1. Welcome!
DearCustomer,
We'repleasedthatyouhavechosentheBluetoothGPSreceiverSatGuideBT‐ GPS‐8andwouldliketo
thankyouforyourconfidenceinourproduct.
TheGPSreceiverissuitableforthemobilenavigationserviceofferedbyvariouspartnersonmany
Bluetoothenabledmobiles.TheGPSreceiverusesitsownbuilt‐inbattery,doesn'tdrainyourmobile's
batteryandallowsyoutouseitoutsideyourvehicle.ThecarchargercablechargesyourGPSreceiver
whiledriving.YoucanalsochargethebatteryofyourGPSreceiverinapowersocketwithamains
adapterbeforetravel,ajourneyorabicycleormotorcycletour.
ThisGPSreceiverisastate‐ of‐ the‐ artdeviceofthehighestquality.ThankstobatteryandBluetooth
technology,youcanusetheGPSreceivercompletelycablefree.Inadditiontothisthebuilt‐in
automaticshutdownensuresalongoperatingtime.TheSiRFStarIIIchipsetinstalledhasverylowpower
consumptionandoffersthehighestlevelsofGPSsensitivity.
ThismanualexplainstheoperationoftheGPSreceiver.
BeforeusingtheGPSreceiverforthefirsttimecarefullyobservethenotesinchapter3"SafetyNotes",
page5.
SatGuidewishesyouagoodjourneyandenjoyyournavigation!
GOODTOKNOW
1) BeforeusingyourGPSreceiverforthefirsttime,pleasefullychargethebatteryforabout1.5
hours.
2) Neverchargewithanunspecifiedchargerorspecifiedchargerthathasbeenmodified.This
cancausebreakdownofthebatteryorswellingandrupturing.
3) Don’toverchargetheGPSreceiverthanmentioningtimeinthefirstpoint.
4) Neveroverchargewithhighcurrents(i.e.higherthanrated,thuscausingbatteriestoswellor
rupture.Don'tleavetheGPSreceiver with chargeronceitisfullycharged.
4
2. GeneralInformation
2.1WhatisGPS?
TheGPS(GlobalPositioningSystem)satellitesystemwasoriginallysetupbytheMinistryofDefenseof
theUnitedStatesofAmericainordertoimproveprecisecontrolformilitarypurposes.TheUScongress
grantedfundsatthattimeforsettingupthesystem,howeveronlyontheconditionthatitwasalso
madeavailableforfreecivilianuse.
GPSsatellitessendtwodivergentsignals:anencoded,veryprecisesignalforNATO(P)andan
unencryptedsignalforcivilianpurposes,i.e.foreveryone(L1).YourGPSreceivercanreceivethe
unencryptedsignalforcivilianpurposes(L1).TheciviliansignalcanbeusedbymeansofGPSreceivers
byanyone,atanytime,world‐wideandlicensefreee.g.forvehiclenavigation.
AlsotheGPSsatellitesysteminEuropeisoperatedbytheGovernmentoftheUnitedStatesofAmerica
whichalsohasexclusiveresponsibilityfortheaccuracyandmaintenanceofthesystem.Thesystemis
constantlyimprovedandmodificationscanconsequentlyinfluencetheaccuracyandtheperformanceof
theGPSreceiver.
Achievableaccuracyfortheciviliansignaliscurrentlyabout10meters.Before2ndMay2000thissignal
wasintentionallyfalsifiedbytheUSA(SA,SelectiveAvailability)andachievableaccuracywas100mat
thattime."SelectiveAvailability"orSAistheartificialdegradationofthesatellitesignalbytheUS
military.Thesignalcancurrentlystillbeartificiallyfalsifiedinemergencies.Thiscanleadtosubstantial
impairmentswiththeuseofyourGPSreceiverandmakeitunusable,atleasttemporarily,forcertain
applications,e.g.navigation.SatGuidehasnoinfluenceonthis.
Thereareabout30satellites(24satellitespluscorrectionandreservesatellites)onsixpathsin
circulation,ofwhichupto12canbepresentoverthehorizon.YourGPSreceiverhas20channelsand
canthereforereceivesignalsfromall12satellitesatthesametime,aslongasitisinvisualcontactwith
them,resultinginoptimizedcalculationoftheGPSreceiver'sposition.
