Schmidt AS 990 User manual

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 1
Product group: Sweeper
Operating Instructions
Airport Sweeper
Airport Stand Cleaner
Model: AS 990
List No. 1048964-2 from 70-1-001 en Edition 11
Read the operating instructions before putting the machine into operation.
Keep the operating instructions in the machine and include them with the machine
if it is transferred.
We reserve the right to make changes to the technical details included in the
specifications and diagrams in these operating instructions. Reproduction,
translation and photocopying in whole or in part without written permission
is forbidden.
Aebi Schmidt Deutschland GmbH
Albtalstraße 36, 79837 St. Blasien, Germany
Telephone: [phone] Internet: www.aebi-schmidt.com
Fax: [phone] E-mail: [email protected]

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 2

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 3
Table of contents
Abbreviations.................................................................................................................11
References .....................................................................................................................11
1The operating instructions ....................................................................................12
2Declaration of Conformity .....................................................................................14
3Explanation of symbols and safety notices ........................................................15
3.1 Explanation of symbols.....................................................................................15
3.2 Safety regulations.............................................................................................15
4Description..............................................................................................................18
4.1 General information ..........................................................................................18
4.2 Operating personnel .........................................................................................18
4.2.1 Sweep mode ..............................................................................................18
4.3 Personal protection equipment.........................................................................19
4.4 Lashing and mounting points............................................................................20
4.4.1 Lashing points ............................................................................................20
4.4.2 Lashing points on the AS 990 ....................................................................20
4.4.3 Suspension points......................................................................................21
4.5 Safety equipment..............................................................................................21
4.5.1 Hopper .......................................................................................................21
4.5.2 Sweeping unit cover...................................................................................21
4.5.3 Mirrors........................................................................................................21
4.6 Protective measures to be taken by the user....................................................22
4.6.1 Park the vehicle safely. ..............................................................................22
4.6.2 General notes on the danger area .............................................................22
4.6.3 Reversing...................................................................................................23
4.6.4 Unloading the hopper.................................................................................23
4.6.5 Driving into junctions ..................................................................................23
4.6.5.1 Danger zone when steering the machine ...............................................23
4.6.5.2 Danger zone in use ................................................................................24
4.6.6 Safety equipment .......................................................................................24
4.7 Labelling ...........................................................................................................25
5Technical data ........................................................................................................29
5.1 Intended use.....................................................................................................32
5.2 Noise emissions and vibration..........................................................................33
5.2.1 Noise emissions .........................................................................................33
5.2.2 Vibration.....................................................................................................33
5.2.2.1 Hand-arm vibration .................................................................................33
5.2.2.2 Whole body vibration ..............................................................................33

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 4
5.3 Avoiding noise and vibration.............................................................................34
5.3.1 Preventing noise ........................................................................................34
5.3.2 Preventing vibrations..................................................................................34
5.4 Machinery Directive ..........................................................................................34
6Vehicle requirements for mounting the AS 990...................................................34
7Parts description ....................................................................................................35
7.1 Control panel ....................................................................................................35
7.2 Hand-held control panel....................................................................................35
7.3 Wanderhose .....................................................................................................36
7.4 Remote start connector.....................................................................................36
7.5 Plug-in connectors............................................................................................36
7.6 Drive engine......................................................................................................37
7.7 AS 990 carbamide tank.....................................................................................37
7.8 Hydraulic system ..............................................................................................37
7.8.1 Hydraulic tank ............................................................................................38
7.8.2 Hydraulic pumps driven by the auxiliary engine .........................................38
7.8.3 Hydraulic pump driven by the vehicle engine.............................................38
7.8.4 Hydraulic valves of the sweeper attachments ............................................39
7.8.5 Oil cooler....................................................................................................40
7.9 Pneumatic system ............................................................................................40
7.9.1 Pneumatic valves .......................................................................................41
7.10 Electrical system...............................................................................................42
7.10.1 Control cabinet ...........................................................................................42
7.10.2 Fuses .........................................................................................................43
7.10.3 Battery isolator switch ................................................................................43
7.10.4 Remote start connector..............................................................................43
7.11 Water system....................................................................................................44
7.11.1 Water tank..................................................................................................44
7.11.2 Water pump................................................................................................44
7.11.3 Water filter..................................................................................................44
7.11.4 Water valves ..............................................................................................44
7.12 Cleaning systems .............................................................................................45
7.12.1 Cleaning equipment with spray hose .........................................................45
7.12.2 Spray hose with automatic roller ................................................................45
7.12.3 High-pressure cleaning system ..................................................................46
7.13 Fan ...................................................................................................................46
7.14 Debris hopper...................................................................................................47
7.14.1 Tipping the hopper .....................................................................................47
7.14.2 Drainage connections ................................................................................47
7.14.3 Leaf filter ....................................................................................................48
7.14.3.1 Spray beam above leaf filter ...................................................................49

