Schrack Technik S1 User manual

Schrack Technik GmbH, Seybelgasse 13, A-1230 Vienna, www.schrack.com Vers. 2016 04
Installation
InstallationInstallation
Installation and operating
and operatingand operating
and operating instruction
instructioninstruction
instruction
Self
Self Self
Self c
cc
contained
ontained ontained
ontained rescue sign e
rescue sign erescue sign e
rescue sign emergency luminaires
mergency luminaires mergency luminaires
mergency luminaires design S1
design S1design S1
design S1
Technical data
Technical dataTechnical data
Technical data
Viewing distance: 27m
Mains Voltage: 230V 50Hz
Connected Load: 6W
Autonomy time: 3h
Permitted temp. range: -5° C to +35° C
Illuminant: LED
Insulation class: I
Protection category: IP 40
Mounting: Wall (NLS1W003SC), ceiling (NLS1D003SC)
Optional for NLS1D003SC: wall bracket, pendulum, ceiling recessed
Self contained emergency luminaire according to EN 60598-1, EN 60598-2-22, ISO 7010 and EN 1838 with
single or double sided labeling. Suitable for maintained and non-maintained operation. Pictogram set (left, right, up
down and white) included.
Security advice
Security adviceSecurity advice
Security advice:
::
:
Attention:
Attention:Attention:
Attention: Works on the 230V mains may only be done from qualified personnel considering the local installation
requirements. Before installation the supply voltage must be switched off.
Remark
RemarkRemark
Remark:
::
: In order to attain the full functionality of a self contained emergency
luminaire the battery has to be charged for min. 24 hours.
Caution
CautionCaution
Caution:
::
: Claims for warranty cannot be lodged in the event of damage caused by non-observance of this
instruction. No liability for follow-on damages resulting from this can be accepted. The installation
instruction must be read thoroughly before commissioning the product.
Dimensional sketch:
Dimensional sketch:Dimensional sketch:
Dimensional sketch: Preparation:
NLS1W003SC NLS1D003SC
Important
ImportantImportant
Important:
::
: Make sure the battery is replaced as stated in regulations otherwise the function of the
lamp is not guaranteed. When replacing the battery don’t throw old battery into
domestic waste! Do not use abrasive cleaners or cleaners that contain solvent.
Function of the test button
Function of the test buttonFunction of the test button
Function of the test button Meaning of LED indication
Meaning of LED indicationMeaning of LED indication
Meaning of LED indication
Test button
Test buttonTest button
Test button
Green LED
State
Press
1 Sek.
Off
Emergency
operation
1Sek.
Press 3 Sek.
Blinking
Short
test
30 Sek
Press 5 Sek.
Flashing
Full autonomy
test 3h/8h
According to setting of SW2
Press 5 Sek. again
Off
Full autonomy test stopped
Press 15 Sek.
System Reset
Fault messages are reset after rectifying the fault and performing a new short test.
Remove protection foils on both sides

Schrack Technik GmbH, Seybelgasse 13, A-1230 Vienna, www.schrack.com Vers. 2016 04
Mounting and Commissioning
Mounting and CommissioningMounting and Commissioning
Mounting and Commissioning
Opening/closing of the luminaire
Electrical connection
Selection of operating mode
M = Maintained
NM = Non Maintained
Wall mounting
214
Ceiling mounting
183
Wall bracket mounting
2
3
4
1
Pendulum mounting
2
3
4
1
214
Ceiling recessed mounting
344
48
Self testing system
Self testing systemSelf testing system
Self testing system
The first short test takes place within 7 days after commissioning at a random time. Thereafter all 7 days a
short test will take place.
The first full autonomy test takes place randomly within 52 weeks after commissioning. Thereafter all 52
weeks a full autonomy test will take place.
In case of mains failure during a full autonomy test, the luminaire will go into emergency battery mode.
If the battery is not fully recharged after a mains failure, a pending full autonomy test will be shifted until the
battery is completely recharged after mains return.
