Schumacher Electric INSTANT POWER XP400 User manual

00-99-001047/0710
Model / Modelo: XP400, XP500, XP750C
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.• FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY OR DEATH.
LEA EL MANUAL COMPLETO ANTES DE UTILIZAR ESTE PRODUCTO.• CUALQUIER FALLA PODRÍA RESULTAR EN SERIAS LESIONES O PODRÍA SER
MORTAL.
OWNER’S MANUAL • MANUAL DEL USUARIO
INSTANT POWER™Jump Starter and DC Power Source /
Fuente de Poder de CD y Arrancador
ADVERTENCIA
XP400 XP500
XP750C

DO NOT RETURN THIS PRODUCT
TO THE STORE!
Call Customer Service for Assistance:
800-621-5485
¡NO LO DEVUELVA ESTE PRODUCTO
A LA TIENDA!
Llame a Servicios al Cliente para Asistencia:
800-621-5485

TABLE OF CONTENTS
SECTION PAGE
IMPORTANT SAFETY INSTRUCTIONS 2
PERSONAL PRECAUTIONS 3
FOLLOW THESE STEPS WHEN CONNECTING TO A BATTERY 4
GROUNDING AND AC POWER CORD CONNECTIONS 4
ASSEMBLY INSTRUCTIONS 4
FEATURES 5
CHARGING THE INTERNAL BATTERY OF THE INSTANT POWER™ 6
OPERATING INSTRUCTIONS 7
MAINTENANCE INSTRUCTIONS 9
MOVING AND STORAGE INSTRUCTIONS 10
TROUBLESHOOTING 10
SPECIFICATIONS 11
REPLACEMENT PARTS/ACCESSORIES 12
LIMITED WARRANTY 12
ÍNDICE
SECCIÓN PÀGINA
INSTRUCCIONES IMPORTANTES DE SEGURIDAD 18
PRECAUCIONES PERSONALES 19
SIGA ESTOS PASOS CUANDO SE CONECTE A LA BATERÍA 20
CONEXIONES A TIERRA Y ENERGÍA DE CA 21
INSTRUCCIONES DE MONTAJE 21
CARACTERÍSTICAS 21
PARA CARGAR LA BATERIA INTERNA DE LA FUENTE
DEL INSTANT POWER™ 22
INSTRUCCIONES DE OPERACIÓN 23
INSTRUCCIONES DE MANTENIMIENTO 26
INSTRUCCIONES PARA EL MANEJO Y ALMACENAMIENTO 26
LOCALIZACIÓN Y SOLUCIÓN DE PROBLEMAS 27
ESPECIFICACIONES 28
REPUESTOS/ACCESORIOS 29
GARANTÍA LIMITADA 29

CONTAINS SEALED NON-SPILLABLE LEAD-ACID
BATTERY. MUST BE DISPOSED OF PROPERLY.
CONTIENE UNA BATERÍA SELLADA DE ÁCIDO-
PLOMO NO DERRAMABLE QUE DEBE DESECHARSE
APROPIADAMENTE.
WARNING: Possible explosion hazard. Contact with battery acid
may cause severe burns and blindness. Keep out of reach of
children.
ADVERTENCIA: Posible Riesgo de una explosión. El contacto
con una batería de ácido puede causar quemaduras y ceguera.
Manténgase alejado de los niños.

•1 •
IMPORTANT: READ AND SAVE THIS SAFETY AND INSTRUCTION MANUAL.
SAVE THESE INSTRUCTIONS – Charge the Instant Power™ internal battery
immediately after purchase, after every use and every 30 days. This manual
will show you how to use your Instant Power™ safely and effectively. Please
read, understand and follow these instructions and precautions carefully, as
this manual contains important safety and operating instructions. The safety
messages used throughout this manual contain a signal word, a message and
an icon.
The signal word indicates the level of the hazard in a situation.
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury to the operator or bystanders.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury to the operator or bystanders.
Indicates a potentially hazardous situation which, if not avoided,
could result in moderate or minor injury to the operator or
bystanders.
Indicates a potentially hazardous situation which, if not avoided,
could result in damage to the equipment or vehicle or property
damage.
Safety messages in this manual contain two different type styles.
Unnumbered type states the hazard.•
Numbered type states how to avoid the hazard.•
The icon gives a graphical description of the potential hazard.
Pursuant to California Proposition 65, this product contains chemicals
known to the State of California to cause cancer and birth defects or
other reproductive harm.

