SATA 51086C Technical manual

12V J
系列锂电冲击起子机
Li-Ion Impact Screwdriver
中文 使用说明书
EN OPERATION INSTRUCTION
C

V_SC_51086C_202105 3
电动工具的通用安全警告：
阅读所有警告和所有说明。 不遵照以下警告和说明
会导致电击、着火和/或严重伤害。保存所有警告
和说明书以备查阅。在所有下列的警告中术语“电
动工具”指市电驱动（有线）电动工具或电池驱动（无
线）电动工具。
通用电动工具安全警告 -工作场地
1) 保持工作场地清洁和明亮。混乱和黑暗的场地
会引起事故。
2) 不要在易爆环境，如有易燃液体、气体或粉尘
的环境下操作电动工具。电动工具产生的火花
会点燃粉尘或气体。
3) 让儿童和旁观者离开后操作电动工具。注意力
不集中会使操作者失去对工具的控制。
通用电动工具安全警告 - 电气安全
1) 电动工具插头必须与插座相配。绝不能以任何
方式改装插头，需接地的电动工具不能使用任
何转换插头。未经改装的插头和相配的插座将
减少触电危险。
2) 避免人体接触接地表面，如管道、散热片和冰箱。
如果你身体接地会增加电击危险。
3) 不得将电动工具暴露在雨中或潮湿环境中。水
进入电动工具将增加电击危险。
4) 不得滥用电线。绝不能用电线搬运、拉动电动
工具或拔出其插头。让电动工具远离热源、油、
锐边或运动部件。受损或缠绕的软线会增加电
击危险。
5) 当在户外使用电动工具时，使用适合户外使用
的外接软线。适合户外使用的软线将减少电击
危险。
6) 如果在潮湿环境下操作电动工具是不可避免的，
应使用剩余电流动作保护器（RCD）。 使用
RCD 可减小电击危险。
通用电动工具安全警告 - 人身安全
1) 保持警觉，当操作电动工具时关注从事的操作
并保持清醒。当你感到疲倦，或在有药物，酒
精或治疗反应时，不要操作电动工具。在操作
电动工具时瞬间的疏忽会导致严重人身伤害。
2) 使用个人防护装置。始终配戴护目镜。安全装
置，诸如适当条件下的防尘面具，防滑安全鞋，
安全帽，听力防护等装置能减少人身伤害。
3) 防止意外起动。确保开关在连接电源和 /或电池
盒、拿起或搬运工具时处于关断位置。手指放
在已接通电源的开关上或开关处于接通时插入
插头可能会导致危险。
4) 在电动工具接通之前，拿掉所有调节钥匙或扳
手。遗留在电动工具旋转零件上的扳手或钥匙
会导致人身伤害。
5) 手不要伸展得太长，时刻注意立足点和身体平
衡。
这样在意外情况下能很好地控制电动工具。
6) 着装适当。不要穿宽松衣服或佩戴饰品。 让衣服、
手套和头发远离运动部件。宽松衣服，佩饰或
长发可能会卷入运动部件中。
7) 如果提供了与排屑装置，集尘设备连接用的装
置，要确保他们连接完好且使用得当。使用这
些装置可减少尘屑引起的危险。
通用电动工具安全警告 - 电动工具使用和注意事项
1) 不要滥用电动工具，根据用途使用适当的电动
工具。选用适当设计的电动工具会使你工作更
有效、更安全。
2) 如果开关不能接通或关断工具电源，则不能使
用该电动工具。不能用开关来控制的电动工具
是危险的且必须进行修理。
3) 在进行任何调节，更换附件或贮存电动工具之
前，必须从电源上拔掉插头和/或使电池盒与
工具脱开。这种防护性措施将减少工具意外启
动的危险。
4) 将闲置不用的电动工具贮存在儿童所及范围之
外，并且不要让不熟悉电动工具或对这些说明
不了解的人操作电动工具。电动工具在未经培
训的用户手中是危险的。
5) 保养电动工具。检查运动件是否调整到位或卡
住，检查零件破损情况和影响电动工具运行的
其他状况。如有损坏，电动工具应在使用前修
理好，许多事故由维护不良的电动工具引发。
6) 保持切削刀具锋利和清洁。保养良好的有锋利
切削刃的刀具不易卡住而且容易控制。

4 51086C V_SC_51086C_202105 5
7)
按照使用说明书，考虑作业条件和进行的作业来
使用电动工具，附件和工具的刀头等。将电动工
具用于那些与用途不符的操作可能会导致危险。
通用电动工具安全警告 -电池式工具使用和注意事项
