Specifications
Power Rating . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
351W, 4.2A (Max)
Antenna Input Impedance . . . . . . . . . . . . . . . . . 75Ω
UHF/VHF/CATV
Digital
Receiving Channel . . . . . . . . . . . . . . . . 2 - 13 (VHF),
14 - 69 (UHF),
01, 14-94, 95-125 (CATV)
1-99 (Digital)
Remote Ready . . . . . . . . . . 32 Key Remote Control
Sound Output . . . . . . . . . . . . . . . . . . . . . . 5.0 W/CH
Intermediate Frequency
Picture IF Carrier. . . . . . . . . . . . . . . . . . 45.75MHz
Sound IF Carrier . . . . . . . . . . . . . . . . . . 41.25MHz
Color Sub Carrier . . . . . . . . . . . . . . . . . 42.17MHz
Cabinet Dimensions
Width. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1206mm
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 720mm
Depth including base . . . . . . . . . . . . . . . . 248mm
REFERENCE No. SM780114
DP42746, J3TZ, PRODUCT CODE 111009300
Contents
Safety Instructions . . . . . . . . . . . . . . . . . . 2
Service Adjustments . . . . . . . . . . . . . 3 – 5
Power Failure Circuit . . . . . . . . . . . . . . . . 6
Mechanical Disassemblies. . . . . . . . 7 – 12
Chassis Electrical Parts List . . . . . . 13 – 20
Cabinet Parts List . . . . . . . . . . . . . . . . . . 21
Component and Test Point
Locations . . . . . . . . . . . . . . . . . . . 22 – 24
Block Diagrams . . . . . . . . . . . . . . . . 25 – 28
Trouble Shooting Flow Charts . . . . 29 – 31
Control Port Functions. . . . . . . . . . . 32 – 33
Schematic Notes . . . . . . . . . . . . . . . . . . . 34
Pin Layouts. . . . . . . . . . . . . . . . . . . . . . . . 35
Capacitor and Resistor Codes . . . . . . . . 36
Board Connections . . . . . . . . . . . . . 37 – 40
Schematic Diagrams . . . . . . . . . . . . 41 – 44
AS
FILE NO.
SERVICE MANUAL Remote Control Plasma
Color Television DP42746 (U.S.A.)
(CANADA)
ORIGINAL VERSION
Chassis No. 42746-00
NOTE: Match the Chassis No. on
the unit’s back cover with
the Chassis No. in the
Service Manual.
If the Original Version
Service Manual Chassis
No. does not match the
unit’s, additional Service
Literature is required. You
must refer to “Notices” to the
Original Service Manual
prior to servicing the unit.
AS
Servicing should be performed by only trained and qualified service personnel.
with a double “Z” is a registered trademark
of Sanyo Manufacturing Corporation.
© Sanyo Manufacturing Corporation 2006

— 2 —
SAFETY PRECAUTIONS
WARNING: The chassis of this receiver has a floating
ground with the potential of one half the AC line voltage in
respect to earth ground. Service should not be attempted by
anyone not familiar with the precautions necessary when
working on this type of equipment.
The following precautions must be observed:
1. An isolation transformer must be connected in the power
line between the receiver and the AC line before any ser-
vice is performed on the receiver.
2. Comply with all caution and safety-related notes provided
inside the cabinet, on the chassis, and on the back.
3. When replacing a chassis in the cabinet, always be certain
that all the protective devices are installed properly, such
as control knobs, adjustment covers, shields and barriers.
4. Before replacing the back cover of the set, thoroughly
inspect the inside of the cabinet to see that no stray parts
or tools have been left inside.
Before returning any television to the customer, the
service technician must perform the following safety
checks to be sure that the unit is completely safe to
operate without danger of electrical shock.
ANTENNA COLD CHECK
Remove AC plug from the 120 VAC outlet and place a
jumper across the two blades. Connect one lead of an ohm-
meter to the jumpered AC plug, and touch the other lead to
each exposed antenna terminal (UHF and VHF antenna ter-
minals). The resistance must measure between 1M ohm and
5.2M ohm. Any resistance value below or above this range
indicates an abnormality which requires corrective action.
LEAKAGE CURRENT CHECK
Plug the AC line cord directly into a 120 VAC outlet. (Do not
use an isolation transformer for this check.) Use an AC volt-
meter, that has 5000 ohms per volt or more sensitivity.
Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15 µF
150 VAC capacitor, between a known good earth ground
(water pipe, conduit, etc.) and all exposed metal parts of the
cabinet (antennas, handle bracket, metal cabinet, screw
heads, metal overlays, control shafts, etc.). Measure the AC
voltage across the 1500 ohm resistor. The AC voltage
should not exceed 750 mV. A reading exceeding 750 mV
indicates that a dangerous potential exists. The fault must
be located and corrected. Repeat the above test with the
receiver power plug reversed.
NEVER RETURN A RECEIVER TO THE CUSTOMER
WITHOUT TAKING THE NECESSARY CORRECTIVE ACTION.
PRODUCT SAFETY NOTICE
When replacing components in a receiver, always keep in
mind the necessary product safety precautions. Pay special
attention to the replacement of components marked with a
star () in the parts list and in the schematic diagrams. To
ensure safe product operation, it is necessary to replace
those components with the exact same PARTS.
SERVICING ELECTROSTATICALLY SENSATIVE DEVICES
Semiconductors (solid-state devices) that can be damaged
by static electricity are referred to as Electrostatically
Sensitive (ES) devices. Examples of typical ES devices are:
Integrated Circuits (IC), Field-Effect Transistors (FET), and
“chip” components. The following techniques should be
observed strictly, to reduce the occurrence of semiconduc-
tor damage due to electrostatic discharge.
1. Immediately prior to handling any semiconductor com-
ponent or an assembly containing a semiconductor
device or devices, discharge the electrostatic buildup on
your body by touching a known earth ground. You may
also obtain and wear a commercially available discharg-
ing wrist strap device.
CAUTION: Be sure to remove the wrist strap before
applying power to any unit being serviced.
2. After removing an ES equipped assembly, place it on a
conductive surface, such as, aluminum foil, to prevent
buildup or exposure to static electricity.
3. Use only grounded-tip soldering irons to solder or unsol-
der ES devices.
4. Use only anti-static solder removal devices. Some suc-
tion-type devices can generate static electricity adequate
to damage ES devices.
5. A replacement ES device will come packaged in protective
material (conductive foam, aluminum foil, or some compa-
rable conductive material). Do Not remove an ES device
from its protective packaging unless you are prepared to
install it immediately.
6. Precisely prior to removing an ES device from its protective
packaging, touch the protective packaging to the chassis or
assembly in which the device will be installed.
CAUTION: Be sure that no power is applied to the chassis or
circuit assembly.
7. Incidental body movements, such as, lifting a foot from a
carpeted floor or the rubbing of fabric together can gener-
ate static electricity sufficient to damage ES devices.
Therefore, minimize all body movements while handling
exposed (unpackaged) ES devices.
0.15 µF 150V AC
1500 ohm
10 watt
Good earth ground
such as a water pipe,
conduit, etc.
AC OUTLET
TELEVISION
RECEIVER
READING SHOULD NOT EXCEED 750 mV.
AC VOLTMETER
(5000 ohms per volt or more sensitivity)
To be touched to all of exposed metal parts.
Voltmeter Hook-up for Leakage Current Check.
SAFETY INSTRUCTIONS