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 5
7.14.4 Exhaust diffuser .........................................................................................49
7.14.5 Emergency tipping for the debris hopper ...................................................50
7.15 Pick-up Systems...............................................................................................50
7.15.1 Debris pick-up unit .....................................................................................51
7.15.2 Liquid pick-up unit ......................................................................................51
7.15.3 Side suction unit.........................................................................................52
7.16 Blast nozzles.....................................................................................................52
7.17 Disc brushes.....................................................................................................53
7.18 Path marking.....................................................................................................53
7.18.1 Water marking............................................................................................53
7.18.2 Foam marking ............................................................................................53
7.19 Wanderhose .....................................................................................................53
7.19.1 Closing and opening suction nozzle channel .............................................55
7.19.1.1 Closing the suction nozzle channel with plug .........................................55
7.19.1.2 Closing the suction nozzle on the rear suction unit.................................55
7.19.1.3 Closing the suction nozzle channel on the liquid pick-up unit
between the axles...................................................................................56
7.19.1.4 Opening and closing the locking plate on the suction hose ....................56
7.19.2 Cleaning system with spray hose roller......................................................58
7.19.3 High-pressure cleaning system (100 bar) ..................................................58
7.19.4 Path marking ..............................................................................................60
7.19.5 Path marking with water jet ........................................................................60
7.19.6 Path marking with foam peaks ...................................................................60
7.20 Front-mounted machines..................................................................................61
7.20.1 Aebi Schmidt vehicle plate .........................................................................61
7.20.2 Protective covering.....................................................................................62
7.21 Hydraulic systems for front-mounted machinery...............................................62
7.21.1 Hydraulic valve block .................................................................................62
7.21.2 Single hydraulic pump................................................................................62
7.21.3 Hydraulic tank ............................................................................................62
7.21.4 Hydraulic connections for controlling the snow plough...............................63
7.21.5 Front hydraulic connections .......................................................................63
7.22 Electrical connection for front-mounted machines............................................64
7.23 Airport stand cleaning system...........................................................................64
7.24 Front spray beam..............................................................................................64
7.25 Hopper floor heating.........................................................................................65
7.26 Ladder...............................................................................................................66
7.27 Mirror above the front window...........................................................................66
8Controlling the machine via the control panel.....................................................67
8.1 Start auxiliary engine ........................................................................................67
8.2 Switching off the auxiliary engine......................................................................69
8.3 Information display............................................................................................70

