Sanyo EM-S2588B User manual

Microwave Oven
SERVICE MANUAL
FILE NO.
REFERENCE No. SM0911027
EM-S2588W
EM-S2588B
Specifications subject to change without notice
Product Code  Model  Suffix V/Hz/Plug  Color Function Cavity Volume  Control Panel  Destination
1 437 648 64  EM-S2588W FC2 120/60/U3 White Touch 0.7Cft. Solo English  USA
1 437 648 65 EM-S2588B FC2 120/60/U3 Black Touch 0.7Cft. Solo English USA
EM-S2588W

SCHEMATIC DIAGRAM
2

EXPLODED VIEW
3
33
34
40
41
26
26
26
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
39
35
36
38
37
29
26
29
29
29
26
27
27
43
27
44
32
32
19
29
26
6
8
42
27
26

    
REF.No. PARTS No. DESCRIPTION Q'TY REMARK
1  MM51500100231  ASS'Y Cavity  1
2  MM56400300751  Cover Wave Guide  1
3  MM51501400157  Base Plate  1
4  MM51302002950  Leg  2
5  MM51502501223  Ass'y BRKT Hing U 1 1
6  MM51300202093  Ass'y C/Panel  1  EM-S2588W
 MM51300202114  Ass'y C/Panel  1 EM-S2588B
7  MM56400101412  PCB  1
8  MM51300101400  Ass'y door  1  EM-S2588W
 MM51300101413  Ass'y door  1 EM-S2588B
9  MM51200100068  Magnetron  1
10  MM51200200340  H.V. Transformer  1
11  MM51200701307  H.V. Capacitor  1
12  MM51200900599  H.V. Diode  1
13  MM56400300751  Filter Noise  1
14  MM56201200605  Fuse  1
15  MM58600500096  Lamp + Socket lamp  1
16  MM51201000486  Power cord Ass'y  1
17  MM51201300630  Thermostat 160/95  1
18  MM53600604180  Board latch  1
19  MM51201600002  Microswitch Interlock  2
20  MM51201600604  Microswitch Monitor  1
21  MM51202800638  Harness main  1
22  MM51301102949  Lever Switch T  1
23  MM51301102958 Lever Switch U  1
24  MM57012800021  Screw CT3x8BBHC  2
25  MM57012800001  Screw 4x8  1
26  MM57012800003  Screw 4x10  14
27  MM57012800027  Screw 4x12  5
28  MM57012800016  Screw 4x20  2
30  MM57012800014  Screw 4x10  3
31  MM57012800032  Screw 4x10  2
32  MM57012500002  Spring Washer  3
33  MM51200300976  Motor Tray  1
34  MM52200100002  Coupler  1
35  MM52200200011  Ring Rotating Ass'y  1
36  MM52100500496  Tray  1
37  MM51300803274  Guide fan  1
38  MM51300902951  Fan  1
39  MM51200600162  Motor fan  1
40  MM51503201610  Damper  1
41  MM51501501923  Holder H.V.C  1
42  MM52200700003  Sponge  1
43  MM52200700439  U-plate sponge  1
44  MM51502600448  Case out  1  EM-S2588W
 MM51502600459  Case out  1  EM-S2588B
PARTS LIST
Jul./'08 4
SANYO Electric Co., Ltd.
Osaka, Japan
