Sauer Danfoss H1 Manual

H1
Axial Piston Pump
Size 045/053,
Single
Technical
Information

211063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Table of revisions
Date Page Changed Rev
30 Jul, 2009 — First edition AA
Feb 2010 various 14 teeth added BA
Jun, 2010 4-6, 10, 12,
14, 16-17
New EC directive CA
Feb 2011 Various Updated drawings DA
Nov 2012 Various AC added EA
Revisions
Front cover illustrations: F301 557, P003 515
Revision History
Further available literature
Description SD order number
Overview, H1 Axial Piston Pumps, Single and Tandem L1012919
Basic Information, H1 Axial Piston Pumps, Single and Tandem 11062168
Technical Information
H1 Axial Piston Pump, Size 045/053, Single 11063344
H1 Axial Piston Pump, Size 045/053, Tandem 11063345
H1 Axial Piston Pump, Size 060/068, Single 11071685
H1 Axial Piston Pump, Size 069/078, Single 11062169
H1 Axial Piston Pump, Size 089/100, Single 11069970
H1 Axial Piston Pump, Size 115/130, Single 11063346
H1 Axial Piston Pump, Size 147/165, Single 11063347
H1 Automotive Control for Single Axial Piston Pumps 045 - 165 cc L1223856
Complementary Products
External Remote Charge Pressure Filter 11064579
Speed and Temperature Sensor 11046759
Pressure Sensor L1007019
Hydraulic Fluids, Technical Information
Hydraulic Fluids and Lubricants 520L0463
Experience with Biodegradable Hydraulic Fluids 520L0465
Design Guideline for Hydraulic Fluid Cleanliness 520L0467
Application Information
Applications Manual, Section 1, Selection of Driveline Components BLN-9885
Applications Manual, Section 2, Pressure and Speed Limits for Hydraulic Units BLN-9884
Applications Manual, Section 4, Transmission Circuit Recommendations BLN-9886
PLUS+1 COMPLIANT (Electrical Installation)
H1 Electrical Displacement Control (EDC) 11022744
H1 3-position (FNR) Electric Control 11025001
H1 Non-Feedback Proportional Electric (NFPE) Control 11025002
Service Manuals
H1 Axial Piston Pump, Size 045/053, Single 520L0958
H1 Axial Piston Pump, Size 045/053, Tandem 520L0928
H1 Axial Piston Pump, Size 069/078/089/100/115/130/147/165, Single 520L0848
T000 143E
© 2012 Sauer-Danfoss. All rights reserved.
Sauer-Danfoss accepts no responsibility for possible errors in catalogs, brochures and other printed material.
Sauer -Danfoss reserves the right to alter its products without prior notice. This also applies to products
already ordered provided that such alterations can be made without a ecting agreed speci cations. All
trademarks in this material are properties of their respective owners. Sauer-Danfoss, the Sauer-Danfoss
logotype, the Sauer-Danfoss S-icon, PLUS+1™, What really matters is inside® and Know-How in Motion™ are
trademarks of the Sauer-Danfoss Group.