WheneveryourGPSreceiverhasaccesstoaclearsky,itcandetermineitsposition,directionandspeed
withinashortperiodoftime.ThickcloudsandheavyrainfallcanimpairGPSreception.Thetimeittakes
toestablishinitialcontacttothesatellites(Time‐ to‐ First‐ Fix,TTFF)isreducedconsiderablybyan
assistedGPSfunctionalityinSatGuideandcantakefewsecondswhentheassistedfunctionalityis
availableandaccesstoclearskyisunobstructedorseveralminuteswhenconditionsarenotoptimal.
5
2.2WhatisBluetooth?
Bluetoothisanopenstandardforanewandeffectivetechnologyforwirelesscommunicationbetween
desktopsandlaptops,PDAs,mobilephones,cameraphones,printers,digitalcameras,computermice,
keyboards,GPSreceiversetc.
WirelessBluetoothtechnologyusesagloballyavailablefrequency(2.4GHz)inordertoguarantee
worldwidecompatibility.Inshort:BluetoothmakesyourGPSreceivercablefreeandmakesmessycable
connectionsathingofthepast.WiththeBluetoothtechnologyintegratedintoyourGPSreceiveryou
canconnecttoaBluetoothenabledmobilephone–wirelessly–withinaradiusofabout10m.
3. SafetyNotes
ThischaptercontainsimportantinformationforthesafeandreliableuseoftheSatGuidenavigation
softwarewithyourmobilephoneandthecorrespondingGPSreceiveranditsaccessories.Pleaseread
thissectioncarefullybeforeyoustartusingthesoftwareandanyofthedevices.
WhenusingtheSatGuidenavigationsoftwarewithyourmobilephoneorlaptop,thecorrespondingGPS
receiveranditsaccessories,makesuretoobservegeneralprecautionarysafetynotessuchasthose
specifiedbelowinordertoavoidfire,electricalshocks,personalinjuriesorotherdamages.
Makesuretoalsoobservethesafetynotesforyourmobilephone.Youcanfindtheseintheuser
manualforyourmobilephone.
¾Switchingon/offorsettingup
TheBluetoothGPSreceiverisoperatedbypressingtheon/offbuttononthesideoftheGPS
receiver.DonotusetheGPSreceiverand/oryourmobilephoneiftheuseofelectronicdevicesor
mobilephonesisprohibited,couldleadtointerferenceordanger.
¾Vehicles
RFsignalscansometimesimpairthefunctionofincorrectlyinstalledorinsufficientlyshielded
electronicsystemsinyourvehicle(e.g.electronicallycontrolledfuelinjectionsystems,electronic
ABSsystems(anti‐ skidsystems),electronicspeedregulators,andairbagsystems).Youcanobtain
informationaboutyourvehiclefromyourvehiclemanufactureroritsrepresentative.Youshould
alsoconsultmanufacturersofanydevicesoraccessoriessubsequentlyfittedinyourvehicle.
¾RoadSafetyFirst!
Alwayssecureyourmobilephoneinasuitableholderwhichenablesyoutoseethedisplaywithout
beingdistractedfromthetrafficsituation.Makesuretheinstallationofthemobilephoneholder,
GPSreceiverandcarchargercableoranyothercablesoraccessoriesinthevehicleinteriordoesnot
obstructthedriver'sviewandnopassengersafetysystems(likeairbags,seatbelts,pedals,controls
etc.)areobstructedorfunctionimpaired.TosecuretheGPSreceiverusetheprovidedmagnetic
holder,whichcanbeattachedtothedashboardofyourcarusingthedoublesidedstickytape
provided.Pleasemakesurethatthemobilephoneholderisattachedsafelyandthatyourmobile
phoneissecuredproperlyinthemobilephoneholder.
6
Keepthespaceinfrontandontopoftheairbagsabsolutelyclear.Makesurethatnopartsor
objectscanbetossedaround.
WhiledrivingconcentrateonlyonthetrafficandneverusetheGPSreceiverandyourmobilephone
whileyouareinmotion.Askyourpassengertousethemorifyouaredrivingonyourown,usethem
onlywhenyourvehicleisstationary.Thesameappliestotheadjustmentanduseofthecarmobile
phoneholder.
Followthedirectionsonlyiftrafficrulesandactualtrafficconditionspermitit.