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 6
8.4 Menu.................................................................................................................71
8.4.1 Level 1 .......................................................................................................71
8.4.2 Level 2 .......................................................................................................71
8.5 Sweep...............................................................................................................72
8.5.1 Putting the disc brush into operation ..........................................................72
8.5.2 Putting the sweeper unit into operation ......................................................73
8.5.3 Putting the suction unit into operation ........................................................74
8.5.4 Suction and sweeping with the sweeper ....................................................75
8.5.5 Putting the side suction into operation .......................................................76
8.5.6 Putting the coarse protection flap on the suction duct into operation .........77
8.5.7 Putting the sprayer/front spray bar into operation ......................................77
8.5.8 Putting the foam path marking into operation.............................................78
8.5.9 Putting the front pick-up into operation.......................................................78
8.5.10 Adjusting the blower output........................................................................79
8.5.11 Rotary beacon............................................................................................79
8.5.12 Working lights, environmental lighting........................................................79
8.5.13 EMERGENCY STOP .................................................................................80
8.5.14 Putting the blower unit into operation .........................................................81
8.5.15 Junction skip ..............................................................................................82
8.5.16 Reversing...................................................................................................82
8.5.17 Reversing camera ......................................................................................83
8.5.18 Acoustic warning signal..............................................................................83
8.5.19 Switching on the high-pressure spray bar in front of the sweeper unit .......84
8.5.20 Controlling front-mounted machine e.g. snowplough, magnetic beam.......85
8.5.20.1 Manual operation....................................................................................85
8.5.20.2 Automatic mode......................................................................................86
8.5.20.3 Turning off the control.............................................................................86
8.5.21 Set plough relief .........................................................................................86
8.5.22 Control snowplough with foldable side blade .............................................87
8.5.23 Activate the wanderhose............................................................................88
8.5.24 Turning on dual suction..............................................................................88
8.5.25 Debris rake.................................................................................................89
8.5.26 Display warning symbols............................................................................89
8.5.27 Service menu for the driver ........................................................................89
8.6 Activating the airport stand cleaner...................................................................90
8.6.1 Putting the suction unit into operation ........................................................90
8.6.2 Switching on the detergent on the front sprayer bar...................................91
8.6.3 Switching on the detergent on the spray bar in front of
the sweeper unit.........................................................................................92
8.6.4 Switching on the high-pressure spray bar in front of the sweeper unit .......93
8.6.4.1 Activate front spray bar...........................................................................94
8.7 Hopper control..................................................................................................95
9Adjustment work ....................................................................................................96
9.1 Set the display brightness.................................................................................96
9.2 Set search lighting............................................................................................96

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 7
9.3 Setting up and measuring the sweep range of the cylindrical brush.................96
9.3.1 Setting the sweeping range........................................................................96
9.3.2 Measuring the sweep range.......................................................................96
9.3.3 Adjusting the side suction unit....................................................................97
9.4 Adjusting the liquid pick-up system...................................................................97
9.4.1 Setting the coarse debris flap.....................................................................97
9.4.2 Setting the rubber bar ................................................................................98
9.4.3 Disc brush, setting the sweeping pattern ...................................................98
9.4.4 Disc brush, setting the contact pressure ....................................................99
9.5 Axle load setting ...............................................................................................99
9.6 Suction assembly limit stop.............................................................................100
9.7 Air suspension limit stop.................................................................................100
10 Transit travel.........................................................................................................101
11 Operation ..............................................................................................................102
11.1 Daily pre-operational checks...........................................................................102
11.2 Before using the machine...............................................................................104
11.3 Use .................................................................................................................104
11.3.1 Cold weather operation ............................................................................105
11.3.2 Reversing.................................................................................................105
11.3.3 Debris suction operation with disc brush..................................................105
11.3.4 Sweeper suction operation with cylindrical brush.....................................106
11.3.5 Suction operation - liquid pick-up (without cylindrical brush)....................107
11.3.6 Wanderhose.............................................................................................108
11.3.7 Liquid pick-up unit ....................................................................................108
11.3.8 Empty hopper...........................................................................................109
11.3.8.1 Letting out dirty water / de-icing agents ................................................110
11.3.8.2 Emptying remaining dirty water / de-icing agents .................................111
11.3.8.3 Unloading debris from the hopper ........................................................112
11.3.8.4 Lower debris hopper.............................................................................113
11.3.9 Blowing operation.....................................................................................113
11.3.10 Winter operation.......................................................................................114
11.3.11 Front-mounted machines .........................................................................114
11.3.11.1 Snow plough .....................................................................................115
12 Checking and care of the vehicle after use........................................................116
13 Extent of wear.......................................................................................................118
13.1 Vehicle............................................................................................................118
13.2 Disc brushes...................................................................................................118
13.3 Debris pick-up unit..........................................................................................118
13.4 Wear plates.....................................................................................................119
13.5 Side suction unit .............................................................................................120
13.6 Liquid pick-up unit...........................................................................................120

