Sanyo EM-N202 User manual

INSTRUCTION MANUAL EM-N202
EM-NI08
EM-MI07
Microwave Oven
;
Read these instructions carefully before using your microwave oven.
~;
If you follow the instructions, your oven will provide you with many years of
1’
good service.
SAVE THESE INSTRUCTIONS
r
@

PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
(a) Never interfere or tamper with safety interlocks.
(b) Do not place any object between the oven front face and the
door or allow soil or cleaner residue to accumulate on sealing
surfaces. Wipe the door sealing area frequently with a mild
detergent, rise and wipe dry. Never use abrasive powders or
pads.
(c) When open, the door must not be subjected to strain; for
example, a child hanging on the opened door or any load on it
could cause the oven to fall forward, and the weight could also
damage the door.
(d) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there is
no damage to the:
(1) DOOR (bent)
(2) HINGES
AND LATCHES (broken or loosened)
(3) DOOR SEALS AND SEALING SURFACES
SPECIFICATIONS
Model: EM-N202/N108/M107
Power Consumption:
1 150W
Maximum Output: 800W*
Oven Capacity:
17L
I Turntable Diameter:
\ 275 mm
I
Dimensions: (w x h x d) 461 x 256 x 355 mm
Weight: Approx.
12.5 kg
Specifications subject to change without notice.
*According to IEC-705 test procedures. The IEC-705 test procedure is an
internationally recognized method of rating microwave wattage output.
Please record your product’s information
When you call to request service, you need to know your complete model
number and serial number. Please fill in the information below. Please also
record purchase date, price and where purchased.
Model Number:
(Located on the front of the oven)
Serial Number:
(Located on the front of the oven)
Date of Purchase:
Purchase Price:
Where Purchased:

TABLE OF CONTENTS
SAFETY
■
■
■
■
SET UP
■
■
■
Proper and Safe Useof Your Oven. . . . . . . . . . . . . . . . . . . ...4
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Earthing Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Utensils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Names of Oven Parts and Accessories. . . . . . . . . . . . . . . . ...8
Turntable installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...8
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...9
OPERATION
■ OperatinglnstructionsforEM-N108/N202
●
9
●
9
●
●
●
●
●
Control Panel and Features. . . . . . . . . . . . . . . . . . . . . . . ...10
Setting Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...12
Child Lock-Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
..I2
Kitchen Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...13
Add 30 Seconds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...13
Time Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...14
Direct Access Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . ...15
Automatic Defrost By Weight.. . . . . . . . . . . . . . . . . . . . ...16
Quick Reheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...18
■ Operating
lnstruc~ons for EM-M107. . . . . . . . . . . . . . . . . . . . . 19
MAINTENANCE
■ Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
■ Questions and Answers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..21
■ Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

PROPER AND SAFE USE OF YOUR OVEN
●
●
●
●
●
✎
●
●
●
The oven must be level.
●
The turntable and turntable roller
rest must be in the oven during
cooking.
Place the cookware gently on the “
turntable and handle it carefully
to avoid possible breakage.
The oven has several built-in
safety switches to ensure that the
power remains off when the door
is open. Do not tamper with these
6
switches.
Do not operate the microwave “
oven when empty.
Do not overcook food. A small
quantity of food with low
moisture content or high fat or ●
sugar content can burn.
Do not cook bacon directly on the
turntable. Excessive local heating ●
of the turntable may cause it to
break.
When heating food in plastic or
Do not place liquids or other
foods with sealed containers in
the microwave oven, it may
explode.
Avoid heating baby bottles or
baby food jars. Transfer the food
into a suitable container for the
microwave oven. The food
temperature should be tested
before giving it to the baby.
Do not heat narrow-necked
containers, such as syrup bottles.
Do not attempt to deep-fry in your
microwave oven as the
temperature of oil cannot be
controlled.
Do not heat cans. Transfer the
contents into a microwave-safe
dish before heating.
Do not use this microwave oven
for commercial purposes. This
microwave oven is made for
household use only.
paper containers, check the oven
frequently due to the possibility of ‘?TE
cause fires in the oven.
It ts quite normal for steam to be
emitted around the door, for misting
to occur on the door, or even for
wat&
droplets to appear below the door
during the cooking cycle. This is
merely condensation from the heat of
the food.
I WARNING -
(a)
(b)
(c)
(d)
(e)
Do not adjust or repair microwave oven yourself. Do not
operate the oven if it is damaged, until it has been repaired by
a service engineer trained by the manufacturer,
It is dangerous for anyone other than a properly qualified
engineer trained by the manufacturer to carry out adjustments
or repairs.
If the power cord is damaged, it must be replaced by a special
prepared cord available from the Manufacturer or its Service
Agent,
On no account remove or interfere with any parts or screws.
THIS COULD PROVE VERY DANGEROUS.
Before use, the user should check that utensils are suitable for
use in microwave ovens.

