Sapporo SP-527 User manual

THERMOSTAT
SET AT NO. 4
INSTRUCTIONS FOR USE AND INSTALLATION OF MODEL SP-527
HOW TO USE THE IRON
1. HANG BOTTLE 1 METER ABOVE PRESSING SURFACE.
(SEE BOTTLE HANGING INSTRUCTION.)
2. CONNECT THE BLACK HOSE END TO THE IRON, AND
CLEAR HOSE END TO THE BOTTLE.
3. EMPTY DEMINERALIZER PACKAGE INTO THE BOTTLE
AND FILL IT WITH TAP WATER ONLY. (IF YOU WANT TO,
USE THE DEMINERALIZER AS AN OPTION.)
4. TIE THE ELECTRICAL CORD AND HOSE TOGETHER.
5. PLUG THE IRON CORD INTO A GROUNDED
ELECTRICAL OUTLET.
6. SET THE TEMPERATURE DIAL ON NO. 4 AND LET THE
IRON HEAT UP FOR TEN MINUTES.
7. OPEN THE BOTTLE VALVE AND ALLOW THE HOSE TO
FILL WITH WATER BY PRESSING THE STEAM SWITCH.
THE IRON IS NOW READY FOR USE.
8. WHEN NOT PRESSING, PLACE THE IRON ON THE
SUPPLIED IRON REST.
9. ALWAYS UNPLUG THE IRON WHEN UNATTENDED OR
NOT IN USE.
DO NOT STAND IRON ON ITS BACK.
IMPORTANT NOTICE
ABOUT DEMINERALIZER:
• THE DEMINERALIZER EXTENDS THE LIFE OF THE
IRON & PREVENTS CALCIUM BUILD-UP.
• WHEN THE DEMINERALIZER CHANGES FROM BLUE
TO BROWN, REPLACE IT BY ORDERING A NEW
PACKAGE FROM YOUR DISTRIBUTOR.
WATER BOTTLE
GROUNDED TYPE
ELECTRIC PLUG
FILTER
BOTTLE VALVE
CLOSE TO FILL
OPEN TO USE
SILICONE HOSE
TIE CORD AND
HOSE TOGETHER
IRON REST
1 METER
DEMINERALIZER
(AVAILABLE AS AN OPTION)

9900
10100
PARTS LIST FOR MODEL SP-527
3300
17000
16018
16000
Sapporo No. Name Style No.
SRP387 Solenoid Valve Assembly 3300
SRP388 Steam Switch Assembly 4400
SRP389 Handle Assembly 5500
SRP390 Main Switch Assembly Complete 6600
SRP218 Thermal Fuse Only 104065
SRP391 Power Cord Assembly 7700
SRP392 Thermostat Assembly 8800
SRP393 Heat Insulator Assembly 9900
SRP394 Iron Cover Assembly 10100
JP165 Blue Silicone Over Metal Iron Rest 110303-B
SRP395 Lead Wires (Set of 3) 11110
SRP357 Water Bottle Complete 16000
SRP306 Red Filter for Hose 16018
SRP358 Silicone Hose Set with Filter 17000
7700
110303-B
8800
11110
6600
4400
104065
5500

PRESSING WITH SAPPORO IRON
NOW THAT YOUR IRON IS PROPERLY SET-UP, PLEASE READ THE FOLLOWING TIPS FOR
PRESSING WITH PROFESSIONAL RESULTS:
• INITIALLY, TO ALLOW WATER TO ENTER INTO THE HOSE AND IRON, PRESS THE STEAM
SWITCH. THIS MAY TAKE A FEW SECONDS, THEN YOU WILL SEE STEAM.
• BEGIN TO PRESS.
• FOR BEST RESULTS, IT IS ONLY NECESSARY TO PRESS THE STEAM SWITCH FOR A FEW
SECONDS AT A TIME. IT IS NOT NECESSARY TO ACTIVATE THE STEAM SWITCH
CONTINUOUSLY.
• THERE ARE SEVERAL SETTINGS ON YOUR TEMPERATURE DIAL. RECOMMENDED
TEMPERATURE SETTINGS ARE AS FOLLOWS:
# 1, 2 – PREHEAT
# 3 – SILK AND DELICATE FABRICS (LOW TEMPERATURE)
# 4 – COTTON AND WOOL (MEDIUM TEMPERATURE)
# 5 – LINEN (HIGH TEMPERATURE)
• A TEFLON SHOE IS RECOMMENDED AND IS AVAILABLE FROM YOUR DISTRIBUTOR TO
PREVENT GARMENT SHINE AND STARCH BUILD-UP.
• WHEN UNATTENDED OR NOT IN USE, ALWAYS TURN OFF AND UNPLUG YOUR IRON.
PROBLEM PROBABLE CAUSE SUGGESTED REMEDY
Iron does not heat. No power to iron. Check electric outlet
Temperature dial is in “OFF” position. Set temperature dial to No. 3, 4 or 5.
Temperature dial is set on No. 1 or 2. Set temperature dial to No. 3, 4 or 5.
No steam or very little steam. Little or no water in bottle. Fill bottle with water.
Bottle not high enough. Bottle must be 36” above the Pressing surfaces.
Clogged filters. Remove and rinse filter under water faucet.
Clogged steam holes.. Clear holes with straightened paper clip.
Iron spits water. Iron is not hot enough. Turn temperature dial up(clockwise).
Let iron heat up.
Stream switch held down too long. Release steam switch and let iron heat up.
Iron too hot. Temperature dial is set too high. Turn thermostat dial down
(counter clockwise).
Iron not hot enough. Temperature dial is set too low. Turn thermostat dial up (clockwise).
TROUBLE SHOOTING GUIDE

IMPORTANT : CAUTION – DO NOT SLIDE ELECTRICAL WIRE OR WATER HOSE OVER HOOK. SLIDE CHAIN LINK
ONLY OVER HOOK.
CAUTION – INJURY TO PERSONS OR DAMAGE TO THE CEILING MAY RESULT IF THE BOTTLE OR MOUNTING
HARDWARE IS PULLED FROM THE CEILING. TO AVOID SUCH INJURY, MOUNT ONLY TO CEILING MEMBERS
THAT ARE STRUCTURALLY SOUND.
FOR HOLLOW CEILINGS:
1. DRILL 5/8” DIAMETER HOLE IN THE CEILING AT DESIRED HOOK LOCATION.
2. ASSEMBLE TOGGLE BOLT BY SCREWING BOLT (A) INTO TOGGLE (B).
3. INSERT FLAPS AND BOLT ASSEMBLY (A/B) HINGE UP INTO CEILING HOLE WITH
THE BOLT (A) PROTRUDING THROUGH CEILING. LOCK ASSEMBLY BY TURNING
HOOK (C) CLOCKWISE UNTIL FIRMLY SEATED.
CEILING HOOK INSTALLATION INSTRUCTIONS
FOR WOOD BEAM CEILINGS
SCREW HOOK CLOCKWISE INTO CEILING UNTIL FIRMLY SEATED.
(A)
(C)
(B)
CEILING
→
→
→
→
FOR EITHER METHOD
HANG THE BOTTLE ASSEMBLY BY A CHAIN FROM THE HOOK SO THAT THE BOTTOM OF THE BOTTLE IS 1 METER (1 YARD-
STICK) FROM THE WATER INLET ON THE IRON.
