Sanoxy WR-M3GU12 User manual

QUICK INSTALLATION GUIDE
WR-M3GU12
3G/3.75G Wireless N Mobile Power Router
1.Router Power Source Supply
There are only two (2) sources of power for WR-M3GU12 Router:
Via Battery.
Via External Power.
Note:
Usually, the battery can last for approximately 4 hours of usage per full charge.

1.1 Charge battery
There are several ways to charge the battery of R-M3GU12 Router's battery:
Via PC/Notebook USB port.⊙
⊙Via Power adaptor (5V 1.2A).
⊙Via General mobile phone charger.
⊙Via car adaptor.
Steps to charge the battery as below:
step1 : Turn off the R-M3GU12 Router.
step 2: Connect Mini 5pin of the USB Charge Cable to R-M3GU12 Router's DC
power Micro USB port.
step 3: Connect the other end of USB Charge Cable to either PC/Notebook USB
port, or to the Power adaptor USB port, Mobile phone charger car adaptor.
Note:
1. hile charging, the R-M3GU12 Router's Battery Light is in blue.
2. hen full charged, the R-M3GU12 Router's Battery Light in no light.
3. e strongly recommended to charge the battery using DC adaptor, and it will
take approximately 3 hours to complete the charging.

1.2 Provide power source to Gadget
The R-M3GU12 Router's USB port is also able to provide power source to charge
battery of a gadget.
Steps to charge battery as below(illustrated with iPhone):
step 1: Connect iPhone and R-M3GU12 Router's USB port by 30pin connector
step 2: Turn the power switch of the R-M3GU12 Router to C. (This step is optional,
suggest to implement it to save battery capacity when you no need router
function).
Note:
hen R-M3GU12 Router's Power Switch turn to C, the R-M3GU12 Router will be
Power-off and charging the smartphone is begun.
hen the R-M3GU12 Router's Power Switch turn to on, the R-M3GU12 Router
will be Power-On and the charging of smartphone will also be begun.
2.Package Contents
1x R-M3GU12

1x Micro USB Charging Cable
1x Quick Installation Guide/ arranty Card
Note:
1. The illustrations in this document may appear different from your model.
2. If any of above items is not packed in your package when open, please
consult your reseller immediately.
3. Using a power supply with a different voltage rating will cause damage and
void the warranty for this product.
3.Overview
4.Computer Setting
Establish Network Connection
Step 1:Open computer’s wireless network connection, set the computer to
“automatically obtain IP address” and “automatically obtain DNS server
address”. (Picture 1 & 2).

Step 2:Make sure your PC have IFI function and IFI status in “ON” condition.
hen IFI connected, click “Refresh network list”, select the router’s wireless
network name in the “Wireless Network Connection” page. ( IFI SSID definition:
SANOXY_XXXX, XXXX is the 8th-11th number of the MAC number, for example
MAC: 9C417C000208, IFI SSID is SANOXY_0020) Make sure IFI connected and
internet access. Then means you can use internet. Please see picture 3 & 4.

→Note 1: if your computer or device doesn’t have IFI Funcation, Please use
RJ45 cable to Connect your IFI device or PC with 3G Router through LAN port.
→Note 2: if can’t surf the internet successfully, then need go to step3
Step 3: Open the web browser and input IP address 192.168.169.1, Press Enter
(Picture 5).
Input password "admin", if you want change password#1.
#1: R-M3GU12 Router login credential is recommended to change to user
preferable password,
if lost password, please press Router’s Reset button more than 5 seconds to load
Factory Default Settings.
The password will be back to “admin”.
5. Hardware Installation, Please make
sure the WR-M3GU12 power switch in
"R"

1. Connect via 3G USB Modem
2.
Before you begin, please make sure you have below items prepared:
1. R-M3GU12 Router.
2. 3G USB Modem (compatible#2 with R-M3GU12 Router).
3. 3G SIM Card (with data plan and valid login credential ready).
Hardware Installation Steps:
step 1. Insert the 3G SIM Card into 3G USB Modem.
step 2. Insert the 3G USB Modem to the R-M3GU12's USB port.
step 3. Turn on the power of R-M3GU12 Router.
step 4. Make the computer connect the IFI SSID of R-M3GU12 (see
4.Computer Setting).
step 5.Then you could surf.
if you could not surf ,Pls do following operations
step 1. Open a browser and enter http://192.168.169.1 at address bar.
step 2. Enter login credential with password as "admin".
step 3. Click Internet > WAN Network. Make sure that the 3G mode is being
selected
in WAN Connection Type >Select Auto APN > Apply#3.
#2: For 3G USB Modem which is incompatible with the R-M3GU12, please
contact us immediately.
#3: If you get the APN, Dial No., username, password from operator, you can also
input it manually.

