of Straight-through Cable and Crossover Cable
After correct connections, log in to the console of IAM device and configure the deployment mode
according to the network topology (see section 3.1.3.1 Deployment).
1. Multi-line function of the IAM device allows multiple Internet lines to be connected in. In this
situation, connect the second networking device to WAN2 interface, the third networking
device to WAN3 interface, and so on.
2. When IAM gateway device is running, the POWER indicator (in green) keeps lighted, the
WAN LINK and LAN LINK indicators (in orange) keep lighted. The ACT indicator (in green) will
flicker if there is data flow. When the device is starting, the ALARM indicator is lighted (in red)
due to system loading and then goes out after one or two minutes, indicating successful startup
of the device. After startup, the ALARM indicator may flash, which means the device is writing
logs. However, if the ALARM indicator stays lighted for a long time and does not go out, please

IAM 11.2 User Manual
www.sangfor.com
16
shut down the device and restart the device after 5 minutes. If this situation remains after
restart, please contact us.
1.6 Wiring Method of Redundant System
If two IAM devices are deployed in high availability mode (HA), please wire the two devices to
external network and internal network as shown below:
Follow the instructions below to wire the two devices:
Use standard RJ-45 Ethernet cable to connect the WAN1 interfaces of the two IAM devices
to a same switch (if multi-line function is applied, the wiring method is the same: just
connect the WAN interfaces of the two devices to a same external line), and then connect
the switch to other networking devices, such as router, fiber optical transceiver and ADSL
Modem, etc.
Use the Console cable (among the accessories) to connect Console interfaces of the two
IAM devices.
Use RJ-45 Ethernet cable to connect the LAN interfaces (eth0) of the two IAM devices to a
same switch, and then connect the switch to the LAN switch, connecting it to the LAN.
After the two devices are correctly wired, switch on the power for both devices and then configure
them. The procedures for configuring the redundant system are the same as that for a standalone
device. You need only configure the active IAM device, which will automatically synchronize its
configurations to the standby IAM device.

IAM 11.2 User Manual
www.sangfor.com
17
Chapter 2 IAM Console
2.1 Web UI Login
The IAM device supports secure HTTPS login, using the standard port of HTTPS protocol. If you log
into the Web Console of the IAM device for the first time, type the default login address
https://10.251.251.251 in the address bar of the browser.
Using HTTPS to login to the WEBUI and manage the IAM device can avoid the potential risks
that the configurations may be intercepted during transmission.
2.1.1 Log into the Web Console
After finishing all the wiring, you can then log into the Web User Interface (UI) to configure the
SANGFOR IAM device. Follow the procedures below to log into the console of the IAM device:
Step 1. Configure an IP address (for example, 10.251.251.100) on the 10.251.251.X subnet for the
computer, and then type the default login IP address and port in the IE address bar:
https://10.251.251.251. Click <Go> and the following alert dialog appears:

IAM 11.2 User Manual
www.sangfor.com
18
Step 2. Click <Yes> to open the login interface, as shown below:
Step 3. Type the user name and password, and click <Login> to log into the IAM device console. The
username and password are Admin by default.
To view the version of the current IAM gateway device, click <Version>.
You can log into the console without installing any ActiveX. Non-IE browsers are also supported.
2.1.2 Remove the Certificate Alert Dialog
During the login to the console, the browser may pop up the certificate alert dialog. To remove it, do
as follows:
Step 1. Log into the console, open the [System] > [General] > [Advanced] > [Web UI] page. Specify
the IP address (to which the certificate will be issued) in the [Issue Console SSL Cert. To]
field. Here, the IP address refers to that of the network interface for login and it is the IP
address of the LAN interface by default. In this example, we suppose that you have logged
into the console through the default address of the LAN interface.

IAM 11.2 User Manual
www.sangfor.com
19
Step 2. Click <Download Certificate> to download the certificate to the local computer and click
<Save> to save it.
Step 3. Locate the certificate in the local computer and double-click it to install.
After the certificate is installed, the alert dialog will not pop up when you login through the default
address of the LAN interface.
Only when you login through the IP address specified in [Issue Console SSL Cert. To] and the
local computer has installed the certificate will this alert dialog be removed. If you login
through other address or the computer has not installed the certificate, the alert dialog will still

IAM 11.2 User Manual
www.sangfor.com
20
pop up.
2.2 Configuration
After logging in to the Web UI, you will see the following major modules: [System], [Objects], [Users],
[Access Mgt], [Bandwidth Mgt], [Endpoint Device] and [Security] as shown below:
The following instructions for the buttons and icons are applicable to all the configuration pages on
the IAM device and will not be described again in the subsequent sections:
If a <Commit> button is included on the configuration page, after you change the
configurations, you need click this button to apply your configuration changes. Generally, it
may take 5 to 10 seconds for the configuration changes to take effect. To make them take
effect immediately, click the icon at the bottom-right of the page.
The icon at the bottom-right of the page is for broadcasting some system messages
or warning messages in real time.
Most of the configuration pages include the icon. When you put your mouse cursor
over this icon, a brief description for the current configuration item will pop up.
When you modify the settings on the [System] > [Network] > [Deployment] page or [System] >
[System Time] page or default encoding on the [System] > [General] > [Advanced] > [Web UI
Options] page, the IAM device will restart and you need to re-login.
