Saregama CARVAAN mini User manual

TOP VIEW: BUTTONS ON CARVAAN MINI TELUGU
power
increase
volume
decrease
volume
play/pause
go to
previous song go to next song
1
USER MANUAL

LEFT SIDE VIEW: MODES ON CARVAAN MINI TELUGU
To choose a mode, press the corresponding mode button on the unit
SAREGAMA
351 pre-loaded evergreen songs of legendary artistes like
Ghantasala, S.P. Balasubrahmanyam, N.T. Rama Rao & Akkineni
Nageswara Rao; this is the default mode on first power on/reset
FM/AM*
Listen to local FM/ AM stations.
To tune to FM, press FM/AM mode button
To tune to AM, press FM/AM mode button again
To tune to AM from any other mode, press FM/AM mode button twice
modes
2
*AM station will play as per broadcast timings

**support for BT version 4.1
To auto tune FM/AM stations, follow the steps:
Step 1: Press play/pause button for 5 seconds
Step 2: Searching for all FM/AM signals will start. You will hear a
searching sound and each FM/AM station will play for approx. 3-4
seconds till all stations are tuned
Step 3: Press next/ previous button to go to next/previous station�
FM frequency: 87.5 to 108 MHZ; AM frequency: 520 to 1710 KHZ
Note: It is recommended that you do not put the unit on charge while
listening to FM/AM as it will interrupt the signal
For detailed process to auto tune FM/AM stations, refer to the insert in
the box
3.5 mm audio
jack for connecting
external
speakers/headphones
3
BLUETOOTH**
Pair your mobile phone/ tablet with Carvaan Mini Telugu. Enjoy songs
stored on your personal device on Carvaan Mini Telugu speakers
RIGHT SIDE VIEW: AUX OUT

When you turn on Carvaan Mini Telugu you will be able
to see a light on the front of the unit. This light
indicates the status as follows:
i. When the blue light is steady, it indicates that a
song has been paused
ii. When the blue light blinks, it indicates that the
battery is very low. Please connect the unit to a power
source to charge it
4
FRONT VIEW: STATUS LIGHT
status
light

charging
port
battery
charging
indicator
Aux In Port for plugging in
phones & other devices
Plug in a USB*** to
enjoy your personal
collection of songs
reset to factory
settings
Pull out the antenna from the back panel of
Carvaan Mini Telugu for improved reception of local
FM stations
***support for USB 2.0
Micro USB to USB charging cable
Frequency: 50 Hz for input and 5V 1A for output
Full battery charge time 1-2 hours
Battery usage: Approximately 4-5 hours once
the battery is fully charged
BACK VIEW: PORTS ON CARVAAN MINI TELUGU
5

1. CARE FOR PRODUCT
a. Keep Carvaan Mini Tamil away from dust
and excessive heat (heat registers, stoves etc.)
b. Prevent spillage of water or any other liquid
as this can cause failure of Carvaan Mini Tamil
or could prove to be a potential fire hazard
c. Clean the unit with a dry cloth only
d. Do not walk on or pinch the power cord
close to the plug
e. Do not immerse Carvaan Mini Tamil into water
2. CARE FOR BATTERY
a. Do not expose the battery to heat sources
greater than 60°C
b. Recycle or dispose the battery when
essential. Please ensure proper battery
handling and disposal methods
c. Do not subject the battery pack to a
mechanical shock
d. In the event of a battery leak, don’t allow the
liquid to come in contact with the skin or eyes.
If contact has been made, wash the affected
area with water & seek medical advice
e. For prolonging battery life, avoid
discharging the battery completely
3. OTHERS
a. Use attachments / accessories as
specified by the manufacturer
b. To register a complaint or a service
request, email [email protected]
WEEE stands for Waste from Electrical
and Electronic Equipment. WEEE Directive
2002/96/EC mandates the treatment,
recovery and recycling of electric and
electronic equipment. Carvaan Mini being
sold in USA market had passed all the
WEEE compliance and carry the "Wheelie
Bin" sticker on the label as well. Saregama
has labelled its branded electronic
products with the WEEE Symbol to alert
our customers that their products bearing
this label should not be disposed in a
landfill or with municipal or household
waste.
6
Carvaan Mini Tamil comes with a 6 months Warranty on all parts, excluding
accessories. This includes servicing/ repair or replacement of damaged parts.
The warranty does not apply and does not cover the following:
• Liability for loss of data/content loaded in the product due to misuse or tampering
• Damage caused due to force majeure events; events caused by fire, water, electrical
disturbances etc.; events beyond the control of Saregama; acts of negligence or
mishandling; usage for commercial, business, industrial, educational or rental
purposes
SAFETY HANDLING
WARRANTY OVERVIEW

The European Directive on the Restriction of Hazardous Substances (RoHS)
holds electrical and electronic equipment companies directly responsible for
the chemical compliance of their products. This means all products must conform to
strict standards, provide extensive compliance documentation, and ensure that
electrical and electronic products sold in the USA do not contain lead, cadmium,
mercury, hexavalent chromium, polybrominated biphenyls (PBBs), and polybrominated
diphenyl ethers (PBDEs) above the legal threshold. Manufacturers, owners, retailers,
and importers alike need to ensure that their products comply in order to be distributed
and sold in USA.
The equipment (Carvaan Mini) has been tested and found to comply with the limits of
the following hazardous substance in the product as per RoHs guidelines.
• Lead (Pb): < 1000 ppm
• Mercury (Hg): < 100 ppm
• Cadmium (Cd): < 100 ppm
• Hexavalent Chromium: (Cr VI) < 1000 ppm
• Polybrominated Biphenyls (PBB): < 1000 ppm
• Polybrominated Diphenyl Ethers (PBDE): < 1000 ppm
• Bis (2-Ethylhexyl) phthalate (DEHP): < 1000 ppm
• Benzyl butyl phthalate (BBP): < 1000 ppm
• Dibutyl phthalate (DBP): < 1000 ppm
• Diisobutyl phthalate (DIBP): < 1000 ppm
7
Warranty is provided only on Product(s) which is purchased from Saregama, Saregama
Authorized Dealer, Authorized Reseller or Authorized Online Resellers.
To claim the Warranty Customer will have to mail their request to [email protected]
The Customer will receive as reply to his/ her email an address on which said Customer
may send the defective unit of the Product (“said address”).
The defective unit of the Product & Accessories must be sent to the said address (with
the original packaging when purchased or similar packaging) at the cost of the
Customer. Once the said defective unit of the Product & Accessories is received at the
said address, Saregama will dispatch a fresh unit of the Product & Accessories to
Customer’s address. In the event on receipt, Saregama finds that the allegedly defective
unit of Product does not have any defects, Saregama will dispatch the same unit of the
Product & Accessories received from Customer, back to the Customer’s address.
To avail the Warranty, customer will have to provide the invoice of the unit of the
Product purchased by customer to Saregama, either by dispatching it along with the
defective unit or by emailing at the email address provided for the same purpose a
scanned copy of the said invoice. The replaced unit of the Product & Accessories shall
become the property of Saregama.
WARRANTY TERMS

The FCC Declaration of Conformity or the FCC label or the FCC mark is a certification mark
employed on electronic products manufactured or sold in the United States which certifies that
the electromagnetic interference from the device is under limits approved by the Federal
Communications Commission.
A device that is marketed for use in the home or a residential area by the customer comes under
Class B devices which require either Verification, Certification, or Self Declaration depending on
the type of product.
Carvaan Mini comes under Class-B and it undergoes all the requirements generated by FCC and
has received the FCC certificate after going a Declaration of Conformity under the new FCC
Doc/Self declaration procedures.
WARRANTY CARD
Customer’s Signature
Customer’s Name:
Customer’s Address:
Product Serial No.: Date of Purchase:
Expiry Date:
I accept the terms and conditions of the warranty.
Retailer’s Name:
Retailer’s Signature/Seal:
8
Song List:www.saregama.com/carvaanmini/telugu/legends/songlist
Detailed Warranty:www.saregama.com/carvaanmini/telugu/legends/warranty
IMPORTANT LINKS