I
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions
should be followed, including the following:
WARNING -
To reduce the risk of burns, electric shock, fire, injury to
persons or exposure to excessive microwave energy:
1. Read all instructions before using.
2. As with most cooking appliances,
close supervision is necessary to
reduce the risk of a fire in the oven
cavity.
If a fire should start or smoke is
observed:
● Keep the oven door closed
● Turn the oven off, and
● Disconnect the power cord or
shut off power at the fuse
or
circuit breaker panel.
Keep in mind the following rules at all
times:
a.
b.
c.
3.
Do not overcook food.
Overcooked food can cause fires
in the oven. Carefully attend to the
oven’s activities, especially if
paper, plastic, or other
combustibles are inside.
Do not store combustible items
such as bread, cookies, paper
products, etc. inside the oven.
They may catch fire if turned on
accidentally.
Do not use wire twist-ties in the
oven. Be sure to inspect
purchased items forwiretwist-ties
and remove before placing food in
the oven
Some products such as eggs in the
shell, water with oil or fat, sealed
containers and closed glass jars
may explode and therefore should
not be heated in this oven.
4.
5.
6.
1
8.
9.
10,
Use this oven onlv for its intended
uses as
described”in the manual. It
is not designed for industrial or
laboratory use. Never use
corrosive chemicals or vapours in
this oven.
As with any appliance, children
should use the oven only under
adult supervision.
Do not store or use this appliance
outdoors.
Keep the oven away from heat and
water sources. Exposure to heat
andwater canlowerefficie ncyand
lead to malfunctioning.
When heating water or other
liquids, use a wide necked
container to allow air bubbles to
escape freely. Using narrow-
necked containers may cause the
liquid to boil over, This may
happen even after the cooking has
stopped.
It is important to keep the door
and the oven interior clean. (See
Cleaning instructions on page 21. )
To prevent delayed eruptive
boiling of hot liquids and
beverages or scalding, stir liquid
before placing the container in the
oven and again halfway through
cooking time. Let stand in the
oven forashortti meand stir again
before removing the container.
SAVE THESE INSTRUCTIONS

EARTHING INSTRUCTIONS
This appliance must be earthed.
If there is an electrical short circuit,
earthing reduces the risk of electric
shock by providing an escape wire for
the electric current. This appliance is
equipped with a cord that has a
earthing wire with a earthing plug.
The plug must be plugged into an
outlet that is properly installed and
earthed.
UTENSILS
The electrical power cord must be
kept dry and must not be ~inched or
crushed in anv way.
~—
I WARNING - Improper use of the
I grounding plug can resukin
electric shock.
ACAUTION
Personal injury Hazard
● Tightly-closed utensils
could explode. Closed
containers are opened
and plastic pouches
pierced before
cooking,
See next page for further instructions “Materials
you can use in microwave oven or to be avoided
in microwave oven. ”
There may be certain non-metallic utensils that
are not safe to use for microwaving. If in doubt,
you can test the utensil in question following the
procedure below.
Utensil Test:
I. Fill a microwave-safe container with 1 cup of
cold water (250 mL) along with the utensil in
ql.restion.
2. Cook on maximum power (P1OO) for 1 minute.
3. Carefully feel the utensil.
If the empty utensil is warm, do not use it for
microwave cooking.
Do not exceed 1 minute testing time.

Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover
thin parts of meat or poultry to prevent overcooking. Arcing
can occur if foil is too close to oven walls. The foil should
be at least 2.5 cm away from oven walls.
Browning dish Follow manufacturer’s instructions, The bottom of
browning dish must be at least 5 mm above the turntable
Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal
tie. Make slits to allow steam to escape.
Paper plates and Use for short-term cooking/warming only. Do not leave
cups
oven unattended while cooking.
I
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a shofl-term cooking only.
Parchment paper Use as a cover to prevent spattering or a wrap for
steaming.
Plastic Microwave-safe only. Follow the manufacturer’s
instructions. Should be labeled “Microwave
Safe!’ Some
plastic containers soften as the food inside gets hot.
“Boiling bags” and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to
retain moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and to retain
moisture.
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum
tray
May cause arcing. Transfer food into microwave-safe dish.
Food carton with May cause arcing. Transfer food into microwave-safe dish.
metal handle
Metal or metal- Metal shields the food from microwave energy. Metal trim
trimmed utensils may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam cups Plastic foam may melt or contaminate the liquid inside
when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and
may split or crack.

NAMES OF OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton
Your oven comes with the following accessories:
Turntable
1
Turntable roller rest
1
Instruction Manual
1
Door Cabinet [nterlor
light Control panel
I _!.’---l----A”
c= ~“~~~~f~~~~~toopendoor
● When you open the door during
Safety interlock system cooking process, the cooking stops
Shuts off oven power if door is
without canceling the program.
Cooking resumes when the door is
opened during operation. closed. (EM-M I07). Press START to
resume cooking. (EM-NI08, N202)
TURNTABLE INSTALLATION
Turntable
Rol
side)
+
Receptacle ~
1.
2.
Place the roller rest on the cavity
bottom.
Place the turntable on top of the
roller rest as shown in the
diagram. Make sure the turntable
hub is securely locked in the
recetMacle.
●
9
●
●
●
●
Never place the turntable upside
down. The turntable should never
be restricted.
Both turntable and roller rest
must always be used during
cooking.
All food and containers of food
are always placed on the
turntable for cooking.
The turntable returns to its
original starting position when
cooking is finished. The light and
fan will remain on but microwave
power is turned off, (EM-N108,
N202)
The turntable rotates clockwise
and counterclockwise; this is
normal.
If turntable or roller rest cracks or
breaks, contact your nearest
authorized service center.

INSTALLATION
Remove all packing material and accessories.
Examine the oven for any damage such as dents or a broken door
Do not install if oven is damaged.
1. Select a level surface that provides enough open space for the inlet and/or
outlet vents.
●
●
b
8
b
●
Leave a minimum clearance of 7.5 cm above the oven.
Do not remove the legs from the bottom of the oven to ensure
proper airflow.
Blocking the inlet and/or outlet opening can damage the oven.
Do not install oven over a range, cooktop or other heat-
producing appliance.
Place the oven as far away from radios and
TV.% as possible.
Operation of microwave oven may cause interference to your
radio, TV. Plug the microwave oven into a different outlet.
When the cabinet is covered with a protective film, remove the
film to fully show the intended colour and finish.
I
2, Plug your oven into a standard household outlet.
When installing in a Built-in situation, you must aliowa minimum of 7.5cm
on each side and the top and at the back of the microwave oven for
ventilation. Failing to do so might cause damage to the microwave oven.
4’llk5
-J ~
min. 7.5 cm
.
A minimum clearance of 7.5 cm is required between the oven and any
adjacent walls including the back wall.
CAUTION: Use with care when handling oven. The control panel side of oven
is heavy inside

OPERATING INSTRUCTIONS FOR EM-N108/N202
CONTROL PANEL AND FEATURES
2-
3
8
7
5
13
EM-NI08
1
-@5
-aE9cw3-- “9
I
10
=“
2
i
L
3-
8--
7-
5-
13-
EM-N202
SA@o fm.d .xi?i..ti
@
POTATO POPCORN BE::[~~E
FROZEN
VEGETABLE START ~
b@9-
mG!!D-
E13
123
456
789
STOP
CLEAR
O“
CLOCK
DOOR RELEASE
-1
-12
4
6
9
“1 o
-11