3
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Content
Technical Specications
General Technical
Specications
Dimensions
Charge Pump
Installation Drawings
Technical Specications ...............................................................................................................................4
Shaft Loads .......................................................................................................................................................6
Mounting Flange Loads ...............................................................................................................................7
Model Code ......................................................................................................................................................8
Electrical Displacement Control (EDC) Options A2 (12 V)/A3 (24 V) ..........................................12
Forward-Neutral-Reverse (FNR) Electric Control Options A9 (12 V)/B1 (24 V) .......................14
Non Feedback Proportional Electric Control (NFPE) Options A8 (12 V) / B8 (24 V) ..............16
Automotive Control (AC) ...........................................................................................................................18
Manual Over Ride (MOR) ...........................................................................................................................20
Displacement Limiter ..................................................................................................................................21
Input Shafts ....................................................................................................................................................22
Option G4, ISO 3019-1, ange outer dia 22 mm-4 (SAE B, 13 teeth) ....................................22
Option G5, ISO 3019-1, ange outer dia 25 mm-4 (SAE B-B, 15 teeth) ................................22
Option G1, ISO 3019-1, outer dia 32 mm-4 (SAE B, 14 teeth) ..................................................23
Option F2, ISO 3019-1, Code 25-3, Diameter 25.4 taper 1:8,
without key and no through-hole in the end of the shaft .......................................................24
Auxiliary Mounting Pads ............................................................................................................................25
Option H2, ISO 3019-1, ange 82-2 (SAE A, 9 teeth) ..................................................................25
Option H1, ISO 3019-1, ange 82-2 (SAE A, 11 teeth) ...............................................................26
Option H3, ISO 3019-1, ange 101-2 (SAE B, 13 teeth) ..............................................................27
Option H5, ISO 3019-1, ange 101-2 (SAE B-B, 15 teeth) .........................................................28
Charge Pump .................................................................................................................................................29
Port Description ............................................................................................................................................30
Dimensions .....................................................................................................................................................32
Twin port, ORB, remote lter .........................................................................................................32
Controls ......................................................................................................................................................35
Electric Displacement Control (EDC), option A2 (12 V) / A3 (24 V).................................35
Electric Displacement Control (EDC) with manual override, option A4 (12 V) / A5 (24 V) ....... 35
Forward-Neutral-Reverse (FNR) with manual override, option A9 (12 V) B1 (24 V) ................... 36
Non Feedback Proportional Electric Control (NFPE) with manual override,
option A8 (12 V) B8 (24V) ................................................................................................................................. 36
Automotive control (AC) with manual override, option A7 (12 V)/C2 (24 V) ...............37
Displacement limiters ...........................................................................................................................38
Displacement limiter, option Band D .......................................................................................38
Twin port, code 62 metric 4 bold FLG, option D6, D8, F2, and F3 ..................................39
Suction ltration, option L ............................................................................................................40
Remote full ow charge pressure ltration, option Pfor end cap option F ................41
External full ow charge pressure ltration, option E .........................................................42
Speed and Temperature Sensor, option H for mounting ange option K ...................43

411063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Technical Specications
For denitions of the following specications, see Basic Information 11062168, Operating
parameters.
Technical Specications
General specications
Design Axial piston pump of cradle swashplate design with variable displacement
Direction of rotation Clockwise, counterclockwise
Pipe connections Main pressure ports: ISO split  ange boss
Remaining ports: SAE straight thread O-ring boss
Recommended
installation position
Pump installation position is discretionary, however the recommended control
position is on the top or at the side, with the top position preferred. If the pump
is installed with the control at the bottom,  ushing  ow must be provided
through port M14 located on the EDC, FNR and NFPE control. Vertical input
shaft installation is acceptable. If input shaft is at the top 1 bar case pressure
must be maintained during operation.
The housing must always be  lled with hydraulic  uid.
Recommended mounting for a multiple pump stack is to arrange the highest
power  ow towards the input source.
Consult Sauer-Danfoss for nonconformance to these guidelines.
Auxiliary cavity pressure
Will be inlet pressure with internal charge pump. For reference see operating
parameter on next page. Will be case pressure with external charge supply.
Please verify mating pump shaft seal capability.
T000 126E
Technical data
Feature Unit Size 045 Size 053
Displacement cm3 [in3]45.0 [2.75] 53.8 [3.28]
Flow at rated (continuous) speed l/min [US gal/min] 153 [40] 183 [48]
Torque at maximum displacement
(theoretical) N•m/bar [lbf•in/ 1000psi] 0.72 [437.7] 0.86 [522.03]
Mass moment of inertia of rotating
components kg•m2[slug•ft2]0.00465 [0.00343] 0.00458 [0.00338]
Mass [weight] dry (without charge
pump or auxiliary mounting
 ange)
kg [lb] 41.0 [90.0]
Oil volume liter [US gal] 1.3 [0.34]
Mounting  ange ISO 3019-1  ange 101-2 (SAE B)
Special bolt diameter. See installation drawings.
Input shaft outer diameter,
splines and tapered shafts
ISO 3019-1, outer dia 22 mm - 4 (SAE B, 13 teeth)
ISO 3019-1, outer dia 25 mm - 4 (SAE B-B, 15 teeth)
ISO 3019-1, outer dia 32 mm - 4 (SAE-B, 14 teeth)
Conical keyed shaft end similar to ISO 3019-1 code 25-3, taper 1:8
Auxiliary mounting  ange with metric
fasteners, shaft outer diameter and
splines
ISO 3019-1,  ange 82 - 2, outer dia 16 mm - 4 (SAE A, 9 teeth)
ISO 3019-1,  ange 82 - 2, outer dia 19 mm - 4 (SAE A, 11 teeth)
ISO 3019-1,  ange 101 - 2, outer dia 22 mm - 4 (SAE B, 13 teeth)
ISO 3019-1,  ange 101 - 2, outer dia 25 mm - 4 (SAE B-B, 15 teeth)
Suction ports ISO 11926-1 – 1 5/16 -12 (SAE O-ring boss)
Main port con guration ∅19.0 - 450 bar split  ange boss per ISO 6162, M10x1.5
ISO 11926-1 – 1 5/16 -12 (SAE O-ring boss)
Case drain ports L1, L2 ISO 11926-1 – 1 1/16 -12 (SAE O-ring boss)
Other ports SAE O-ring boss. See installation drawings at the back of this manual.
Customer interface threads Metric fasteners
T301 001E

