scandia AURORA Specification sheet

AURORA
ELECTRIC FIREPLACE
OPERATION AND INSTALLATION
MANUAL
www.scandiastoves.com.au
36" Electric Fireplace
50" Electric Fireplace
74" Electric Fireplace
Contents of this manual may be updated without notice.
Version 1.1 08/12/12022
SCANDIA AURORA

Introduction 3
Recessed Wall Installation 4
Wall Mounted Installation 7
Operation 10
Care And Maintenance 13
Warranty 14
2
Model Name Model Number
Aurora 36” SG010400165
Aurora 50" SG010400168
Aurora 74” SG010400171
CONTENTS
WARNING
This appliance must be installed in accordance with:
• Manufacturer’s Installation Instructions
• Current AS/NZS 3000
• Local Regulations and Municipal Building Codes
Including local OH&S requirements. For continued safety of this appliance it must be installed and
maintained in accordance with the manufacturer’s instructions.
Specifications
Model Aurora 36” Aurora 50" Aurora 74”
Rated Power 1500W
Rated Voltage 240V ~ 50Hz
Appliance Dimensions
Height 429 mm 429 mm 429 mm
Width 915 mm 1270 mm 1880 mm
Depth 150 mm 150 mm 150 mm
Unit Net Weight 18.4 KG 21.6 KG 30.5 KG
Installation Options Recessed or Wall
Power cable length 1.8m
Power cable position Right hand rear corner

3
IMPORTANT INSTRUCTIONS
When using electrical appliances the following precautions should always be followed to reduce
the risk of fire, electric shock or injury to persons:
UNPACKING THE APPLIANCE
Carefully remove the appliance from the box and check all items are present and inspect for any
physical damage to the appliance, accessories, power cord and plug.
Prior to installing the appliance, test to make sure the appliance operates properly by plugging the
power cord into a conveniently located and grounded GPO.
INTRODUCTION
Congratulations on purchasing a genuine Scandia Electric Fireplace. When cared for properly, these high
quality, finely crafted appliances will offer many years of reliable performance. This instruction manual has
been developed to ensure optimum performance from your Scandia Electric Fireplace. It’s very important
that you thoroughly read and understand all instructions before using your new appliance.
1Read all instructions before using this appliance.
2The appliance maybe hot when in use. To avoid burning, do not touch hot surfaces. Keep
combustible items, such as furniture, pillows, bedding, papers, clothes, and curtains at least 1m from
the hot air outlet of the appliance.
3Extreme caution is necessary when any appliance is used near children or infants.
4Do not operate the appliance with a damaged cord or plug or when it has been dropped or
damaged in any manner, instead return the appliance to place of purchase.
5Do not use this appliance outdoors.
6This appliance is not intended for use in bathrooms or laundry areas.
7If you need to disconnect the appliance, turn controls to off, then remove plug from outlet.
8Do not inset or allow foreign objects to enter any inlet or outlet vents as this may damage the
appliance.
9To prevent damage to the appliance, do not block air inlets or the heating outlet.
10 Do not operate this appliance using a powerboard or extension leads.
11 Use this appliance only as describes in this manual. Any other use is not recommended by the
manufacturer.
12 Never cover or partially cover the appliance during use.
13 This appliance is not intended for use by persons (including children) with reduced physical, sensory
or capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.Children should
be supervised to ensure that they do not play with the appliance.
14 Never operate this appliance using an external switching device, such as a timer or remotely switched
circuit.

RECESSED WALL INSTALLATION
B
A
C
Model A
(Width)
B
(Height)
C
(Depth)
Aurora 36” 890 410 160
Aurora 50” 1245 410 160
Aurora 74” 1855 410 160
WALL
WALL CAVITY DIMENSIONS
ST4*8-Screws Wall Mount Bracket
Step 1
1. “Remove the four silver colored screws on the top of the appliance and take off the wall
bracket (See Step 1).
4
Find a suitable location to build the cavity for the fireplace. Minimum clearance from the the mantel is
200mm; the installation location must be near a GPO. Do not locate the appliance immediately below
a GPO.
WARNING:

RECESSED WALL INSTALLATION....continued
Wall
Fix the Suction Lif
ters to the glass,
lif
t upwards then outwards.
Ta
ke off the left
silv
er screw
Ta ke off the righ
t
silver screw
ST4*40 - Screws
Step 2
Step 3
2. To remove the glass, unscrew the 2 silver screws on the left and right hand sides of the
appliance. Remove the glass front using the suction lifter provided, move the glass upwards
and then outwards (Step 2).
3. Before positioning the appliance into the cavity, connect the plug to the GPO, move the
appliance into the cavity then fix the 2 silver screws from the inside of the appliance into the
cavity wall (See Step 3).
5

