Sauer Danfoss Series S90 180 cc Guide

BLN-2-41695 May, 1997
Pump
Service Parts Manual
180 cc - Axial Piston
Series 90
Genuine Parts
Original
Ersatzteile

2
saue Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Contents
Unit and Service Parts Identification ...............................................................................................................3-4
Order Code ...................................................................................................................................................... 5
Housing ..........................................................................................................................................................6-7
Swashplate .....................................................................................................................................................6-7
Displacement Limitation ................................................................................................................................. 8-9
End Cap ...................................................................................................................................................... 10-13
Charging System ........................................................................................................................................ 14-15
Auxiliary Mounting Flange .......................................................................................................................... 16-21
Charge Pressure ........................................................................................................................................ 22-23
Shaft ........................................................................................................................................................... 22-23
Control ........................................................................................................................................................ 24-29
Filtration ...................................................................................................................................................... 30-31
High Pressure Regulation........................................................................................................................... 32-33
Orifice ......................................................................................................................................................... 34-35
Rotating Group ........................................................................................................................................... 36-37
Valve Plate ................................................................................................................................................. 36-37
Special Hardware/Side Cover .................................................................................................................... 36-37
Overhaul Kit .................................................................................................................................................... 38
SB-9507 ...................................................................................................................................................... 40-41
SB-9625 ...................................................................................................................................................... 42-43
SB-9711 ...................................................................................................................................................... 44-45
SB-9713 ...................................................................................................................................................... 46-47
SB-9714 ...................................................................................................................................................... 48-49
Copyright 1997 Sauer-Danfoss. All rights reserved.
Contents subject to change. Information contained herein should be confirmed before placing orders.
Printed in U.S.A.

3
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Service Parts Identification
The following information and procedure is used to identify the module group, item number, manufactured date,
part number, and part name of the parts included in the Series 90 Pump.
The parts listed include all parts which may be used when performing either "Minor Repairs", "Major Repairs", or
"Conversions" on the Series 90 Pump.
Model Code Typ
Serial No. Fabr Nr
MADE IN GERMANY
Model No. Ident Nr
Ames, Iowa, U.S.A. NeumŸnster, Germany
Model Code Typ
Serial No. Fabr Nr
MADE IN U.S.A.
Model No. Ident Nr
- Nameplate -
A - 92 - 26 - 12345
123456
N - 92 - 26 - 12345
Each pump will have a nameplate affixed to the housing. The
name plate will include the following information.
Model Code
The Sauer-Danfoss model code completely defines the
specific unit and must be used when ordering the complete unit
for the first time or for ordering parts to service the product.
Model Number
The Sauer-Danfoss model number is used by the factory in
manufacturing. On repeat orders, a complete unit can also be
ordered by the model mumber.
Serial Number
The Sauer-Danfoss serial number is used to identify the
manufacturing location, manufacturing date and the unit se-
quence in the build. The serial number is also used to identify
the unit's warranty time period.
Identification Number
Pumps manufactured in Germany will have an identification
number instead of a model number.
The letter code indicates the location of original manufacture
(assembly). "A" indicates the unit was originally assembled
in Ames, Iowa, USA. "N" indicates the unit was originally
assembled in NeumŸnster, Germany.
The first number (2 digits) indicates the year of manufacture.
("92" would indicate the unit was manufactured in 1992)
The second number (2 digits) indicates the calender week of
manufacture.
The third number (5 digits) is a sequential number used to
identify a specific unit.
Ames, Iowa, U.S.A. NeumŸnster, Germany
90L180 MA 1 C
8 S 3 F1 H 03
NNN 35 35 24
90L180 MA 1 C
8 S 3 F1 H 03
NNN 35 35 24
9820107