— 3 —
SERVICE ADJUSTMENTS
Volume – :Enter Service Menu
POWER VOL
CH

GENERAL
This set has an On-screen Service Menu system included in
the CPU that allows remote operation for most of the ser-
vice adjustments.
ON-SCREEN SERVICE MENU SYSTEM
1. Enter the Service Menu:
•Turn off the receiver and disconnect the AC power
supply.
•While pressing the Volume (–) button on the televi-
sion, reconnect the AC power supply. The Service
Menu will now appear. The remote can now be used
to make adjustments. See Figure 1 below.
2. Service Adjustments:
•Press the Channel or key to select the desired
service menu item you want to adjust. See page 4
for the On-screen Service Menu.
•Use the Volume + or – key or number keys to adjust
the data.
The + or – keys will increase or decrease the data
sequentially. The number keys (0 ~ 7) toggle only
their respective bits between 1 and 0 and are used to
change the Sub-Address. For example to change bit
5 press the number 5 key. See below.
Note: Using the + or – is not recommended due to possi-
ble rapid changes.
3. Exit from the Service Menu:
•Press the MENU key to turn off the Service Menu
display.
(b7) (b6) (b5) (b4) (b3) (b2) (b1) (b0)
0 1 0 1 0 1 1 0 BINARY DATA
(8 bit)
080 ATT
07 00000111
Figure 1. Service Menu Display
ITEM NO.
TITLE
BINARY DATA
(8 bit)
HEX DATA
1
4 5 6
7 8
0
9
2 3
POWER
INPUT
INFO
RECALL
MENU
CAPTION EXIT
VOL
RESETAUDIOPIX SHAPE
CH
ENTER
TUNER MUTE
SLEEP
Menu:
Exit Service Menu
Volume + / –:
Adjust Service Menu
Numeric:
0, 1, 2, 3, 4, 5, 6, 7:
Change Binary Data
Channel  :
Select Item

— 4 —
ON-SCREEN SERVICE MENU
•All data except in gray box area is fixed. Do not change for correct operation.
•Data in gray box is initial. Can be set according to adjustment information.
Table 1. ON-SCREEN SERVICE MENU
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should
be checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data
marked with an * should be changed from Initial Reference Data. See page 3 for On-Screen Service Menu access and
adjustments.
PROGRAM CODES
The microprossesor used in this model is a multi-purpose type and is used in several different models. To ensure
proper operation and the correct features for your particular model, the program codes must be correct.
Note 1. Option Data 1 (NO. 087 OPT) should be hexadeci-
mal 0A (00001010 binary). See 087 above. If this program
code is wrong the TV will not operate properly.
Note 2. Option Data 2 (NO. 088 OP2) should be hexadeci-
mal 00 (00000000 binary). See 088 above. If this program
code is wrong the TV will not operate properly.
No. TITLE INITIAL REFERENCE INITIAL SETUP INITIAL SETUP FUNCTION
DATA HEX DATA HEX DATA BINARY
080 ATT 07 07 00000111 Attenuation -MTS Input Level (3~0)
081 SPC 20 20 00100000 Spectral - High Separation (5~3)
082 WDB 20 20 00100000 Wide Band - Low Separation (5~0)
083 SCO 00 00 00000000 Sub Color (NOT AVAILABLE)
084 STI 00 00 00000000 Sub Tint (NOT AVAILABLE)
085 SB 00 00 00000000 Sub Bright (NOT AVAILABLE)
086 SSH 00 00 00000000 Sub Sharpness (NOT AVAILABLE)
087 OP1 0A 0A 00001010 b7:PDP HD=0 b3:W/HDMI=1, PDP: b1,b0=10
088 OP2 00 00 00000000 b7:HD=0
08A PER 00 00 00000000 Temperature Failure History (No Failure = 0, Failure = 1)
PUT 0000 0000 00000000 Total Operation Time
1C0 ↓↓↓00000000 Not Used
1FF ↓↓↓↓Not Used
200 1R01 00 00 00000000 ROM Correction Data
↓↓ ↓ ↓ ↓↓
298 2R48↓00 00 00000000 ROM Correcetion Data

— 5 —
SERVICE ADJUSTMENTS (Continued)
MULTI-SOUND SECTION ADJUSTMENTS
Note: Multi-Sound Section must be adjusted after
A101 (U/V Tuner), IC3401 (MTS Decoder), Digital
Module or IC802 (EEPROM) is replaced.
INPUT LEVEL ADJUSTMENT
1. Connect a signal to the analog antenna terminal with
audio of 1 KHZ100% modulation.
2. Turn off the receiver and disconnect the AC power cord
(AC 120V line).
3. Connect voltmeter (RMS) to TP317 and ground on the
Main PC board.
4. While pressing the VOLUME – key, reconnect the AC
power cord. The Service Menu will now appear.
5. Select NO. 080 (ATT: MTS Input Level) with the or 
key.
6. Adjust the + or – key for a voltmeter reading of 400 ±
20 mVrms at TP317.
Minimize L leakage
Minimize R leakage
4KHz
300Hz
TP317 (R)
TP318 (L)
Figure 2. Separation Adjustments
SEPARATION ADJUSTMENT
7. Turn off the receiver and disconnect the AC power cord
(AC 120V line).
8. Connect oscilloscope CH1 to TP317 and CH2 to TP318
and ground.
9. Connect an MTS TV/Stereo generator to antenna terminal.
10. While pressing the VOLUME – key, reconnect the AC
power cord. The Service Menu will now appear.
11.Select pilot, 300Hz audio frequency and Left modulating
signal.
12. Select NO. 082 (WDB: Wide Band) with the or key.
13. Adjust the + or – key for minimum low frequencies at
TP317. See Figure 2.
14. Select 4 KHz audio frequency and Right modulating signal.
15. Select NO. 081 (SPC: Spectral) with the or key.
16. Adjust the + or – key for minimum high frequencies at
TP318. See Figure 2.
Repeat adjustments (steps 11–16) until no further decreases
in amplitude can be obtained. Press the MENU key to turn
off the Service Menu display.