•2 •
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS -1. This manual contains important safety and operating instructions
RISK OF ELECTRIC SHOCK OR FIRE.
Read the entire manual before using this product. Failure to do so could result1.1 in serious injury or death.
Keep out of reach of children.1.2
Use only recommended attachments. Use of an attachment not recommended1.3
orsoldbySchumacher®ElectricCorporationmayresultinariskofre,
electric shock or injury to persons or damage to property.
Donotputngersorhandsintoanyofthe1.4 Instant Power’s™ outlets.
Do not expose the1.5 Instant Power™ to rain or snow.
Use of an improper extension cord to charge the Instant Power™ could result1.6
inariskofreandelectricshock.Makesure:
That the pins on the plug of the extension cord are the same number, size•and shape as those of the plug on the Instant Power™.
That the extension cord is properly wired and in good electrical condition.•
That the extension cord has a wire size of 18 gauge (AWG) or larger and is•50 feet long or less.
To reduce the risk of electric shock, turn off and/or unplug the Instant Power™1.7 before attempting any maintenance or cleaning. Simply turning off the controls
will not reduce this risk.
Do not operate the1.8 Instant Power™ if it has received a sharp blow, been
droppedorotherwisedamagedinanyway;takeittoaqualiedservice
person. (Call customer service at: 1-800-621-5485.)
Do not disassemble the1.9 Instant Power™;takeittoaqualiedserviceperson
when service or repair is required. Incorrect reassembly may result in a risk of
reorelectricshock.(Callcustomerserviceat:1-800-621-5485.)
RISK OF EXPLOSIVE GASES.
WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS.1.10 BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL BATTERY
OPERATION. FOR THIS REASON, IT IS OF UTMOST IMPORTANCE THAT
YOU FOLLOW THE INSTRUCTIONS EACH TIME YOU USE THE INSTANT
POWER™.
To reduce the risk of a battery explosion, follow these instructions and those1.11 published by the battery manufacturer and the manufacturer of any equipment
you intend to use in the vicinity of the battery. Review the cautionary markings
on these products and on the engine.

•3 •
PERSONAL PRECAUTIONS2.
RISK OF EXPLOSIVE GASES. A
SPARK NEAR THE BATTERY MAY
CAUSE A BATTERY EXPLOSION.
TO REDUCE THE RISK OF A
SPARK NEAR THE BATTERY:
Working in the vicinity of a lead-acid battery is dangerous. Batteries generate2.1 explosive gases during normal battery operation. For this reason, it is of
utmost importance that you follow the instructions each time you use the
Instant Power™.
NEVERsmokeorallowasparkorameinthevicinityofabatteryorengine.2.2
Do not permit the internal battery of the Instant Power™ to freeze. Never2.3 charge a frozen battery.
To prevent sparking, NEVER allow clips to touch together or contact the same2.4
piece of metal.
When charging the internal battery of the Instant Power™, work in a well2.5 ventilated area and do not restrict the ventilation in any way.
Be extra cautious to reduce the risk of dropping a metal tool onto a battery. It2.6 might spark or short-circuit the battery or other electrical part that may cause
an explosion.
Remove personal metal items such as rings, bracelets, necklaces and watches2.7 when working with a lead-acid battery. A lead-acid battery can produce a short-
circuit current high enough to weld a ring or the like to metal, causing a severe
burn.
Be sure the area around the battery is well ventilated while the jump starter is2.8 being used.
RISK OF CONTACT WITH BATTERY ACID.
BATTERY ACID IS A HIGHLY CORROSIVE
SULFURIC ACID.
Consider having someone close enough by to come to your aid when you work2.9 near a lead-acid battery.
Have plenty of fresh water and soap nearby in case battery acid contacts your2.10 skin, clothing or eyes.
Wear complete eye and body protection, including safety goggles and2.11 protective clothing. Avoid touching your eyes while working near the battery.
If battery acid contacts your skin or clothing, immediately wash the area with2.12
soapandwater.Ifacidentersyoureye,immediatelyoodtheeyewithcold
running water for at least 10 minutes and get medical attention right away.
If battery acid is accidentally swallowed, drink milk, the whites of eggs or water.2.13 DO NOT induce vomiting. Seek medical attention immediately.
Stay clear of fan blades, belts, pulleys and other parts that may cause injury.2.14
Clean the battery terminals before using the jump starter. During cleaning,2.15 keep airborne corrosion from coming into contact with your eyes, nose and
mouth. Use baking soda and water to neutralize the battery acid and help
eliminate airborne corrosion. Do not touch your eyes, nose or mouth.
Determine the voltage of the battery by referring to the vehicle owner’s manual2.16 and make sure that the output voltage of the jump starter is correct.
Make sure that the Instant Power™ cable clips make tight connections.2.17