1)
只用制造商规定的充电器充电。将适用于某种电
池盒的充电器用到其他电池盒时会发生着火危险。
2) 只有在配有专用电池盒的情况下才能使用电动
工具。
使用其他电池盒会发生损坏和着火危险。
3) 当电池盒不用时，将它远离其他金属物体，例
如回形针，硬币，钥匙，钉子，螺钉或其他小
金属物体，以防一端与另一端连接。电池端部
短路会引起燃烧或火灾。
4) 在滥用条件下，液体会从电池中溅出，避免接触。
如果意外碰到了，用水冲洗。如果液体碰到眼睛，
还要寻求医疗帮助。从电池中溅出的液体会发
生腐蚀或燃烧。
5）在电池包插入机器前，请确保机器开关在“关”
的位置。
通用电动工具安全警告 -维修
1) 让专业维修人员使用相同的备件维修电动工具。
这将保证所维修的电动工具的安全。
专业要求
1)
对机器进行任何修护工作之前，都须先取出电池包
2) 禁止将机器置于雨或水中。
3) 请勿将电池包存储于高于 40℃的环境下。
4) 在0至30℃的环境下充电，理想充电温度是 18
至24℃。
5) 仅限配套使用本机随附的充电器和电池包。
6) 避免电池包连接短路。（比如：不要让螺栓、
钉子等接触到电池包的正负极）
7) 禁止燃烧电池包或弃之于火中，会引起爆炸。
8) 禁止给已损坏的电池包充电。
9) 如果充电器上的电源线损坏，请及时更换。
10) 取下电池包之前务必先拔下充电器电源插头。
11) 充电过程中，充电器和电池包发热属正常现象。
12) 不使用机器时，请勿将充过电的电池包插在充
电器上。
13) 充电结束，请立即将电池包拔离充电器。
14)
机器工作时，机身和电池包都会发热，属正常现象。
15) 禁止将废弃电池包置于火中或随生活垃圾处理，
必须送回当地收集站或回收点回收。
16) 在墙体、地板、天花板上拧螺钉或钻孔之前，
要仔细检查是否布有电线电缆、天然气管道或
者水管，以免被螺钉或钻头损坏。
17)
使用机器时需戴防护耳罩，否则可能导致听力受损 。
18)
机器工作时，附件和金属部件会发烫，属正常现象。
19) 操作机器时，机器可能会接触到隐藏的电线，
必须握住机器的绝缘表面。接触到通电导线会
使机器表面的金属带电，使用者受到电击。
电池包在温度过高或过度使用的情况下，可能会发
生漏液现象。如果电池漏出的液体沾到皮肤上，要
先用肥皂清洗，然后用柠檬汁、醋进行冲洗；若不
慎触及眼睛，应立即用清水进行冲洗，并马上去医
院检查治疗。
充电器安全警告：
1. 使用前请阅读说明书。
2. 仅在室内使用，禁止置于雨或水中。
3. 禁止给不可充电电池充电。
4. 如果电源软线损坏，为避免危险，必须由制造商、
其维修部或类似部门的专业人员更换。
充电式冲击起子机使用安全警告：
1. 当进行作业时紧固件可能会接触到隐藏的电线，
请握住电动工具的绝缘抓握表面。紧固件接触到
“带电”的电线时，工具上曝露的金属部分可能
也会“带电”，并使操作者触电。
2. 请务必确保立足稳固。在高处使用工具时确保下
方无人。
3. 请牢握本工具。
4. 佩带耳罩。
5. 操作之后，请勿立刻触摸起子头或工件。它们可
能会非常烫而导致烫伤皮肤。
6. 手应远离旋转的部件。
标记
为减少伤害，用户应仔细阅读说明书
警告标记
请戴防护耳罩
请戴防护眼镜
请戴防尘面具
仅在室内使用
禁止置于雨或水中
禁止置于火中
请勿丢弃电池，将废旧电池送回到你
当地收集或回收点回收
该产品包含有某些有毒有害物质，
在环保使用期限内可以放心使用，超
过环保使用期限之后则应该进入回收
循环系统。
2
产品中有毒有害物质或元素的名称及含量
部件名称
有毒有害物质或元素
铅
（Pb）
汞
（Hg）
镉
（Cd）
六价铬
（Cr(VI）
多溴联苯
（PBB）
多溴二苯醚
（PBDE）
外壳的金属部分 ○ ○ ○ ○ ○ ○
外壳的非金属部分 ○ ○ ○ ○ ○ ○
机械传动机构 × ○ ○ ○ ○ ○
电机组件 × ○ ○ ○ ○ ○
控制组件 × ○ ○ ○ ○ ○
附件 ○○○○○○
配件 ○○○○○○
连接件 ×○○○○○
电源线＊① ○ ○ ○ ○ ○ ○
电池系统＊② × ○ ○ ○ ○ ○
