SAP Citrix User manual

Citrix Receiver
Configuration and User Guide
rev: 13.12.2013

© 2013 SAP AG. All rights reserved.
SAP, R/3, SAP NetWeaver, Duet, PartnerEdge, ByDesign, SAP
BusinessObjects Explorer, StreamWork,SAPHANA, and other SAP
products and services mentioned herein as wellas their respective
logos are trademarks or registered trademarks of SAP AG in Germany
and other countries.
Business Objects andthe Business Objects logo, BusinessObjects,
Crystal Reports, Crystal Decisions, Web Intelligence, Xcelsius, and
other Business Objects products and services mentioned herein as
well as their respective logos are trademarks or registeredtrademarks
of Business Objects Software Ltd. Business Objects is an SAP
company.
Sybase and Adaptive Server, iAnywhere,Sybase 365, SQL
Anywhere, andother Sybase products and services mentioned herein
as wellas their respective logos are trademarks or registered
trademarks of Sybase Inc. Sybase is an SAP company.
Crossgate, m@gic EDDY, B2B 360°, and B2B 360° Services are
registered trademarks of Crossgate AG inGermany and other
countries. Crossgate is an SAP company.
Allother product and service names mentioned are the trademarks of
their respective companies. Data contained in this document serves
informational purposes only. National product specifications may vary.
These materials are subject to change without notice.These materials
are provided by SAP AG and its affiliated companies ("SAP Group")
for informational purposes only, without representation or warranty of
any kind,and SAP Groupshall not be liable for errors or omissions
withrespect to the materials. The only warranties for SAP Group
products and services are those that are set forth in the express
warranty statements accompanying such products andservices, if
any. Nothing herein should be construed as constituting anadditional
warranty.
http://access
.sap.com/
TABLE OF CONTENTS
Introduction.....................................................................................................................................3
Installation.......................................................................................................................................3
Accessing our portal .......................................................................................................................3
Starting an Application....................................................................................................................7
Using the local installed Citrix Receiver..........................................................................................7
Usability Features of the Citrix Receiver .......................................................................................10
Citrix Toolbar.....................................................................................................................12
Toolbar Settings....................................................................................................................12
Preferences..........................................................................................................................13
Add additional resources...................................................................................................15
Easy Access......................................................................................................................17

CITRIX RECEIVER USER GUIDE
3
Introduction
Citrix Receiver allows you to connect to SAP WTS (Windows Terminal Services) and VDI virtual
desktops provided by the E2E Desktop Virtualization Team.
The virtual desktops are web-based Windows virtual PCs complete with Microsoft Office, Outlook
email and other standard SAP applications. You can access your virtual desktop using an internet
browser on aWindows, Macintosh or mobile device that has the Citrix Receiver installed.
With the migration from our old access portal, mywts.sap.com, to our new portal,
https://access.sap.com , Citrix Receiver becomes the main entry point for all resources we provide.
In order to use the Citrix Receiver with our new access platform, please follow instructions in this
guide.
Installation
If the Receiver is older than version 4.1 or not yet installed on your local machine, please download
and install the latest version from the download page:
http://access.sap.com/default.asp?Zone=Download
Accessing our portal
To connect to our resources just go to http://access.sap.com.
This shows the main entry page.
1. From here, select the region you want to connect to.

CITRIX RECEIVER USER GUIDE
4
In this example we have chosen EMEA:
2. On the regional page, select the corporate access type.
In this example, we selected Office, which then opens the logon page of the Citrix Access
Gateway.
3. Enter your UserID in the User name field. There is no additional Domain information needed,
regardless which domain your user belongs to.
4. Enter your Domain Password and a Passcode generated with your SecurID card.
After successful logon you will see the CitrixWeb Receiver Home Screen with the applications you
have already subscribed to. If you have not subscribed to any applications, you will see at least the
SAP Desktop which is pre-configured for all Office sites globally.

CITRIX RECEIVER USER GUIDE
5
If you do not see any applications, you can add them by clicking the +button on the left side of the
home screen of the Web Receiver.

CITRIX RECEIVER USER GUIDE
6
You will see then a folder structure that includes the different resources we provide.
In this example, we clicked on the folder Preview which shows the SAP Desktop – Preview, which
you can add to your home screen by just clicking on it (indicated by a green checkmark).