Makesurethatyoualwayskeepcontrolofyourvehicleinalltrafficconditions.
¾Interference
MobilephonesandGPSreceivers,especiallytheBluetoothmodel,canbeaffectedbyinterference
whichimpairsperformance.
¾Switchoffinhospitals
Obeyallregulationsandrules.SwitchofftheGPSreceiverandyourmobilephoneintheproximity
ofmedicalinstruments.
¾Switchoffonboardofairplanes
MobilephonesandGPSreceiverscancauseinterferenceinairplanes.SwitchofftheGPSreceiver
andyourmobilephonebeforeenteringanairplaneandonboardanairplaneduringtheflight.
¾Restricteduse
TherecanberestrictionswithregardstousingmobilephonesandtheGPSreceiver,e.g.inpublic
placesoringovernmentbuildings,laboratories,explosiveareas,petrolstationsetc.Pleaseobserve
appropriatewarnings.
¾Accessories
Onlyuseandconnectapprovedandcompatibleaccessories.Donotusefaultybatterychargers,in
particularnofaultycarchargercablesandmainsadapters.
¾Battery
TheGPSreceiverhasaninternalbattery.BatteriesandthustheentireGPSreceivermustbe
disposedofinthecorrectmannerandmustnotbedisposedofinthedomesticwaste.
ATTENTION:
Atalltimes,roadtrafficregulationshavepriorityoverdirectionsfromthenavigationsoftware!
7
Donotusedefectivebatterychargers,carchargercablesormainsadapters.
Onlyqualifiedcustomerservicepersonnelshouldrepairthedevice.Batteriescanexplodedueto
incorrecthandling.YoushouldnotdismantletheGPSreceivernorthrowitintoopenfires.Non
observanceofthiswarningcancausepersonalinjuryordamagethedevice.
¾Connectingtootherdevices
ConnectonlycompatibleproductstotheGPSreceiver.
¾Waterimpact
NeitheryourmobilephonenortheGPSreceiveroritsaccessoriesarewaterprooforwaterresistant.
Keepthemdry.DonotuseyourmobilephoneortheGPSreceiveranditsaccessoriesinthe
proximityofwaterorinrooms/areaswithhighhumidity.Donotpourliquidsontoyourmobile
phoneortheGPSreceiveranditsaccessoriesanddonotimmersetheminwater.TheGPSreceiver
isnotintendedforuseontheoutsideofavehicle(e.g.ontheroofofacar).
¾HighTemperaturesandFire
DonotuseyourmobilephoneortheGPSreceiveranditsaccessoriesintheproximityoffireanddo
notexposethemtotemperatureshigherthan60°C(45°Cwhencharging).Donotexposeyour
mobilephoneortheGPSreceiveranditsaccessoriestodirectsunlight,inparticularnotinyour
vehicle.DonotstoreyourmobilephoneortheGPSreceiveranditsaccessoriesincold
temperatures,inparticularnotunder0°C.
¾Cleaning
Beforeyoustartcleaninganyofthedevicesmakesureyourmobilephone,theGPSreceiverandits
accessoriesareswitchedoffcompletely.Presstheon/offbuttononthesideoftheGPSreceiverto
turnitoff.DisconnecttheGPSreceiverfromthecarchargercableandcigarettelightersocketor
fromthemainsadapterandmainssocketbeforecleaning.Donotuseliquidoraerosolcleanersto
cleanyourmobilephone,theGPSreceiveroritsaccessories.Adampclothissufficient.
¾Children
Donotpermitchildrentoplaywithyourmobilephone,theGPSreceiveroritsaccessories.Theyare
nottoys–childrencouldhurtthemselvesorothers.Yourmobilephone,theGPSreceiverandits
accessoriesconsistofmanysmallpartswhichcouldbeswallowedbysmallchildren.Careless
handlingcanleadtodamageofyourmobilephone,theGPSreceiveroritsaccessories.
¾Electronicdevices
MostmodernelectronicdevicesareshieldedagainstHFsignals(radiofrequency).Itcanhappen
howeverthatcertainelectronicdevicesarenotshieldedagainsttheHFsignalsofyourGPSreceiver.