本表格依据 SJ/T11364 的规定编制。
○: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
×: 表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
且目前业界没有成熟的替代方案，符合欧盟 RoHS 指令环保要求。
＊①适用于采用电源线连接供电的产品。
＊②适用于采用充电电池供电的产品。
产品环保使用期限内的使用条件参见产品说明书。

6 51086C V_SC_51086C_202105 7
机件：
1. 套筒
2. 工作灯
3. 起停开关
4. 电量显示
5. 电池包锁钮
6. 换向拨杆
7. 电池包
随机附件
机器型号 内容 数量
51086C 2.0 安时锂电 电池包 1
30 分钟 充电器 1
我们建议您从所购买电动工具的商店选配您的附件。
请使用有知名品牌的高质量的附件。请选择适合您
工作所需的正确附件。请参考附件包装，您将获得
附件使用的更多的方法及帮助。
机器规格
机器型号 51086C
电压 12 V
空载转速 0-2300 转/分钟
冲击频率
0-3000 次/分钟
最大转矩
100 牛顿 .米
最大夹头直径 6.35 毫米
机器重量 1.1 千克
电池容量 2000 毫安时
充电时间 30 分钟
操作指南
注意：
使用机器前，请仔细阅读说明书。
使用之前
1) 充电
本充电器和机器需配套使用，严禁使用其他充电器。
本机器内设保护线路，当电池电量不足时，保护线
路开启，机器停止转动。
在温度较高的环境中或者长时间使用后，机器可能
会发烫，这时请不要立即充电，待电池冷却后再充电，
否则将缩短电池的使用寿命或者因电池过热导致无
法充电。
机器首次充电时或者长时间不用后，第一次充电器
效率可能只能达到 60% 左右，需经 2-3 次的充放电
之后，电池效率方可达到 100%。
2) 安装 /拆除电池包（见图 A）
要取出电池包时，按下电池包锁钮，然后将其拉出。
要插入电池包时，只要将其轻推入机器即可 . 切忌
用力过猛。
操作
1. 启动 /关闭 (见图 B)
按住开关（1），机器启动，松开则机器停止运转。
2. 开关调速
在开关上的施力大小，可改变转速。改变范围在 0
至最大转速间，施力小，转速低，起转缓稳容易控制。
在稳定可靠的启动后，充分按下开关以获得更快的
速度 。
请勿长时间轻轻按压开关低速操作，否则机器内
部会产生过热反应。每次停机后再改变机器的转
速档位。
3. 开关锁定（见图 C）
开关具有锁住保护功能，有利于减少在没有使用的
情况下误启动机器。将转向拨杆（3）调节至正中
位置，就可以将机器锁住。
A
3
C
1
2
3
4
7
6
5
1
B
E
D
套筒
夹头

8 51086C V_SC_51086C_202105 9
4. 改变旋转方向（见图 C）
正转：把转向拨杆（3）标有“”一面推到底（移
至左侧），可用于钻孔和旋入螺丝。反转：把转向
拨杆拨标有“ ”的一面推到底（移至右侧），
可用于转松或转出螺丝。
机器完全静止后才可变换转向。
5. 安装或拆卸起子头（见图 D）
注意：在安装或拆卸钻头时，一定先确认机器是否
已关掉，电池包是否已取出。
机器拥有快装夹头系统；
安装起子头时，向前拉动套筒并将起子头一直插到
夹头最里端。然后松开套筒以固定起子头。
拆卸起子头时，向前拉动套筒并将起子头向外侧拉
出，然后松开套筒以使其复位。
开机前，注意确保起子头被夹头完全固定。
6. 工作灯
机器带有照明工作灯：当使用机器按下开关时，照
明灯亮；松开，照明灯熄灭。
7. 电池电量指示（图 E）
按下机器开关，电量指示灯亮，可按照下表判断电
池包剩余电量 ,释放开关，电量指示灯熄灭。
LED 灯显示 剩余电量
0-25%
25-50%
50-75%
75-100%
8. 操作
适当的紧固转矩随螺丝／螺栓的种类或尺寸以及待
紧固工件的材料等因素而有所不同。
紧握工具并将起子头的尖端置于螺丝的头部。对工
具施加向前的压力达到使起子头不会从螺丝上滑落
的程度，这样便可启动工具开始操作。
