Santec VOGUE 6565VO Series User manual

VOGUE COLLECTION
PAPER HOLDER
MODEL: 6565VO10
6565VO__
KEEP THIS INSTRUCTION BOOKLET FOR FUTURE REFERENCE
Important : Please register your product online at www.santecfaucet.com within
30 days of purchase. Santec reserves the right to request additional documents
before servicing warranty requests.
01 02
#DESCRIPTION PART #
1
2
3
5
* Please specify the nish when ordering the part.
Paper Holder Post- Left *
Paper Holder Post- Right *
Accessories Bell *
Flange * P00076
#10-24 Set Screw PM-027
4
PA-2200
PA-2925R
PA-2925L
#DESCRIPTION PART #
6
7
8
Mounting Post
Screws
Toggle
Allen Key PM-033
9
Spring PA-2900
10
Rubber Washer PM-400
11
PM-026
PM-016
PM-960
PARTS BREAKDOWN
Ø2 38"

03 04
Place the trim parts against the assigned wall location. Make sure that the roller is leveled and the roller
post positions are correct. Leave 5” to 5-1/4” space between the roller posts for the rollers. Mark the
roller post ange positions and remove the trims.
1.
Using the mounting hardware position as a reference, mark the screw hole positions in the center of the
post ange mark on the wall.
INSTALLING ON WOODEN SURFACE
For wooden surface, the mounting posts can be
secured by screwing the screws directly into the wall.
INSTALLING ONTO DRYWALL SURFACE
Using a drill, pre-drill holes for the anchors. Insert the
anchors into the wall. The mounting posts can be
secured by screwing the screws into the anchors.
INSTALLING ONTO A SOLID SURFACE
Measure the dimensions carefully. Using a drill,
pre-drill the holes. Secure the mounting posts by
screwing the screws into the wall.
2.
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
Using the Allen key provided, loosen the roller posts’ set screws. Slip the left roller post onto the left
mounting hardware post. Align the roller post and secure it by tightening the set screw.
3.
Insert the rollers with the spring onto the secured roller post. Slip the right roller post onto the right
mounting hardware post. Insert the right side of the rollers into the right roller post. Align the roller post
and tighten the set screw rmly.
4.
Check both roller posts to make sure they are rmly secured. If not, tighten the set screws with the
Allen key.
5.
5” ~ 5 ”
WALL
14

Effective 01/01/09 - Replaces and supersedes any previously issued warranty
FINISH CARE INFORMATION
SANTEC LIFETIME LIMITED WARRANTY
PLEASE REGISTER YOUR PRODUCT ONLINE FOR WARRANTY SERVICES
www.santecfaucet.com/registration
1.
2.
3.
4.
Finishes: Santec Polished Chrome, Polished Nickel and Satin Nickel nishes carry a Lifetime
Limited warranty against manufacturing defects and tarnish to the original purchaser with the
exclusion of kitchen drain assemblies which, due to the nature of their use, are not warranted.
Santec recommended custom nishes carry a ten (10) years limited warranty against
manufacturing defects and tarnish to the original purchaser with the exclusion of kitchen and
pop-up drain assemblies which, due to the nature of their use, are not warranted. Kitchen
products carry a three (3) year limited warranty.
Cartridges: Santec Cartridges carry a lifetime limited warranty against manufacturing defects for
the life of the product to the original purchaser.
Parts: Santec parts carry a ten (10) year limited warranty against manufacturing defects, to the
original purchaser. Kitchen products carry a ve (5) year limited warranty.
Warranty exclusions and limitations: This warranty does not cover: damage due to negligence,
accident, abuse, improper installation, or improper maintenance such as, but not limited to: heat
from soldering during installation, the use of plumbers putty, damage from tools used during
installation, the use or exposure to chemicals or cleaning products either abrasive or non
abrasive or the use of any cleaning tool or product other than a soft, clean cloth. Pop-up
assemblies are not covered under warranty. This warranty does not cover: changes in the nish
or in the product due to normal wear or aging and does not cover any products or parts which
have been altered or used in a manner not typical for the product. This warranty does not cover
and Santec will not be held liable for damage to products caused by the freight carrier and a
claim should be made immediately to the freight carrier should this occur. This warranty does
not cover any cost involved in the installation, repair, or replacement of any Santec product or
part. This warranty does not cover and Santec will not be held liable for any loss, damages, or
expenses, incidental or consequential whatsoever, originating from the purchase, installation,
use, repair, failure, or replacement of any Santec product or part, as allowed by law. The
product or components of the covered product will either be repaired, renished or replaced, at
the sole discretion of Santec. Santec reserves the right to examine any product claimed
defective prior to any warranty claim being accepted or processed, at its sole discretion. This
warranty gives you specic legal rights and you may have other rights which may vary from state
to state.
For clear coated or enamel color nishes:
We recommend that all faucets, drains, etc
be gently wiped dry with a soft cloth after use
to avoid water spotting and water deposit
buildup. A mild liquid hand soap, such as
Ivory may be used occasionally if desired.
Use of non-abrasive carnauba wax will add
protection to the nish and should be used if
the faucets will not be dried after use.
For non-clear coated and specialty nishes:
We recommend that all faucets, drains, etc be
gently wiped dry with a soft cloth after use to
avoid water spotting and water deposit
buildup. Use of a non-abrasive carnauba wax
is required occasionally.
