SUBMITTAL SHEET
SUBMITTAL SHEETSUBMITTAL SHEET
SUBMITTAL SHEET
SYSTEM INDOOR/OUTDOOR
18KHS22 KHS1822/CH1822
WALL MOUNTED HEAT PUMP
GENERAL DATA (AT 230V)
POWER V/PH/HZ 230-208/1/60
Circuit Ampacity, Min. (A) 30
Fuse size, Max. (A) 30
COMPRESSOR Rotary-Hermetic
No. used 1
R.L. Amps - L.R. Amps (A) 7.1 - 52.0
Crankcase Heater (W) 30
OUTDOOR FAN - TYPE Propeller
Dia. (in.) - No. used 15 3/4 - 1
Type Drive - No. speeds Direct - 2
No. Poles - RPM (High) 6 - 1,020
No. Motors - HP 1 - 1/12
CFM (High) 1,190
F.L. Amps. (A) 0.5
OUTDOOR COIL – TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe Type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 15.9
Face Area (sq.ft.) 5.34
Tube Size (in.) 3/8
INDOOR FAN - TYPE Cross - Flow
Dia. & Length (in.) - No. used 4 & 30-1
No. speeds 3 & Auto
No. Poles -RPM (High) 4-1,600
No. Motors - HP 1 - 1/75
CFM (HI/MED/LOW) 440/380/320
F.L. Amps (A) 0.4
INDOOR COIL – TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 14.1
Face Area (sq. ft.) 2.08
Tube Size (in.) 3/8
Drain Connection Size (in.) 1 - 1/4
REFRIGERANT R22
Lbs. - R22 (O.D. Unit) 4.25
Control Capillary Tube
Connection Flare
Line Length, Max (ft.) 65
Lift difference, Max (ft.) 23
Line Size - in. O.D. Discharge 1/4
Line Size - in. O.D. Suction 5/8
DIMENSIONS (in.) H x W x D
Indoor Unit -Uncrated 14- 3/16 x 39 x 7-13/16
-Crated 18 x 42-17/32 x 10-23/32
Outdoor unit -Uncrated 24-13/16 x 32-11/16 x 12-13/32
-Crated 28- 3/32 x 39- 5/32 x 16- 9/32
WEIGHT INDOOR OUTDOOR
Net (lbs.) 29.8 134.5
Shipping (lbs.) 37.5 143.3
Shipping Volume (cu.ft.) 4.8 10.3
SS18KHS22-1
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity (BTU/H) 16,500/16,000
Sensible Capacity (BTU/H) 10,390/10,060
Latent Capacity (BTU/H) 6,110/5,940
SEER 10.0/10.0
Dehumidification(Pints/H) 5.3/5.2
Amps (A) 8.0/8.6
Power Inputs (W) 1,810/1,760
HEATING
Total Capacity (BTU/H) 18,000/17,600
HSPF 6.8/6.8
Amps (A) 8.0/8.6
Power Inputs (W) 1,810/1,760
Back-up Strip Heater (KW) 1.80/1.47
Outdoor Sound Rating (bels) 7.8
FEATURE
Controls Microprocessor
Remote Controller LCD Wireless type
Temperature Control IC Thermostat
Timer ON/OFF, 24 hours
Night Setback Built-In
Air Louve (Horizontal) Manual
(Vertical) Automatic
Power Failure Automatic Restart Built-In
Self Diagnosis Built-In
Heating/Cooling Automatic Changeover Built-In
OPTION
Refrigerant Line Set AP2507BH (20 ft)
AP2510BH (30 ft)
AP2515BH (50 ft)
Low Ambient Control N/A
Fresh Air Intake N/A
Central Remote ON-OFF Control Available
Airduct Extension N/A
Indoor Frame Extension PLB 182
Condensate Drain Pump Available
Non-Removable Remo-con Bracket Available
OPERATING RANGE
Cooling Indoor Air Outdoor Air
Intake Temp. Intake Temp.
Maximum 95 F DB/71 F WB 115 F DB
Minimum 67 F DB/57 F WB 67 F DB
Heating Maximum 80 F DB/67 F WB 75 F DB / 65 F WB
Minimum - F DB/ - F WB 17 F DB/ 15 F WB
CERTIFICATION
18KHS22
AIRCONDITIONING PRODUCTS

DIMENSIONAL DATA
Indoor Unit: KHS1822
Outdoor Unit: CH1822
38-31/32
14-3/16
7-25/32
Rear panel
(Center point of gravity)
Drain hose O.D. 1-1/4
Narrow tube O.D. 1/4
Wide tube O.D. 5/8
Center of
tubing hole
(For right rear)
5-19/32
1-61/64
Wireless remote
control unit
6-7/64
2-13/64 19/32
Check port
1/4 narrow tubing
service valve
5/8 wide tubing
service valve
2-3/8
3-3/4
11-7/32
1-3/162-1/432-11/16
3/4
24-13/16
Air discharge
Air
intake
Air intake
21-3/16 5-3/4
12-3/12
13-1/4
4 15/32 dia. hole
WARRANTY
SANYO products are warranted against defects in materials and workmanship for the
period below;
LABOR PARTS
Compressor 30 Days 5 Years
Other Components N/A 1 Year
Because of a policy of continuous product improvements, SANYO reserves the right
to change specifications and design without notice.
Full specific warranty rights, conditions, exclusions and obligations are specified in the
warranty packed with each products.
SANYO FISHER COMPANY
A Division of SANYO North America Corporation
21605 Plummer St. Chatsworth, CA 91311
Phone : [phone]
Fax : [phone]
Website: http://www.sanyohvac.com