1）冲击时间越久，扭矩越大，在 6-10S 左右达到
最大值。
2）速度越快，扭矩越大。
3）待紧固工件越硬，扭矩越大。
4）在拧小的螺钉时，低速短时拧紧螺钉，否则会
损坏螺钉。
• 使用适合螺丝／螺栓头部的起子头。
• 在拧螺丝时，最好预先钻个导向孔。
• 当紧固 M8 或更小号的螺丝时，选择合适的冲击力
并注意调节施加在开关扳机上的压力以免损坏螺
丝。
• 握持工具时将其笔直对准螺丝。
• 如果紧固螺丝的冲击力太强或紧固时间过久，螺
丝或起子头尖端将会受到过度的牵拉、挤、压损
坏等。在开始作业前，一定要进行测试操作以确
定所使用螺丝的适当紧固时间。
紧固转矩受下述多种因素影响。紧固后，请务必使
用转矩扳手确认转矩。
1）当电池组电量将要完全耗尽时，电压将会下降，
紧固转矩也会减小。
2）起子头或套筒起子头使用尺寸不当的起子头或
套筒起子头将会减小紧固转矩。
3）螺栓
• 即使转矩系数和螺栓等级相同，但因其直径不
同，所需紧固转矩也不同。
• 即使螺栓的直径相同，但因其转矩系数、等级
及其长度不同，所需紧固转矩也不相同。
4）握持工具的方式或上螺栓部位的材料也会影响
转矩。
5）低速操作工具也会减小紧固转矩。
�
使用短小的螺丝批头时，请利用磁性连接杆 ( 不含 )。
拧螺丝时，在螺纹上涂抹少许肥皂液或其他润滑液，
以便轻松拧入。
问题解答：
1、为什么按压开关而机器却不运转？
在开关上部有一个转向拨杆，处在锁住的位置。将
其拨向需要转动方向的位置，再按下按钮，机器就
会开始转动。
2、为什么在还未拧紧时，机器就停止运转？
机器带有低压保护，在电池包电量过低时，机器不
能工作，请确认电池包电量。
本机带有温度保护，当长时间满负荷工作时，电池
包会过热，温保系统会启动导致机器停止运转，请
将机器冷却到常温后再继续使用。
3、为什么同一个电池包的工作时间会有长有短？
一个电池包如果放置时间过长而不使用的话，就会
缩短其工作时间，这就是充电次数问题。
在经过几次充电和使用之后，这种状况就会得到改
善。在干重活时，电池包的电量也会消耗的很快。
不要在 0℃以下或 35℃以上的环境里充电，这同样
会影响到电池包的工作表现。
保养与维护
对机器作任何换修工作之前，请务必先拔出插头。
您的电动工具不需要再添加润滑油或进行其它保养。
不要用水或化学清洗剂来清洗你的电动工具，用干
布擦拭干净就可以了。工具需储藏在干燥的环境中，
并保持马达通风口处的清洁。尽量不要在灰尘较大
的环境中使用。
为了有利于与电池包寿命，请注意：
1）电池包存放：将电池包充电 30%-50% 电量，存
放在 26℃以下环境中。
2）不超过 6个月时间，将电池包充满电使用一次。
废弃电池包的处理
为保护自然环境，请妥善回收或处理电
池包。该电池包含有锂电池。请向当地
废物处理部门咨询有关回收和（/或）
处理的信息。通过使用手电钻把电池包
电量耗尽，卸下电池包，用结实的胶带
包裹好极片端口，避免短路和漏电。请
勿试图打开或拆取任何部件。
环境保护
处理废弃物
为了响应环保，对于坏损的机器、配
件及包装材料必须详细加以分类处理，
以便利于回收。
为方便分类回收，各塑胶部位都做有
材料标识。

10 51086C 11
V_SC_51086C_202105
GENERAL SAFETY WARNING OF ELECTRIC
TOOL:
Read all warnings and instructions. Failure to follow
the warnings listed below and instruction may result
in electric shock, fire and/or serious injury. Keep all
warnings and instruction for review. "Electric tool"
in all of the following warnings refers to the electric
tool driven by mains supply (wired) or the battery
(wireless).