5
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Technical Specications
Technical Specications
(continued)
Fluid specications
Feature Unit
Viscosity
Intermittent 1)
mm2/s [SUS]
5[42]
Minimum 7 [49]
Recommended range 12-80 [66-370]
Maximum 1600 [7500]
Temperature
range 2)
Minimum (cold start) 3)
°C [°F]
-40 [-40]
Recommended range 60-85 [140-185]
Rated 104 [220]
Maximum intermittent 1) 115 [240]
Filtration
(recommended
minimum)
Cleanliness per ISO 4406 22/18/13
Effi ciency (charge pressure  ltration) β-ratio β15-20 = 75 (β10 ≥ 10)
Effi ciency (suction and return line  ltration) β35-45 = 75 (β10 ≥ 2)
Recommended inlet screen mesh size µm 100 – 125
1) Intermittent = Short term t < 1min per incident and not exceeding 2 % of duty cycle based load-life
2) At the hottest point, normally case drain port
3) Cold start = Short term t < 3min, p ≤ 50 bar [725 psi], n ≤ 1000 min-1(rpm) T000 129E
Operating parameters
Feature Unit Size 045 Size 053
Input speed
Minimum for internal charge supply
at minimum charge pressure. Perfor-
mance (pressure and displacement)
may be limited due to limited control
pressure
min-1 (rpm)
500
Minimum for external charge supply
at minimum charge pressure. Full
performance (pressure and displace-
ment) possible at minimum charge
and control pressure supply.
500
Minimum for full performance (pres-
sure and displacement) for internal
charge supply at minimum charge
and control pressure
1175 1250
Rated 3400
Maximum 3500
System pressure
Maximum working pressure
bar [psi]
420 [6090] 380 [5510]
Maximum pressure 450 [6525] 400 [5800]
Maximum low loop 45 [650]
Minimum low loop pressure 10 [150]
Charge pressure Minimum bar [psi] 16 [232]
Maximum 35 [508]
Control pressure
Minimum (at corner power for EDC
and FNR) bar [psi]
21.5 [312]
Minimum (at corner power for NFPE) 24 [348]
Maximum 40 [580]
Charge pump inlet pressure
Rated bar (absolute) [in Hg vacuum] 0.7 [9]
Minimum (cold start) 0.2 [24]
Maximum bar [psi] 4.0 [58]
Case pressure Rated bar [psi] 3.0 [44]
Maximum 5.0 [73]
Lip seal external pressure Maximum bar [psi] 0.4 [5.8]
T000 171E
For denitions of the following specications, see Basic Information 11062168, Operating
parameters.

611063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Shaft Loads External radial shaft loads
H1 pumps are designed with bearings that can accept some external radial loads.
The external radial shaft load limits are a function of the load position and orientation,
and the operating conditions of the unit. External radial shaft loads impact lifetime.
For lifetime calculations please contact Sauer-Danfoss representative.
The maximum allowable radial load (Re)is based on the maximum external moment
(Me) and the distance (L) from the mounting ange to the load. It may be determined
using the following table and formula.
Re= Me/ L
Me= Shaft moment
L= Flange distance
Re = External force to the shaft
Radial load position
P301 168
L
270° Re
Re
Me
180° R
e
90° Re
0° Re
Thrust loads should be avoided. Contact factory in the event thrust loads are anticipated.