WARNING:
ALWAYS use extreme caution when handing glass. Failure to do so could result in personal injury or
property damage. Two suction lifters are provided to handle the glass front safely.
RECESSED WALL INSTALLATION....continued
Plastic
Tr ay
Crystal Embers
Wood Fire Logs
N
ote:
St
ore the suction lifter in
a sa
fe place for future use.
Step 4
Step 5
4. Position the plastic base tray as shown, place the crystals and wood fire logs into position (See
Step 4)
5. Install the glass in the direction of the arrows, once securely in place remove the suction lifter.
6

WALL MOUNTED INSTALLATION
Wall
ST4*40-Screws
ST4*8-Screws Wall Mount Bracket
Step 1
Step 2
Step 3
1. Remove the four silver colored screws on the top of the appliance and take off the wall bracket
(See Step 1).
Locate structural members behind the
wall and mark out using the wall bracket
(See Step 2).
Screw the wall bracket into place (See
Step 3).
7

WALL MOUNTED INSTALLATION....continued
Ta ke off the left
silver screw
Ta ke off the right
silver screw
Step 4
Step 5
2. Lift fireplace and place onto the bracket, fix the 4 silver screws back to the top (Step 4).
3. To remove the glass, unscrew the 2 silver screws on the left and right hand sides of the appliance.
Remove the glass front using the suction lifters provided, move the glass upwards and then
outwards (Step 5). Remove the glass in the direction of the arrows, using the suction lifter
provided.
8

WALL MOUNTED INSTALLATION....continued
Ta ke off the left
silver screw
Ta ke off the right
silver screw
Plastic
Tr ay
Crystal Embers
Wood Fire Logs
Step 7
Step 6
4. Position the plastic base tray and place the crystals and wood fire logs into position (Step 6).
5. Install the glass in the direction of the arrows, once securely in place remove the suction lifter.
• Take care when installing the glass panel. Installing the glass front requires 2 people.
• Carefully set the left and right hand hooks of the glass front inner onto the corresponding left
and right hand locating tabs of the firebox.
Make sure the glass is correctly attached to the firebox on both sides. Also ensure the control panel
springs are located correctly and not mis-aligned 9

10
Touch Control Switch Panel
OPERATION
SAFETY INSTRUCTIONS
OPERATING THE FIREPLACE
Ensure the appliance is plugged into the GPO and switched on. The Control Switch Panel is on
the bottom of fireplace (See image below)
1Only use this appliance in accordance with the instructions in this manual.
2Be cautious when handling and disposing of the packaging. The packaging contains plastic
wrapping that may be lethal to children.
3Never operate this appliance using an external switching device, such as a timer or remotely
switched circuit.
4The appliance is only suitable for indoor use.
5Never use the appliance in the bathroom, shower or near a swimming pool.
6Never leave infants or small children unattended near the appliance.
7In case of a faulty appliance, disconnect the plug immediately and return to the
original point of purchase.

11
OPERATION....continued
REMOTE CONTROL FUNCTIONS
Power ON/OFF
Heat setting
Flame setting
Top light setting
Timer Setting
Flame log setting
Power ON/OFF
Flame setting
Flame log setting
Top light setting
Heat setting
Timer Setting
You can keep pressing “Flame
setting” button for 10 seconds
to connect to the mobile APP.
WARNING:
NEVER dispose of batteries in fire. Failure to observe this precaution may result in an explosion.
Dispose of batteries at your local battery recycling centre.
• This remote control uses two AAA batteries
(Included).
• Instructions for battery installation are on
the Remote Control battery compartment.
POWER Turns the appliance ON/OFF.
FLAME Controls flame effect.
13 colors : ( L01,L02...L12,L13)
FLAME LOG Controls flame log effect.
13 colors : ( C01,C02...C12,C13)
TOP LIGHT Controls Top light colors.
3 colors : ( F0 OFF-F1 yellow-F2 blue-F3 purple)
HEATER
Controls the heater function
Press button to initiate the heater.
(OFF) no heater or fan.
(LO), heater fan warm air (750W)
(HI), heater fan hot air (1500W)
NOTE: Heater functions cycle from OFF-LO-HI
Control with
Smart Phone
App
You can operate the Aurora Electric Fireplace series with a
smartphone App. Use the “Flame” button to pair devices. Scan
the QR code below for App Operation Instructions
TIMER
Controls the Timer.
9 Settings: (1h, 2h, 3h, 4h, 5h, 6h, 7h, 8h,9h) Press button until
reach desired setting.
ICON FUNCTIONS

