ScatterBox MOD300 User manual

Quick Start Guide - qMOD300 Copyright 2021 System Q Ltd
1
Digital HD Modulator
ScatterBox is a registered trademark of System Q Ltd
MOD300 - Quick Start Guide
www.systemq.com/PDF
/manual/xMOD300.pdf
The MOD300 converts a HDMI output from a DVR (or other equipment such as a Satellite box) into a
digital RF signal or “Digital TV channel”. It can then be viewed on a DVB-T equipped TV.
Note: The MOD300 has to process and digitise the HDMI input and this creates a delay or “latency” in its
output, this is typically in the region of 1 second.
1) Remove all the power to the modulator when connecting or removing cables.
2) Connect a HDMI cable from the DVR / NVR (or other video equipment) to the HD IN of the MOD300.
3) When combining the RF signal of a TV aerial and the MOD300, connect the TV aerial coax (f-
connector) to the RF.IN port. If using a masthead amplifier, see the full manual.
4) Connect a coax (f-connector) to the RF.OUT port direct to a TVs aerial socket or to a distributor to
multiple TVs.
5) Connect the 12V DC power supply to the MOD300, then re-tune the TVs.

Quick Start Guide - qMOD300 Copyright 2021 System Q Ltd
2This symbol indicates that equipment must not be mixed with general household waste. For treatment, recovery and recycling please return to your local designated
WEE/CG0783SS collection point as defined by your local council.
All specifications are approximate. System Q Ltd reserves the right to change product specificationsor features without notice. Whilst every effort is
made to ensure that these instructionsare complete and accurate, System Q Ltd cannot be held responsible for anylosses, no matter how they arise,
from errors or omissionsin these instructions,or the performance or non-performance ofthe equipment refered to.
Digital HD Modulator
ScatterBox is a registered trademark of System Q Ltd
LED Indicators
· Power = On when the power supply is connected
· HD / AV = Indicates the source which it is set (HD is on as default)
Controls
· = Increase or decrease the selected parameter /menu
· = Move to the next or previous digit / character
· Ok = Enter the menu system / select parameter / confirm selection
· Exit = Return to the previous menu / cancel selection
The MOD300 has been designed for use in the UK, as standard the channel appears as "SBox" and
channel 800 on the TV.
Settings will need to adjusted if using multiple MOD300s or if the default channel is already in use or to
change the channel name. For menu configuration see the full manual.
Video
Encoding
MPEG-4 AVC/H.264
Resolution
1920 *1080p at 60Hz , 1920 *1080p at 50Hz ,
1920 *1080i at 60Hz , 1920 *1080i at 50Hz ,
1280*720p at 60Hz , 1280*720p at 50Hz
Aspect Ratio
16:9, 4:3
Bitrate
1.000~18.000 Mbps
Audio
Encoding
MPEG Layer 1
Sample rate
48KHz
Bitrate
64, 96, 128, 192, 256, 320kbps
CVBS Encoding
Input
PAL, NTSC
DVB-T Modulator
Section
Standard
DVB-T COFDM
Bandwidth
6M, 7M, 8M
Constellation
QPSK, 16QAM, 64QAM
Code rate
1/2, 2/3, 3/4, 5/6, 7/8
Guard interval
1/4, 1/8, 1/16, 1/32
FFT Carrier Mode
2K, 8K
MER
30dB
RF Frequency
177 ~ 858 MHz
RF Output
0~ +6 dBm
General
Insertion Loss
-3dB
Language
English
Firmware
Upgradable Via USB
RF In / Out
F-Connector
Power supply
12V DC 2A Plug-in (Supplied)
Operating temperature
5°C ~ 45°C
Dimensions
(H)45mm x (W)198mm x (D)111mm