General safety warning of electric tool - workplace
1) Keep the work area clean and bright.
Disordered and dark site may cause accidents.
2) Do not operate the electric tool in the
explosive environment such as the flammable
liquid, gas or dust. The spark generated by the
electric tool will ignite the dust or gas.
3) Operate the electric tool in the event of no
children and bystanders around it. Inattention
may cause the operator to lose control of tool.
General safety warning of electric tool - electrical
safety
1) Plug of electric tool shall be supported by the
socket. Never modify the plug in any way. Any
change-over plug shall not be used for the
electric tool to be grounded. Unmodified plug
and corresponding socket will reduce the risk
of electric shock.
2) Do not contact the grounded surface such as
the pipe, cooling fin and refrigerator. If your
body is grounded, the risk of electric shock will
increase.
3) Do not expose the electric tool to the rain or
moisture. Water entering the electric tool will
increase the risk of electric shock.
4) Do not abuse the wire. Never carry, pull the
electric tool with wire or pull out its plug.
Keep the electric tool away from heat source,
oil, sharp edges or moving parts. Damaged
or entangled cords may increase the risk of
electric shock.
5) For the outdoor application, an external cord
for outdoor use shall be used. A cord suitable
for outdoor will reduce the risk of electric
shock.
6) If it is inevitable to operate the electric tool
in the humid conditions, the residual current
device (RCD) shall be used. RCD is able to
reduce the risk of electric shock.
General safety warning of electric
tool - personal safety
1) Keep alert and awake when operating the
electric tool. Do not operate the electric tool
when you are tired or have medication, alcohol
or a therapeutic response. Instantaneous
negligence in the operation of electric tool may
result in serious personal injury.
2) Wear the personal protective equipment.
Always wear the goggles. Safety devices,
such as the dust mask, anti-slip safety shoes,
helmet, listening protection, etc., are able to
reduce the personal injury.
3) Prevent the accidental starting. Make sure
that the tool is switched off when connecting
the power supply and/or battery box, picking
up or carrying the tool. Putting the finger on
the switch which is powered on or inserting the
plug when the switch is turned on may result in
the danger.
4) Remove all adjustment keys or wrenches
before turning on the electric tool. A wrench
or key left on the rotating part of electric tool
may cause the personal injury.
5) Do not stretch your hands excessively, and
always pay attention to the foothold and body
balance. This provides excellent control of
electric tool in unexpected situations.
6) Dress properly. Do not wear loose clothing or
jewelry. Keep the clothes, gloves and hair away
from moving parts. Loose clothes, accessories
or long hair may get caught in moving parts.
7) If a device for connecting the chip conveyor
and dust collector is provided, make sure that
they are connected well and used properly.
These devices are able to reduce the risk of
dust.
WARNING
General safety warning of electric tool - use and
precautions of electric tool
1) Do not abuse the electric tool and select the
appropriate electric tool according to the
application. The appropriately designed electric
tool will make your work more efficient and
safer.
2) The electric tool shall not be used if the switch
is unable to turn on/off the power. Electric
tools that cannot be controlled with switches
are dangerous and shall be repaired.
3) Before making any adjustments, replacing
the accessories or storing the electric tool,
remove the plug from the power supply and/
or disengage the battery box from the tool.
This protective measure will reduce the risk of
accidental start of tool.
4) Place the unused electric tool outside the
reach of children, and do not let the electric
tool operated by the people who are not
familiar with the electric tool or who do not
understand these instructions. The electric tool
is a potential threat in the hands of untrained
users.
5) Maintenance of electric tool Check whether
the moving parts are in place or stuck, check
the parts for damage and other conditions
that affect the operation of electric tool. The
damaged electric tool shall be repaired before
use. Many accidents are caused by poorly
maintained electric tools.