¾Cardiacpacemaker
Thefollowingappliestopeoplewithacardiacpacemaker:
Youshouldalwaysobserveaminimumdistanceof20cmbetweenyourmobilephoneorGPS
receiverandyourcardiacpacemaker,ifyourmobilephoneortheGPSreceiverareswitchedon.
8
)YoushouldnotkeepyourmobilephoneortheGPSreceiverinyourbreastpocket.Ifyouhave
reasontobelievethatinterferenceisoccurring,switchoffyourmobilephoneandtheGPS
receiverimmediatelybypressingtheon/offbuttononthesideoftheGPSreceiver.Seek
medicaladviceimmediately.
¾Hearingaids
MobilephonesandtheGPSreceivercancauseinterferencewithsomehearingaids.
¾Electrostaticdischarge(ESD)
TheGPSreceivercontainsclass1components.Theseshouldbeprotectedagainstelectrostatic
discharges(ESD).
¾Disposal
Yourmobilephone,theGPSreceiveranditsaccessoriesmustbedisposedofcorrectlyorrecycled
andmustnotbeputindomesticwaste.
4. FirstSteps
4.1Chargingthebuilt–inbattery
UsingtheCarChargerCable:
Plugthechargercableintothecigarettelightersocketofyourcar(12Vto24V).Dependingonthecar
youmighthavetoturntheignitionkeytoposition1or2inordertopowerthecigarettelighter.Please
checkyourcar'susermanualforfurtherinformation.
ATTENTION:
Makesureyouobservethenotesinchapter3"SafetyNotes"page5beforeusingtheGPSreceiver
forthefirsttime.
ATTENTION:
UsethecarchargercableonlyforchargingyourGPSreceiverasdescribedinthisusermanualand
notforchargingmobilesorotherdevices.Thebatteryisbuilt‐inandcanonlybechargedinsidethe
GPSreceiver.Thebatter
y
mustbechar
g
edbeforefirstuse.
9
(forillustration)
Assoonasthecarchargercableissuppliedwithelectricityfromthecigarettelightersocket,thepower
displayofthecarchargercablelightsup.
ATTENTION:
Ifsurgesoccurwhenstartingtheengine,werecommendyoutoremovethecarchargercablefrom
thecigarettelightersocketwhenstarting.
10
Incaruseandmainsoperation–connectingtheGPSreceiverwiththechargercable:
Inserttheplug(Øabout2mm)ofthecarchargercableintothechargingsocketoftheGPSreceiver.
(forillustration)
Whilstchargingthebatterythebatterydisplayshowsayellowlight.Whenthebatteryisfully
chargedtheyellowlightinthebatterydisplaydisappears.Thedeviceisthenreadyforuse.Please
removethechargercablefromthesocketoftheGPSreceiverandthecarchargerdevicefromthe
cigarettelightersocketorthemainsadapterfromthemainssocket.
ForlongbatterylifetheGPSreceiverhastotaldischargeprotection.About15minutesbeforeautomatic
shutdownthebatterydisplayshowsaredlight.Pleasechargethebatterypromptly.
\
Normalchargingtimeisabout2hours.IfyouchargetheGPSreceiverwhennavigatingandthe
GPSreceiverisswitchedonchargingcantakelonger.
Notethatanewbatteryachievesfullperformanceonlyafterhavingbeenfullychargedanddischarged
twoorthreetimes!Thebatterycanbechargedanddischargedhundredsoftimesbuteventuallywears
out.Iftheoperatingtimeisclearlyshorterthannormallythebatterymustbechangedbyaqualified
customerservicerepresentative.
ATTENTION:
Pleasefullychargethebatteryforabout1.5hoursbeforefirstuse.
11
ATTENTION:
TheGPSreceivershutsdownautomatically.IfnoBluetoothconnectionisactiveitswitchesitself
offafterabout5minutesinordertoensurealongeroperatingtime.
ATTENTION:
InappropriatehandlinginvalidatesthewarrantyofyourGPSreceiveranditsaccessories!Toavoid
this,pleasepayattentiontothecleaningRecommendationsfortheGPSreceiverandits
accessoriesinthismanual(Chapter7"ServicingandMaintenance",page24).
ATTENTION:
Makesurethatthecigarettelightersocketdoesnotcomeoutwhenremovingthecarcharger
cablefromtheinstrumentpanel.Pressdownontheedgeofthecigarettelightersocketatthe
sametimeas
p
ullin
g
withtheotherhand.
