SBL LFP-12V8AH User manual

1
Manual Instruction
Read the instruction manual carefully and make sure that you understand the
contents before you use the product. When installing, using and maintaining the
battery, the user safety must be guaranteed.
1. General information
A lithium battery is required to achieve a stable power supply even under heavy
loads, absolutely the best replacement for a lead battery. In addition to the
extremely light weight advantage, it offers additional enormous energy reserves.
Thanks to the integrated BMS (battery management system), SBL LiFePo4 batteries
for 12V DC applications. An increase in capacity through further LiFePo4 batteries
can be easily implemented. The lithium iron phosphate battery is the safest of the
regular lithium battery types. The nominal voltage of a LiFePO4 cell is 3.2V. A 12.8V
LiFePO4 battery therefore consists of four cells connected in series.
It accepts parallel connections for increased capacity and serial connections for
increased voltage, max connections four batteries.
BMS
BATTERY MANAGEMENT SYSTEM
The battery Management system (BMS) installed in every battery ensures that the
battery in the event of under voltage or overload switches off and automatically
again turns on as soon as the problem is resolved.
EASY REPLACEMENT THE EXISTING BATTERY
The dimensions of the housing are identical with the most common AGM, lead acid
or GEL batteries. With optionally available round poles can also use existing pole,
terminals can be reused. An exchange the battery holder or a change the loading
structure is not necessary.
APPLICATION AREAS
The areas of application of this battery are specifically for the stationary or mobile
area. Lithium batteries are diverse. Especially Mobile homes, solar, e-boats, electric
scooters, golf carts or electron-mobiles / wheelchairs and cleaning machines will
always be more often equipped with it.
BATTERY CHARGING
Use the suitable lithium battery charger. Waiting until the battery is fully charged.
PERFORMANCE / EFFICIENCY
ASBL LiFePo4 battery can do more than 96% of the energy made available directly
to save. A 100% utilization of the existing capacity takes place with the same output
voltage.
1.1. PRODUCT FEATURES / BENEFITS / AREAS OF APPLICATION
HIGH PERFORMANCE TRACTION / STORAGE BATTERY
INTEGRATED (BMS) BATTERY MANAGEMENT SYSTEM
SAFE LITHIUM TECHNOLOGY (LIFEPO4)
HIGH CYCLES LIFE
HIGH DISCHARGE CURRENT
LIGHT WEIGHT
ONE TO ONE REPLACEABLE WITH LEAD BATTERY
LOW SELF-DISCHARGE
THE RIGHT BATTERY FOR EVERY APPLICATION
MOTORHOMES, CARAVANS AND CARAVANS
PHOTOVOLTAICS, SOLAR SYSTEMS AND RENEWABLE ENERGIES
HIGH PERFORMANCE TRACTION / STORAGE BATTERY
FISHING, ELECTRIC BOAT MOTORS AND SONAR
MOBILE POWER SUPPLY, CAMPING AND LEISURE
EMERGENCY POWER SUPPLY / UPS
1.2. BATTERY MANAGEMENT SYSTEM
The battery management system (BMS) built into each battery ensures that the
battery switch off in the event of under voltage or overload and automatically again
turns on as soon as the problem is resolved.
THE ADDITIONAL FUNCTIONS OF SBL BMS ARE:
- Protection of the cell against under voltage by switching off the load in goodtime.
- Protection of the cell against over voltage by reducing the charging current or
switching off the charging process.
- Shutting down the system in the event of excess temperature.
- Charging of the battery will be stopped in case of under temperature.
1.3. TECHNICAL DATA FOR STANDARD LITHIUM LIFEPO4 BATTERY
Model
LFP-12V8AH
LFP-12V20AH
LFP-12V40AH
LFP-12V100AH
Nominal Voltage(V)
12.8
12.8
12.8
12.8
Nominal Capacity(Ah)
8
20
40
100
Usable Capacity (Wh)
102
256
512
1280
Dimension (mm)
151*65*97
181*77*168
198*166*170
330*172*215
Charge Current(A)
8
18
30
80
Discharge Current(A)
10
20
50
100
Cycle Life
≥2000@25
≥2000@25
≥3000@25
≥5000@25
Working Temperature(℃)
﹣20～60
﹣20～60
﹣20～60
﹣20～60
Discharge Voltage(V)
12.8
12.8
12.8
12.8
Charge Voltage(V)
14.6
13.5～14.6
13.5～14.6
13.5～14.6
Internal Impedance(mΩ)
≤20
≤20
≤20
≤20
Water Dust Resistance
IP65
IP65
IP65
IP65

2
2. SAFETY GUIDELINES AND MEASURES
2.1. Intended Use
PLEASE FOLLOW THESE INSTRUCTIONS AND SAVE FOR FUTURE.