6) Keep the cutting tool sharp and clean. Well-
maintained tools with sharp cutting edges are
not easy to get stuck and easy to control.
7) Use the electric tool, accessories, cutter
bit, etc. in accordance with the instructions,
taking into account the operating conditions
and works to be performed. Applying the
electric tool for operations that do not match
the purpose may be dangerous.
General safety warning of electric tool - use and
precautions of battery tool
1) Charge the battery only with the charger
specified by the manufacturer. Unmatched
charger and battery pack may cause the risk of
fire.
2) Use the electric tool only if a dedicated battery
box is provided. Unmatched battery pack may
cause the risk of damage and fire.
3) When the battery box is not in use, keep it
away from other metal objects, such as the
clip, coin, key, nail, screw or others, to prevent
one end from being connected to the other
end. A short circuit at the end of battery may
cause a fire.
4) The abuse will make the liquid splash out of
the battery. Therefore, the exposure shall be
avoided. In case of accidental exposure, rinse
it with water. In case of splash into the eye,
seek the medical assistance. Liquid spilled
from the battery may cause the corrosion or
burning.
5) Before inserting the battery pack into the
machine, make sure that the machine is
switched off.
General safety warning of electric tool - repair
1) Have the qualified maintenance personnel to
repair the electric tool with the same spare
parts. This will ensure the safety of the electric
tool being repaired.
Professional requirements
1) Be sure to take out the battery pack before
repairing the machine.
2) Do not place the machine in the rain or water
3) Do not store the battery pack above 40 °C.
4) Charge the battery from 0 to 30 °C, preferably
18 to 24 °C.
5) Only use the accompanied charger and battery
pack.
6) Avoid the short circuit of battery pack (for
example: do not make the bolts and nails touch
the positive and negative poles of battery pack)
7) Do not burn the battery pack or discard it in the
fire. Otherwise, an explosion may occur.
8) Do not charge the damaged battery pack.

12 51086C 13
V_SC_51086C_202105
9) Replace the damaged power cord timely.
10) Be sure to pull the plug off before removing the
battery pack.
11) During the charging, it is normal for the charger
and battery pack to heat up.
12) When the machine is not in use, do not insert
the charged battery pack into the charger.
13) After the charging is over, please pull the
battery pack off the charger immediately.
14) During the operation, it is normal for the body
and battery pack to heat up.
15) Do not put the discarded battery pack in fire
or dispose it with domestic garbage, and be
sure to send it to the local collection station or
recycling point.
16) Carefully check for the cable, natural gas or
water pipes before driving the screw or drilling
the hole in the wall, floor and ceiling.
17) Wear the earmuffs when operating the
machine. Otherwise the hearing may be
damaged.
18) During the operation, it is normal for the
accessories and metal parts to heat up.
19) The operating machine may come into contact
with the hidden wires. Therefore, be sure to
hold the insulating surface of machine. Contact
with the live wires may electrify the metal on
the surface of machine and cause an electric
shock of user.
WARNING
Battery pack leakage may occur if the operating
temperature is too high or the pack is excessively
used. If the liquid leaking from the battery gets on
the skin, wash it with soap first, then rinse it with
lemon juice or vinegar. In case of contact with the
eyes, rinse the eyes with clean water immediately
and go to the hospital for treatment.
Safety warning of charger:
1. Please read the instruction before use.
2. Only for indoors, no rain or water
3. Do not charge the non-rechargeable battery.
4. The damaged power cord shall be replaced
by the professional technician from the
manufacturer, its service department or similar
department.
Safety warning of rechargeable impact
screwdriver
1. The fasteners may come into contact with
the hidden wires. Therefore, be sure to hold
the insulating surface of machine. Contact
with the live wires may electrify the metal on
the surface of machine and cause an electric
shock of user.
2. Be sure to stand firmly. Make sure that no one
is underneath when using the tool at height
3. Please hold this tool firmly
4. Wear earmuffs.
5. Do not touch the screwdriver bit or workpiece
immediately after operation. They can be very
hot and cause burns to the skin.
6. Keep hands away from rotating parts.
MARK
2
To reduce the damage, the user shall
read the warning marks in instructions
carefully
Do not place the machine in the rain or
water
Do not discard the battery and return
the used battery to the local collection
or recycling point.
It may be recycled and shall not be
discarded at will. The battery pack
contains certain toxic and harmful
substances, and may be used safely
during the environment-friendly
use period. After the above period
is expired, it shall be put into the
recycling system.