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 8
14 Attaching and detaching machine parts ............................................................121
14.1 Attaching and detaching the suction vehicle using the quick
change system................................................................................................121
14.2 Quick-change procedure of front-mounted machines.....................................123
14.2.1 Lower front-mounted machine with pressure ...........................................123
15 Faults.....................................................................................................................124
15.1 Pneumatic system ..........................................................................................125
15.2 Hydraulic system ............................................................................................125
15.3 Water system..................................................................................................126
15.4 Electrical system.............................................................................................126
15.5 Warning and notice symbols...........................................................................127
16 Reversing ..............................................................................................................130
17 Transit travel.........................................................................................................131
17.1 Transport speed..............................................................................................131
18 After sweeping......................................................................................................132
19 Towing...................................................................................................................133
20 Maintenance work that the driver may carry out ...............................................134
20.1 Vehicle............................................................................................................134
20.2 Auxiliary engine ..............................................................................................134
20.3 General maintenance .....................................................................................134
20.3.1 Refuelling .................................................................................................134
20.3.1.1 Vehicle..................................................................................................134
20.3.1.2 Auxiliary engine ....................................................................................135
20.4 Refilling the carbamide tank............................................................................135
20.5 Filling the water tank.......................................................................................136
20.5.1 Filling the cleaning agent tank..................................................................137
20.5.2 Calling up kilometres and hours ...............................................................137
20.6 Cleaning the water filter..................................................................................139
20.7 Cleaning the machine.....................................................................................139
20.7.1 Cleaning the machine with high-pressure cleaner....................................139
20.7.2 Cleaning with the spraying hose ..............................................................140
20.8 Cleaning brushes of foreign bodies ................................................................141
20.9 Drain water system.........................................................................................141
20.9.1 Activate drain mode .................................................................................141
20.9.2 Drain water system ..................................................................................142

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 9
21 Maintenance and repair work that may only be carried out
by workshop personnel .......................................................................................143
21.1 Maintenance notes: ........................................................................................145
21.2 Lubricants.......................................................................................................146
21.3 Maintenance service.......................................................................................147
21.3.1 Hydraulic filter ..........................................................................................147
21.3.2 Hydraulic oil..............................................................................................147
21.3.3 Lubrication................................................................................................147
21.3.4 Oil refill .....................................................................................................147
21.3.5 Oil change................................................................................................147
21.3.6 At the end of the season ..........................................................................147
21.4 Lubrication and maintenance schedule ..........................................................148
21.4.1 Notes on lubrication via a central lubrication unit .....................................148
21.4.2 Snowplough .............................................................................................148
21.4.3 Magnetic beam.........................................................................................149
21.4.4 Front mounted sweeper machine.............................................................149
21.4.5 Vehicle .....................................................................................................149
21.4.6 Aebi Schmidt vehicle hydraulic system ....................................................149
21.5 Maintenance schedule....................................................................................150
21.5.1 Vehicle .....................................................................................................150
21.5.2 Debris pick-up unit ...................................................................................151
21.5.3 Layout ......................................................................................................153
21.5.4 Liquid pick-up unit ....................................................................................155
21.5.5 General maintenance...............................................................................155
22 Maintenance and repair work ..............................................................................156
22.1 Changing the cylindrical brush........................................................................156
22.2 Changing disc brushes ...................................................................................158
22.3 Grease the brush drive universal joint ............................................................158
22.4 Changing the hydraulic oil and filter................................................................159
22.4.1 Filter change ............................................................................................159
22.4.1.1 Return filter ...........................................................................................159
22.4.2 Changing the hydraulic oil........................................................................161
22.5 Replace castor wheel .....................................................................................161
22.6 Changing the rubber bars...............................................................................162
22.7 Setting the wear plates ...................................................................................162
22.8 Changing hydraulic hoses...............................................................................163
22.9 Vehicle hydraulics Changing the hydraulic oil and filter.................................163
22.9.1 Filter change ............................................................................................164
22.9.2 Changing hydraulic fluid...........................................................................165

