SUBMITTAL SHEET
SUBMITTAL SHEETSUBMITTAL SHEET
SUBMITTAL SHEET
SYSTEM INDOOR/OUTDOOR
09KHS22 09KHS22/CH0922
WALL MOUNTED HEAT PUMP
GENERAL DATA (At 230V )
POWER V/PH/HZ 230 - 208/1/6
Circuit Ampacity, Min. (A) 15
Fuse size, Max. (A) 15
COMPRESSOR Rotary-Hermetic
No. used 1
R.L. Amps - L.R. Amps (A) 4.0-30
Crankcase Heater 20W
OUTDOOR FAN - TYPE Propeller
Dia. (in.) - No. used 15-3/4 - 1
Type Drive - No. speeds Direct - 1
No. Poles - RPM 6 - 820
No. Motors - HP 1 - 1/38
CFM (High) 750
F.L. Amps. (A) 0.4
OUTDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe Type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 15.9
Face Area (sq.ft.) 3.29
Tube Size (in.) 3/8
INDOOR FAN - TYPE Cross - Flow
Dia. & Length (in.) - No. used 3-17/32 & 24-5/8 - 1
No. speeds 3 & Auto
No. Poles -RPM (High) 4-1,450
No. Motors - HP 1 - 1/75
CFM (HI/MED/LOW) 220/190/160
F.L. Amps (A) 0.2
INDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 14.1
Face Area (sq. ft.) 1.63
Tube Size (in.) 3/8
Drain Connection Size (in.) 23/32
REFRIGERANT R22
Lbs. - R22 (O.D. Unit) 2.91
Control Capillary Tube
Connection Flare
Line Length, Max (ft.) 50
Lift difference, Max (ft.) 23
Line Size - in. O.D. Discharge 1/4
Line Size - in. O.D. Suction 3/8
DIMENSIONS (in.) H x W x D
Indoor Unit - Uncrated 13-19/32 x 31- 1/ 2 x7- 3/32
- Crated 17- 3/16 x 33- 7/ 8 x 9 -21/32
Outdoor unit -Uncrated 20- 7/8 x 29-17/32 x 11-1/32
-Crated 23- 17/32x 35-13/32 x 13- 7/8
WEIGHT INDOOR OUTDOOR
Net (lbs.) 24.3 90.4
Shipping(lbs.) 28.7 97.0
Shipping Volume (cu.ft.) 3.2 6.7
SS09KHS22-1
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity (BTU/H) 9,000/8,800
Sensible Capacity (BTU/H) 5,690/5,530
Latent Capacity (BTU/H) 3,310/3,270
SEER 10.0/10.0
Dehumidification (Pints/H) 2.2/2.1
Amps (A) 4.5/4.6
Power Inputs (W) 950/930
HEATING
Total Capacity (BTU/H) 10,900/10,700
HSPF 6.8/6.8
Amps (A) 4.7/4.8
Power Inputs (W) 1,030/980
Back-up Strip Heater (KW) 1.0/0.82
Outdoor Sound Rating(bels) 7.0
FEATURE
Controls Microprocessor
Remote Controller LCD Wireless type
Temperature Control IC Thermostat
Timer ON/OFF, 24 hours
Night Setback Built-In
Air Louver (Horizontal) Manual
(Vertical) Manual
Power Failure Automatic Restart Built-In
Self Diagnosis Built-In
Heating/Cooling Automatic Changeover Built-In
OPTION
Refrigerant Line Set AP0905BH (15 ft)
AP0907BH (20 ft)
AP0910BH (30 ft)
Low Ambient Control N/A
Fresh Air Intake N/A
Central Remote ON-OFF Control Available
Airduct Extension N/A
Indoor Frame Extension N/A
Condensate Drain Pump Available
Non-Removable Remo-con Bracket Available
OPERATING RANGE
Cooling Indoor Air Outdoor Air
Intake Temp. Intake Temp.
Maximum 95 F DB/71 F WB 115 F DB
Minimum 67 F DB/57 F WB 67 F DB
Heating Maximum 80 F DB/67 F WB 75 F WB/65 F WB
Minimum - F DB/ - F WB 17 F WB/15 F WB
CERTIFICATION
09KHS22
AIRCONDITIONING PRODUCTS

DIMENSIONAL DATA
Indoor Unit: KHS0921, KHS0922
Wireless remote
control unit
31-1/2
7-3/32
7-11/64 17-23/32
Rear panel
(center point
of gravity)
6-23/32
13-19/32
1-49/64
3-3/4
15/32
1-49/64
1-3/8
5-1/2
1-49/64
Center of
tubing hole
(for right
rear)
O.D. 3/8" wide tubing
O.D. 1/4" narrow tubing
Drain hose O.D. 23/32
1-5/8
6-7/64
2-13/64 19/32
Outdoor Unit: CH0921, CH0922
4 15/32 dia. hole
Air intake
Air discharge
23-15/16 2-3/8
29-17/32
Air
intake
Check port
2-1/4 1-3/16 9-27/32
20-7/8
21/32
2-23/32 2-3/8
1/4" narrow tubing
service valve
3/8" wide tubing
service valve
10-23/32
11-7/8
WARRANTY
SANYO products are warranted against defects in materials and workmanship for the
period below;
LABOR PARTS
Compressor 30 Days 5 Years
Other Components N/A 1 Year
Because of a policy of continuous product improvements, SANYO reserves the right
to change specifications and design without notice.
Full specific warranty rights, conditions, exclusions and obligations are specified in the
warranty packed with each products.
SANYO FISHER COMPANY
A Division of SANYO North America Corporation
21605 Plummer St. Chatsworth, CA 91311
Phone : [phone]
Fax : [phone]
Website: http://www.sanyohvac.com