Do not place it in the fire
Please wear the earmuffs
Warning marks
Please wear the protective glasses
Please wear the dust mask
Only for indoors

14 51086C 15
V_SC_51086C_202105
Machine part:
1. Chuck
2. Work light
3. Start/stop switch
4. Battery level display
5. Battery pack lock button
6. Reversing yoke
7. Battery pack
Accompanied accessories:
Model Content Quantity
51086C 2.0 Ah Li-ion battery
pack
1
30min charger 1
We recommend that you choose the accessories
from the store where you purchased the electric
tool. Please use the high-quality accessories from
the well-known brands. Please choose the right
accessory for your job. Please refer to the accessory
package and you will get more methods and help for
using the accessory.
Specification
Model 51086C
Voltage 12V
No-loading speed 0-2300/rev/min
Frequency 0-3000 impacts/min
Max. torque 100 N•m
Maximum
diameter of chuck
6.35mm
Machine weight 1.1kg
Battery capacity 2000mAh
Recharge time 30min
OPERATION GUIDELINE
Before the use
1) Charging
This charger and machine shall be used together. Do
not use other chargers.
The machine has a protection circuit. When the
battery is low, the protection circuit is turned on and
the machine stops rotating.
The machine may become hot under the high
temperatures or after a long period of operation. At
this time, do not charge immediately but wait until
the battery is cooled. Otherwise, the service life of
battery will be shortened or the charging failure may
be caused due to overheating.
For the first charging or after a long period of storage,
the efficiency of first charging may only reach about
60%. After 2-3 charging and discharging cycles, the
battery efficiency may reach 100%.
2) Installation and removal of battery pack (see
Figure A)
Press the lock buttons on both sides of battery pack
and pull it out. To insert the battery pack, simply push
it into the machine. Avoid the excessive force
OPERATION
1. Start/stop (see Figure B)
Press and hold the switch (1) to start the machine,
and release it to stop the machine.
2. Speed regulation
Change the force applied to the switch to regulate the
rotating speed. The range of adjustment is between
0 and the maximum rotating speed. The smaller the
force is, the lower the rotating speed is. The drilling
starts slowly and stably. After the stable and reliable
start, press the switch fully for higher speed.
WARNING
Do not operate at low speed for a long time by
pressing the switch. Otherwise the machine will be
overheating inside. Change the rotating speed after
stop.
3. Switch lock (see Figure C)
The switch has the lock protection function which
Caution: Please read the instruction
carefully before operating the machine.
A
3
C
E
D
Sleeve
Chuck
1
2
3
4
7
6
5
1
B

16 51086C 17
V_SC_51086C_202105
0-25%
25-50%
50-75%
75-100%
LED display Remaining battery
8. Operation
The proper tightening torque may vary depending
on the type or size of screw/bolt and the material of
workpiece to be fastened.
Hold the tool and place the tip of bit on the head of
screw. Apply a forward pressure to the tool to make
the screwdriver bit not slip off the screw, and start the
tool to begin the operation.
1) The longer the impact lasts, the greater the
torque is. The maximum value is achieved at
about 6-10 s.
2) The higher the speed is, the greater the torque
is.
3) The harder the workpiece to be fastened is, the
greater the torque is.
4) Be sure to tighten the small screw slowly for a
short time. Otherwise the screw will bedamaged.
Note:
1) Use a screwdriver bit that fits the screw /bolt
head.
2) When tightening the screw, it is best to pre-drill
a pilot hole.
3) When tightening the M8 or smaller screw, select
the appropriate impact force and take care to
adjust the pressure applied to the switch trigger
to avoid damage to the screw.
4) Hold the tool and align it with the screw.
5) If the impact force for fastening the screw is
too strong or the fastening time is too long, the
screw or screwdriver bit tip may be subjected
to excessive pulling, squeezing, pressure and
even be damaged. Be sure to perform a test
to determine the proper tightening time of the
screw before starting the job.
helps to avoid the accidental activation of the hand
drill. Lock the machine by adjusting the reversing yoke
(2) to the center position.
4. Rotation reversing (see Figure C)
Forward: Push the side of reversing yoke (3) marked
with “ " to the end (left side) for drilling a
hole and driving the screw. Reverse: Push the side of
reversing yoke marked with “ " to the end (right
side) for releasing or unscrewing the screw.