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 10
22.10 Electrohydraulics Changing the oil and cleaning the oil strainer....................166
22.10.1 Removing the oil ......................................................................................166
22.10.2 Draining oil ...............................................................................................166
22.10.3 Fill the hydraulic equipment with oil..........................................................166
22.10.4 Clean the oil strainer ................................................................................167
22.11 Pump drive......................................................................................................167
22.11.1 Pump drive via belts.................................................................................167
22.12 Welding work..................................................................................................168
23 Circuit diagrams ...................................................................................................169
24 Special tools and their use ..................................................................................170
24.1 Vehicle............................................................................................................170
24.2 Auxiliary engine ..............................................................................................170
24.3 AS 990............................................................................................................170
25 Shutdown ..............................................................................................................171
25.1 Vehicle............................................................................................................171
25.2 Auxiliary engine ..............................................................................................171
25.3 Snow plough...................................................................................................171
25.4 Sweep and pick-up unit ..................................................................................171
26 Index ......................................................................................................................172

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 11
Abbreviations
Co. company
etc. and so on
etc. et cetera, and so on
e.g. for example
and/or or respectively
approx. approximately
if required if required
possible/any possible/any
cpl. complete
min. minimum
max. maximum
perm. permissible
DIN German Industry Standards
StVZO German Road Traffic Act
UVV Accident Prevention Regulations
No. Number
PA polyamide
rpm revolutions per minute
min. minute
s second
km/h Kilometres per hour
km kilometre
cm centimetre
mm millimetre
V volt
Nm Newton metre
MA torque for screw connections
l litre
ml millilitre
t ton
kg kilogram
g gram
90° angle annotation
°C degrees Celsius
dB Decibel
m/s² acceleration
References
During the machine wash,
proceed as for Machine
Cleaning.
Texts written in italics refer to a corresponding chapter
in the operating instructions

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 12
Corrections and amendments to technical documents
If you wish to suggest changes to this manual, or
if you notice an error or would like to suggest other
improvements, please copy the page, mark the error
or text for improvement and attach a brief comment.
All recommendations will be examined and,
if accepted, will be included in the next version
of this publication.
Please send your suggestions to the service
representative for your area or directly to the
manufacturer.
1 The operating instructions
Before operating the AS 990 (called "AS 990" or
"machine" in the following) for the first time, please
read this manual thoroughly and familiarise yourself
with the features of the machine in advance.
Make sure that you read thoroughly and understand
the contents of this manual, particularly the safety
instructions. Only then can you be confident that you
are operating the machine safely and economically.
Anyone working with the machine must fully
understand the machine’s functions and must
be able to safely operate AS 990.
If there are references to other documents in this
operating manual, this documentation is also binding.
(e.g. for engines, vehicles, etc.).
Should you require further information, e.g. hydraulic
or electrical circuit diagrams, your nearest
Aebi Schmidt service workshop will be pleased to
help.
These operating instructions contain all the important
instructions for using and carrying out maintenance
on your machine. To ensure this is the case, the
operating instructions should always be available
with the machine.
To prolong superior performance, we recommend
that you observe the required maintenance intervals
and use only original Aebi Schmidt spare parts.
In this way, the machine can complete its tasks
to your satisfaction and offer a long service life.
During the warranty period, the required work must
be performed by Aebi Schmidt Customer Service,
which has the necessary factory information, expert
knowledge, and tools.

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 13
Have the maintenance work performed only be
qualified workshops, especially on safety-related
systems.
Observe all safety and hazard instructions observed
and retain in full and in a legible condition.
Before carrying out any maintenance work, apply
the parking brake, turn the ignition OFF and switch
off the battery isolator switch.
The directions "right" and "left" in this manual refer
to the direction of travel or from the driver's line of
vision, facing forwards.
The control panel can be adapted to your specific
requirements. In this case, certain functions that are
described in these operating instructions may not
be activated on your control panel. Changes to set
parameters may only be performed by Aebi Schmidt
customer service.
Any alterations, additions or modifications that may
affect the vehicle's safety must first be approved by
Aebi Schmidt. This also applies to settings for safety
devices and welding of load-bearing parts or to
modifications to the hydraulic or electronic systems.
Should you have any questions or problems with the
machine, our service department will be pleased to
assist you.
The operating instructions belong with the machine
and should remain with it should it be transferred to
a third party.
The operating instructions must not be reprinted,
translated or copied without written permission.

