Sanyo FWBP507FF User manual

Blu-ray Disc™ / DVD
Player
FWBP507FF / FWBP505F Q
Owner’s Manual
INSTRUCCIONES SIMPLIFICADAS
INCLUIDOS EN ESPAÑOL.
To obtain a more detailed electronic copy of this
manual or much further contents, go to
www.sanyo-av.com
Para obtener una copia electrónica más detallada de este manual o mucho otras
contenido, visite
Need help?
Please call toll free 1 866 212 0436 or visit our web site above:
¿Necesita ayuda? Llame por favor sin costo al 1 866 212 0436 ó visite nuestro sitio web en:

2
CONTENTS
INTRODUCTION.....................................................3
Safety instructions .........................................................3
Included accessories......................................................4
FEATURES ..............................................................5
Features...........................................................................5
System information .......................................................6
Symbols used in this owner’s manual........................6
FUNCTIONAL OVERVIEW ....................................7
Front panel ......................................................................7
Rear panel .......................................................................7
Remote control...............................................................8
Guide to on-screen display.........................................10
CONNECTIONS.................................................... 11
Connection to aTV ....................................................... 11
Connection to an audio system .................................12
HDMI audio output.......................................................13
BEFOREYOU START............................................14
Finding a viewing HDMI input on yourTV................14
Initial setup....................................................................14
INFORMATION ON PLAYBACK..........................16
Information on playback .............................................16
Guide to file list............................................................. 19
How to insert a disc......................................................20
BASIC PLAYBACK ................................................21
Playing back a disc.......................................................21
Playing back contents from a USB memory stick....22
Using the title / disc / pop menu................................23
SPECIAL PLAYBACK............................................24
Fast forward / fast reverse...........................................24
Slow forward playback................................................24
Step by step playback..................................................24
Repeat playback............................................................25
Shuffle / random playback ..........................................25
Slide show.....................................................................26
PiP (BONUSVIEW™) setting.......................................27
Title / chapter search....................................................28
Track / file search ..........................................................28
Time search...................................................................29
Number select search..................................................29
Switching subtitles.......................................................30
Switching audio soundtrack .......................................31
Switching camera angles............................................32
Noise reduction ............................................................32
Closed caption..............................................................32
LIST OF SETTINGS..............................................33
SETUPS.................................................................37
HDMI CEC......................................................................37
HDMI video resolution.................................................38
Parental control ............................................................40
Software update ...........................................................42
Voice guide....................................................................43
Restore default settings...............................................43
TROUBLESHOOTING..........................................44
SPECIFICATIONS .................................................47
MAINTENANCE ...................................................48
TRADEMARK INFORMATION ............................49
GLOSSARY ...........................................................51
LIMITEDWARRANTY ..........................................53
ESPAÑOL ..............................................................54
Mando a distancia........................................................54
Encontrar el HDMI en su televisor .............................55
Instalacion inicial..........................................................56
Garantía limitada..........................................................57

EN 3
Register Online at www.sanyo-av.com/support/ today to get the most benefits from your purchase.
Registering your model with SANYO makes you eligible for all of the valuable benefits such as software
upgrades and important product notifications. Register Online at www.sanyo-av.com/support/
1. INTRODUCTION
1.1. Safety instructions
See “Quick Start Guide” for more details of Safety Instructions.
To avoid the hazards of electrical shock and fire
• Do not handle the AC power cord with wet hands.
• Do not pull on the AC power cord when disconnecting it from an AC outlet. Grasp it by the plug.
• Do not put your fingers or objects into the unit.
Location and handling
• Do not install the unit in direct sunlight, near strong magnetic fields, or in a place subject to dust or strong
vibration.
• Avoid a place with drastic temperature changes.
• Install the unit in a horizontal and stable position. Do not place anything directly on top or bottom of the unit.
Depending on your external devices, noise or disturbance of picture and/or sound may be generated if the unit is
placed too close to them. In this case, please ensure enough space between external devices and the unit.
• Depending on the environment, the temperature of this unit may increase slightly.This is not a malfunction.
• Be sure to remove the disc and unplug the AC power cord from the outlet before moving the unit.
• In order to avoid interruption of ventilation, this unit should not be placed in built-in
equipment such as a book cabinet, rack, etc., and the vents of this unit should not be covered with anything such
as a tablecloth, curtain, newspaper, etc. Make sure to leave a space of 5.9 inches (15 cm) or more around this
apparatus.
• When installing this unit in a temperate environment, avoid a place with rapid temperature changes.
• This unit should not be used in a tropical environment as it has not been evaluated under such conditions.
• No objects should be placed directly on or under this unit, especially lighted candles or other flaming objects.
Dew condensation warning
• Dew condensation may form inside the unit in the following conditions. If so, do not use this unit at least for a
few hours until its inside gets dry.
– The unit is moved from a cold place to a warm place.
– Under conditions of high humidity.
– After heating a cold room.
Note about recycling
• This unit’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
• Batteries should never be thrown away or incinerated but disposed of in accordance with your local
regulations concerning chemical wastes.
• For product recycling information, please visit - www.sanyo-av.com
Click on
Disposal of used batteries
• In certain localities, disposing batteries with household waste is not permitted. Please ensure you dispose of
batteries according to local regulations.

EN 4
Country code statement
• For product available in the USA market, only channel 1~11 can be operated. Selection of other channels is not
possible.
To maintain compliance with FCC RF exposure requirements, use only belt-clips, holsters or similar accessories
that do not contain metallic components in its assembly.The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements and should be avoided.
This device complies with Industry Canada license-exempt RSS standard(s).
• Operation is subject to the following two conditions:
(1) this device may not cause interference and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
1.2. Included accessories
• Remote control (NC092UH or NC092UL)
• Quick Start Guide
SANYO is a registered trademark of SANYO Electric Co., Ltd. and is used by Funai Electric Co., Ltd. and Funai
Corporation, Inc. under license from SANYO Electric Co., Ltd.
Any liability related to SANYO products, including design and quality, is the sole responsibility of Funai Electric
Co., Ltd. and Funai Corporation, Inc.
Please contact Funai Corporation, Inc. for any questions or claims related to SANYO products:
www.sanyo-av.com
© 2017 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form or for any purpose without the express prior written
consent of Funai.
Furthermore, any unauthorized commercial distribution of this manual or any revision hereto is strictly
prohibited.
Information in this document is subject to change without notice. Funai reserves the right to change the
content herein without the obligation to notify any person or organization of such changes.

EN 5
2. FEATURES
2.1. Features
Blu-ray Disc™
You can enjoy Blu-ray Disc™ which is capable of
storing five times more data than a conventional DVD.
BD-Java
With some Blu-ray™ discs which contain Java
applications, you can enjoy interactive functions such
as games or interactive menus.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before
thanks to video upscaling. Upscaling will increase the
resolution of standard definition DVD to high definition
up to 1080p over an HDMI connection. The picture
will be less jagged and more realistic for a near high
definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with DVD, CD and USB
memory stick ensures that you can continue to enjoy
your current audio-video collection. Additionally, you
can enjoy AVCHD (for DVD-RW/-R only) / photo files /
music files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which realizes real-to-
life sound and makes you feel that you are really there.
Easy and simple connection to your HDTV via HDMI
Connect this unit to your HDTV with one single HDMI
(High-Definition Multimedia Interface) cable. It is
recommended to use a High Speed HDMI cable for
better compatibility. The high definition video output
signal will be transferred to your HDTV without
conversion to analog signals, so you will get excellent
picture and sound quality, completely free from noise.
HDMI CEC (Consumer Electronics Control)
This unit supports HDMI CEC, which allows integrated
system control over an HDMI cable and is part of the
HDMI standard. This function may not work properly
on some devices.
PiP (BONUSVIEW™)
Some BD-Videos have the PiP function which enables
you to display the secondary video in the primary
video. You can call up the secondary video by pressing
[MODE] whenever the scene contains a secondary
video.
Pop menu
Some BD-Videos have a pop menu which is a
navigation menu that can be called up and be operated
on the TV screen without interrupting playback. You
can call up the pop menu by pressing [DISC MENU].
Contents in the pop menu vary depending on the disc.
HDMI 1080p/24 output (Blu-ray Disc™ only)
This unit is equipped with the feature which can
provide smooth movement during playback of film
originated material with a frame rate of 24 frames per
second with progressive. (Available only when the
display device is connected with an HDMI cable.) Refer
to “HDMI video resolution” on page 38.
Playing back contents from a USB memory stick
You can play back photo files / music files stored on a
USB memory stick. BD-ROM discs sometimes store
picture-in-picture commentary, subtitles or other
extras on a USB memory stick for use during playback
with the BD-Video.
Playing back AVCHD files
This unit supports playback of AVCHD format files
(new format for high definition video camcorders)
recorded on a disc / SD memory card using USB
card reader. Your high definition personal archive is
playable in HD quality.
x.v.Color
This unit supports playback of video contents on
discs recorded with “x.v.Color” technology. To watch
this video content with the “x.v.Color” space, a TV
or other display device supporting both video image
reproduction using “x.v.Color” standard and capability
of manual switching of its color space setting is
required. Please refer to the User Manual of your
display device for further information.

EN 6
2.2. System information
“System Information” screen provides information about this unit’s software version.
You can also download the latest software from the SANYO website and update it yourself if it is newer than
the version currently on your unit. The current version of software on your unit can be seen on the “System
Information” screen.
To access “System Information”, follow the procedure below.
1. Press [HOME].
2. Use []to select “Setup”, then press [OK].
3. Use []to select “ ”.
2.3. Symbols used in this owner’s manual
To specify which media type each function is applicable to, a combination of the symbols shown below will be
depicted next to that function's explanation.
Symbol Description
[BD Video]
BD
VIDEO
BD
VIDEO Description refers to BD-Video
[DVD Video]
DVD
VIDEO
DVD
VIDEO Description refers to DVD-Video
[CD]
C DC D Description refers to Audio CD / DTS-CD
[AVCHD]
AVCHDAVCHD Description refers to DVD-RW/-R with AVCHD files
[JPEG]
FILE
FILE
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB memory stick with photo files.
[MUSIC]
MUSIC
FILE
MUSIC
FILE
Description refers to BD-RE/-R, DVD-RW/-R, CD-RW/-R and USB memory stick with music files.
If you do not find any of the symbols listed above under the function heading, the operation is applicable to all
media types.

EN 7
3. FUNCTIONAL OVERVIEW
3.1. Front panel
1 3* 4*2 5* 6 7
*The unit can also be turned on by pressing this button.
1. Disc tray
2. Infrared sensor window
3. (OPEN/CLOSE) button*
4. (PLAY/PAUSE) button*
• Press to start playback.
• During playback, press to pause playback.
5. (POWER) button*
6. Power-on indicator
7. USB input
CautionC
• Do not connect any device other than USB memory stick or USB card reader into the USB input. (e.g. PC, external
HDD, digital camera, keyboard, mouse, USB-hub, etc.)
• When connecting a USB memory stick, connect it directly to the USB Input. Do not use a USB extension cable.
NoteD
• Due to new ENERGY STAR®requirements, this unit will automatically turn on the screen saver after 5 minutes of
inactivity and enter standby mode after 25 minutes of inactivity.
3.2. Rear panel
1 2
1. AC power cord
2. HDMI OUT jack
CautionC
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage
to the unit.
• This unit does not have aTV RF modulator.

