Sceptre LCD Monitor User manual

i
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device ma not cause harmful interference, and
2. This device must accept an interference received, including
interference that ma cause undesired operation.
FCC WARNING
This equipment has been tested and found to compl with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequenc energ
and, if not installed and used in accordance with the instructions, ma
cause harmful inerference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined b turning the
equipment off and on, the user is encouraged to tr to correct the
interference b one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
To compl with the limits for an FCC Class B computing device, alwa s
use the shielded signal cord supplied with this unit.

ii
The Federal Communications Commission warns that changes or
modifications of the unit not expressl approved b the part responsible
for compliance could void the user’s authorit to operate the equipment.
CE mark for Class B ITE (Followin European standard EN55022/1998; EN61000-
3-2/1995; EN61000-3-3/1995, EN55024/1998, EN60950-1/2001)
Radio Frequency Interference Statement
Warnin :
This is a Class B product. In a domestic environment, this product ma
cause radio interference in which case the user ma be required to take
adequate measures.
Canadian Doc Notice
For Class B Computin Devices
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus as set out in the Radio Interference
Regulation of the Canadian Department of Communications.
“Le présent appareil numérique n’èmet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de la class B
prescrites dans le Règlement sur le brouillage radioélectrique édicté par le
ministère des Communications du Canada."

iii
TABLE OF CONTENTS
TABLE OF CONTENTS...........................................................................................III
Your New LCD Monitor 1
Unpacking 1
Product feature 2
Identifyin Components 3
Adjustin the Tiltin An le 5
Connectin AC Power and Video Cable 6
Power Mana ement System 6
The LCD Monitor's Control Panel 7
Adjustin the Monitor’s Display 8
TFT LCD Monitor Specifications 14
Supported Timin 17
Troubleshootin 17

1 Rev.1
The LCD Monitor
Your New LCD Monitor
Your LCD Monitor has been desi ned to be versatile, er onomic
and user-friendly. The LCD Monitor is capable of displayin most
standards, from 640x400 VGA to 1280x1024 SXGA. The di ital
controls located on the front panel allow the user to easily adjust
the Monitor’s display parameters, and the LCD Monitor’s small
footprint ives you more room in your workspace for other
peripherals. Li htwei ht and compact, the LCD Monitor is the
perfect solution for users on the o. You can use the LCD Monitor
for everythin from makin business presentations to playin
computer ames.
The architecture of the LCD Monitor incorporates an LCD panel that
produces a clear display with low radiation emission. And with its low
power consumption, the LCD Monitor helps you reduce your power bill.
Unpackin
Before unpackin your LCD Monitor, prepare a suitable workspace for
your LCD Monitor and computer. Look for a stable, level and clean
surface near a wall outlet. Even thou h the LCD Monitor uses very
little power, you should put it in a location, which allows sufficient
airflow to ensure that the LCD Monitor and your computer do not
overheat. Set up your LCD Monitor so that the panel is not facin a
window where sunli ht often comes in. The lare caused by sunli ht
reflectin off of the LCD Monitor’s screen will make it difficult to use
the Monitor for viewin .
Note: Using a computer for an extended period of time with a poor workstation
set-up and incorrect working habits can cause health problems. The science of
ergonomics studies the relationship between health and a suitable working
environment. There is a section on ergonomics at the end of this chapter. For
more information on ergonomics, contact your nearest computer bookstore, or
local library. The Internet also has information on this and other sub ects.

2
After unpacking our LCD monitor, make sure the following items are
included in the box and are in good condition:
• LCD monitor
• Power Cord
• Monitor-To-PC Analog signal cable 15pin, which has been
attached with monitor
• User’s manual
If you find that any item to be missin or appear to be dama ed,
contact your dealer immediately. Do not throw away the packin
material or shippin carton in case you need to ship or store the
LCD monitor in the future.
Product feature
 500:1 high contrast ratio
 1280 X 1024 native resolution
 VESA 100 mm wall mount compliance using M3 screws at 8
mm length
.

3 Rev.1
Identifyin Components
A. The LCD Monitor — Front View
Figure 1-1: The LCD Monitor Front View
1. Power-On Indicator
The LED indicator lit blue when the power is on and red when
the LCD monitor is in power-saving mode.
2. Monitor Stand
3. LCD Screen
The LCD monitor screen is a 17-inch TFT 1280 x 1024 screen.
4. LCD Monitor Control Panel
Refer to Chapter 2 for more details.
3
2
1
4
3

4
B. "Hot Keys" for Quick Adjustment of Monitor Settin s
Figure 1-2: "Hot Ke s"
1. Brightness Adjustment "hot ke ":
Press the “+” button to allow ou to
adjust the brightness of the LCD
Monitor directl
Brightness
50
2. Contrast Adjustment “ Hot ke ”
Press the “-“ button to allow ou to
adjust the contrast of the LCD Monitor
directl
Contrast
50
3. Auto adjustment “ Hot Ke “
Press this to allow ou to do the
auto adjustment to get the optimized
view
Auto


 +

5 Rev.1
Adjustin the Tiltin An le
The LCD Monitor’s an le settin s ran e from 0°
°°
° to 90
00
0°
°°
°
Figure 1-3: Tilting the Monitor

6
Connecting AC Power and Video Cable
Note: Turn off your PC and the LCD monitor before connectin your
LCD monitor to the computer.
Figure 1-4: The AC Adapter
Power Mana ement System
This LCD Monitor complies with the VESA DPMS power mana ement
proposal.
When the LCD Monitor is in power-savin mode or detected an
incorrect si nal timin , the monitor screen will be blank and the power
LED indicator from blue li ht chan e to red li ht.