12
NOTE:
When the heater is first turned on, a slight odor may be present. This is normal and should not occur
again unless the heater is not used for a long period of time.
To improve operation, aim the remote control at the front of the fireplace. DO NOT press the buttons
too quickly. Give the unit time to respond to each command.
Your Scandia Aurora Electric Fireplace can be connected and fully operated using a WiFi
Smartphone App, it can also be connected to either a Google Home or Amazon Alexia device for
simple on/off operation commands.
Please scan the following QR code for detailed instructions on how to connect your Aurora
Fireplace using the WiFi Smartphone App, Google Home or Amazon Alexia:
OPERATION....continued
WIFI SMARTPHONE AND SMART HOME INSTRUCTIONS
1Turn the ON/OFF switch on the CONTROL PANEL to OFF.
2Unplug the power cord from the outlet.
3Inspect the appliance to make sure no vents are obstructed or blocked with dust or lint.. If so use
a vacuum to clean these areas.
4With the power switch in the OFF position, plug the power cord back into the outlet. Switch ON
the power switch.
5If the appliance switches off again then the appliance is faulty and must be returned to the
original point of purchase.
TEMPERATURE LIMITING CONTROL
This appliance is equipped with a temperature limiting control. Should the heater reach an unsafe
temperature (100OC), the heater will automatically turn OFF.
To reset:

13
CARE AND MAINTENANCE
CLEANING
NEVER immerse or spray with water. Doing so could result in electric shock, fire, or personal
injury.
METAL:
Wipe using a soft cloth, slightly dampened with a citrus oil based product.
DO NOT use brass polish or household cleaners as these products will damage the metal trim.
GLASS:
Use a good quality glass cleaner sprayed onto a cloth or towel, clean the glass then dry
thoroughly with paper towel or a lint-free cloth.
NEVER use abrasive cleaners directly on the glass surface.
VENTS:
Use a vacuum or duster to remove dust or debris from the vent inlet and outlet areas.
PLASTIC:
Wipe gently with a slightly damp cloth and a mild solution of soap and warm water.
NEVER use abrasive cleansers directly on the plastic surface.

WARRANTY
2 YEAR LIMITED WARRANTY
This limited warranty (Warranty) is given by Scandia Heating (Aust) Pty Ltd (ACN 005 868 093)
(Scandia or we) to the original retail purchaser (You) of the Electric Fireplace to which this Warranty
applies.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure does not amount to a major failure.
The benefits that this Warranty provides are in addition to other rights and remedies available to you
under the Australian Consumer Law. This Warranty does not limit those rights and remedies.
IMPORTANT: For this Warranty to apply, you must fully complete the online warranty registration
form within 30 days after the original purchase. By completing this, you also agree that, to the extent
permitted by law, our liability to You on any basis in relation to the Electric Fireplace (other than under
the Australian Consumer Law) is limited to our obligations under this Warranty.
SCOPE OF WARRANTY
If:
• a defect in material or workmanship appears in the following parts within the corresponding
warranty period after the date of the original purchase, such as to make the Electric Fireplace
unfit for normal home use and;
• you comply with the requirements below regarding making a claim, then, subject to the exclusions
below, we will (or will arrange to) replace or repair the relevant part or (at our option) replace the
entire Electric Fireplace with the same or comparable model.
EXCLUSIONS
This Warranty does not apply:
• if the Electric Fireplace is not installed or operated to the specifications detailed in this
manual;
• where the defect is not due to the original design or manufacture of the part (including
where the appliance or part has been subject to accident, abuse, alteration, misuse or
neglect or has been installed, altered, inspected, operated, cleaned or maintained negligently
or not in accordance with applicable local laws, regulations and standards and the
instructions and requirement included in this manual);
• if you are not a retail purchaser, or in the case of non domestic use (e.g. any commercial
venue);
• to any accessories or optional parts;
• to noise caused by minor expansion, contraction or movement of parts;
• to any initial smell due to dust, paint or surfaces curing;
14

WARRANTY....continued
• to changes in surface finishes as a result of ordinary use (including interior and exterior
colour changes or fingerprint marks) or any discolouration of glass;
• to any surface rust which may occur in transit, storage or use;
• to any defect caused, or likely to have been caused, by an unsuitable environment, including
but not limited to:
– Close proximity to beaches;
– atmospheres containing chlorine or fluorine.
HOW TO MAKE A CLAIM
Any claim under this Warranty must be in writing to our mail or email address below. It must
be sent within the applicable warranty period and must include:
• the model number of the Electric Fireplace;
• A copy of the receipt detailing the place, price and date of purchase; and
• reasonable details of the defect.
REGISTER ONLINE
Register your product warranty online by visiting:
www.scandiastoves.com.au/warranty
Your data will be used by Scandia to provide you with
information about your purchase upon request.
REGISTER YOUR PRODUCT
15

Head Office
58 Access Way,
Carrum Downs VIC 3201
Australia
Scandia Heating (Aust) Pty Ltd
[phone]
[e-mail]
www.scandiastoves.com.au