4
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Date Code
The date code is defined as the year and week of manufacture. The same reference number may list more than
one part number. This indicates that there is more than one configuration for that reference number. You will see
that there are different date codes for the different part numbers. Find the date code of your unit via the name-
plate to determine which service part number you need to order.
EXAMPLE: The service part desired is Item E10.
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model
E10 92-19 →746107 Side cover (SB-9203) 1
" 89-41 → 92-18 340133 Side cover 1
All units using this module group with a date code of 89-41 and up to and including 92-18 must use part number
340133. All units with a date code of 92-19 and up must use part number 746107.
Service Bulletins
A Service Bulletin Number (SB- _ _ _ _) may follow the Description of the part you desire. You must read that
Service Bulletin prior to ordering that part. A copy of each of these Service Bulletins, as of the print date of this
bulletin, are included at the end of this manual. Service Bulletins contain more detailed information such as
interchangeability, what additional parts are involved, etc. It is suggested that you add additional Service Bulletins
to this manual as you receive them.
Procedure to Identify a Given Part/Part Number
General
The modular design of Series 90 units results in a simplified Service Parts List and Part Identification Procedure.
The same item numbers are used for same part description on all units within a product type. (Example: The shaft
seal - Item Number L40 has the same item number on all variable displacement pumps.)
All Item Numbers begin with a letter. The letter identifies a particular module. (Example: any items beginning with
K relate to the charge relief valve; items beginning with L relate to the input shaft components, etc.)
Example of a Part Identification
The nameplate on a Series 90 pump has an Order Code of 90L180 MA 1 C 8 S 3 F1 H 03 NNN 35 35 24. Use
the following procedures to determine the part number of the filtration kit used on this pump.
1) Referring to the input shaft module in the Model Code (see page 5), the shaft option for this unit is identified by
the code F1 (90L180 MA 1 C 8 S 3 F1 H 03 NNN 35 35 24)
2) Referring to the Service Parts List, find the shaft group. Next find the order code that relates to this unit, which
is F1. The shaft is found to be item L1 and part number 772590.

5
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
9 0
Series
Rotation
Pump Size (cc)
Control Type
Pressure Regulation
Auxilary Mounting Pad
End Cap Ports
Filtration Displacement Limitation
Input Shaft
Charge
Pressure Setting
High Pressure Setting
Port A
High Pressure Setting
Port A
Control Orifice
Charging System
L 1 8 0 M A 1 C 8 S 3 F 1 H 0 3 N N N 3 5 3 5 2 4
Special Hardware Features
R MPJGNFLHT W YZK

6
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
Common Parts
B70A
B70
B80A
B80
B10
B20
B20
D50
D60
D95
D10
D55
D65
M14 D75
D70
D75
D70
D85
D80
D80
B30
B50
B50
D87 D87A
D86
B83
B83A
B82
B82A

7
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Common Parts
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model/Kit
B10 94-20 →789438 Housing assembly 1
B20 94-20 →648550 (9004800-1904) Pin 2
B30 94-20 →746313 Cradle bearing assembly 1
B50 94-20 →001289 (9004800-3708) Pin 2
B70 94-20 →515965 (9005110-5600) Plug 2
B70A 94-20 →085043 (9004201-3700) O-ring 2
B80 94-20 →676734 (9005110-9500) Plug 1
B80A 94-20 →093823 (9004201-9200) O-ring 1
B82 94-20 →515965 (9005110-5600) Plug 2
B82A 94-20 →085043 (9004201-3700) O-ring 2
B83 94-20 →515965 (9005110-5600) Plug 2
B83A 94-20 →085043 (9004201-3700) O-ring 2
D10 94-20 →746339 Servo arm assembly 1
D50 94-20 →770362 Swashplate 1
D55 94-20 →746362 Screw 1
D60 94-20 →745703 Swashplate guide 1
D65 94-20 →504494 Screw 1
D70 94-20 →127464 Washer 2
D75 94-20 →333369 Spiral head pin 2
D80 94-20 →700948 Cage locator link 2
D85 94-20 →500449 Screw 1
D86 94-20 →770594 Pin 1
D87 94-20 →504519 Plug 1
D87A 94-20 →039297 (9004201-1200) O-ring 1
D95 94-20 →746396 Spring 1
M14 94-20 →747451 Feedback link (SB-9625) 1
Bold Items indicate recommended parts to be stocked for servicing
180 cc Variable Displacement Pump

8
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
F12 F11
F103
F11
F12
F50
F40
F60
S02
S04
F50
F40
F60
F34
F80
F70
F35
F80
S01
F70
F35
F34
F60
F60
F40
S03 F50
F40
F50
F20
Displacement Limitation