LOOK AT NEAR TO THE LITHIUM LIFEPO4 BATTERY.
The battery may only be used for the purposes described in the operating
instructions.
Use for other purposes is considered improper use and has the invalidity of the
result in product guarantee. The manufacturer is not liable for damage caused by
faulty, improper use or improper use of the product. Use in aviation or in medical
devices that serve to support life contradict the intended use. LiFePO4 Batteries are
designed for use as energy storage. Possible areas of application for the battery are
used as a service and on-board battery in leisure vehicles or boat.
2.2. MARKINGS
Conformity mark (CE mark).
RoHS Conformity according to RoHS directive.
Conformity mark for material safety data sheet.
Fire, naked flames and smoking are prohibited! Sparking when handling avoid
cables and short circuits.
Not waterproof.
Dispose of the Lithium LiFePO4 battery in accordance with your local, state, and
local authority, federal laws and regulations. Batteries can be sent to the
manufacturer, can be returned. Do not mix with other (industrial) waste.
This product or parts of this product can be recycled.
The connections of the lithium battery are always live. Therefore, never place objects
or tools on the lithium battery. Avoid short circuits. Use isolated tools.
Do not wear metallic objects such as watches, bracelets, etc. on your body. Use ata
class D fire extinguisher, foam or CO2 fire extinguisher.
2.3. STORAGE AND TRANSPORT INFORMATION
The battery must be packed and protected well during transport.
The lithium battery must be transported according to the rules for transport, these
should always be followed (transportation code UN3480/UN38.3).
Never lift the battery by the terminals, only by the handles.
The battery should be stored in temperatures from -10℃to +30℃.
During transport, the battery should be about 50-60% charged.
The battery should be charged every three months to keep it active so that it always
works maximum.
2.4. DISPOSAL
Batteries that are marked with the recycling symbol must be returned to approved
recycling points. You can also contact the manufacturer by arrangement to be
returned. Batteries must not be disposed of in household or industrial waste.
2.5. IMPORTANT INSTRUCTIONS
Do not open the LiFePO4 battery without consulting the dealer. Unauthorized
opening of the battery voids the manufacturer's warranty.
▪ Only use the battery for the application for which it is intended.
▪ Do not short-circuit the LiFePO4 battery. The cable connections to the consumers
must go through a backup to be protected.
▪ Installation and maintenance may only be carried out by qualifiedspecialists.
▪ Do not expose to permanent direct sunlight. Protect from the effects of heat.
Temperatures above +60 ° C can damage the battery.
▪ Use only compatible chargers. The battery is in a longer storage of all disconnect
devices.
▪ Pay attention to proper assembly.
▪ Avoid damage of any kind, for example by falling, drilling, etc. (Risk of short circuit).
▪ Always keep the battery dry and clean.
▪ Note the plus (+) and minus (-) markings on the LiFePO4 battery and the device and
pay attention to the correct polarity.
▪ The cycle capacity may vary due to the change in the working temperature andthe
charge and discharge rate differ from the nominal capacity.
▪ Suitable for parallel connection. Before connecting, bring to the same charge level.
Batteries from different manufacturers or different types should not be
interconnected.
3. INSTALL THE BATTERY
Lithium LiFePo4 batteries are heavy. Make sure it is adequate and safe attached and
always use the appropriate transport equipment. In an accident unsecured, batteries
could become a projectile! Always take carefully with lithium batteries.
Make absolutely sure that the LiFePO4 battery is not connected with reversed
polarity. Should the battery be connected incorrectly, the BMS electronics will be
irreparably damaged and must be replaced with a new BMS board. This is not a
warranty case.
The battery models LFP-12V8AH or LFP-12V20AH or LFP-12V40AH is Not
designed in serial connections suitable! The battery model LFP-12V100AH is
acceptable for series connection, max 4 batteries (48V).
Disregard can lead to a defect!