7
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Shaft Loads
(continued)
Mounting Flange
Loads
All external shaft loads aect bearing life. In applications with external shaft loads,
minimize the impact by positioning the load at 0° or 180° as shown in the gure.
Sauer-Danfoss recommends clamp-type couplings for applications with radial shaft
loads.
Contact your Sauer-Danfoss representative for an evaluation of unit bearing life if you
have continuously applied external loads exceeding 25 % of the maximum allowable
radial load (Re) or the pump swashplate is positioned on one side of center all or most of
the time.
Maximum external shaft load based on shaft deection
Unit Size 045/053
External radial moment – MeNm [lbf•in] TDB [TBD]
T000 174E
H1 single pump front ange load
The moments shown below apply for control orientation top or side (see table and
gures).j
P301 214
Control on top Control on side
For calculation details refer to H1 Pump Basic Information Manual 11062168, section
Mounting Flange Loads.
Mounting ange load
Unit
Size 045/053
Control orientation
Control on top Control on side
Rated moment – MRNm [lbf•in] 2020 [17 880] 1300 [11 510]
Shock load moment – MS4110 [36 380] 2930 [25 935]
T000 175E
P301 213
MR
MS

811063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
A B D F E G H J K M N S T V W X Y
H1 P A
Displacement
045 45 cm³ [2.75 in³]
053 53.8 cm³ [3.28 in³]
ARotation
L Left hand (counter clockwise)
R Right hand (clockwise)
BProduct Version
ARevision code
DControl
A2 Electric Displacement Control (EDC) 12V, Deutsch connector
A3 Electric Displacement Control (EDC) 24V, Deutsch connector
A4 Electric Displacement Control (EDC) 12V, Deutsch connector, Manual override
A5 Electric Displacement Control (EDC) 24V, Deutsch connector, Manual override
A9 Forward-Neutral-Reverse (FNR) 12V, Deutsch connector, Manual override
B1 Forward-Neutral-Reverse (FNR) 24V, Deutsch connector, Manual override
A8 Non Feedback Proportional Electric (NFPE) 12V, Deutsch connector, Manual override
(align with option E: Displacement Limiters & option W: Special Hardware)
B8 Non Feedback Proportional Electric (NFPE) 24V, Deutsch connector, Manual override
(align with option E: Displacement Limiters & option W: Special Hardware)
A7 AC-1 (Automotive), 12V, Manual Override (align with option E: Displacement Limiters & option W:
Special Hardware)
C2 AC-1 (Automotive), 24V, Manual Override (align with option E: Displacement Limiters & option W:
Special Hardware)
FOrices
C1 Orices, 0.8 mm in servo supply 1 and 2, recommended for propel applications
C2 Orices, 1.3 mm in servo supply 1 and 2 (Standard), recommended for propel applications
C3 No orice, recommended for non-propel applications
EDisplacement limiters
NNone
CNo limiters, with nested springs (required for NFPE) (align with option Y: Settings for adjustment, if
applicable)
BAdjustable externally (align with option Y: Settings for adjustment, if applicable)
DAdjustable externally with nested springs, required for NFPE
GEndcap options
Twin port
High
pressure
ports
ISO 11 926 O-ring ports ISO 6162 split ange ports
Match
with below
options
(M+N)
With pressure limiter Without pressure limiter
(HPRV only) With pressure limiter Without pressure
limiter
(HPRV only)
Match
with below
options (T)
Suction
ltration
Remote and
external
charge supply
for full charge
ow ltration
Suction
ltration
Remote or
external
charge supply
for full charge
ow ltration
Suction
ltration
Remote and
external
charge supply
for full charge
ow ltration
Suction
ltration
Remote or
external
charge supply
for full charge
ow ltration
D6 X
D8 X
E5 X
E6 X
E9 X
F1 X
F2 X
F3 X
Model Code