9
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
F: Displacement Limitation Group
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model/Kit
F103 94-20 →509288 Servo piston assembly 1
F11 94-20 →755264 O-ring 2
F12 94-20 →507801 Piston ring 2
F20 94-20 →746479 Slider block 1
3 S02 94-20 →8510150 Servo piston kit - no limitation 1
F40 94-20 →092742 (9004104-1520) O-ring 1
F50 94-20 →755272 O-ring 1
F60 94-20 →507205 Screw 4
S03 94-20 →8510150 Servo piston kit - no limitation 1
F40 94-20 →092742 (9004104-1520) O-ring 1
F50 94-20 →755272 O-ring 1
F60 94-20 →507205 Screw 4
4 S01 94-20 →8510151 Servo piston kit - adjustable 1
F34 94-20 →755033 Set screw 1
F35 94-20 →649822 Seal nut 1
F40 94-20 →092742 (9004104-1520) O-ring 1
F50 94-20 →755272 O-ring 1
F60 94-20 →507205 Screw 4
F70 94-20 →394312 Plug 1
F80 94-20 →084640 Seal ring 1
S04 94-20 →8510151 Servo piston kit - adjustable 1
F34 94-20 →755033 Set screw 1
F35 94-20 →649822 Seal nut 1
F40 94-20 →092742 (9004104-1520) O-ring 1
F50 94-20 →755272 O-ring 1
F60 94-20 →507205 Screw 4
F70 94-20 →394312 Plug 1
F80 94-20 →084640 Seal ring 1
Bold Items indicate recommended parts to be stocked for servicing
180 cc Variable Displacement Pump

10
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
End cap
G068
G078
G088
G568A
G568
G908
G568A
G568
G20
G40
G558A
G558
G048
G308
G558A
G558
G908
G563A
G563
G553A
G553
G533A
G533
G043
G523
G523A
G543A
G523A
G513A
G573A
G543
G523
G542
G513
G573
G963
G40
G953
G903
G903
G303
G563A
G563
G20
G523A
G523
G93
G95
G95
G93
G95
G95
G968
G93
G95
G95
G93
G95
G95
G958

11
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
180 cc Variable Displacement Pump
G: End Cap Group
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model/Kit
G93 94-20 →713818 (8800565) Lifting bracket 2
G95 94-20 →505479 Washer 4
3 & 83 G043 94-20 →752006 End cap, twin ports 1
G20 94-20 →303693 Journal bearing 1
G40 94-20 →303651 Bushing 1
G303 94-20 →504417 End cap gasket (SB-9713) 1
G513 94-20 →765990 (9005100-3700) Plug 1
G513A 94-20 →039297 (9004201-1900) O-ring 1
G523 94-20 →504519 Plug 3
G523A 94-20 →039297 (9004201-1200) O-ring 3
G533 94-20 →681296 (9005110-7500) Plug 1
G533A 94-20 →001131 (9004201-5000) O-ring 1
G542 94-20 →787838 Set screw 1
G543 94-20 →515965 (9005110-5600) Plug 1
G543A 94-20 →085043 (9004201-3700) O-ring 1
G553 94-20 →515965 (9005110-5600) Plug 1
G553A 94-20 →085043 (9004201-3700) O-ring 1
G563 94-20 →046151 (9005100-5600) Plug 2
G563A 94-20 →085043 (9004201-3700) O-ring 2
G573 94-20 →504519 Plug 1
G573A 94-20 →039297 (9004201-1200) O-ring 1
G903 94-20 →085183 Screw 2
G953 94-20 →675900 Screw 1
G963 94-20 →290502 Screw 1
8 & 80 G048 94-20 →501471 End cap, twin ports 1
G20 94-20 →303693 Journal bearing 1
G40 94-20 →303651 Bushing 1
G068 94-20 →364281 Housing assembly 1
G078 94-20 →694356 (9007314-0608) Screw 4
G088 94-20 →689117 Gasket 1
G308 94-20 →504417 End cap gasket (SB-9713) 1
G558 94-20 →515965 (9005110-5600) Plug 2
G558A 94-20 →085043 (9004201-3700) O-ring 2
G568 94-20 →046151 (9005100-5600) Plug 2
G568A 94-20 →085043 (9004201-3700) O-ring 2
G908 94-20 →085183 Screw 2
G958 94-20 →290502 Screw 1
G968 94-20 →675900 Screw 1
Bold Items indicate recommended parts to be stocked for servicing