•4 •
FOLLOW THESE STEPS WHEN CONNECTING TO A BATTERY3.
A SPARK NEAR THE BATTERY
MAY CAUSE A BATTERY
EXPLOSION. TO REDUCE THE
RISK OF A SPARK NEAR THE
BATTERY:
Attach the output cables to the battery and chassis as indicated below. Never3.1 allow the output clips to touch each other.
Position the DC cables to reduce the risk of damage by the hood, door and3.2 moving or hot engine parts. NOTE: If it is necessary to close the hood during
the jumping process, ensure that the hood does not touch the metal part of the
battery clips or cut the insulation of the cables.
Stay clear of fan blades, belts, pulleys and other parts that can cause injury.3.3
Check the polarity of the battery posts. The POSITIVE (POS, P, +) battery post3.4 usually has a larger diameter then the NEGATIVE (NEG, N, -) post.
Determine which post of the battery is grounded (connected) to the chassis.3.5 If the negative post is grounded to the chassis (as in most vehicles), see step
3.6. If the positive post is grounded to the chassis, see step 3.7.
For a negative-grounded vehicle, connect the POSITIVE (RED) clip from the3.6 Instant Power™ to the POSITIVE (POS, P, +) ungrounded post of the battery.
Connect the NEGATIVE (BLACK) clip to the vehicle chassis or engine block
away from the battery. Do not connect the clip to the carburetor, fuel lines or
sheet-metal body parts. Connect to a heavy gauge metal part of the frame or
engine block.
For a positive-grounded vehicle, connect the NEGATIVE (BLACK) clip from the3.7 Instant Power™ to the NEGATIVE (NEG, N, -) ungrounded post of the battery.
Connect the POSITIVE (RED) clip to the vehicle chassis or engine block away
from the battery. Do not connect the clip to the carburetor, fuel lines or sheet-
metal body parts. Connect to a heavy gauge metal part of the frame or engine
block.
When disconnecting the Instant Power™, turn all switches to off (if applicable),3.8 remove the clip from the vehicle chassis and then remove the clip from the
battery terminal.
GROUNDING AND AC POWER CORD CONNECTIONS4.
RISK OF ELECTRIC SHOCK OR FIRE.
The Instant Power™ internal charger plug is for use on a nominal 120-volt4.1 circuit. The extension cord utilized with the internal charger plug must be
plugged into an outlet that is properly installed and grounded in accordance
withalllocalcodesandordinances.Theplugpinsmusttthereceptacle
(outlet). Do not use with an ungrounded system.
ASSEMBLY INSTRUCTIONS5.
Remove all cord wraps and uncoil the cables prior to using the Instant
Power™.