Extremetemperatureshaveanegativeinfluenceonthechargingabilityandcapacityofyourbattery.
Capacityandbatterylifeisreducedifthedeviceiskeptinexcessivelycoldorhotplaces,suchasacarin
extremesummerorwinterconditions.Youshouldalwaystrytokeepthebatteryintemperaturesof
between15°Cand25°C.AGPSreceiverwithabatterythatistoocoldortoohotmaynotfunction
temporarily,evenifthebatteryisfullycharged.Batteryperformanceislimitedinparticularwhen
temperaturesarebelowfreezingpoint.
ATTENTION:
DonotleavethechargingcableconnectedtothechargingsocketoftheGPSreceiverlongerthan
necessaryasoverchargingcanshortenitslifespan.Whennotusedafullychargedbatterywill
dischargeovertime.
DonotleavethecarchargercableintheGPSreceiversocketorthecigarettelightersocket
whenyouleaveyourvehicle.Ifusingamainsadapterremovethisfromthemainssocketif
chargingiscomplete.
12
4.2SwitchingtheGPSreceiveronandoff
Presstheon/offbuttonforapproximately3secondstoswitchthedeviceonoroff.
Pleasemakesureyourbatteryhasenoughpowerwhenusingit.Shouldthebatterypowerrunlow
pleaseusethecarchargercableorthemainsadapter.Forfurtherinformationonchargingthebattery
pleaserefertochapter4.1"Chargingthebuilt‐inbattery".
(forillustration)
ForfurtherinformationaboutusingtheGPSreceiverwiththeSatGuidenavigationsoftwarepleaserefer
tochapter6"ConnectingtheGPSReceiverwithyourMobilePhone".
4.3Thebuilt‐inbattery
ATTENTION:
DonotswitchyourmobilephoneandtheGPSreceiveroniftheuseofelectronicdevicesaswellas
mobilephonesisprohibited,canleadtointerferenceordanger.
ATTENTION:
TheGPSreceiverhasaninternalbatterywhichcannotberemoved.Donottrytoremovethe
battery.Wronghandlingcancausethebatterytoexplode.Onlyqualifiedcustomerservice
personnelshouldchangeadefectivebattery.Thebatterymustbedisposedoforrecycledaccording
tothelocalenvironmentalregulations.
13
ATTENTION:
Wheninstallingyourmobilephone,themobilephoneholder,theGPS
receiverandthecarchargercableinthevehicleinteriormakesuretheydo
notobstructthedriver'sviewandnopassengersafetysystems(likeairbags,
seatbelts,pedals,controlsetc..)areobstructedorfunctionimpaired.Always
keepthespaceinfrontandontopoftheairbagsabsolutelyclearofany
objects!
4.4Normaloperatingposition
TheGPSreceiverissecuredtothedashboardusingthesuppliedmagneticholder.Fixthemagnetic
holderinthemiddleofthedashboard,usingthesupplieddoublesidedtape.Thesurfacemustbeeven,
cleananddry.Cleanthesurfacebeforehand.Payattentiontothecleaningrecommendationsforthe
GPSreceiver(chapter7"ServicingandMaintenance")andthecleaningrecommendationsforthe
dashboard.
Whiledrivingconcentrateonlyonthetraffic,neverusetheGPSreceiverandyourmobilephonewhen
driving.Leavetheoperationofthedevicetoyourpassengeror,whentravellingalone,usetheGPS
receiverandmobilephoneonlywhenstationary.
Followtheinstructionsonlyifthetrafficregulationsandthecurrenttrafficsituationpermitit.
Makesurethatyouarealwaysincontrolofyourvehicleinalltrafficsituations.
ATTENTION:
Wecannotguaranteethesuccessfulfixationofthemagneticholder,aswehavenoinfluenceon
thesurfaceormaterialofyourcar'sdashboard.Whenremovingthemagneticholderfromthe
dashboardatalaterpointmakesurethatyoudonotdamageit.
Ifthetapeunderthemagneticholderlosesitsstickinessduetoexposureto
thesunthenpleaseexchangeit.
ATTENTION:
Roadtrafficregulationsalwayshavepriorityoverdirectionsfromthenavigationsoftware!