12
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
End cap
G068
G078
G088
G568A
G568
G908
G568A
G568
G20
G40
G558A
G558
G048
G308
G558A
G558
G968 G908
G958
G93
G95
G95
G93 G95
G95

13
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
180 cc Variable Displacement Pump
G: End Cap Group
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model/Kit
G93 94-20 →713818 (8800565) Lifting bracket 2
G95 94-20 →505479 Washer 4
8H G048 94-20 →510441 End cap, twin ports 1
G20 94-20 →303693 Journal bearing 1
G40 94-20 →303651 Bushing 1
G068 94-20 →364281 Housing assembly 1
G078 94-20 →694356 (9007314-0608) Screw 4
G088 94-20 →689117 Gasket 1
G308 94-20 →504417 End cap gasket (SB-9713) 1
G558 94-20 →515965 (9005110-5600) Plug 2
G558A 94-20 →085043 (9004201-3700) O-ring 2
G568 94-20 →046151 (9005100-5600) Plug 2
G568A 94-20 →085043 (9004201-3700) O-ring 2
G908 94-20 →085183 Screw 2
G958 94-20 →290502 Screw 1
G968 94-20 →675900 Screw 1
Bold Items indicate recommended parts to be stocked for servicing

14
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
H50
H60
H40
H05
H50
H05L
H90LA
H90L
H06L
H80
H70
H80
H70
Charging System

15
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
180 cc Variable Displacement Pump
H: Charging System Group
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model/Kit
HH05 94-20 →503517 Charge pump, 34 cc (SB-9507) 1
H40 94-20 →750133 Pin 1
H50 94-20 →503519 Charge pump shaft (SB-9714) 1
H60 94-20 →734608 Key 1
H70 94-20 →303644 Retaining plate 1
H80 94-20 →378083 Screw 6
JH05 94-20 →503518 Charge pump, 47 cc (SB-9507) 1
H40 94-20 →750133 Pin 1
H50 94-20 →503519 Charge pump shaft (SB-9714) 1
H60 94-20 →734608 Key 1
H70 94-20 →303644 Retaining plate 1
H80 94-20 →378083 Screw 6
LH05L 94-20 →339762 Charge pump spacer 1
H06L 94-20 →711218 Distance plate 1
H50 94-20 →503519 Charge pump shaft (SB-9714) 1
H70 94-20 →303644 Retaining plate 1
H80 94-20 →378083 Screw 6
H90L 94-20 →676734 (9005110-9500) Plug 1
H90LA 94-20 →093823 (9004201-9200) O-ring 1
Bold Items indicate recommended parts to be stocked for servicing

16
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
J10
J60
J70
J80
J90
J92
J
J95
J50
J15
J30
'A' & 'AB'
J80
J70
J60
J10
J92
J90
J
J95
'B' & 'BC'
J50
J15
J30
J95
J92
J90
J80 J70
J60
J10
J
'C' & CD
J50
J15
J30
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
Auxiliary Mounting

