Savannah 390026 User manual

#390026
AIR HOCKEY
SAVANNAH

1
#11
#18
#9 #10 #12
#13
#5 #6 #7
#1 #2 #3
#19
#8
#4
Parts List for Pottery Barn Air Hockey Table
32 pieces
5/16"X19mm Washer
5/16"X3/4" Bolt
16 pieces
Main Cabinet
1 piece 2 pieces
Left Leg Right Leg
Leg leveler
4 pieces
3/8"X2-1/4" Bolt
8 pieces 8 pieces
3/8"X23mm Washer
1/4"X1-3/4" Bolt
4 pieces
2 pieces 2 pieces
2 pieces
2 pieces 2 pieces
End Leg Panel
1 piece
Pusher
4 pieces
#20
Puck
4 pieces
#14
4 pieces
1/4"X19mm Washer
#15
5/16"X1-1/4" Bolt
2 pieces
#16
2 pieces
5/16"X23mm Washer
lron plate Main plate
Turnbuckle Support plate
#17
5/16"X2" Bolt
16 pieces
#21
Wrench
1 piece 1 piece
Allen Key
#22

Attach the main plate(#8) on the inside of the end leg panels(#4) using bolts(#9)
and washers(#10) Attach the iron plate(#7) to the outside of the end leg panels
using bolts(#9) and washers(#10).
Attach the end leg panel(#4) to the legs(#2 & #3) using bolts(#17) and washers(#10).
Step 2：
Step 1：

3
Step 4：
Step 3：
12
11
12 11
16
15
18
5
1
14 13
6
Attach the legs to the main cabinet(#1)
using bolts(#11) and washers(#12)
Set the support plate(#6) between the
main frame and Attach using
bolts(#13) and washers(14).
Insert the leg levelers(#18) into each
leg. Attach the turnbuckle(#5) to the
support plate(#6) using bolts(15)
and washers(#16) and hang the hook
on the mainplate(#8).

4
Set the table right side up using two aduits. Enjoy with your friends and family!
Step 5:
