Sanyo Xacti VPC-C4 User manual

INSTRUCTION MANUAL
Please read these instructions carefully before using the camera. Make sure to
read and understand the section “USING YOUR CAMERA SAFELY AND
CORRECTLY” on pages 7 to 20. Keep this manual in a safe place for later
reference.
An SD Memory Card is not included with Model VPC-C4GX.
Important note
This manual explains how to safely operate the VPC-C4EX, VPC-C4EXS,
VPC-C4E, VPC-C4, VPC-C4S and VPC-C4GX.
Any information regarding only one of these products will be labeled as such.
Digital Movie
VPC-C4EX
VPC-C4EXS
VPC-C4E
VPC-C4
VPC-C4S
VPC-C4GX

iEnglish
Warning
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
FOR AMERICAN USERS
WARNING:
This product contains chemicals, including lead, known to the State of
California to cause cancer, and birth defects or other reproductive harm.
Wash hands after handling.
iThis equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
hReorient or relocate the receiving antenna.
hIncrease the separation between the equipment and receiver.
hConnect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
hConsult the dealer or an experienced radio/TV technician for help.
iChanges or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
Model number: VPC-C4, VPC-C4S
Trade Name: SANYO
Responsible party: SANYO FISHER COMPANY
Address: 21605 Plummer Street, Chatsworth, California 91311
Telephone No.: [phone]
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interfer-
ence that may cause undesired operation.
Declaration of Conformity

English ii
FOR CANADIAN USERS
iThis Class B digital apparatus complies with Canadian ICES-003.
FOR EU USERS
Conformity to EC Directives
iThis unit complies with EC Directives 89/336/EEC
and 73/23/EEC.
iThe rating plate can be found inside the set after
the battery cover and battery are removed.

1English
OUTLINE OF OPERATION
To help you get started enjoying using your camera right away, given below is
an outline of the basic operation, from setup to shooting to playback.
SETUP
1Connect the AC adaptor/charger (page 154).
2Install the SD Memory Card* in the camera
(page 38).
CAUTION
iThis camera uses an SD Memory Card instead
of photographic film to record images. Be sure
to install the SD Memory Card before operating
the camera.
iBe sure to format the SD Memory Card with this
camera before using it. A card that is not
formatted using the camera may limit your full
use of all the camera's capabilities.
SHOOTING
1Turn on the camera (page 40).
2Capture images.
hFor shooting video clips, see page 47.
hFor shooting still photos, see page 49.
The novice photographer may find the section
“HINTS FOR TAKING PICTURES” on page 182
of this Instruction Manual to be helpful. Please
use it in conjunction with the explanations under
the main headings in the manual, to capture the
best photos.

English 2
PLAYBACK
1Play back the images (page 55).
* About the SD Memory Card
In this manual, the SD Memory Card is
referred to as “card”.
An SD Memory Card is not included with
Model VPC-C4GX.
Symbols used in this manual
HINT Points that may prove useful when using the camera.
NOTE Points giving some extended instructions or special points to pay
attention to.
CAUTION Points that require special attention.
(page xx) Refer to the page indicated for detailed information.
You may find the answers to questions or problems concerning camera
operation in the sections “COMMONLY ASKED QUESTIONS” (page 155)
and “TROUBLESHOOTING” (page 162).

3English
CONTENTS
OUTLINE OF OPERATION ................................................................... 1
USING YOUR CAMERA SAFELY AND CORRECTLY ......................... 7
FOR CORRECT USE OF YOUR CAMERA ......................................... 21
CHECKING THE INCLUDED ACCESSORIES .................................... 25
GETTING THE MOST OUT OF YOUR CAMERA ............................... 29
PREPARATION
PARTS NAMES ................................................................................... 32
CHARGING THE BATTERY PACK ..................................................... 35
INSTALLING THE BATTERY PACK AND CARD ................................ 37
TURNING THE CAMERA ON AND OFF ............................................. 40
OPERATION BUTTONS ...................................................................... 42
BASIC OPERATION
SHOOTING/RECORDING
BEFORE TAKING PICTURES ............................................................. 44
CAPTURING IMAGES ......................................................................... 47
BASIC SHOOTING FUNCTIONS ........................................................ 51
RECORDING AN AUDIO MEMO ......................................................... 53
PLAYBACK
VIEWING IMAGES .............................................................................. 55
VIEWING VIDEO CLIPS ...................................................................... 58
PLAYING BACK AUDIO MEMOS ........................................................ 60