•5 •
FEATURES6.
XP400
Battery Status Indicators1.
Battery Status Switch2.
Built-In Worklight3.
Worklight ON/OFF Switch4.
12V DC Power Outlet5.
Internal Battery Charger Plug6. (not shown)
Battery Clips7.
1
2
34
5
7
XP500
Battery Status Indicators1.
Battery Status Switch2.
Built-In Worklight3.
Worklight ON/OFF Switch4.
12V DC Power Outlet5.
Internal Battery Charger Plug6. (not shown)
Battery Clips/USB ON/OFF Switch7.
USB Port8.
Battery Clips9.
1
7
28
34
5
9
XP750C
Battery Status Indicators1.
Battery Status Switch2.
12V DC Power Outlet3.
Internal Battery Charger Plug4. (not shown)
Battery Clips/USB ON/OFF Switch5.
USB Port6.
Built-In Worklight7.
Worklight ON/OFF Switch8.
Air Compressor ON/OFF Switch9. (not shown)
Air Compressor Gauge (not shown)10.
Air Compressor Hose11.
Air Compressor Hose Wrap Cleats12.
(not shown)
Air Compressor Adapters and13.
Storage Bag (not shown)
Battery Clips14.
1
5
2
6
78
3
14 11

•6 •
CHARGING THE INTERNAL BATTERY OF THE INSTANT POWER™7.
IMPORTANT: CHARGE IMMEDIATELY AFTER PURCHASE, AFTER EACH
USE AND EVERY 30 DAYS TO KEEP THE INSTANT POWER™ INTERNAL
BATTERY FULLY CHARGED.
LED Indicators:7.1
TO CHECK THE INTERNAL BATTERY’S CHARGE STATUS, PRESS THE
BATTERY STATUS BUTTON ON THE FRONT OF THE INSTANT POWER™.
The LED lights will indicate the charge level as follows:
A red LED indicates a 50% or less charge and you should immediately•recharge the Instant Power™.
A yellow LED indicates a 50 to 75% charge. The Instant Power™ may be•used but should be recharged as soon as possible.
A green LED indicates the internal battery is fully charged.•
Charging the Internal Battery using the Built-In Charger:7.2
Tocharge,ipthechargerplugonthebackoftheInstantPower™upand1. plug an 18 gauge (AWG) or larger extension cord onto it. (Extension cord
not included; must be purchased separately.)
Plug the extension cord into a 120V AC electrical wall outlet.2.
The RED LED will glow indicating charging.3.
The GREEN LED will light when the battery has reached full charge. This4. could take up to 72 hours due to the age and condition of the battery. The
charger will automatically go into maintain mode and maintain the battery at
full charge without damaging it.
Charge the Instant Power™ as soon as possible after use.5.
Do not use the Instant Power™ while charging the internal
battery.
You may also charge the internal battery while driving, using the male-to-male
charger cable (p/n 94500109 – not included). Insert one end of the accessory
cable into the 12V DC power outlet and the other end into the vehicle’s
accessory outlet (lighter socket). Completely disconnect the charger cable
when the engine is not running.
The RED LED and the GREEN LED do not operate during
this method of charging. Using this method to charge the battery overrides the
maintain mode and the battery can be overcharged. Monitor the progress of
the battery and when it reaches a full (100%) charge, disconnect the charger.
Do not leave the battery unattended or it could explode causing property
damage or personal injury.