9
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Model Code
(continued)
A B D F E G H J K M N S T V W X Y
H1 P F N N N N N N
HMounting
FISO 3019-1, ange 101-2 (SAE B)
JInput shaft
G4 ISO 3019-1, outer dia 22 mm - 4 (SAE B, 13 teeth splined shaft 16/32 pitch)
G5 ISO 3019-1, outer dia 25 mm - 4 (SAE B-B, 15 teeth splined shaft 16/32 pitch)
G1 ISO 3019-1, outer dia 32 mm - 4 (SAE B, 14 teeth splined shaft 12/24 pitch)
F2 Conical keyed shaft end similar to ISO 3019-1 code 25-3, taper 1:8 (key not supplied with pump)
KAuxiliary mounting pad
NN None
H2 ISO 3019-1, ange 82 - 2, outer dia 16 mm - 4 (SAE A, 9 teeth 16/32 coupling)
Shipping cover
H1 ISO 3019-1, ange 82 - 2, outer dia 19 mm - 4 (SAE A, 11 teeth 16/32 coupling)
H3 ISO 3019-1, ange 101 - 2, outer dia 22 mm - 4 (SAE B, 13 teeth 16/32 coupling)
H5 ISO 3019-1, ange 101 - 2, outer dia 25 mm - 4 (SAE B-B, 15 teeth 16/32 coupling)
MOverpressure protection type and setting side “A” **
NOverpressure protection type and setting side “B” **
** Pressure protection type must be the same for side “A” and “B”
LHigh pressure relief valve + pressure
limiters with bypass
Use the selection for ports “A”and “B”
KHigh pressure relief valve only with bypass
(no pressure limiters)
L18 K18 180 bar [2610 psi]
L20 K20 200 bar [2900 psi]
L23 K23 230 bar [3336 psi]
L25 K25 250 bar [3630 psi]
L28 K28 280 bar [4061 psi]
L30 K30 300 bar [4350 psi]
L33 K33 330 bar [4786 psi]
L35 K35 350 bar [5080 psi]
L38 K38 380 bar [5510 psi]
L40 K40 400 bar [5800 psi] (45 cm3 only)
L42 K42 420 bar [6090 psi] (45 cm3 only)
Contact factory for pressures not shown or for applied pressure above maximum working pressure
(see System Pressure page 5)
SCharge pump
B12 cm³/rev [0.73 in³/rev]
NNo charge pump, external charge supply, (align with Option T: Filtration Options, option E)
TFiltration options (align with option G: Endcap selection)
LSuction ltration (see basic drawings)
PRemote full charge ow ltration (see endcap drawings)
EExternal charge ow ltation (see endcap drawings), (align with option S: Charge pump, option N)
VCharge pressure relief setting (contact factory for pressure not shown)
20 20 bar [290 psi]
24 24 bar [348 psi]
WSpecial hardware features
PN None
P1 NFPE valve plate (align with option D: Control Selection and option E: Displacement Limiters)

10 11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Model Code
(continued)
XPaint and nametag
NNN Black paint and Sauer-Danfoss nametag
YSpecial settings
NNN None
D3F AC1-control, System F: Functional basis, Motor Speed Sensor, CAN J1939 in/out without
Customer Files, 12V
D4F AC1-control, System F: Functional basis, Motor Speed Sensor, CAN J1939 in/out without
Customer Files, 24V
D3H AC1-control, System H: Functional basis, Motor Speed Sensor, CAN J1939 out, SIL2 certiable
without Customer Files, 12V
D4H AC1-control, System H: Functional basis, Motor Speed Sensor, CAN J1939 out, SIL2 certiable
without Customer Files, 24V
A B D F E G H J K M N S T V W X Y
H1 P F N N N N N N

11
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Notes
Notes

12 11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Electrical Displacement
Control (EDC)
Options
A2 (12 V)/A3 (24 V)
P003 479E
"0"
-b -a
ba
100 %
100 %
Displacement
Current mA
Control signal requirements
Pump displacement vs. control current
Feedback from
Swash plate
PTF00B
M14
C1 C2
F00A
P003 478E
EDC-Schematic diagram
P003 191
12
P003 480
Connector
EDC Principle
The Electrical Displacement Control
(EDC) consists of a pair of proportional
solenoids on each side of a three-
position, four-way porting spool. The
proportional solenoid applies a force
input to the spool, which ports hydraulic
pressure to either side of a double acting
servo piston. Dierential pressure across
the servo piston rotates the swashplate,
changing the pump‘s displacement from
full displacement in one direction to full
displacement in the opposite direction.
Under some circumstances, such as
contamination, the control spool could
stick and cause the pump to stay at some
displacement.
A serviceable 125 μm screen is located in
the supply line immediately before the
control porting spool.
Control current
Voltage a*
mA
b
mA
Pin
connections
12 V 640 1640 any order
24 V 330 820
* Factory test current, for vehicle movement or
application actuation expect higher or lower value.
T000133E
Description Quantity Ordering number
Mating connector 1 Deutsch® DT06-2S
Wedge lock 1 Deutsch® W2S
Socket contact (16 and 18 AWG) 2 Deutsch® 0462-201-16141
Sauer-Danfoss mating connector kit 1 K29657
T000 134E

