SCAN&GO BLK2GO User manual
USER MANUAL
www.scan-go.eu
Scan&Go srl
Via della Tecnica 34 A/B - 41051
Castelnuovo Rangone (MO) - Italy
Cell. +39 3924627285
BLK2GO Backpack
June 2021
BLK2GO Backpack
COMPONENTS
1
2 3
1
2
3
This Backpack is designed to be used with BLK2GO
laser scanner comfortably on the operator's shoul-
ders, thus leaving the hands free.
The support (4) is made of aluminum tubes, the incli-
nation can be adjusted by the operator allowing to
keep the scanner at different heights,
(1) the BLK2GO Adapter is equipped with 5/8 con-
verter
(2) Standard Leica pin with locking knob allows 360 °
rotation to orient the scanner in any direction.
4
4
1. BLK2GO Adapter
2. Standard Leica pin 5/8 ”
3. Base for initialization
4. Adjustable support
Weight (without BLK2GO) 2 Kg
BLK2GO Backpack
Base for initialization
Correct position of the adjustable support
ATTENTION: the locking strap must be positioned above the knob and tightened very well
BLK2GO Backpack
Install the upper part of the support by using the supplied knobs.
Adjust the inclination of the tube and the support
The use of the above part of the support for
scanning without the Backpack
BLK2GO Backpack
(3) Place the scanner with BLK2GO adapter and standard Leica pin on the base for initializa-
tion of the scanner.
Fix the scanner on the support and start walking when scanning
3
Thanks to the quick release the scanner can be easily
used by hand in all situations when the Backpack would
be bulky or not suitable
.
Made in Italy