— 6 —
POWER FAILURE CIRCUIT
32
41
IC801 (CPU)
D1606
D1607
39
11 10 3 4 9 5 6 11
4
D1605 D1604 D1603 D1601
14
Power Fail
Power On
Thermal Detector
D1602
K8MA
DIGITAL
BOARD
IC1601
A9V
POWER BOARD
K8B K8A
Q803
Q801
D5V
12V AMP
TV33V
D3.3V
A5V
CPU (IC801) is programmed so the set will go to the stand-
by mode when there is circuit failure as described below.
(Refer to”Power Supply Lines.”)
1. Power Failure : Detected voltage failure. (Connected to
IC801 pin 32.)
(Normal: High; Failure: Low)
2. Temperature Failure : Detected temperature failure for
Power Unit of PDP module. (Connected to IC801 pin 41.)
(Normal: Low; Failure: High)
LED Flashing
When IC801 detects the Power Failure 3 times the LED will
flash to indicate a power failure has occurred.
Note: The LED does not flash for Temperature Failures.
Note: If power failure is detected 3 times in 15 minutes, the
set will enter the standby mode and cannot be
switched On. To reset the operating programs of the
CPU it is necessary to disconnect the AC cord for a
short time.
History of Power Failure
When finishing the repair or stopping the Power Failure,
the history of past failures can be checked.
To see the history
1. Enter the service mode. See “Service Adjustments”
page 3.
2. Select Item No. 08A PER Temperature Error.
If Temperature Failure has accured the data in Item No.
08A will be 01h (1).
Attention:
After servicing, reset the data of Item No. 08A to 00h (0)
with the Volume + or – key.

— 7 —
MECHANICAL DISASSEMBLY
BACK CABINET REMOVAL – SIDES
Remove 24 screws to take the side cabinets off.
(A:3X8, 6pcs; B:4X12, 18pcs)
BACK CABINET REMOVAL– CENTER
Remove 31 screws to take the back cabinet off.
(C:3X8, 10pcs; D:4X12, 17pcs; E:6X18, 4pcs)
A
B
B
B
A
B
B
A
B
BBB
A
BB B
A
B
B
A
B
B
BB
D
E
E
D
D
DD
E
E
DDDD
D
D
D
CCC
C
CCC
CC
DD
C
DD
D

— 8 —
BOARD LOCATIONS
1: MAIN BOARD REMOVAL
Remove 2 tuner nuts (Digital and Analog) and take off the
terminal base. Disconnect plugs K8MB, K8MA, K8A, K8B,
K8F, K8E, and KSP. Remove 11 screws (3X8: 2 types) to
take the main board with the shield case (assembly parts)
off.
2: D-TU BOARD REMOVAL
Remove the terminal base. Disconnect plug K8LV. Remove
5 screws (3X8) to take the D-TU (digital) board with the
shield case (assembly parts) off.
3: FILTER BOARD REMOVAL
Disconnect plug KAC. Remove 3 screws (3X8) to take the
filter board with the shield case (assembly parts) off.
4: KEY SW BOARD REMOVAL
Disconnect plug K8E. Remove a screw (4X12) to take the
key switch board with the panel, button, and holder
(assembly parts) off.
5: CONTROL BOARD REMOVAL
The control board can be taken off, after the filter glass is
removed. (Refer to ‘FILTER GLASS REMOVAL’.)
6: SPEAKER REMOVAL
Disconnect plug KSP. Remove 4 screws (4X10) to take off
each speaker.
1
23
4
5
6 6
Hook
Terminal
Base
MECHANICAL DISASSEMBLY (CONT.)
SCREW LOCATIONS

— 9 —
AC IN120V
ACIN 120V
UHF/VHF/CATV
UHF/VHF/CATV
DIGITAL
DIGITAL
ANTENNA IN
ANTENNAIN
SERVICE
SERVICE
DIGITAL
DIGITAL
AUDIO
AUDIO
OUTPUT
OUTPUT
HDMI
HDMI
INPUT
INPUT
STAND REMOVAL
Position TV face down on a padded or cushioned surface to protect the screen and finish.
Remove 2 screws (6X18) from each foot and remove.
FILTER GLASS REMOVAL
1. Remove the key switch board.
2. Disconnect the following socket connections.
Control Board ~ Main Board: K8E
Speakers ~ Main Board: KSP
3. Remove 8 screws (4X8) to take the panel module, power unit,
and panel holders (Mounting Brackets) with boards off.
KAC
K8E
KSP
K8P
K8B
K8A
K8LV
K8MA
K8MB
PLUG LOCATIONS

— 10 —
FRONT CABINET REMOVAL
1. Remove 18 screws (F:4X12) to take the filter glass with upper and
lower plates (assembly parts) off.
2. Remove the speakers.
3. Remove a screw (4X10) to take the control board and holder off.
F
F
F
F
FF F F F F
F
F
F
F
F
F
F
F
4. Remove 20 screws (G:3X8) to take the filter glass and upper plates off.
MECHANICAL DISASSEMBLY (CONT.)
GG
G
G
GG G G G G G G
G
G
G
GGGG
G
FILTER GLASS REMOVAL (Cont.)

— 11 —
PANEL MODULE REMOVAL
1. Remove the key switch board.
2. Disconnect the following socket connections.
Main Board ~ Power Unit: CN8004, CN8007
D-TU Board ~ Power Unit: CN8010
Filter Board ~ Power Unit: CN8001
Control Board ~ Main Board: K8E
Speakers ~ Main Board: KSP
PDP Module ~ D TU Board K8LV
3. Remove the main board, D-TU board, and filter board.
4. Remove the 16 screws from the panel holders (Mounting
Brackets) to take the panel module off.
(H:4X8, 14pcs; I:5X10, 2pcs)
HH
H
H
H
H
HH
H
HH
H
H
H
I
H
H
H
HHI
H
Control Board (Upper)
Holder (Lower)

— 12 —
POWER UNIT REMOVAL
Remove 9 screws to take the power unit off.
ATTENTION
This PDP TV uses several different kinds of
screws. Using the correct screw is required to
prevent damage.
The gasket is provided to prevent interference
to other radio and television receivers. The
gasket must be returned to its previous position
after servicing.
Lead wires must be redressed to previous posi-
tions after servicing.
MECHANICAL DISASSEMBLY (CONT.)