13
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Electrical Displacement
Control (EDC)
Options
A2 (12 V)/A3 (24 V)
(continued)
Control response
H1 controls are available with optional control passage orices to assist in matching
the rate of swashplate response to the application requirements (e.g. in the event of
electrical failure). Software ramp or rate limiting should be used to control vehicle
response in normal operation. The time required for the pump output ow to change
from zero to full ow (acceleration) or full ow to zero (deceleration) is a net function of
spool porting, orices, and charge pressure. A swashplate response table is available
for each frame indicating available swashplate response times. Testing should be
conducted to verify the proper software and orice selection for the desired response.
H1 pumps are limited in mechanical oricing combinations. Software is envisioned
as the means to control the swashplate response in normal operating conditions.
Mechanical servo orices are to be used only for fail-safe return to neutral in the event of
an electrical failure.
Typical response times shown below at the following conditions:
∆p = 250 bar [3626 psi]
Viscosity and temperature = 30 mm2/s (50 °C) [141 SUS (122 °F)]
Charge pressure = 20 bar [290 psi]
Speed = 1800 min-1 (rpm)
Flow table
Shaft rotation CW CCW
Coil energized* C2 C1 C2 C1
Port A in out out in
Port B out in in out
Servo port pressurized M5 M4 M5 M4
* For coil location see installation drawings. T000 136E
Response times
Stroking direction 0.8 mm [0.03 in] Orice 1.3 mm [0.05 in] Orice No orice
Neutral to full  ow 1.7 s 0.9 s 0.5 s
Full  ow to neutral 1.1 s 0.6 s 0.3 s
T000 177E
Solenoid data
Voltage 12V 24V
Maximum current 1800 mA 920 mA
Coil resistance @ 20 °C [70 °F] 3.66 Ω14.20 Ω
Coil resistance @ 80 °C [176 °F] 4.52Ω 17.52Ω
PWM Range 70-200 Hz
PWM Frequency (preferred)* 100 Hz
Inductance 33 mH 140 mH
IP Rating (IEC 60 529) + DIN 40 050, part 9 IP 67
IP Rating (IEC 60 529) + DIN 40 050, part 9
with mating connector IP 69K
* PWM signal required for optimum control performance. T000 135E

14 11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Forward-Neutral-Reverse
(FNR) Electric Control
Options
A9 (12 V)/B1 (24 V)
The 3-Position (F-N-R) control uses an
electric input signal to switch the pump
to a full stroke position.
Under some circumstances, such as
contamination, the control spool could
stick and cause the pump to stay at some
displacement.
A serviceable 125 μm screen is located in
the supply line immediately before the
control porting spool.
Solenoid connector
12
P003 480
3-Position electric control,
hydraulic schematic
P003 190E
100 %
“0“
100 %
Voltage VDC
Displacement
Pump displacement vs. electrical signal
P003 193
P003 189
C2C1
F00A
M14
TP
F00B
Control current
Voltage
Min. current to
stroke pump
mA
Pin
connections
12 V 750 any order
24 V 380
T000 138E
Description Quantity Ordering number
Mating connector 1 Deutsch® DT06-2S
Wedge lock 1 Deutsch® W2S
Socket contact (16 and 18 AWG) 2 Deutsch® 0462-201-16141
Sauer-Danfoss mating connector kit 1 K29657
T000 134E

15
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Forward-Neutral-Reverse
(FNR) Electric Control
Options
A9 (12 V)/B1 (24 V)
(continued)
Control response
H1 controls are available with optional control passage orices to assist in matching
the rate of swashplate response to the application requirements (e.g. in the event of
electrical failure). Software ramp or rate limiting should be used to control vehicle
response in normal operation. The time required for the pump output ow to change
from zero to full ow (acceleration) or full ow to zero (deceleration) is a net function of
spool porting, orices, and charge pressure. A swashplate response table is available
for each frame indicating available swashplate response times. Testing should be
conducted to verify the proper software and orice selection for the desired response.
H1 pumps are limited in mechanical oricing combinations. Software is envisioned
as the means to control the swashplate response in normal operating conditions.
Mechanical servo orices are to be used only for fail-safe return to neutral in the event of
an electrical failure.
Typical response times shown below at the following conditions:
∆p = 250 bar [3626 psi]
Viscosity and temperature = 30 mm2/s (50 °C) [141 SUS (122 °F)]
Charge pressure = 20 bar [290 psi]
Speed = 1800 min-1 (rpm)
Pump output ow direction vs. control signal
Shaft rotation CW CCW
Coil energized* C1 C2 C1 C2
Port A in out out in
Port B out in in out
Servo port pressurized M5 M4 M5 M4
* For coil location see installation drawings. T000 140E
Response times
Stroking direction 0.8 mm [0.03 in] Orice 1.3 mm [0.05 in] Orice No orice
Neutral to full  ow 1.8 s 0.9 s 0.5 s
Full  ow to neutral 1.6 s 0.8 s 0.4 s
T000 179E
Solenoid data
Voltage 12 V 24 V
Minimum supply voltage 9.5 Vdc 19.0 Vdc
Maximum supply voltage (continuous) 14.6 Vdc 27.0 Vdc
Maximum current 1050 mA 500 mA
Nominal coil resistance @ 20 °C [70 °F] 8.4 Ω34.5 Ω
PWM Range 70-200 Hz
PWM Frequency (preferred)* 100 Hz
IP Rating (IEC 60 529) + DIN 40 050, part 9 IP 67
IP Rating (IEC 60 529) + DIN 40 050, part 9
with mating connector IP 69K
* PWM signal required for optimum control performance. T000 139E

