SBL LFP-24V50AHBLH User manual

Manual Instruction
Read the instruction manual carefully and make sure that you understand the
contents before you use the product. When installing, using and maintaining the battery,
the user safety must be guaranteed.
1. General information
A lithium battery is required to achieve a stable power supply even under heavy loads,
absolutely the best replacement for a lead acid battery. In addition to the extremely light
weight advantage, it offers additional enormous energy reserves. Thanks to the
integrated BMS (battery management system), SBL LiFePo4 batteries are for 12V DC
or 24V DC applications. An increase in capacity through further LiFePo4 batteries
can be easily implemented. The lithium iron phosphate battery is the safest of the
regular lithium battery types. The nominal voltage of a LiFePO4 cell is 3.2V. A 12.8V
LiFePO4 battery therefore consists of four cells connected in series and a 25.6V
LiFePO4 battery consists of eight cells connected in series.
The battery is integrated Bluetooth. Bluetooth app can be loaded down by the look
on “ SBL Connect”(App Store or Google play).
It accepts parallel connections for increased capacity and serial connections for increased
voltage. Max serial connections four batteries for 12V series and max serial connections
two batteries for 24V series (max. 48V).
The battery consists of two energy-efficient heating elements controlled fully automatically
by the BMS, which use the charging current to bring the cell temperature constantly above
freezing point, thus guaranteeing maximum charging and discharging performance even at
extreme temperatures.
BMS (BATTERY MANAGEMENT SYSTEM)
The Battery Management system (BMS) installed in every battery ensures that the
battery in the event of under voltage or overload switches off and automatically again
turns on as soon as the problem is resolved.
EASY REPLACEMENT THE EXISTING BATTERY
The dimensions of the housing are identical with the most common AGM, lead acid or
GEL batteries. With optionally available round poles can also use existing pole, terminals
can be reused. An exchange the battery holder or a change the loading structure is not
necessary.
APPLICATION AREAS
The areas of application of this battery are specifically for the stationary or mobile area.
Lithium batteries are diverse. Especially Mobile homes, solar, e-boats, electric scooters,
golf carts or electron-mobiles / wheelchairs and cleaning machines will always be more
often equipped with it.
BATTERY CHARGING
Use the suitable lithium battery charger . Waiting until the battery is fully charged.
PERFORMANCE / EFFICIENCY
A SBL LiFePo4 battery can do more than 96% of the energy made available directly to
save. A 100% utilization of the existing capacity takes place with the same output
voltage.
1.1. PRODUCT FEATURES / BENEFITS / AREAS OF APPLICATION
HIGH PERFORMANCE TRACTION / STORAGE BATTERY
INTEGRATED (BMS) BATTERY MANAGEMENT SYSTEM
SAFE LITHIUM TECHNOLOGY (LIFEPO4)
HIGH CYCLES LIFE
HIGH DISCHARGE CURRENT
LIGHT WEIGHT
ONE TO ONE REPLACEABLE WITH LEAD BATTERY
LOW SELF-DISCHARGE
THE RIGHT BATTERY FOR EVERY APPLICATION
MOTORHOMES, CARAVANS
PHOTOVOLTAICS, SOLAR SYSTEMS AND RENEWABLE ENERGIES
HIGH PERFORMANCE TRACTION / STORAGE BATTERY
FISHING, ELECTRIC BOAT MOTORS AND SONAR
MOBILE POWER SUPPLY, CAMPING AND LEISURE
EMERGENCY POWER SUPPLY / UPS
1.2. BATTERY MANAGEMENT SYSTEM
The battery management system (BMS) built into each battery ensures that the battery
switch off in the event of under voltage or overload and automatically again turns on as
soon as the problem is resolved.
THE ADDITIONAL FUNCTIONS OF SBL BMS ARE:
- Protection of the cell against under voltage by switching off the load in good time.
- Protection of the cell against over voltage by reducing the charging current or switching
off the charging process.
- Shutting down the system in the event of excess temperature.
- Charging the battery is stopped in case of under temperature.
1.3. TECHNICAL DATA FOR LITHIUM LIFEPO4 BATTERY WITH BLUETOOTH AND HEATING