English 4
SHOOTING SETTINGS
PAGE 1 (BASIC SETTINGS)
DISPLAYING THE SHOOTING SETTING SCREENS .........................61
IMAGE QUALITY ..................................................................................67
SCENE SELECT ..................................................................................69
FILTERS ...............................................................................................71
FLASH SETTING ..................................................................................72
SELF-TIMER ........................................................................................74
PAGE 2 (ADVANCED SETTINGS)
MOTION COMPENSATION (IMAGE STABILIZER) .............................76
FOCUS RANGE ...................................................................................77
NOISE-REDUCTION ............................................................................79
FLICKER-REDUCTION ........................................................................80
ISO SENSITIVITY .................................................................................81
WHITE BALANCE ................................................................................82
PLAYBACK SETTINGS
PAGE 1 (BASIC SETTINGS)
DISPLAYING THE PLAYBACK SETTING SCREENS .........................83
PLAYBACK MODE ...............................................................................87
VOLUME ...............................................................................................88
LCD MONITOR BRIGHTNESS ............................................................89
IMAGE PROTECT ................................................................................90
ERASING DATA ...................................................................................92
PAGE 2 (ADVANCED SETTINGS)
ROTATE IMAGE ...................................................................................94
EDITING VIDEO CLIPS ........................................................................95
PRINT SETTINGS ..............................................................................103
DISPLAYING IMAGE DATA (INFORMATION SCREEN) ..................110

5English
CAMERA SETTINGS
OPTION SETTINGS
DISPLAYING THE OPTION SCREEN ............................................... 111
DATE AND TIME ............................................................................... 113
OPERATION SOUNDS ..................................................................... 116
HELP DISPLAY ................................................................................. 118
WIND NOISE REDUCTION ............................................................... 119
DIGITAL ZOOM SETTING ................................................................. 120
SCREEN LANGUAGE ....................................................................... 121
TV OUTPUT SETTING ...................................................................... 122
POWER SAVE FUNCTION ............................................................... 124
FILE NO. RESET FUNCTION ............................................................ 126
FORMATTING A CARD ..................................................................... 129
RESETTING THE CAMERA SETTINGS ........................................... 131
CHECKING THE REMAINING CARD MEMORY .............................. 132
CHECKING THE REMAINING BATTERY PACK CHARGE .............. 134

English 6
OTHER DEVICES AND CONNECTIONS
DOCKING STATION
DOCKING STATION ..........................................................................136
CONNECTING TO OTHER EQUIPMENT ..........................................138
PREPARING AND USING THE REMOTE CONTROL UNIT .............140
PLAYBACK WITH THE DOCKING STATION ....................................144
DIRECT PRINTING ............................................................................145
CONNECTIONS .................................................................................154
APPENDICES
COMMONLY ASKED QUESTIONS ...................................................155
TROUBLESHOOTING ........................................................................162
SPECIFICATIONS ..............................................................................174
HINTS FOR TAKING PICTURES .......................................................182

7English
USING YOUR CAMERA SAFELY AND CORRECTLY
CAMERA
kIf the camera makes a strange noise, emits a
strange odor, or if smoke comes out from it,
immediately turn off the power and remove the
battery pack
iIf the camera is used under these conditions, it may
cause a fire or electric shock. Immediately turn off the
camera, remove the battery pack, and wait to make
sure no more smoke comes from the camera. Then
take it to the dealer for service. Do not try to repair or
open the camera yourself.
kDo not modify or open the cabinet
iHigh voltage circuits are inside, and there is a high risk
of fire or electric shock if they are touched. Any
internal check, setting, or repair should be performed
by the dealer.
kDo not use while driving
iDo not capture images, play back images, or watch
the LCD monitor while driving a vehicle. Doing so may
cause an accident.
iBe careful where you put down the camera inside an
automobile. During sudden stops or turns it may fall
behind the brake pedal and prevent braking.
kBe aware of your surroundings when using the
camera
iPay close attention to your surroundings when using the
camera. Failure to do so may lead to an accident or
injury.
iWhen using the camera while walking, be very careful of
your surroundings and especially the traffic to avoid
accidents.
iDo not use the camera inside an airplane or elsewhere
where its use may be restricted.
WARNING