— 13 —
CHASSIS ELECTRICAL PARTS LIST
CAUTION: To Protect against electrical shock and for continued product safety, refer to SAFETY PRECAUTIONS,
and PRODUCT SAFETY NOTICE on Page 2.
PRODUCT SAFETY NOTICE
PRODUCT SAFETY SHOULD BE CONSIDERED WHEN A REPLACEMENT IS MADE IN ANY AREA OF A RECEIVER.
COMPONENTS INDICATED BY A STAR () IN THIS PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE
COMPONENTS IN WHICH SAFETY CAN BE OF SPECIAL SIGNIFICANCE. IT IS PARTICULARLY RECOMMENDED
THAT ONLY PARTS DESIGNATED ON THE FOLLOWING PARTS LIST BE USED FOR COMPONENT REPLACEMENT
DESIGNATED BY A STAR. NO DEVIATIONS FROM RESISTANCE,WATTAGE, ANDVOLTAGE RATINGS MAY BE MADE
FOR REPLACEMENT ITEMS DESIGNATED BY A STAR.
Note: Schematic part location numbers may not always match with the part descriptions.
The part descriptions are correct and should be used.
Tolerance Symbols:
A...0.05% B...0.1% C...25%
D...0.5% F...1% G...2%
J...5% K...10% M...20%
P...+5 -15%
Rated Value, ohms:
K...1,000 M...1,000,000
Material:
CARBON .............
MT-FILM ..............
OXIDE-MT ...........
SOLID ..................
MT-GLAZE ...........
WIRE WOUND .....
CERAMIC RES ....
FUSIBLE RES .....
Performance Symbols:
A...General B...Non-flammable
Z...Low noise
Other... Temperature coefficient
Rated Wattage
CARBON 4.7K J A 1/4W
Read description of the Resistor as follows:
NOTES:
(Example)
Carbon
Metal Film
Oxide Metal Film
Composition
Metal Glaze
Wire Wound
Ceramic
Fusible
RESISTORS
NOTES:
Read description of the Capacitor as follows:
(Example)
CERAMIC 100P K 50V
Rated Voltage
Tolerance Symbols:
Less than 10pF
A :Not specified B : ±0.1% C : ±0.25%
D : ±0.5% F : ±1% G : ±2%
H :±3% J :±5% K :±10%
L :±15% M :±20% N :±30%
P :+100-0% Q :+30-10% T :+50-10%
U :+75-10% V :+20-10% W :+100-10%
X :+40-20% Y :+150-10% Z : +80-20%
A : Not specified B : ±0.1pF C : ±0.25pF
D : ±0.5pF E : +0 -1pF F : ±1PF
G : ±2pF H : +0.1 -0pF L : +0 -0.1pF
R : ±0.25 -0pF S : +0-0.25pF
More than 10pF
Rated value: P=pico farad, U=micro farad
Material:
CERAMIC........... Ceramic
MT-PAPER......... Metallized Paper
POLYESTER...... Polyester
MT-POLYEST.....Metallized Polyester
POLYPRO.......... Polypropylene
MT-POLYPRO.... Metallized Polypropylene
COMPO FILM..... Composite Film
MT-COMPO........ Metallized Composite
STYRENE........... Styrene
TA-SOLID........... Tantalum Solid
AL-SOLID........... Aluminium Solid
ELECT................ Electrolytic
NP-ELECT.......... Non-polarised Electrolytic
OS-SOLID.......... Aluminium Solid with Organic
Semiconductive Electrolytic
CAPACITORS

— 14 —
Schematic
Location Part No. Description Schematic Location Part No. Description
MAIN PC BOARD
CAPACITORS
C002 CE1C470M4ZANN ELECT 47U M 16V
C004 CK1H472KLZBNG CERAMIC 4700P K 50V
C005 CE1E4R7M4ZANN ELECT 4.7U M 25V
C007 CK1H472KLZBNG CERAMIC 4700P K 50V
C008 CE1E4R7M4ZANN ELECT 4.7U M 25V
C009 CE1E4R7M4ZANN ELECT 4.7U M 25V
C012 CE1C102M4ZANN ELECT 1000U M 16V
C013 CE1C102M4ZANN ELECT 1000U M 16V
C015 CEXLB1C101WAN ELECT 100U M 16V
C016 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C017 CH1H103JAGANN MT-COMPO 0.01U J 50V
C018 CH1H103JAGANN MT-COMPO 0.01U J 50V
C019 CH1H103JAGANN MT-COMPO 0.01U J 50V
C020 CH1H103JAGANN MT-COMPO 0.01U J 50V
C101 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C102 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C105 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C106 CEXLB1H470WAN ELECT 47U M 50V
C107 CEXLB0J102WAN ELECT 1000U M 6.3V
C805 CC1H220JLZCNG CERAMIC 22P J 50V
C806 CC1H220JLZCNG CERAMIC 22P J 50V
C807 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C810 RGF5602JTCANL MT-GLAZE 56K JA 1/10W
C811 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C813 CEXLB1A470WAN ELECT 47U M 10V
C814 CK1H222KLZBNG CERAMIC 2200P K 50V
C815 CC1H220JLZCNG CERAMIC 22P J 50V
C816 CC1H220JLZCNG CERAMIC 22P J 50V
C820 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C824 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C825 CC1H330JLZCNG CERAMIC 33P J 50V
C826 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C827 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C829 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C834 CEXLB1C220WAN ELECT 22U M 16V
C835 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C836 CC1H120JLZCNG CERAMIC 12P J 50V
C837 CC1H120JLZCNG CERAMIC 12P J 50V
C838 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C839 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C840 CK1H333KLZBNG CERAMIC 0.033U K 50V
C841 CEXLB1H2R2WAN ELECT 2.2U M 50V
C843 CC1H221JLZCNG CERAMIC 220P J 50V
C1001 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1002 CEXLB1C100WAN ELECT 10U M 16V
C1003 CEXLB1C100WAN ELECT 10U M 16V
C1004 CEXLB1H2R2WAN ELECT 2.2U M 50V
C1005 CEXLB1H2R2WAN ELECT 2.2U M 50V
C1021 CEXLB1C101WAN ELECT 100U M 16V
C1022 CEXLB1C100WAN ELECT 10U M 16V
C1023 CEXLB1C100WAN ELECT 10U M 16V
C1024 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1025 CEXLB1C100WAN ELECT 10U M 16V
C1026 CEXLB1H2R2WAN ELECT 2.2U M 50V
C1027 CEXLB1H2R2WAN ELECT 2.2U M 50V
C1061 CEXLB1C101WAN ELECT 100U M 16V
C1062 CEXLB1C100WAN ELECT 10U M 16V
C1063 CEXLB1C100WAN ELECT 10U M 16V
C1064 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1065 CEXLB1C100WAN ELECT 10U M 16V
C1066 CEXLB1H2R2WAN ELECT 2.2U M 50V
C1067 CEXLB1H2R2WAN ELECT 2.2U M 50V
C1101 CEXLB1E4R7WAN ELECT 4.7U M 25V
C1102 CEXLB1E4R7WAN ELECT 4.7U M 25V
C1201 CEXLB1C101WAN ELECT 100U M 16V
C1202 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1203 CEXLB1C100WAN ELECT 10U M 16V
C1251 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1601 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1602 CEXLB0J221WAN ELECT 220U M 6.3V
C1603 CEXLB1C221WAN ELECT 220U M 16V
C1604 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1605 CEXLB1C221WAN ELECT 220U M 16V
C1606 CEXLB1H470WAN ELECT 47U M 50V
C1607 CEXLB1C221WAN ELECT 220U M 16V
C1608 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1612 CEXLB0J221WAN ELECT 220U M 6.3V
C1613 CEXLB0J221WAN ELECT 220U M 6.3V
C1614 CEXLB0J221WAN ELECT 220U M 6.3V
C1616 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1617 CEXLB0J221WAN ELECT 220U M 6.3V
C1618 CEXLB0J221WAN ELECT 220U M 6.3V
C1619 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1620 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1621 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1623 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C1624 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1625 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1801 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1851 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1852 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1853 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1854 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C1855 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C3401 CPXLB1H4R7ZAN NP-ELECT 4.7U M 50V
C3402 CEXLB1HR10WAN ELECT 0.1U M 50V
C3403 CPXLB1H4R7ZAN NP-ELECT 4.7U M 50V
C3404 CK1H562KLZBNG CERAMIC 5600P K 50V
C3405 CK1H123KLZBNG CERAMIC 0.012U K 50V
C3406 CEXLB1H1R0WAN ELECT 1U M 50V
C3407 CEXLB1HR47WAN ELECT 0.47U M 50V
C3408 CEXLB1C470WAN ELECT 47U M 16V
C3409 CEXLB1E4R7WAN ELECT 4.7U M 25V
C3410 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
C3411 CPXLB1H4R7ZAN NP-ELECT 4.7U M 50V
C3412 CEXLB1E4R7WAN ELECT 4.7U M 25V
C3413 CEXLB1C471WAN ELECT 470U M 16V
C3414 CPXLB1H4R7ZAN NP-ELECT 4.7U M 50V
C3415 CK1H272KLZBNG CERAMIC 2700P K 50V
C3416 CK1H473KLZBNG CERAMIC 0.047U K 50V
C3417 CT1A3R3KDRANG TA-SOLID 3.3U K 10V
C3418 CPXLB1H4R7ZAN NP-ELECT 4.7U M 50V
C3419 CT1A100KDRANG TA-SOLID 10U K 10V

— 15 —
Schematic
Location Part No. Description Schematic Location Part No. Description
C3420 CEXLB1H1R0WAN ELECT 1U M 50V
C3421 CEXLB1H1R0WAN ELECT 1U M 50V
C3422 CEXLB1H1R0WAN ELECT 1U M 50V
C3423 CEXLB1H1R0WAN ELECT 1U M 50V
C3424 CEXLB1H1R0WAN ELECT 1U M 50V
C3425 CK1H223KLZBNG CERAMIC 0.022U K 50V
C3426 CK1H472KLZBNG CERAMIC 4700P K 50V
C3427 CPXLB1H4R7ZAN NP-ELECT 4.7U M 50V
C3428 CEXLB1HR10WAN ELECT 0.1U M 50V
C3429 CK1H472KLZBNG CERAMIC 4700P K 50V
C3430 CEXLB1C471WAN ELECT 470U M 16V
DIODES
D001 DDRB551V-30-G DIODE RB551V-30 TE-17
D801 DD1SS355----G DIODE 1SS355 TE-17
D802 DZUDZS6.2B--G ZENER DIODE UDZS6.2B TE-17
D803 DD1SS355----G DIODE 1SS355 TE-17
D1601 DD1SS355----G DIODE 1SS355 TE-17
D1602 DD1SS355----G DIODE 1SS355 TE-17
D1603 DD1SS355----G DIODE 1SS355 TE-17
D1604 DD1SS355----G DIODE 1SS355 TE-17
D1605 DD1SS355----G DIODE 1SS355 TE-17
D1606 DD1SS355----G DIODE 1SS355 TE-17
D1607 DZUDZS3.0B--G ZD UDZS3.0B-TE-17
D1801 DZUDZS10B---G ZENER DIODE UDZS10B TE-17
D3401 DDRB551V-30-G DIODE RB551V-30 TE-17
INTEGRATED CIRCUITS
IC001 QLA42072N-E-N IC LA42072N-E
IC801 QXXAAJQ0730-- IC LC87F4164AU-PDP001
QXXAVC779---M IC LC874164A-57XX-E
IC802 Q24LC08BT/SNP IC 24LC08BT/SN
IC803 QMN1381-Q---N IC MN1381-Q
IC805 QTC7SH08FU--P IC TC7SH08FU
IC806 QTC7SET08F--P IC TC7SET08F-TE85L
IC1201 QCD4052BNSR-P IC CD4052BNSR
QTC4052BF---P IC TC4052BF-EL
IC1251 QCD4052BNSR-P IC CD4052BNSR
QTC4052BF---P IC TC4052BF-EL
IC1601 QBA90BC0WFP-P IC BA90BC0WFP-E2
IC1604 QXXAVC550---G IC PQ018EZ02ZPH
IC3401 QCXA2234Q---P IC CXA2234Q-T6
COILS
L001 1AV4L26B2770G INDUCTOR, 220 OHM
L002 1AV4L26B2770G INDUCTOR, 220 OHM
L004 1AV4L26B2770G INDUCTOR, 220 OHM
L005 1AV4L26B2770G INDUCTOR, 220 OHM
L101 1AV4L2FB3R3MG INDUCTOR, 3.3U M
L102 1AV4L2FB3R3MG INDUCTOR, 3.3U M
L103 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L106 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L107 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
L801 1AV4L2FB3R3MG INDUCTOR, 3.3U M
L802 1AV4L26B2770G INDUCTOR, 220 OHM
L805 1AV4L26B0130G INDUCTOR, 600 OHM
L806 1AV4L26B0130G INDUCTOR, 600 OHM
L1021 1AV4L2FB3R3MG INDUCTOR, 3.3U M
L1201 1AV4L2FB3R3MG INDUCTOR, 3.3U M
L1601 1AV4L26B2770G INDUCTOR, 220 OHM
L1602 1AV4L26B2770G INDUCTOR, 220 OHM
L1605 1AV4L26B0130G INDUCTOR, 600 OHM
L1609 1AV4L26B2770G INDUCTOR, 220 OHM
L1610 1AV4L26B2770G INDUCTOR, 220 OHM
L1611 1AV4L26B2770G INDUCTOR, 220 OHM
L1612 1AV4L26B2770G INDUCTOR, 220 OHM
L1615 1AV4L26B2770G INDUCTOR, 220 OHM
L1616 1AV4L26B2770G INDUCTOR, 220 OHM
L1617 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1618 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1619 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1620 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1801 1AV4L26B0130G INDUCTOR, 600 OHM
L1803 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1804 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1805 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1806 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1807 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1808 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1809 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1810 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1815 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1885 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1891 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1893 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1894 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1895 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L1896 RGFR000ZTAANL MT-GLAZE 0.000 ZA 1/10W
L3401 1AV4L2FB3R3MG INDUCTOR, 3.3U M
TRANSISTORS
Q101 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q102 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q801 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB

— 16 —
Schematic
Location Part No. Description Schematic Location Part No. Description
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q803 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q804 T2SA1037AK-RP TR 2SA1037AK T146 R
T2SA1037AK-SP TR 2SA1037AK T146 S
T2SA1037K-R-P TR 2SA1037K-T-96-R
T2SA1037K-S-P TR 2SA1037K-T-96-S
T2SA1179-M6-P TR 2SA1179-M6
T2SA1179-M7-P TR 2SA1179-M7-TB
T2SA1179N-M6P TR 2SA1179N-M6-TB
T2SA1179N-M7P TR 2SA1179N-M7-TB
T2SA1235A1E-P TR 2SA1235A1E
T2SA1235A1F-P TR 2SA1235A1F
Q805 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q901 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q902 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q1021 T2SA1037AK-RP TR 2SA1037AK T146 R
T2SA1037AK-SP TR 2SA1037AK T146 S
T2SA1037K-R-P TR 2SA1037K-T-96-R
T2SA1037K-S-P TR 2SA1037K-T-96-S
T2SA1179-M6-P TR 2SA1179-M6
T2SA1179-M7-P TR 2SA1179-M7-TB
T2SA1179N-M6P TR 2SA1179N-M6-TB
T2SA1179N-M7P TR 2SA1179N-M7-TB
T2SA1235A1E-P TR 2SA1235A1E
T2SA1235A1F-P TR 2SA1235A1F
Q1022 T2SA1037AK-RP TR 2SA1037AK T146 R
T2SA1037AK-SP TR 2SA1037AK T146 S
T2SA1037K-R-P TR 2SA1037K-T-96-R
T2SA1037K-S-P TR 2SA1037K-T-96-S
T2SA1179-M6-P TR 2SA1179-M6
T2SA1179-M7-P TR 2SA1179-M7-TB
T2SA1179N-M6P TR 2SA1179N-M6-TB
T2SA1179N-M7P TR 2SA1179N-M7-TB
T2SA1235A1E-P TR 2SA1235A1E
T2SA1235A1F-P TR 2SA1235A1F
Q1023 T2SA1037AK-RP TR 2SA1037AK T146 R
T2SA1037AK-SP TR 2SA1037AK T146 S
T2SA1037K-R-P TR 2SA1037K-T-96-R
T2SA1037K-S-P TR 2SA1037K-T-96-S
T2SA1179-M6-P TR 2SA1179-M6
T2SA1179-M7-P TR 2SA1179-M7-TB
T2SA1179N-M6P TR 2SA1179N-M6-TB
T2SA1179N-M7P TR 2SA1179N-M7-TB
T2SA1235A1E-P TR 2SA1235A1E
T2SA1235A1F-P TR 2SA1235A1F
Q1061 T2SA1037AK-RP TR 2SA1037AK T146 R
T2SA1037AK-SP TR 2SA1037AK T146 S
T2SA1037K-R-P TR 2SA1037K-T-96-R
T2SA1037K-S-P TR 2SA1037K-T-96-S
T2SA1179-M6-P TR 2SA1179-M6
T2SA1179-M7-P TR 2SA1179-M7-TB
T2SA1179N-M6P TR 2SA1179N-M6-TB
T2SA1179N-M7P TR 2SA1179N-M7-TB
T2SA1235A1E-P TR 2SA1235A1E
T2SA1235A1F-P TR 2SA1235A1F
Q1062 T2SA1037AK-RP TR 2SA1037AK T146 R
T2SA1037AK-SP TR 2SA1037AK T146 S
T2SA1037K-R-P TR 2SA1037K-T-96-R
T2SA1037K-S-P TR 2SA1037K-T-96-S
T2SA1179-M6-P TR 2SA1179-M6
T2SA1179-M7-P TR 2SA1179-M7-TB
T2SA1179N-M6P TR 2SA1179N-M6-TB
T2SA1179N-M7P TR 2SA1179N-M7-TB
T2SA1235A1E-P TR 2SA1235A1E
T2SA1235A1F-P TR 2SA1235A1F
Q1063 T2SA1037AK-RP TR 2SA1037AK T146 R
T2SA1037AK-SP TR 2SA1037AK T146 S
T2SA1037K-R-P TR 2SA1037K-T-96-R
T2SA1037K-S-P TR 2SA1037K-T-96-S
T2SA1179-M6-P TR 2SA1179-M6
T2SA1179-M7-P TR 2SA1179-M7-TB
T2SA1179N-M6P TR 2SA1179N-M6-TB
T2SA1179N-M7P TR 2SA1179N-M7-TB
T2SA1235A1E-P TR 2SA1235A1E
T2SA1235A1F-P TR 2SA1235A1F
Q1101 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S