16 11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Non Feedback
Proportional Electric
Control (NFPE)
Options A8 (12 V) /
B8 (24 V)
The Non Feedback Proportional Electric
(NFPE) control is an electrical automotive
control in which an electrical input
signal activates one of two proportional
solenoids that port charge pressure to
either side of the pump servo cylinder.
The NFPE control has no mechanical
feedback mechanism.
The pump displacement is proportional
to the solenoid signal current, but it also
depends upon pump input speed and
system pressure. This characteristic also
provides a power limiting function by
reducing the pump swashplate angle
as system pressure increases. A typical
response characteristic is shown in the
accompanying graph.
Under some circumstances, such as
contamination, the control spool could
stick and cause the pump to stay at some
displacement.
A serviceable 125 μm screen is located in
the supply line immediately before the
control porting spool.
P003 188
C2C1
F00A
M14
TP
F00B
NFPE Schematic
P003 192
Control signal requirements
"0"
Signal Current
mA(DC)
abc
a
b
c
Displacement
100 %
100 %
NFPE control
∆p = 300 bar
∆p = 300 bar
∆p = 0 bar
∆p = 0 bar
P003 187E
Pump displacement vs. input signal
12
P003 480
Connector
Control current
Size
(cm3)Voltage a* mA
b
mA
c
mA
Pin
connections
45 12 V 710 1135 1380
any order
24 V 360 585 675
53 12 V 715 1140 1495
24 V 365 570 720
* Factory test current, for vehicle movement or ap-
plication actuation expect higher or lower value.
T301 002E
Description Quantity Ordering number
Mating connector 1 Deutsch® DT06-2S
Wedge lock 1 Deutsch® W2S
Socket contact (16 and 18 AWG) 2 Deutsch® 0462-201-16141
Sauer-Danfoss mating connector kit 1 K29657
T000 134E

17
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Non Feedback
Proportional Electric
Control (NFPE)
Options A8 (12 V) /
B8 (24 V)
(continued)
Control response
H1 controls are available with optional control passage orices to assist in matching
the rate of swashplate response to the application requirements (e.g. in the event of
electrical failure). Software ramp or rate limiting should be used to control vehicle
response in normal operation. The time required for the pump output ow to change
from zero to full ow (acceleration) or full ow to zero (deceleration) is a net function of
spool porting, orices, and charge pressure. A swashplate response table is available
for each frame indicating available swashplate response times. Testing should be
conducted to verify the proper software and orice selection for the desired response.
H1 pumps are limited in mechanical oricing combinations. Software is envisioned
as the means to control the swashplate response in normal operating conditions.
Mechanical servo orices are to be used only for fail-safe return to neutral in the event of
an electrical failure.
Typical response times shown below at the following conditions:
∆p = 250 bar [3626 psi]
Viscosity and temperature = 30 mm2/s (50 °C) [141 SUS (122 °F)]
Charge pressure = 20 bar [290 psi]
Speed = 1800 min-1 (rpm)
Pump output ow direction vs. control signal
Shaft rotation CW CCW
Coil energized* C1 C2 C1 C2
Port A in out out in
Port B out in in out
Servo port pressurized M5 M4 M5 M4
* For coil location see installation drawings. T000 140E
Response times
Stroking direction 0.8 mm [0.03 in] Orice 1.3 mm [0.05 in] Orice No orice
Neutral to full  ow 2.2 s 1.1 s 0.7 s
Full  ow to neutral 1.3 s 0.7 s 0.3 s
T301 004E
Solenoid data
Voltage 12V 24V
Maximum current 1800 mA 920 mA
Coil resistance @ 20 °C [70 °F] 3.66 Ω14.20 Ω
Coil resistance @ 80 °C [176 °F] 4.52Ω 17.52Ω
PWM Range 70-200 Hz
PWM Frequency (preferred)* 100 Hz
Inductance 33 mH 140 mH
IP Rating (IEC 60 529) + DIN 40 050, part 9 IP 67
IP Rating (IEC 60 529) + DIN 40 050, part 9
with mating connector IP 69K
* PWM signal required for optimum control performance. T000 135E