WARNING
The rotating speed can only be changed after the
machine is completely still.
5. Installation or removal of screwdriver bit
(see Figure D)
Caution: When installing or removing the bit, be sure
to confirm that the machine has been turned off and
that the battery pack has been removed.
The machine is designed with a quick-loading chuck
system;
When installing the screwdriver bit, pull the sleeve
forward and insert the screwdriver bit into the chuck.
Loosen the sleeve to fix the screwdriver bit.
When removing the screwdriver bit, pull the sleeve
forward and pull the bit out, and then release the
sleeve to reset it.
WARNING
Before starting the machine, make sure that the
screwdriver bit is fully fixed by the chuck.
6. Work light
Machine is equipped with the work light: when the
switch is pressed, the light will come on; when it is
released, light will go out.
7. Battery level display (Figure E)
When the machine switch is pressed, the battery
indicator will come on. The remaining capacity of
battery pack may be determined according to the
following table, and when the switch is released, the
indicator will go out.
Tightening torque is affected by many factors as
described below. After tightening, be sure to confirm
the torque with the torque wrench.
1) When the battery pack is about to run out
completely, the voltage will drop and the
tightening torque will also decrease.
2) The improperly sized screwdriver bit or sleeve
screwdriver bit may reduce the tightening
torque.
3) Bolt
Even if the torque coefficient and the bolt level are
the same, the tightening torque is different because
of the different diameters.
Even if the diameter of bolt is the same, the required
tightening torque is different depending on its toque
coefficient and its length.
4) The way the tool is held or the material on the
bolt will also affect the torque.
5) Operating at low speed will also reduce the
tightening torque.
WARNING
For the short screwdriver bit, use a magnetic
connecting rod (not included). When tightening the
screw, apply a little soap or other lubricant to the
thread to facilitate the operation.
QUESTION AND ANSWER:
1. Why does the machine not operate after the
switch is pressed?
A reversing yoke is located on the upper part of
switch. It is locked. Turn it to the position where the
rotation is in need, and then press the button to
rotate the machine.
2. Why does the hand drill stop when the screw has
not been tightened?
The machine has low-voltage protection. When the
level of battery pack is too low, the machine will not
work. Please confirm the level of battery pack.
The machine has temperature protection. When
the battery is working at full load for a long time,
the battery pack will overheat and the temperature
protection system will start to stop the machine.
Cool the machine to normal temperature before
resumption.
3. Why is the service life of same kind of battery pack
is different?
If a battery pack is left unused for a long time, its
service life may be shortened. This is the matter
of charging frequency. Repeated charging and
application may improve the situation. In case of
heavy work, the battery pack will run out soon. Do not
charge in a temperature below 0 °C or above 35 °C.
Otherwise, the performance of battery pack will be
affected.
MAINTENANCE
Be sure to pull off the plug before repairing or
replacing the machine.
The electric tool does not require additional
lubrication or other maintenance. Do not wash the
electric tool with the water or chemical cleaner. Wipe
it off with a dry cloth. Tool shall be stored under the
dry conditions and kept clean at the vent of motor. Try
not to use it in a dusty environment.
To prolong the service life of battery pack:
1) Store the battery pack below 26 °C after
charging it to 30%-50%.
2) Charge the battery pack fully once in less than 6
months.

18 51086C 19
V_SC_51086C_202105
To protect the natural environment, please
recycle or dispose of the battery pack
properly. The battery pack contains a Li-
ion battery. Please consult the local waste
disposal department for the information
on recycling and/or disposal. Exhaust the
battery pack with the hand drill, remove the
battery pack, and wrap the pole port with
strong tape to avoid the short circuit and
leakage. Do not attempt to open or remove
any part.
The damaged machine, accessories and
packaging materials shall be classified in
detail for recycling in line with environmental
protection requirements.
All plastic parts are marked with material
identifications to facilitate the classification
and recycling.
DISPOSAL OF DISCARDED BATTERY PACK
ENVIRONMENTAL PROTECTION

/ Model 51086C
/ Version No V-SC-51086C-202105
SATA TOOL (SHANGHAI) LIMITED
177 302
Customer service: Room 302, Area A, No. 177, Bibo Road, Pudong New Area, Shanghai
/Post: 201203
/Tel.: [phone]
/Fax: [phone]
