Sanyo WCHDX20053 Installation and user guide

WCHDX20053
Heat Pump: 16 tons VRF Outdoor Unit
Capacities
Cooling: Btu/h
Power Input: KW
Heating: Btu/h
Power Input: KW
Cooling Mode Nominal Conditions
Indoor: °F DB/°F WB
Outdoor: °F DB
Pipe Length (feet):
Level Difference (feet):
Heating Mode Nominal Conditions
Indoor: °F DB
Outdoor: °F DB/ °F WB
Pipe Length (feet):
Level Difference (feet):
Operating Range
Cooling: °F DB:
Heating: °F DB:
Compressor
Quantity/Type:
Capacity Control Range:
Fan
Quantity/Type:
Fan Motor Output (KW):
Power Supply
V/PH/Hz.
Minimum circuit Amps (MCA): Amps
Max. Overcurrent Protection (MOCP):
Weight (lbs):
Refrigerant:
Coil
Coil Face Area (sq. ft.):
Number of Rows:
Protection Devices
High Pressure Switch:
Overcurrent (CT Method):
Crankcase Heaters (W):
External Finish:
191,000
15.8
215,000
15.8
80/67
95
25
0
70
47/43
25
0
Yes
Yes
25 + 32 (each)
208-230 / 3 / 60
38 (each)
50 (each)
1 Propeller Fan (each)
0.7 (each)
14 to 109
-4 to 59
1 Inverter driven rotary & 1 fixed speed scroll (each)
10-100%
650 (each)
410A
Electrostatic Powder Coating
22.5 (each)
ECO-i™Submittal Data
4 (each)
Job Name:
Location:
Engineer:
Submitted to:
Submitted by:
Reference:
Approval:
Date:
Construction:
Unit #:
Drawing #:
Compressor Warranty: 6 Years
Parts Warranty: 1 Year
Coiled Coated to Protect Against Corrosion
Salt Protection also available
PrintForm

Dimensions
Sanyo Commercial Solutions
A Division of SANYO North America
1300 Michael Drive, Suite A
Wood Dale, IL 60191 USA
www.sanyohvac.com