English 8
kDo not get the camera wet
iThis camera is not water-resistant. Do not allow it to get
wet, as doing so may cause a fire or electric shock.
iDo not use the camera in a bathroom.
iIf the camera gets wet, immediately turn it off and
remove the battery pack. Then take it to a dealer for
repair. Using the camera after it has been become wet
may cause a fire, electric shock, or other accident.
kDo not use during a storm
iTo avoid the risk of being struck by lightning, do not use
the camera during a thunderstorm. In particular, if used
in an open field, you have an increased chance of being
struck by lightning. Quickly seek refuge in a place that
will protect you from lightning.
kDo not place on an unstable surface
iThe camera may fall, resulting in damage to the camera
or injury.
iIf the camera has fallen and its body is damaged, turn it
off, remove the battery pack, and take it to the dealer for
repair. Using the camera after its body has been
damaged may cause a fire or electric shock.
kDo not look through the camera into the sun
iDo not look through the camera at the sun or any other
strong source of light. Doing so may seriously injure
your eyes.
kDo not use the flash close to a person's face
iTo prevent possible eye injury, do not use the flash near
a person's face (especially young children or babies). If
the flash is used close to a person's opened eyes, there
is a risk that it may damage that person's eyesight.
WARNING

9English
USING YOUR CAMERA SAFELY AND CORRECTLY
kDo not use where there is risk of explosion
iDo not use the camera in a location where there is
explosive gas, or any other flammable material in the
air. Doing so may cause a fire or an explosion.
kKeep the camera out of the reach of children
iThe following may happen if children play with the
camera:
hThey may wrap the neckstrap around their neck
and suffocate.
hThey may swallow the battery pack or other small
parts. In such a case, consult a physician
immediately.
hThey may damage their eyesight if the flash goes
off too close to their eyes.
hThey may get hurt by the camera.
kCautions when carrying the camera
iDo not walk around with the camera suspended from
your neck. It may hit other objects and get damaged.
When walking around, hold the camera in your hand
or place it in a pocket.
iBe careful not to drop the camera or subject it to
strong shocks.
iMake sure direct sunlight does not hit the camera
lens, as that may damage the internal parts. When not
using the camera, be sure to always turn it off and
close the lens cover.
kIf the camera is not going to be used for a long
period of time
iFor safety's sake, remove the battery pack from the
camera. This will prevent any possible excess heat or
leakage of battery fluid that may result in injuries or
damage to nearby objects. (Note that when the
battery pack is removed for a long period, the time and
date settings will be cleared.)
WARNING
CAUTION

English 10
kCautions during use and storage
iThis camera is a precision instrument. When using or
storing the camera, make sure to avoid the following
locations to avoid damage.
hPlaces in direct sunlight
hPlaces where humidity and temperature are high
hPlaces that may get wet
hPlaces close to an air conditioner or heater
hInside a car
hPlaces where there is dust and dirt
hPlaces where there is a fire burning
hPlaces where volatile products are stored
hPlaces subject to vibration
CAUTION
Operating environment:
hTemperature 0 to 40°C (32 to 104°F) (operation)
–20 to 60°C (–4 to 140°F) (storage)
hHumidity 30 to 90% (operation, no condensation)
10 to 90% (storage, no condensation)

11 English
USING YOUR CAMERA SAFELY AND CORRECTLY
DOCKING STATION AND AC ADAPTOR/CHARGER
kDo not recharge battery packs that are not Li-ion
battery packs (Model DB-L20)
iDo not recharge a battery pack other than the
supplied Li-ion battery pack (DB-L20). Recharging a
dry-cell battery or other type of rechargeable battery
may cause excess heat, combustion, or leakage, and
cause a fire, injuries, burns, or damage to nearby
objects.
kConcerning the power cord
iThe voltage rating for the power cord supplied with
this camera conforms to the standards of the country
in which the camera was sold.
kDo not disassemble or modify
iIt is dangerous to touch the inside. Doing so may
cause a fire or electric shock.
iDo not use as a direct current generator.
kDo not get the docking station or AC adaptor/
charger wet
iMake sure they do not get wet, as doing so may cause
a fire or electric shock.
iDo not use the camera in a bathroom.
iIf the docking station or AC adaptor/charger gets wet,
immediately unplug it from the power outlet and
remove the battery pack. Then contact the place of
purchase. If used while wet, it may cause a fire,
electric shock, or an accident.
DANGER