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 14
2 Declaration of Conformity

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 15
3 Explanation of symbols and
safety notices
3.1 Explanation of symbols
The following symbols are used to indicate
information that will make work easier, extend the
service life of the machine, preserve the environment
and prevent accidents.
DANGER
This symbol denotes information that could lead to
serious personal injury or possibly death if it is not
adhered to.
WARNING This symbol denotes information that could lead
to personal injury if it is not adhered to.
NOTE This symbol denotes information that helps
to prevent damage to the machine.
TIP
Information that contributes to a general
improvement of work or machine output is marked
with this symbol.
ENVIRONMENT This symbol denotes information that contributes
to preserving the environment.
3.2 Safety regulations
The safety notices are present where there is direct
danger. General safety notices are described
hereafter and must be adhered to.
DANGER
The operating safety of the machine must be
checked regularly, at least once a year. You
can commission Aebi Schmidt works customer
service to carry out an occupational safety check
based on current accident prevention guidelines,
if required.
DANGER
All safety and hazard instructions for the
machine must be observed and retained in
full and in a legible condition.

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 16
DANGER
In addition to the operating instructions,
generally applicable statutory and other
regulations regarding accident prevention and
environmental protection must be observed and
followed.
DANGER
Check the warning equipment for winter service
vehicles for completeness and proper function
according to local road traffic regulations
(StVZO (Road Traffic Act) in Germany).
DANGER
No changes, attachments, or conversions may
be made without the permission of Aebi Schmidt.
This particularly applies to safety device settings
and welded areas of support components.
DANGER
The front and rear fields of vision are limited.
Ensure that no one is standing in the danger area
when driving away. A person could be run over
and be severely injured or killed. If necessary,
use a spotter.
DANGER
Park the machine safely:
Lower hopper
Close hopper door
Raise the front-mounted unit, sweeper unit,
and disc brush into the transport position
and secure them from unintentional lowering
using a transport safety cable.
Turn off the vehicle engine and auxiliary
engine
Remove the ignition key of the vehicle and
auxiliary engine
Switch off the control panel
Close the driver's cab doors
Place wheel chocks under both wheels of
one axle so that the machine cannot roll away.
DANGER
When lowering and raising or pivoting and
switching on the disc brush and debris pick-up
system, feet, for example, can get stuck or
caught in the rotating components. Start up
the machine only when you or the spotter can
directly see the danger zone.

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 17
DANGER
Inspection, maintenance, and repair work is only
to be performed by suitably trained personnel.
After completing maintenance and repair work,
all protective equipment is to be put back in
place properly. Work on the machine may be
performed only when the vehicle is safely shut
down.
DANGER
Low quality replacement parts could cause
accidents. Use only original parts or replacement
parts of the same quality.
DANGER
Oil can get onto area where the public walk
or drive and cause accidents. The hydraulic
equipment, (hoses and pipelines, hydraulic
pump, hydraulic block, hydraulic tank, hydraulic
connections etc.) must be checked daily for
damage (chafe marks, cracks, leakages, screw
connections that have come loose etc.) and to
ensure that it is fastened tight before use and
repaired if necessary. Replace defective parts.
Hoses are to be replaced at least every 6 years.
Note the manufacturer's date (month/year) on
the hose fixtures.
DANGER
Care must be taken to ensure that no persons
are located in the danger zone when starting and
using the machine. Work on the AS 990 may only
be carried out if the machine has been shut down
safely.
WARNING
Injury due to excessive physical strain
Corresponding maintenance and repair work,
etc. must always be carried out with suitable
lifting equipment or personal support.
WARNING
Hot oil (over 50°C) or oil that comes out under
high pressure can burn or penetrate the skin.
This can cause serious injuries. Let hydraulic
fluid cool down before carrying out repair work,
free the hydraulic hose to be opened of pressure
and wear protective clothing.
WARNING
Plastics may contain hazardous materials
(such as adhesives, solvents or hardeners).
Prolonged skin contact with plastics may lead
to skin irritations.
Gloves must be worn for prolonged contact
with rubber or plastic parts, such as connecting
the hydraulic couplings, changing the plastic
brushes, etc.