14
Notes:
Pleasenotethat,whenusingtheGPSreceiverforthefirsttimesynchronizationwiththesatellites
stronglydependsonthedirectandunobstructedexposuretothesky.Thetimeittakestoestablish
initialcontacttothesatellites(Time‐ to‐ First‐ Fix,TTFF)isreducedconsiderablybyanassistedGPS
functionalityinSatGuideandcantakefewsecondswhentheassistedfunctionalityisavailableand
accesstoclearskyisunobstructedorseveralminuteswhenconditionsarenotoptimal.
Usually,theGPSreceiverwiththeSiRFStarIIIchip‐setalsoreceivesGPSdatawithoutproblemsfromthe
dashboardpositioninvehicleswithheatreflectingormetal‐coatedwindscreens.Ifthisisnotthecase
checkwhetherthereisanuncoatedsectionofwindscreeninyourcarandfixtheGPSreceiverinthis
positiontakingintoaccountthesafetynotesonpage5.YoucanalsopositionyourGPSreceiveronthe
parcelshelfinthebackofyourcar.TherangeofyourBluetoothGPSreceiverisupto10m.
GOODTOKNOW
ForbestGPSreceptionyourvehicleshouldbeunderclearskiesandifpossiblenotbepositioned
undertrees,onroadssurroundedbyhigh‐ risebuildingsorinatunnel.Thebetterandless
obstructedtheviewtothesky,thebetterthesatellitedatareception.Fortheinitialsatellite
searchitmayalsobehelpfultostopyourcarforafewminutesandnotdrivearound.
15
5. FirstStepsButtons,DisplaysandConnectors
(forillustration)
5.1Start‐updisplay
IftheGPSreceiverhasbeenswitchedonandisreadyforuse,thefollowinglightsaredisplayed:
¾Bluetoothdisplay(blue)flashesirregularandshowsthattheGPSreceiverisreadyfora
Bluetoothconnection.AssoonasthemobilephonehasestablishedaBluetoothconnectiontothe
GPSreceiver,thedisplaylightsupcontinuously.
¾GPSdisplay(green)flashesandthusshowsthattheGPSreceiverislookingforsatellites,but
hasnotfoundanyyet.ItmeanstheGPSreceiverisnotyetuseablee.g.forpositioning.Assoonasit
hasfoundsatellites,thisdisplaylightsupgreencontinuously–thismeansthedeviceisreceiving
validGPSsignals.
16
¾Batterydisplay(red/yellow)doesnotlightup–thismeansthebatterystatusisOK.
5.2Displays
Thefollowinginformationisdisplayedbythe3LEDdisplays:
‐BluetoothDisplay(blue)
Irregularflashing:theGPSreceiverisreadyforaBluetoothconnection
Continuouslylit:aBluetoothconnectionhasbeenestablished
‐GPSDisplay(green)
Flashing:GPSreceiverissearchingforsatellites
Continuouslylit:enoughsatellitesforpositioning/navigationhavebeenfound
‐BatteryDisplay(red/yellow)
Unlit:batterystatusisOKorchargingiscompleteortheGPSreceiverisswitchedoff
Continuouslylitred:theGPSreceiverisswitchedonbutthebatteryhastoberecharged
Continuouslylityellow:thechargercableisconnectedtotheGPSreceiverandtheGPS
receiverischarging
17
6. ConnectingtheGPSReceiverwithyourMobilePhone
TheGPSreceivercommunicateswiththemobilephoneusingtheBluetoothSerialPortProfile(SPP).Itis
shownas„SatGuideBT‐ GPS‐8“.Dependingonthedeviceandthesoftwareyoumayhavetoentera
PINtopairit.Thisis:“0000”(fourzeros)foryourGPSreceiver.
TheBluetoothdisplay(blue)iscontinuouslylitassoonastheGPSreceiverhasestablisheda
Bluetoothconnectiontothemobilephone.Thisisthecaseassoonasyoustart‐upyourSatGuide
navigationsoftwaretosearchforaGPSsignal–andthenuntilyoustopusingSatGuideormovethe
GPSreceiveroutsideoftheBluetoothreceptionrange.
7. ServicingandMaintenance
YourGPSreceiverwasdesignedandmanufacturedwithgreatcareandshouldalsobetreatedwithcare.