English 12
kCautions when plugging in
iSecurely plug the power cord all the way into the
power outlet. If the docking station or AC adaptor/
charger is used with the power cord not fully plugged
in, heat may be generated and cause a fire.
iDo not use if the power cord is damaged or cannot be
correctly plugged into the power outlet. Using in this
condition may cause a fire or electric shock.
iDo not allow dust, etc., to build up on the power cord
or power outlet. A build-up of dust may cause a short
circuit or generate heat and cause a fire.
iWhen unplugging the power cord, be sure to hold the
plug part and slowly pull it out of the power outlet.
Pulling the cord portion may damage the power cord
and cause a fire or electric shock.
kDo not pull on the power cord to unplug it
iDo not leave the power cord plugged into the power
outlet while the other end is not plugged into the
docking station or AC adaptor/charger. The loose end
can cause electrocution if touched with wet hands or if
handled by children.
iUse only the supplied power cord. If a different power
cord is used, it may be rated for a different current
load, and that may cause a fire.
iThe supplied power cord is for exclusive use with the
devices supplied with your camera. Do not use it with
other devices, as doing so may cause a fire or electric
shock.
iDo not use a bundled power cord, as the heat
generated may cause a fire.
iWhen using an extension cord, make sure that the
total wattage of the connected devices does not
exceed the rated value of the extension cord. If the
power load exceeds the rated value, it may cause a
fire.
DANGER

13 English
USING YOUR CAMERA SAFELY AND CORRECTLY
kKeep out of the reach of children
iChildren may place the battery pack or other small
components in their mouth or perform some other
such unforeseeable action. If swallowed, consult a
physician immediately.
kIf smoke or a strange odor is emitted, or if strange
noises are heard, immediately unplug the power
cord from the power outlet
iIf used under these conditions, it make cause a fire or
electric shock.
iIf strange conditions such as these occur, immediately
unplug the device, remove the battery pack, and wait
to make sure no more smoke is emitted. Then contact
the place of purchase. Do not try to repair or open the
device yourself.
kDo not handle with wet hands
iHandling the docking station or AC adaptor/charger
with wet hands may cause an electric shock.
kDo not use during a storm
iDo not touch the docking station, AC adaptor/charger
or power cord while it is plugged into a power outlet
during a thunderstorm. Doing so may cause an
electric shock.
DANGER

English 14
kDo not damage the power cord
iDo not place heavy objects on the power cord. Do not
place the power cord near a heat source. Do not
excessively bend the power cord, modify it, or secure
it with staples. Doing so may damage the power cord
and cause a fire or electric shock.
iIf the power cord is damaged, or if it does not plug
properly into the docking station, AC adaptor/charger
or wall outlet, contact the place of purchase.
kDo not place on an unstable surface
iThe camera may fall, resulting in damage to the
camera or injury.
iIf it falls and the body is damaged, remove the battery
pack and contact the place of purchase. If used while
damaged, it may cause a fire, electric shock, or other
damage.
kOperating and storage conditions
iDo not use close to a heat source (close to a stove or
heater) or leave it exposed to direct sunlight.
CAUTION
Operating environment:
hTemperature 0 to 40°C (32 to 104°F) (charging)
–20 to 60°C (–4 to 140°F) (storage)
hHumidity 20 to 80% (charging and storage)