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 18
4 Description
4.1 General information
The Aebi Schmidt automatic vacuum sweeper,
Model AS 990 is a machine mounted on an HGV
chassis. The HGV can be fitted with a single-circuit
hydraulic system to control the front-mounted
machines. The pick-up unit consists of vacuum unit
with two suction nozzles steered by guide rollers.
The sweeper liquid is picked up pneumatically, i.e.
a vacuum is created within the hopper by a high-
powered blower. This produces airflow within the
pick-up unit, which sucks up the dirt/liquid from the
sweeping surface and deposits it in the hopper.
Outgoing air is either routed upwards and out of
the unit or is blown out through the blast nozzles.
The machine can be fitted with the following
additional (optional) equipment:
Liquid pick-up system
Blowing equipment (Blowing direction right or left)
Raise/lower blowing direction
Channel brushes (right/left disc brushes)
Spray beam above leaf filter
Exhaust diffuser
Path marking with foam peaks
High-pressure spray equipment
Water tank heater
Aircraft stand cleaning system
Side suction unit
Front spray beam
Set/adjust speed of cylindrical brushes
4.2 Operating personnel
4.2.1Sweep mode
Prerequisites for the machine driver:
Valid driving licence to drive the vehicle.
Training and instruction for the machine.
Training and instruction for the sweeper unit
and pick-up unit.
Training and instruction for the auxiliary engine.
Training and instruction for the front-mounted
machines, for example, the magnetic beam.
Driver training with the machine.

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 19
Operating personnel who have been trained and
instructed in how to use the machine may initially
only use it under the supervision of experienced
persons. Once training and instruction in the entire
machine has been completed, this should be
confirmed in writing.
DANGER
Reduction in the perception of dangers when
operating the machine
►After a long period of use (e.g., winter), carry
out subsequent training to guarantee safety
4.3 Personal protection equipment
Hearing protection
When the device is running and the motor cabin is
open, hearing protection must be worn when close
to the clearing vehicle. Hearing protection must be
worn at levels above 85dB(A).
Gloves
Prolonged skin contact with plastics may lead to
skin irritations. Plastics may contain hazardous
materials (such as adhesives, solvents or
hardeners).
Protect hands from the cold. Skin can freeze
onto cold objects.
Sharp objects (such as cutting edge change,
brush change) can injure hands.
Sharp edges may arise due to wear or damage
to components. These can injure hands.
Fluids (such as oils, coolant, battery acid etc.)
can injure hands.
Safety shoes
Reduce foot injuries and improve grip

Translation of Original Operating Instructions
Airport Sweeper / Airport Stand Cleaner
2017-02-02 20
Reflective clothing, weather protection and protective
clothing
Reflective clothing improves visibility when
outside the machine.
Weather protective clothing should protect
against dangers to health when working in the
open air.
Protective clothing improves protection against
damaging influences such as maintenance work,
cleaning the machine, etc.
Facial protection
Facial protection protects the eyes in particular, e.g.,
from flying dirt particles when cleaning the machine
with a high-pressure washer.
4.4 Lashing and mounting points
4.4.1 Lashing points
Loading personnel must adhere to the regulations on
loading and handling and be experienced in properly
securing loads. The load surface must be free of dirt
(non-slip). The machine is to be parked securely on
the load surface. The machine is to be fastened and
lashed down in such a way that it cannot move on
the loading surface during braking, acceleration, and
when driving through curves. Particular care should
be taken to ensure that the machine is well secured
in the direction of travel (for braking manoeuvres).
Make sure that lashing materials used to secure
the machine do not cause damage to it. The stability
should be re-tested after it has been secured.
A subsequent check of the load, and rectification
if necessary (for example retensioning the lashing
material) is to be made after approximately 10 km
of transit.
4.4.2 Lashing points on the AS 990
The lashing points on the vehicle are to be used
to lash the machine. These points are described in
the operating manual or can be requested from
the manufacturer.