7 Rev.1
The Display Controls
The LCD Monitor’s Control Panel
Figure 2-1: The Control Panel
1. : Enable the OSD Menu button or
/ Move the cursor to the left ( when OSD is enabled)
2. : Move the cursor to the Ri ht ( When OSD is enabled)
/ Auto-adjustment hot key
3. - : Enter into the sub-menu or decrease the value
/ Contrast hot key
4. + : Enter into the sub-menu or increase the value
/ Bri htenss hot key
5. :Power Switch
T is button lets you turn power for t e LCD monitor ON or
OFF. W en OSD menu is on t e screen, it could turn off t e
OSD menu.


 +

8
Adjusting the Monitor’s Display
OSD Main Menu
1. Pressin the 

 button causes the screen below to appear.
2. Use the 

 &

 key to select the desired roup, then press – or +
key to enter into sub-menu
3. Repeat step 2 to select the chan ed item, then – or + to chan e
the value.
Monitor Control
OSD Main SCREEN
Main Menu
Sub Menu
Description

9 Rev.1
MONITOR-CONTROL
Allow you to adjust the LCD monitor’s display settin s.
Press the Adjustment control button to display the submenu.
Use the Function Select button to select one of the followin
submenu options:
Auto Adjustment
Press the Adjustment control button to let the monitor
determine and select the settin that is most appropriate
for your system requirements.
H-POSITION:
To move the LCD monitor's display left or ri ht on a horizontal plane.
V- POSITION:
To move the LCD monitor's display up or down on a vertical plane.
PHASE:)
To adjust the focus and clarity of the display
CLOCK:
To adjust the display pixel ali nment.

10
RESET:
To reset all of the Monitor-Control submenu settin s to the
factory default.
GRAPHIC/TEXT:
Press the adjustment control button to switch between
text and raphic display modes.
EXIT:
To exits the Monitor-Control submenu
OSD-CONTROL
The OSD-Control menu lets you adjust the position of the OSD on the
screen. Press the Adjustment control button to display the submenu.
OSD-H-POSITION:
To chan e the position of the OSD on a horizontal plane
OSD-V-POSITION:
To chan e the position of the OSD on a vertical plane.
OSD-TIMER:
The OSD menu display time can be set at 5, 10, 15, 20, 25 or 30
seconds.
EXIT:
To exit the OSD-Control submenu.
GRAPHIC-CONTROL:
The Graphic-Control option lets you make adjustments that effect
the contrast,bri htness and color of the LCD monitor’s display.

11 Rev.1
CONTRAST:
To adjust the contrast level of the display screen
BRIGHTNESS:
To adjust the li ht level on the display screen.
COLOR:
To select the LCD monitor’s color display. The available options are
cold, warm and User. Selectin the user option lets you make individual
adjustments to the R, G and B colors.
COLOR R, G and B ADJUST:
To make individual adjustments to the Red, Blue,
Green
(RGB) ain for the color temperature.
AUTO LEVEL:
To automatically adjust the display white balance.
You have to set display in full white mode before actrive the color auto
Adjustin .
RESET:

12
To reset all of the Graphic-Control submenu settin s to the factory
default.
EXIT:
To exit the Graphic-Control submenu.
MISC-CONTROL:
The Misc-Control menu option lets you select the OSD
display lan ua e and view system information.
LANGUAGE:
The supported lan ua es include German, En lish, French, Spanish,
Italian,Japanese .
SHARPNESS:
To adjust the sharpness level of the display.
INFORMATION:
To indicate display mode timin s and firmware version.
EXIT:
To exit the Misc-Control submenu.
EXIT:
Use the OSD Exit item to close the OSD menu. The OSD
will disappear by itself if left inactive.

13 Rev.1

14
Note:
1) No video
When the monitor is ON and there is no video si nal received, the
followin messa e will be displayed
2) Si nal out of ran e
When the frequency ran e of the si nal is out of the monitor
specifications, the display will show the followin messa e
OVE R RA N G E
NO VI D E O

15 Rev.1
Appendix A
TFT LCD Monitor Specifications
LCD Panel 17" SXGA
Control
Functions
Power
Software Power switch with LED indicator
(ON/OFF)
Main Menu Submenu
MONITOR-
CONTROL
Auto Adjustment, H-POSITION,
V- POSITION, PHASE, CLOCK,
GRAPHIC/TEXT, RESET, EXIT
OSD-CONTROL OSD-H-POSITION, OSD-V-
POSITION, OSD-TIMER, EXIT
MISC-CONTROL LANGUAGE,SHARPNESS,
INFORMATION, EXIT
GRAPHIC-
CONTROL
CONTRAST, BRIGHTNESS, COLOR,
COLOR R, G and B ADJUST, AUTO
LEVEL, RESET, EXIT
On-Screen
Displa
(OSD)
EXIT
Displa Area
(mm)
338 X 270
(17" diagonal)
Displa
Colors
16.2 M
Video
Interface
VGA Compatible Analog RGB (15-pin mini D-Sub)
Plu and Play DDC1 and DDC2B

16
Scanning Frequenc
H / V, Hz
30-81K
50-75
Power Management VESA DPMS
Power Consumption
(ON / OFF)
35W / 1W Max.
Dimensions
W X H X D
17.32 X 19.57 X 4.33 (
inch)
440 X 497 X 110.00 (mm)
Net Weight
(approx.)
9.39 lbs
(4.27Kg)
Power Suppl
(
100–240 V AC, 50/60 Hz)
Environment Operation tmperature : 0 to 35°C,
humidit : 10–90%
Storage
tmperature : -20 to +60 °C,
humidit : 8–95%
Regulator CCC,UL,CUL,FCC ,CE,CB
