SCAN&GO SferaZERO User manual

SferaZERO
USER MANUAL
www.scan-go.eu
SCAN&GO srl
Via della Tecnica 34 A/B - 41051
Castelnuovo Rangone (MO) - Italy
Cell. [phone]
[email protected]u
Made in Italy
January 2018

DETAILS and ACCESSORIES
A SferaZERO
B Adapter with 5/8” female / Leica pin male
C Adapter Leica pin female / 5/8” male
D Magnetic level bracket
A
C
D
E

 Install the MAGNETIC LEVEL BRACKET on the vehicle hood
 Screw the adapter C at bolt 5/8” present in the centre of the Magnetic Level Bracket
 Place the SferaZERO on the Magentic level bracket. Chek the locking of the adapter D lock
C
Assembly of SferaZERO:
INSTRUCTIONS FOR INSTALLATION AND USE
Place the GNSS receiver
in the support
12
Screw the adapter D to the GNSS receiver, in
order to block the SferaZERO
Pull down the Semisphere until they reach the receiver.
Lock the two lateral screws
3

NEW surveying technology & solutions