17
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
180 cc Variable Displacement Pump
J: Auxiliary Mounting Pad Group
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model/Kit
A & AB J 94-20 →8510100 Aux. mtg. A flange kit, 9 tooth 1
J10 94-20 →766964 Coupling 1
J15 94-20 →501402 Cover assy., CW 1
" 94-20 →501401 Cover assy., CCW 1
J30 94-20 →303651 Bushing 1
J50 94-20 →505068 O-ring 1
J60 94-20 →505136 Flange adaptor 1
J70 94-20 →279729 Washer 4
J80 94-20 →750414 Screw 4
J90 94-20 →726950 (9004104-0420) O-ring 1
J92 94-20 →545475 (9802336) Cover plate 1
J95 94-20 →012203 (9007200-3714) Screw 2
B & BC J 94-20 →8510101 Aux. mtg. B flange kit, 13 tooth 1
J10 94-20 →767566 Coupling 1
J15 94-20 →501402 Cover assy., CW 1
" 94-20 →501401 Cover assy., CCW 1
J30 94-20 →303651 Bushing 1
J50 94-20 →505068 O-ring 1
J60 94-20 →505132 Flange adaptor 1
J70 94-20 →279729 Washer 4
J80 94-20 →750414 Screw 4
J90 94-20 →726935 (9004104-0450) O-ring 1
J92 94-20 →689091 (4460370) Cover plate 1
J95 94-20 →647248 (9007200-5021) Screw 2
C & CD J 94-20 →8510102 Aux. mtg. C flange kit, 14 tooth 1
J10 94-20 →768523 Coupling 1
J15 94-20 →501402 Cover assy., CW 1
" 94-20 →501401 Cover assy., CCW 1
J30 94-20 →303651 Bushing 1
J50 94-20 →505068 O-ring 1
J60 94-20 →505139 Flange adaptor 1
J70 94-20 →279729 Washer 4
J80 94-20 →750414 Screw 4
J90 94-20 →726943 (9004104-0490) O-ring 1
J92 94-20 →307363 (8800406) Cover plate 1
J95 94-20 →647248 (9007200-5021) Screw 4
Bold Items indicate recommended parts to be stocked for servicing

18
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
J70
J10
J60
J90
J95
J92
J80
J
'D' & 'DE'
J50
J15
J30
J10
J60
J92
J90
J95
J80
J70
'E' & 'EF'
'H' & 'EG'
J50
J15
J30
J80N
J15N
J30
J40N
'N' & 'NN'
J
Auxiliary Mounting

19
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
180 cc Variable Displacement Pump
J: Auxiliary Mounting Pad Group
Order Date Code Qty. per
Code Item Begin → End Part Number Description Model/Kit
D & DE J 94-20 →8510103 Aux. mtg. D flange kit, 13 tooth 1
J10 94-20 →768564 Coupling 1
J15 94-20 →503663 Cover assy., CW 1
" 94-20 →503666 Cover assy., CCW 1
J30 94-20 →303651 Bushing 1
J50 94-20 →505068 O-ring 1
J60 94-20 →767681 Flange adaptor 1
J70 94-20 →279729 Washer 4
J80 94-20 →750414 Screw 4
J90 94-20 →726927 O-ring 1
J92 94-20 →338400 Cover plate 1
J95 94-20 →338426 (9007200-7524) Screw 4
E & EF J 94-20 →8510104 Aux. mtg. E flange kit, 13 tooth 1
J10 94-20 →768564 Coupling 1
J15 94-20 →503663 Cover assy., CW 1
" 94-20 →503666 Cover assy., CCW 1
J30 94-20 →303651 Bushing 1
J50 94-20 →505068 O-ring 1
J60 94-20 →505141 Flange adaptor 1
J70 94-20 →279729 Washer 4
J80 94-20 →750414 Screw 4
J90 94-20 →505068 O-ring 1
J92 94-20 →750422 Cover plate 1
J95 94-20 →338426 (9007200-7524) Screw 4
H & EG J 94-20 →8510105 Aux. mtg. E flange kit, 27 tooth 1
J10 94-20 →751701 Coupling 1
J15 94-20 →503663 Cover assy., CW 1
" 94-20 →503666 Cover assy., CCW 1
J30 94-20 →303651 Bushing 1
J50 94-20 →505068 O-ring 1
J60 94-20 →505141 Flange adaptor 1
J70 94-20 →279729 Washer 4
J80 94-20 →750414 Screw 4
J90 94-20 →505068 O-ring 1
J92 94-20 →750422 Cover plate 1
J95 94-20 →338426 (9007200-7524) Screw 4
N & NN J15N 94-20 →501400 Charge pump cover 1
J30 94-20 →303651 Bushing 1
J40N 94-20 →916940 O-ring 1
J80N 94-20 →308734 Screw 4
Bold Items indicate recommended parts to be stocked for servicing

20
Series 90
180 cc Pump
BLN-2-41695
May, 1997
Genuine Parts
Original
Ersatzteile
Enlarged Bold type item numbers
are recommended parts to be
stocked for servicing
J80
J70
J60
J10
J92
J90
J
J95
'V' & 'BB'
J50
J15
J30
Auxiliary Mounting