Pleaseobservetheadvicebelow,toavoidexpiryoftheproductguaranteeandtoenjoyyourproductfor
manyyearstocome.
¾KeeptheGPSreceiveranditsaccessoriesoutofreachofinfants.
¾KeeptheGPSreceiveranditsaccessoriesdry.Rain,humidityandliquidspillscontainminerals
whichcorrodeelectroniccircuits.
¾DonotuseorstoretheGPSreceiveranditsaccessoriesindustyordirtyenvironments.Moving
partscanbedamaged.
¾DonotkeeptheGPSreceiveranditsaccessoriesinhotconditions.Hightemperaturescanshorten
thelifespanofelectronicdevicesanddeformormeltcertainplastics.
¾DonotkeeptheGPSreceiveranditsaccessoriesincoldconditions.Iftheywarmupagain
afterwards(totheirnormaloperatingtemperature),theycancreateinternalhumidity,whichcan
damageelectroniccircuitboards.
¾DonottrytoopentheGPSreceiveranditsaccessories.TheGPSreceiveranditsaccessoriescan
bedamagedbyinappropriatehandlinganditinvalidatesthewarranty!
¾Donotdrop,hitorshaketheGPSreceiveranditsaccessories.Inappropriate
handlingcanbreakcircuitboardsinsidetheGPSreceiver.
¾Donotusecorrosivechemicals,cleaningsolutionsorstrongsolventsforthecleaningoftheGPS
receiveranditsaccessories.
¾DonotpainttheGPSreceiveranditsaccessories.Thepaintcanjamdevicepartsandimpair
correctoperation.
¾Onlyusetheintegratedaerial.Unauthorizedmodificationsorunauthorizedaccessoriescould
damagetheGPSreceiveranditsaccessoriesandcontraveneregulationsforradios.
¾AlltheabovenotesapplyequallytoGPSreceivers,carchargercablesandallotheroptional
accessories.
ATTENTION:
Inappropriate handing invalidates the warranty for the device!
18
8. IncludedinDelivery
¾GPSreceiverwithBluetoothtechnologySatGuideBT‐GPS‐8
¾Magneticholder(withdoublesidedtape)tosecuretheGPSreceiver.
¾Carchargercablewithspiralcableandcigarettelighterplug(Input12Vto24V,output5V),fuse:
F2A/L250
9. TechnicalData
GPSreceiver:
¾20‐ChannelGPSreceiver
¾All‐In‐Viewtracking
¾L1frequency1575,42MHzC/Acode
¾GPSchip‐set:SiRFstarIII
¾Datalog:NMEA0183Version3.01(WGS‐84)
¾Positionaccuracy:5to10m–withoutSelectiveAvailability(SA)
¾Positioncalculation:continuouslyeachsecond
¾FastTTFF(Time‐To‐First‐Fix/timeittakestoestablishinitialcontacttoa
satellite):
)Hotstart1to6secondsaverage
)Warmstart35to40secondsaverage
)Coldstart42to60secondsaverage
¾Dynamicproperties:
)Altitudeunder18000m
)Speedunder514mpersecond
)Accelarationunder4g
¾Bluetooth:
)BluetoothVersion1.1
)Class2
)Profile:SerialPortProfile(SPP)
)Coveragedistance:upto10m
)PIN:0000
)Identifier:SatGuideBT‐GPS‐8
¾3LEDsforBluetooth‐,GPSandbatterydisplay
¾Aerial:integratedaerial
¾Built‐inbattery:Lithium‐Polymer‐Battery900mAh/5V,notchangeable
¾Operatingtime:upto9hours.
¾Automaticshutdownafterapprox.5minutes
¾Connectorforchargingequipment(+5.0to5.2VDC,750to800mA)
¾Dimensions:approx.90x42x12mm(LxWxH)
¾Weight:approx.65g
19
PackageIncludes:
Carchargercablewithspiralcableandcigarettelighterplug(Input12Vto24V,output5V),
fuse:F2A/L250
Validforalldevices:
¾Operatingtemperaturerangewhennotcharging:0to+60°C
¾Operatingtemperaturerangewhencharging:0bis+45°C
¾Temperaturerangewhennotinoperation(transport):‐20to+60°C
¾CE‐conformity
Table of contents