Model
LFP-24V50AHBLH
LFP-24V100AHBLH
LFP-12V100AHBLH
Nominal Voltage(V)
25.6
25.6
12.8
Nominal Capacity(Ah)
50
100
100
Usable Capacity (Wh)
1280
2560
1280
Dimension (mm)
309*168*209
278*175*190
330*172*214
345*190*245
483*171*240
278*175*190
330*172*214
355*175*190
Charge Current(A)
30
80
80
Discharge Current(A)
50
100
100
Cycle Life
≥3000@25
≥5000@25
≥5000@25
Working
Temperature ℃
﹣30～60
﹣30～60
﹣30～60
Discharge Voltage(V)
25.6
25.6
12.8
Charge Voltage(V)
29.2
29.2
14.6
Internal Impedance
(mΩ)
≤20
≤20
≤20
Water Dust
Resistance
IP65
IP65
IP65
Series /Parallel
connections
Both acceptable
( series max. 2)
Both acceptable
(series max. 2)
Both acceptable
(max. 4)
Model
LFP-12V150AHBLH
LFP-12V200AHBLH
LFP-12V300AHBLH
Nominal Voltage(V)
12.8
12.8
12.8
Nominal
Capacity(Ah)
150
200
300
Usable Capacity
(Wh)
1920
2560
3840
Dimension (mm)
330*172*214
355*175*190
345*190*245
483*171*240
521*238*218
Charge Current(A)
100
100
100
Discharge Current(A)
150
200
200
Cycle Life
≥5000@25
≥5000@25
≥5000@25
Working
Temperature ℃
﹣30～60
﹣30～60
﹣30～60
Discharge Voltage(V)
12.8
12.8
12.8
Charge Voltage(V)
14.6
14.6
14.6
Internal Impedance
(mΩ)
≤20
≤20
≤20
Water Dust
Resistance
IP65
IP65
IP65
Series /Parallel
connections
Both acceptable
(max. 4)
Both acceptable
(max. 4)
Both acceptable
(max. 4)
2. SAFETY GUIDELINES AND MEASURES
2.1. Intended Use
PLEASE FOLLOW THESE INSTRUCTIONS AND SAVE FOR FUTURE. LOOK
AT NEAR TO THE LITHIUM LIFEPO4 BATTERY.
The battery may only be used for the purposes described in the operating instructions. Use
for other purposes is considered improper use and has the invalidity of the result in
product guarantee. The manufacturer is not liable for damage caused by faulty, improper
use or improper use of the product. Use in aviation or in medical devices that serve to
support life contradict the intended use. LiFePO4 Batteries are designed for use as energy
storage. Possible areas of application for the battery are used as a service and on-board
battery in leisure vehicles or boat.
2.2. MARKINGS
Conformity mark (CE mark).
RoHS Conformity according to RoHS directive.
Conformity mark for material safety data sheet.
Fire, naked flames and smoking are prohibited! Sparking when handling avoid cables
and short circuits.
Not waterproof.
Dispose of the Lithium LiFePO4 battery in accordance with your local, state, and local
authority, federal laws and regulations. Batteries can be sent to the manufacturer, can be
returned. Do not mix with other (industrial) waste.
This product or parts of this product can be recycled.
The connections of the lithium battery are always live. Therefore, never place objects or
tools on the lithium battery. Avoid short circuits. Use isolated tools.
Do not wear metallic objects such as watches, bracelets, etc. on your body. Use at a class
D fire extinguisher, foam or CO2 fire extinguisher.
2.3. STORAGE AND TRANSPORT INFORMATION
The battery must be packed and protected well during transport.
The lithium battery must be transported according to the rules for transport, these should
always be followed (transportation code UN3480/UN38.3).
Never lift the battery by the terminals, only by the handles.
The battery should be stored in temperatures from -10℃to +40℃.
During transport, the battery should be about 50-60% charged.
The battery should be charged every three months to keep it active so
that it always works maximum.
2.4. DISPOSAL
Batteries that are marked with the recycling symbol must be returned to approved
recycling points. You can also contact the manufacturer by arrangement to be returned.
Batteries must not be disposed of in household or industrial waste.

2.5. IMPORTANT INSTRUCTIONS
Do not open the LiFePO4 battery without consulting the dealer. Unauthorized opening of
the battery voids the manufacturer's warranty.
▪ Only use the battery for the application for which it is intended.
▪ Do not short-circuit the LiFePO4 battery. The cable connections to the consumers
must go through a backup to be protected.
▪ Installation and maintenance may only be carried out by qualified specialists.
▪ Do not expose to permanent direct sunlight. Protect from the effects of
heat. Temperatures above +60 ° C can damage the battery.
▪ Use only compatible chargers. The battery is in a longer storage of all
disconnect devices.
▪ Pay attention to proper assembly.
▪ Avoid damage of any kind, for example by falling, drilling, etc. (Risk of short circuit).
▪ Always keep the battery dry and clean.
▪ Note the plus (+) and minus (-) markings on the LiFePO4 battery and the device and
pay attention to the correct polarity.
▪ The cycle capacity may vary due to the change in the working temperature and
the charge and discharge rate differ from the nominal capacity.
▪ Suitable for parallel connection and series connection and maximum fourbatteries for
12V series batteries and maximum two batteries for 24V series batteries.
Before connecting, bring to the same charge level. Batteries from different
manufacturers or different types should not be interconnected.
3. INSTALL THE BATTERY
Lithium LiFePo4 batteries are heavy. Make sure it is adequate and safe attach and
always use the appropriate transport equipment. In an accident unsecured, batteries
could become a projectile! Always take carefully with lithium batteries.
Make absolutely sure that the LiFePO4 battery is not connected with reversed polarity.
Should the battery be connected incorrectly, the BMS electronics will be irreparably
damaged and must be replaced with a new BMS board. This is not a warranty case.
The battery model LFP-12V100AHBLH or LFP-12V150AHBLH or LFP-
12V200AHBLH or LFP-12V300AHBLH is acceptable for serial connection, max 4
batteries (48V). The battery model LFP-24V50AHBLH or LFP-24V100AHBLH is
acceptable for serial connections, max 2 batteries (48V). Series or parallel
connections are only for the same standard battery.
Disregard can lead to a defect!