— 17 —
Schematic
Location Part No. Description Schematic Location Part No. Description
Q1102 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q1201 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q1202 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q1203 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q1251 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q1252 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q1801 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q3404 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
Q3405 T2SC2412K-R-P TR 2SC2412K-T-96-R
T2SC2412K-S-P TR 2SC2412K-T-96-S
T2SC2812-L6-P TR 2SC2812-L6-TB
T2SC2812-L7-P TR 2SC2812-L7-TB
T2SC2812N-L6P TR 2SC2812N-L6-TB
T2SC2812N-L7P TR 2SC2812N-L7-TB
T2SC3928A1R-P TR 2SC3928A1R
T2SC3928A1S-P TR 2SC3928A1S
RESISTORS
 R001 RG11R00JTEANL MT-GLAZE 1 JA 1W
 R002 RG11R00JTEANL MT-GLAZE 1 JA 1W
R003 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R004 RGF6801JTCANL MT-GLAZE 6.8K JA 1/10W
R005 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R006 RGF6801JTCANL MT-GLAZE 6.8K JA 1/10W
 R007 RG11R00JTEANL MT-GLAZE 1 JA 1W
R012 RGA2R20JTDANL MT-GLAZE 2.2 JA 1/2W
R013 RGA2R20JTDANL MT-GLAZE 2.2 JA 1/2W
R014 RGA2R20JTDANL MT-GLAZE 2.2 JA 1/2W
R015 RGA2R20JTDANL MT-GLAZE 2.2 JA 1/2W
R016 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R101 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R102 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R103 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R104 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R105 RGF56R0JTCANL MT-GLAZE 56 JA 1/10W
R109 RGF4700JTCANL MT-GLAZE 470 JA 1/10W
R110 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R111 RGF33R0JTCANL MT-GLAZE 33 JA 1/10W
R112 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R801 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R803 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R806 RGF2202JTCANL MT-GLAZE 22K JA 1/10W
R807 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R809 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R812 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R815 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R816 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R818 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R822 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R823 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R824 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R825 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R828 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R829 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R830 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R831 RGF4702JTCANL MT-GLAZE 47K JA 1/10W
R832 RGF4702JTCANL MT-GLAZE 47K JA 1/10W

— 18 —
Schematic
Location Part No. Description Schematic Location Part No. Description
R833 RGF2701JTCANL MT-GLAZE 2.7K JA 1/10W
R834 RGF2701JTCANL MT-GLAZE 2.7K JA 1/10W
R838 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R839 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R840 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R841 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R842 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R843 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R844 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R846 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R847 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R848 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
R849 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R850 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R851 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R853 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R854 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R855 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R856 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R858 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R859 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R860 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R861 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R863 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R864 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R865 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R866 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R867 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R868 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R870 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R873 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R874 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R875 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R876 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R883 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R884 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R885 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R887 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R888 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R889 RGF1004JTCANL MT-GLAZE 1M JA 1/10W
R893 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R894 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R895 RGF4703JTCANL MT-GLAZE 470K JA 1/10W
R896 RGF3901JTCANL MT-GLAZE 3.9K JA 1/10W
R897 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
R899 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R900 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R901 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R902 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R903 RGF3302JTCANL MT-GLAZE 33K JA 1/10W
R904 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R905 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R906 RGF56R0JTCANL MT-GLAZE 56 JA 1/10W
R907 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R908 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R909 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1001 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1002 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1003 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1004 RGF4703JTCANL MT-GLAZE 470K JA 1/10W
R1005 RGF4703JTCANL MT-GLAZE 470K JA 1/10W
R1006 RGF2200JTCANL MT-GLAZE 220 JA 1/10W
R1007 RGF2200JTCANL MT-GLAZE 220 JA 1/10W
R1008 RGF2200JTCANL MT-GLAZE 220 JA 1/10W
R1009 RGF2200JTCANL MT-GLAZE 220 JA 1/10W
R1010 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1011 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1021 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1022 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1023 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1024 RGF4703JTCANL MT-GLAZE 470K JA 1/10W
R1025 RGF4703JTCANL MT-GLAZE 470K JA 1/10W
R1027 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1028 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1029 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1030 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1031 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1032 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1033 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1034 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1035 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1036 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1037 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1038 RGF5600JTCANL MT-GLAZE 560 JA 1/10W
R1039 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1040 RGF5600JTCANL MT-GLAZE 560 JA 1/10W
R1041 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1042 RGF5600JTCANL MT-GLAZE 560 JA 1/10W
R1043 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1061 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1062 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1063 RGF75R0JTCANL MT-GLAZE 75 JA 1/10W
R1064 RGF4703JTCANL MT-GLAZE 470K JA 1/10W
R1065 RGF4703JTCANL MT-GLAZE 470K JA 1/10W
R1067 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1068 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1069 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1070 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1071 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1072 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1073 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1074 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1075 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1076 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1077 RGF1202JTCANL MT-GLAZE 12K JA 1/10W
R1078 RGF5600JTCANL MT-GLAZE 560 JA 1/10W
R1079 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1080 RGF5600JTCANL MT-GLAZE 560 JA 1/10W
R1081 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1082 RGF5600JTCANL MT-GLAZE 560 JA 1/10W
R1083 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1101 RGF8200JTCANL MT-GLAZE 820 JA 1/10W
R1102 RGF8200JTCANL MT-GLAZE 820 JA 1/10W
R1103 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R1104 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R1105 RGF1001JTCANL MT-GLAZE 1K JA 1/10W