2: Connect via iPhone
Before you begin, please make sure you have below items prepared:
1. R-M3GU12 Router.
2. iPhone#4(with 3G Internet connectivity ready).
3. iPhone 30Pin connector (for connection between iPhone and R-M3GU12
Router).
Hardware Installation Steps:
step 1. Connect iPhone and R-M3GU12 Router's USB port by 30pin connector.
step 2. Turn on iPhone Personal Hotspot from Settings > General > Personal
Hotspot#4(please select to turn on USB only when prompted in the iPhone).
step 3. Turn on the power of R-M3GU12 Router.
#4:Only applicable to iPhone 3G/3Gs or below, and firmware must below iOS5
(not including iOS5). iPhone 4 and above is eligible in providing Hotspot solely.

3.Connect via ADSL Modem
Before you begin, please make sure you have below items prepared:
1. R-M3GU12 Router.
2. ADSL Modem with Telephone line connected at RJ11.
3. RJ45 Cable (use existing RJ45 cable from modem).
Installation Steps:
step1. Connect LAN port of ADSL Modem and AN/LAN port of R-M3GU12
Router by RJ45
cable.
step2. Turn on the power of both ADSL Modem and R-M3GU12 Router.
step3. Make the computer connect the IFI SSID of R-M3GU12 (see
4.Computer Setting).
step4. Open a browser, login with password "admin", then input relevant ADSL
login credential#5(ID and password) in the pop up menu.
step 5. Then you could surf.
If you could not surf ,Pls do following operations
Step1. Open a browser and enter http://192.168.169.1 at address bar.
step2. Enter login credential with password as "admin".
Step3. Click Internet > WAN Network. Make sure that the PPPOE(ADSL) is being
selected in WAN Connection Type .

Step4. Please make sure the User Name and Password are correct.
#5:For unsuccessful login with the ADSL credential, kindly contact the ADSL
ISP(Internet Service Provider) immediately.
4. Connect via Cable/DHCP Modem
Before you begin, please make sure you have below items prepared:
1. R-M3GU12 Router.
2. Switch or Router with Internet access ready (eg:existing office LAN, hotel
LAN, etc which has Internet facility ready).
3. RJ45 Cable (use existing RJ45 cable from modem).
Hardware Installation Steps:
step 1. Connect LAN port of Switch or Router and AN/LAN port of R-M3GU12
Router by RJ45
cable.
step 2. Turn on the power of R-M3GU12 Router.
step 3. Make the computer connect the IFI SSID of R-M3GU12 (see
4.Computer Setting).
step 4. Then you could surf.
If you could not surf , Pls do following operations
step 1. Open a browser and enter http://192.168.169.1 at address bar.
step 2. Enter login credential with password as "admin".
step 3. Click Internet >WAN Network. Make sure that the DHCP is being selected in
WAN Connection Type.
5.Connect via WIFI Hotspot
Before you begin, please make sure you have below items prepared:
1. R-M3GU12 Router.
2. IFI account.

Installation Steps:
step 1. Turn on the power of R-M3GU12 Router.
step 2. Make the computer connect the IFI SSID of R-M3GU12 (see
4.Computer Setting).
step 3. Open a browser and enter http://192.168.169.1 at address bar.
step 4. Enter login credential with password as "admin".
step 5. Click Internet>WAN Network. Make sure that the WIFI mode is being
selected
in WAN Connection Type. Click at “Get APlist from air”, then select the SSID that
the ISP provides and type the Password, press Apply.
6. Configure the Router(Web-GUI)
6.1 Connections Status:
Display the current network's connection status, including Signal Performance,
Network Mode,
etc .Click at Home to find out more details.
6.2 WIFI Management:
To configure the iFi of the Router, including to turn On or Off the iFi, assign
SSID, assign iFi password, etc. Below are a few major iFi configuration that
mostly concerns:
a) Setting WiFi SSID
Click the Wireless > WiFi Settings, enter desire iFi SSID at Network
Name(SSID) then click Apply.
b) Forget WiFi password or SSID

Load Factory Default settings by clicking Admin > Settings > Load Default
button.
Alternatively, user may press the Reset button from the button of the device
for more than
5seconds, a reboot will be happening. The password will be back to "admin".
c) Setting Security Method
iFi default security method is Disable. Please make sure that the router's
encryption
method is same as the device or PC Encryption method if want to configure
the security
method, click Wireless >Security > Security mode. Select security, same as
the PC or
iFi Device. Please make the number of the passwords in 8-64bits.
6.3 MANUAL APN
Firstly setting "3G" mode: Internet >WAN Network >WAN Connection Type >3G
,then select "Manual APN" >fill in APN information accordingly and press
"Apply".