18 11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Automotive Control (AC) The H1 Automotive Control (H1 AC) is an
electric NFPE Control with an integrated
Microcontroller, installed on the pump.
The integrated Microcontroller enhanced
control performance with a exible,
congurable control scheme for an entire
single path propel transmission. With the
pre-installed application software and
easily changeable control parameters, it
is possible to tailor the vehicle’s driving
behavior to the individual requirements
of the customer.
The H1 AC Control oers the following
features and functions:
P003 544
CAN PPC PSC PPU CC2
CC1
WARRANTY VOID IF REMOVED
CC3
Driving Proles
• Four selectable system modes, selectable via switch.
• Independent curves and settings for forward and reverse (4 x 2 curves).
• Switch selectable between automotive and engine speed independent driving
modes.
• Engine speed independent drive modes for sweepers, snow blowers (non-automotive
mode).
–Load independent drive modes for o road applications (non-
automotive for rollers and forestry machines).
• Load independent swash plate control via pump swash plate angle sensor to achieve
EDC behavior
• Creep speed mode (slow shunting, digging operation, etc.)
• Constant speed mode (sweepers, snow-blowers, etc.)
• Integrated vehicle speed limiter function.
Advanced Control Functions
• Inch function without separate control valve.
• Integrated temperature sensor for:
–Hydraulic systems overheat protection.
–Low temperatures pump ow limitation.
–Compensation of oil viscosity changes if using (radial piston motors, etc.).
–Congurable engine anti stall protection.
–Engine over speed protection while inching.
Integrated Motor Controller
• Integrated electric motor control for:
–Proportional, variable PCOR or two position motor controls.
–Brake pressure defeat, depending on the FNR position
or the real vehicle driving direction.
–Initial breakaway motor torque override.
• Separate over speed protection for the hydro motor.

19
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Auxiliary Functions
• Four auxiliary outputs for :
–Intelligent brake light control.
–Automatic park brake function.
–Vehicle speed dependent output to activate (load stabilizer, warning lights, etc.).
–Reverse buzzer controlled by FNR or reverse driving.
–System status lamp (fault detection for pump solenoids).
Economic Features
• Technology and enabler for economic driving and fuel savings.
• Easy combination options to other components of the PLUS+1 Family.
CAN Options
• Engine remote control via CAN J1939.
• Integrated signal converter (analog driving pedal into CAN signal, etc.).
• Compatible to all CAN J1939 components on market (displays, etc.).
Functional Safety
• External Safety Certication for SIL-2 (IEC 61508).
• Safety controlled Vehicle Start-Protection (engine speed check, battery check and FNR
must be in neutral, etc.).
• Operator presence detection.
• Vehicle speed dependent direction change lock.
• Brake test mode for roller applications to fulll EN500-4.
Installation Features
• Factory calibration for hysteresis compensation.
• Starting current adjustment in the factory
• Pre-installed application software and parameter les
Refer to the “Technical Information – H1 Automotive Control” L1223856 for details about
installation and wiring.
General Technical Specications
Automotive control (AC)
(continued)

20 11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
Manual Over Ride (MOR)
Feedback from
Swash plate
PTF00B
M14
C2
C1
F00A
P003 205E
MOR-Schematic diagram (EDC shown)
P003 204
All controls are available with a Manual Over Ride (MOR) either standard or as an option
for temporary actuation of the control to aid in diagnostics.
Forward-Neutral-Reverse (FNR) and Non Feedback Proportional Electric (NFPE) controls
are always supplied with MOR functionality.
Unintended MOR operation will cause the pump to go into stroke. The vehicle or device
must always be in a „safe“ condition (i.e. vehicle lifted o the ground) when using the
MOR function. The MOR plunger has a 4 mm diameter and must be manually depressed
to be engaged. Depressing the plunger mechanically moves the control spool which
allows the pump to go on stroke. The MOR should be engaged anticipating a full stroke
response from the pump.
Warning
An o-ring seal is used to seal the MOR plunger where initial actuation of the function will
require a force of 45 N to engage the plunger. Additional actuations typically require
less force to engage the MOR plunger. Proportional control of the pump using the MOR
should not be expected.
Refer to control owtable for the relationship of solenoid to direction of ow.