CITRIX RECEIVER USER GUIDE
7
You can also search for published resources in the Search field. Note that from here you can start
it but not add it to your home screen. This is only possible via the above explained method.
Starting an Application
To start on of the Desktops or Applications in your home screen just simply click on it. The session
will then be started.
Using the local installed Citrix Receiver
You can add the Store used above to your local Citrix Receiver for easier access. To do so:
1. Click on your Username in the Web Receiver and select Activate…

CITRIX RECEIVER USER GUIDE
8
2. Click Open to open the file receiverconfig.cr. The file will be opened by your locally installed
Citrix Receiver.

CITRIX RECEIVER USER GUIDE
9
3. Click Add.
The local Citrix Receiver will open and connect to the Store you have added.
Now you will see the same published resources you have already added to your home screen on
the Web Receiver.

CITRIX RECEIVER USER GUIDE
10
Usability Features of the Citrix Receiver
Below you will find some useful information about the usability of Citrix Receiver.
A very useful feature is that you don’t have to recognize any URL to access the resources.
When your Laptop is connected to the corporate network, the Receiver will log you on
automatically.
When you are working from outside SAP you will be prompted with a logon dialog to enter your
credentials including a SecurID Passcode.
1. In the User name field enter your UserID. There is no additional Domain information needed,
regardless which domain your user belongs to.
2. Enter your Domain Password and your Passcode you have generated with your SecurID
card.

CITRIX RECEIVER USER GUIDE
11
3. Click the SAP Desktop icon to start a session. (A spinning circle appears while the session
loads.
The session window appears and you see the logon process.
You may be prompted with the following pop-up.
If this occurs, you can choose to block or permit the session access to your local resources. You
can change this later as well via the Citrix Toolbar.

CITRIX RECEIVER USER GUIDE
12
Citrix Toolbar
At the top of the session window you will see a toolbar. You can show/hide this toolbar by clicking
on the small bar with the arrow:
Hide Toolbar:
Show Toolbar:
Toolbar Settings
Home Returns to the Citrix Receiver home screen.
Ctrl+Alt+Del Sends this key combination to the session.
Preferences See next chapter for details on the Preferences.
Full-screen Switches the session window to full screen mode.
In full screen mode your local key combinations will be sent to the session
(except Ctrl+Alt+Del).
In addition, if you have multiple sessions open you will see them in the Toolbar as
shown in the example below.
Window Switches the full screen session to Window mode.
In Window mode you can resize the session window to any size you want.
Disconnect The session will be disconnected (which will be held for 10 minutes, then it will be
logged off!)

CITRIX RECEIVER USER GUIDE
13
Preferences
If you select the Preferences menu, you can do multiple settings to fit your needs.
The screenshots below show the recommended settings, but you are free to set different ones.

CITRIX RECEIVER USER GUIDE
14

CITRIX RECEIVER USER GUIDE
15
Add additional resources
You can search for a specific resource by typing keywords in the Search field at the top of the
screen.
In this example it shows all available resources where the term “sap desktop” is either in the name
or the description.
From the local Receiver you can also add the resource to your home screen.

CITRIX RECEIVER USER GUIDE
16
From here you can browse the folders and look for the resource you want to add.
A small arrow indicates that there are subfolders in this group. If you click on the arrow the
subfolders will be shown, as well as all resources available to you in the Projects mainfolder.
In the example below we have chosen the folder “Development” from the subfolder menu to show
the resources in this folder.
If you now click on one of these resources it will be added to your home screen in Receiver, as
indicated by a green checkmark.

CITRIX RECEIVER USER GUIDE
17
To remove a resource, right-click on it and select “remove”. Alternatively, move your mouse to the
left top corner of the icon which will then show an X. Click the X to remove the resource.
You can also change the order of the apps on your home screen in Receiver by simply dragging
the icon to another location and then dropping it. This is very useful to get a better overview if you
have multiple resources subscribed.
Easy Access
To make connecting to WTS easier, you are not required to start the Citrix Receiver to connect to
your SAP Desktop or other resources you have subscribed.
Once you have installed and configured the Citrix Receiver, you can simply start the application
from the Start Menu. Selecting any application from there will first launch Citrix Receiver for you.
Just click on the link in the Start Menu and the session will be started.
The first session will take some time, because the receiver will be started in the background and
check the store to verify if any new apps have been added. Therefore, we recommend patience
during the first launch.

CITRIX RECEIVER USER GUIDE
18