EN 8
3.3. Remote control
1 12*
13
14
16
17
2
3
4
11
15
18
19
5
6*
7
8
20
21
9
10
* The unit can also be turned on by pressing these
buttons.
1. (POWER) button
• Press to turn on the unit, or to switch the unit into
standby mode. (To completely turn off the unit,
you must unplug the AC power cord.)
2. DISC MENU button
• During playback (Blu-ray Disc™ or DVD), press to
select the menu (top menu or pop menu/menu).
3. buttons
• Press to select items or settings.
4. SEARCH button
• Press to display the number select menu or the
search menu.
5. (REVERSE) button
• During playback, press to fast reverse the
playback.
6. (PLAY) button*
• Press to start playback or resume playback.
7. (SKIP) button
• During playback, press once to return to the
beginning of the current title, chapter, track or file.
• During playback, press twice to return to the
previous title, chapter, track or file.
• During the JPEG playback, press to return to the
previous file.
8. (STOP) button
• Press to stop playback.
9. DISPLAY button
• Press to display the on-screen display menu.
10. REPEAT button
• Press to select repeat mode.
11. RED / GREEN / BLUE /YELLOW buttons
• Press to activate shortcut keys on some BD-video
functions. When a file list is shown, press to switch
between pages.
12. (OPEN/CLOSE) button*
• Press to open or close the disc tray.
13. HOME button
• Press to display the home menu.
14. MODE button
• During playback, press to display the play menu.
15. OK button
• Press to confirm or select menu items.
16. RETURN button
• Press to return to the previously displayed menu
or screen function.
17. (FORWARD) button
• During playback, press to fast forward the
playback.
• When playback is in pause, press to slow forward
the playback.
18. (SKIP) button
• During playback, press to skip to the next chapter,
track or file.
• When playback is in pause mode, press to forward
the playback picture by picture.
19. (PAUSE) button
• Press to pause playback.
20. AUDIO button
• Press to select the audio channel (such as audio
languages) on a disc.
21. SUBTITLE button
• Press to select subtitles on a disc.
continued on next page

EN 9
NoteD
• Use the included remote control. Remote-control
operation on any other remote control, such as a
universal remote control, is not guaranteed.
CInstalling the batteries in the remote control
Install 2 AAA (1.5V) batteries matching the polarity
indicated inside battery compartment of the remote
control.(not included)
1 2 3
CautionC
Incorrect use of batteries can result in hazards such
as leakage and bursting. Please follow the guidelines
below:
• Lithium or ni-cad and ni-mh rechargeable batteries
are not recommended to use for remote control.
• Do not mix different types of batteries such as
alkaline and standard (carbon-zinc).
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the + and - ends of each battery match
the indications in the battery compartment.
• Remove batteries from battery compartment, when
the remote is not going to be used for a month or
more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public rules that apply in your country or area.
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
CUsing the remote control
Remote control usage guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on
the unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the infrared
sensor window of the unit.
• Remote controls of different devices can interfere
with each other. Avoid using a remote control from
another device which is located close to the unit.
• Replace the batteries when you notice a fall-off in the
operating range of the remote control.
• The maximum operable ranges from the unit are as
follows.
– Line of sight:
approx. 23 feet (7 m)
– Either side of the center:
approx. 16 feet (5 m) within 30°
– Above:
approx. 16 feet (5 m) within 15°
– Below:
approx. 10 feet (3 m) within 30°
16 feet (5 m) 16 feet (5 m)23 feet (7 m)
30˚ 30˚

EN 10
3.4. Guide to on-screen display
CHome menu
When you turn on the unit, home menu will appear automatically. Otherwise, press [HOME].
USB SetupDisc
123
1. “Disc”:Initiates playback of inserted disc, displays a list of tracks/files.
2. “USB”:Displays a list of tracks/files on the connected USB memory stick.
3. “Setup”:To access the setup menu.
CSetup menu
OSD
System
Setup
Menu
Audio
Subtitle
English
English
English
Off
Language
Security
1
2
1. Category
2. Menus / Options: Displays options for the highlighted item on the left whenever available
CPlay menu
During playback, press [MODE] to display the play menu.
e.g.) Blu-ray Disc™
Search
Audio
Subtitle
Subtitle Style
BDMV
Repeat
Display