— 19 —
Schematic
Location Part No. Description Schematic Location Part No. Description
R1106 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1201 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1202 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1203 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1204 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1205 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1206 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1207 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R1208 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1209 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1210 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1253 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1254 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1255 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1256 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1257 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1260 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1261 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1262 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1263 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1264 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1265 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1266 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1267 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1268 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1269 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1270 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1271 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1272 RGF2203JTCANL MT-GLAZE 220K JA 1/10W
R1605 RGF3302JTCANL MT-GLAZE 33K JA 1/10W
R1606 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
 R1609 RG11R20JTEANL MT-GLAZE 1.2 JA 1W
R1610 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
 R1626 RG12R20JTEANL MT-GLAZE 2.2 JA 1W
R1802 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1803 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1804 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1805 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1806 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1807 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1809 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1812 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1813 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1814 RGF8200JTCANL MT-GLAZE 820 JA 1/10W
R1815 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1816 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1817 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1819 RGE1000JTBANL MT-GLAZE 100 JA 1/8W
R3401 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R3402 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R3403 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R3404 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R3405 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R3406 RGF1004JTCANL MT-GLAZE 1M JA 1/10W
R3407 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
R3416 RGF1501JTCANL MT-GLAZE 1.5K JA 1/10W
R3417 RGF1801JTCANL MT-GLAZE 1.8K JA 1/10W
R3418 RGF4701JTCANL MT-GLAZE 4.7K JA 1/10W
R3419 RGF6802FTCANL MT-GLAZE 68K FA 1/10W
R3420 RGF3301JTCANL MT-GLAZE 3.3K JA 1/10W
R3421 RGF3001JTCANL MT-GLAZE 3K JA 1/10W
R3422 RGF3901JTCANL MT-GLAZE 3.9K JA 1/10W
R3425 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R3426 RGF47R0JTCANL MT-GLAZE 47 JA 1/10W
R3427 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R3428 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R3431 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R3432 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R3439 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R3440 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
SURGE-ABSORBER
SC1001 1AV4Z30B0220G SURGE-ABSORBER
SC1002 1AV4Z30B0220G SURGE-ABSORBER
SC1003 1AV4Z30B0220G SURGE-ABSORBER
SC1004 1AV4Z30B0220G SURGE-ABSORBER
SC1005 1AV4Z30B0220G SURGE-ABSORBER
SC1006 1AV4Z30B0220G SURGE-ABSORBER
SC1021 1AV4Z30B0220G SURGE-ABSORBER
SC1022 1AV4Z30B0220G SURGE-ABSORBER
SC1023 1AV4Z30B0220G SURGE-ABSORBER
SC1024 1AV4Z30B0220G SURGE-ABSORBER
SC1025 1AV4Z30B0220G SURGE-ABSORBER
SC1061 1AV4Z30B0220G SURGE-ABSORBER
SC1062 1AV4Z30B0220G SURGE-ABSORBER
SC1063 1AV4Z30B0220G SURGE-ABSORBER
SC1064 1AV4Z30B0220G SURGE-ABSORBER
SC1065 1AV4Z30B0220G SURGE-ABSORBER
SC1101 1AV4Z30B0220G SURGE-ABSORBER
SC1102 1AV4Z30B0220G SURGE-ABSORBER
SC1801 1AV4Z30B0220G SURGE-ABSORBER
SC1802 1AV4Z30B0220G SURGE-ABSORBER
SC1803 1AV4Z30B0220G SURGE-ABSORBER
SC1804 1AV4Z30B0220G SURGE-ABSORBER
SC1805 1AV4Z30B0220G SURGE-ABSORBER
SC1806 1AV4Z30B0220G SURGE-ABSORBER
SC1807 1AV4Z30B0220G SURGE-ABSORBER
CRYSTAL / OSCILLATORS
X801 1AV4V10B0560N OSC, CRYSTAL 32.768KHZ
1AV4V10B0570N OSC, CRYSTAL 32.768KHZ
MISCELLANEOUS
 A101 1AV4F1FAM0170 TUNER, TU/IF
A801 1AA0B10N2020A ASSY, PWB, MAIN J3TZ
K1001 1AV4J31B07700 TERMINAL, BOARD
K1021 1AV4J12B3960N JACK, RCA-5(6-1)
K1061 1AV4J12B3960N JACK, RCA-5(6-1)
K1101 1AV4J12B3970N JACK, RCA-2
1LB4J12B08100 JACK, RCA-2

— 20 —
Schematic
Location Part No. Description Schematic Location Part No. Description
FILTER PC BOARD
CAPACITORS
 C602 CGXAV27224CAN MT-POLYEST 0.22U M 275V
 C606 CKXAV2E102AAC CERAMIC 1000P M 250V
 C607 CKXAV2E102AAC CERAMIC 1000P M 250V
COILS
 LF601 1AV4F35B1390N LINE FILTER
 LF602 1AV4F35B1390N LINE FILTER
MISCELLANEOUS
 SC601 1AV4Z30B0170N SURGE-ABSORBER
 VA601 DVXAAEV0043-- VARISTOR ENC471D-14AS
 VA602 DVXAAEV0047-- VARISTOR ENC271D-10AS
A600 1AA0B10N20300 ASSY, PWB, FILTER-J3TZ
 F601 F32S10RA2LTTL FUSE 250V 10A
F601A 1AV4J20B0040N HOLDER, FUSE
F601B 1AV4J20B0040N HOLDER, FUSE
K601 1AV4U20B61300 UNIT, NOISE FILTER
CONTROL PC BOARD
CAPACITORS
C1902 CK1H102KLZBNG CERAMIC 1000P K 50V
C1903 CK0J106KGMBNG CERAMIC 10U K 6.3V
C1904 CK0J106KGMBNG CERAMIC 10U K 6.3V
DIODES
D1903 DLSLP-381C51N LED SLP-381C-51
D1903A 1AV2SA9SD01K- SPACER
RESISTORS
R1900 RGFR000ZTCANL MT-GLAZE 0.000 ZA 1/10W
R1916 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1917 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
SURGE-ABSORBERS
SC1901 1AV4Z30B0220G SURGE-ABSORBER
SC1902 1AV4Z30B0220G SURGE-ABSORBER
MISCELLANEOUS
A1901 1AA0B10N2020B ASSY, PWB, CONTROL J3TZ
A1902 1AV4U20B24401 UNIT, REMOCON RECEIVER
KEY SWITCH PC BOARD
CAPACITORS
C1951 CK1E104ZLZFNG CERAMIC 0.1U Z 25V
DIODES
D1957 DZUDZS10B---G ZENER DIODE UDZS10B TE-17
D1958 DZUDZS10B---G ZENER DIODE UDZS10B TE-17
COILS
L1955 1AV4L26B0130G INDUCTOR, 600 OHM
RESISTORS
R1953 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1954 RGF1000JTCANL MT-GLAZE 100 JA 1/10W
R1956 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1957 RGF1001JTCANL MT-GLAZE 1K JA 1/10W
R1958 RGF1002JTCANL MT-GLAZE 10K JA 1/10W
R1959 RGF1801JTCANL MT-GLAZE 1.8K JA 1/10W
R1961 RGF2201JTCANL MT-GLAZE 2.2K JA 1/10W
R1962 RGF3901JTCANL MT-GLAZE 3.9K JA 1/10W
R1963 RGF5601JTCANL MT-GLAZE 5.6K JA 1/10W
SWITCHES
SW1951 1AV4S10B3530G SWITCH, PUSH 1P-1TX1
SW1952 1AV4S10B3530G SWITCH, PUSH 1P-1TX1
SW1953 1AV4S10B3530G SWITCH, PUSH 1P-1TX1
SW1954 1AV4S10B3530G SWITCH, PUSH 1P-1TX1
SW1955 1AV4S10B3530G SWITCH, PUSH 1P-1TX1
MISCELLANEOUS
A1951 1AA0B10N2020C ASSY, PWB, KEY_SW J3TZ
DIGITAL PC BOARD
A5500 1AA0B10N20400 ASSY, PWB, DIGITAL-J3TZ
Nonservicable part. No discreet parts provided for this pc board.
MISCELLANEOUS
 EL901 1AV4T44B01700 PDP MODULE / POWER SUPPLY
 U901 1AV4U20C02100 UNIT, PDP-LOGIC
SP901 1LB4A10B05700 SPEAKER 8
SP902 1LB4A10B05700 SPEAKER 8