15 English
USING YOUR CAMERA SAFELY AND CORRECTLY
Li-ion BATTERY PACK (DB-L20)
This camera uses a Li-ion battery pack (Model
DB-L20).
kIf there is leaking, discoloration, change
of shape, rise in temperature, damaged exterior,
strange odor or any other abnormal condition,
immediately discontinue use and remove the
battery pack from the camera, taking care to keep
it well away from fire
iContinued use of the battery pack under any of these
conditions may result in fire, injury, explosion or other
serious damage.
iIf battery fluid is leaking, placing the battery pack in
close proximity to a fire or other heat source may
ignite the battery fluid and result in fire, damage,
eruption of battery fluid, or smoke fumes.
kDo not transform, take apart, or modify
iSafety mechanisms and protective devices have been
in incorporation in the battery pack for the purpose of
preventing danger. Any modification, by transforming,
disassembling, or directly soldering to it, etc., will
defeat these safety devices and possibly cause the
battery pack to catch fire, explode, or leak or spew
battery fluid.
kDo not connect the (+) and (–) terminals with a
wire or other metal implement. Do not carry loose
or keep with necklaces, hairpins, etc.
iDoing so may result in a short circuit, high voltage
flow, fire, explosion, leaking or spewing battery fluid,
or heat generation. Metal such as a wire or necklace,
etc. may cause heat to be generated.
kDo not throw the battery pack in the fire or subject
it to heat
iDoing so may cause the insulation to melt, damage
the gas discharge valve and safety mechanisms, or
ignite the battery fluid, resulting in fire or explosion.
DANGER
Batterij niet
weggooien, maar
inleveren als KCA.
NL

English 16
kDo not drop, hit, or submit the battery pack to
strong shocks
iIf the safety mechanisms and protective devices are
broken, an abnormal chemical reaction may occur
inside the battery pack, or cause the battery pack to
catch fire, explode, leak or spew battery fluid, or
generate heat.
kDo not allow the battery pack to come into contact
with fresh or salt water, or allow the terminals to
become wet
iIf the safety mechanisms and protective devices are
damaged by corrosion, an abnormal chemical
reaction may occur inside the battery pack, or cause
the battery pack to catch fire, explode, leak or spew
battery fluid, or generate heat.
kOperating and storage conditions
DANGER
iTemperature when using or recharging: 0 to 40°C (32 to 104°F)
iDo not use, recharge, store or leave the battery pack near fire or inside
a car exposed to the hot sun, etc. (locations in which the temperature
reaches 60°C [140°F] or higher).
iAt high temperatures, the safety mechanisms and protective devices
inside the battery pack may be damaged by corrosion, causing an
abnormal chemical reaction to occur, or cause the battery pack to
catch fire, explode, leak or spew battery fluid, or generate heat. If the
safety mechanisms and protective devices are damaged, the battery
pack will become unusable. An environment with extremely high or low
temperatures will cause the battery capacity to deteriorate and shorten
the usable time, and may even shorten the battery life.
iAvoid storing the battery pack with it near full charge. It is
recommended to store the battery pack when it is near fully
discharged.
iIf the battery pack is completely discharged, it may become unable to
be recharged again. To avoid this, charge the battery pack for at least
five minutes every six months.
iStorage temperature: –10 to 30°C (14 to 86°F)
iWhen not using the battery pack, remove it from the camera and store
at –10 to 30°C (14 to 86°F) in a place with no condensation.
iHumidity: 10% to 90% (no condensation)

17 English
USING YOUR CAMERA SAFELY AND CORRECTLY
kUse only the supplied docking station and AC
adaptor/charger
iIf another charger is used, the battery pack may be
overcharged, or recharged with an abnormal voltage,
causing an abnormal chemical reaction to occur, or
cause the battery pack to catch fire, explode, leak or
spew battery fluid, or generate heat.
kUse the battery pack only in the specified device
iIf the battery pack is used in a device other than that
specified, it may cause an abnormal voltage flow, or
cause the battery pack to catch fire, explode, leak or
spew battery fluid, or generate heat.
kDo not peel or damage the outer case
iDamaging the outer case, inserting nails, hitting with a
hammer, stepping on the battery pack, etc. may cause
a short circuit inside the battery pack or cause the
battery pack to catch fire, explode, leak or spew
battery fluid, or generate heat.
kIf the battery pack is leaking and the electrolyte
gets on your skin or clothing, immediately rinse
with clean water
iIf the electrolyte gets into your eyes, you risk losing
your eyesight. Immediately rinse your eyes with clean,
running water, and seek medical attention right away.
Any electrolyte that comes into contact with your skin
or clothing may harm your skin. Immediately rinse the
area with clean, running water.
kInsert the battery pack correctly, as specified
iWhen installing the battery pack in the charger or
camera, pay attention to the indicated polarity (+ and –),
and insert it correctly.
iIf the battery pack is installed with the wrong
orientation, it may cause an abnormal chemical
reaction while in the charger, an abnormal voltage
flow when it is used, or cause the battery pack to
catch fire, explode, leak or spew battery fluid, or
generate heat.
DANGER