•7 •
OPERATING INSTRUCTIONS8.
Jump Starting a Vehicle Engine8.1
Do not use the Instant Power™ while charging the internal
battery.
Turn the vehicle’s ignition OFF before making cable connections.1.
Connect the Instant Power™ to the battery following the precautions listed2. in section 3.
Risk of Explosion.
If you have connected the clips backwards on Model XP750C, an
audio alarm will sound. DO NOT turn the ON/OFF switch to the ON
(clockwise) position. This could cause serious damage to the Instant
Power™ or the vehicle. Reverse the connections and the audio alarm
will stop. NOTE: Models XP400 and XP500 do not have an audio
alarm.
Crank the engine. If the engine does not start within 5-8 seconds, stop3. cranking and wait at least 1 minute before attempting to start the vehicle
again. (This permits the battery to cool down.)
After the engine starts, turn the On/Off switch to the OFF4. (counterclockwise) position (models XP500 and XP750C), disconnect the
black clip (-) and then the red clip (+) in that order.
Recharge the Instant Power™ as soon as possible after use.5.
Risk of Explosion.
To prevent sparking, NEVER allow the clips to touch together or to
contact the same piece of metal. Never attempt to jump start a frozen
battery.
Powering a 12V DC Device:8.2
The Instant Power™ is a power source for all 12V DC accessories that are
equippedwitha12Vaccessoryplug.Useitforpoweroutagesandshingor
camping trips. Estimated usage time is listed in the chart below.
Make sure the device to be powered is OFF before inserting the 12V DC
accessory plug into the 12V DC accessory outlet.
Ensure the battery clips are securely clipped on the storage holders.1.
Open the protective cover of the DC power outlet on the front of the Instant2. Power™.
Plug the 12V DC device into the DC power outlet, and turn the 12V DC3. device on (if required).
If the 12V DC device draws more than 15A or has a short circuit, the4. internal circuit breaker of the Instant Power™ will trip and disconnect the
power to the device. Disconnect the 12V DC device. The breaker will
automatically reset after an overload occurs.
The DC power outlet is wired directly to the internal battery. Extended
operation of a 12V DC device may result in excessive battery drain. Recharge
immediately after unplugging the 12V DC device.

•8 •
Appliance Type Estimated
Wattage
Estimated
Usage Time
XP400
Estimated
Usage Time
XP500
Estimated
Usage Time
XP750C
Cell Phone 4 watts 15 hours 21 hours 36 hours
Fluorescent Light 4 watts 15 hours 21 hours 36 hours
Radios, Fan 9 watts 6.7 hours 9.3 hours 16 hours
Depth Finder 9 watts 6.7 hours 9.3 hours 16 hours
Camcorder, VCR 15 watts 4 hours 5.6 hours 9.6 hours
Electrical Tool 24 watts 2.5 hours 3.5 hours 6 hours
Electrical Cooler 48 watts 1.3 hours 1.8 hours 3 hours
Car Vacuum, Air
Compressor 80 watts 0.8 hours 1.1 hours 1.8 hours
NOTE: Estimated run-times. Actual time may vary. Times are based on the
internal battery being fully charged
Using the USB Port (Models XP500 and XP750C)8.3
The USB port provides up to 500mA at 5V DC.
Ensure the battery clips are securely clipped on the storage holders.1.
Turn the Instant Power™ On/Off switch to the ON (clockwise) position.2.
Plug the device into the USB port on the front panel.3.
Turn the USB device on.4.
ReversethesestepswhennishedusingtheUSBport.5.
Charge the Instant Power™ as soon as possible after using the USB port.6.
Using the Built-In Light8.4
PositiontheInstantPower™onaat,stablesurfaceneartheintended1. work area.
Ensure the battery clips are securely clipped on the storage holders.2.
Toggle the Work Light switch to the ON position.3.
The Instant Power™ light will turn on and illuminate your work area.4.
Toggle the Work Light switch to the OFF position when the work is5. completed.
Charge the Instant Power™ as soon as possible after using the built-in6. light.
NOTE: With a fully charged internal battery, the built-in light on the XP400
should provide approximately 50 hours of continuous, useful light, the built-in
light on the XP500 should provide approximately 70 hours of continuous,
useful light and the built-in light on the XP750C should provide approximately
120 hours of continuous, useful light.

•9 •
Using the Air Compressor (Model XP750C)8.5
Risk of explosion.
Readtheinstructionsoftheproductbeinginatedbeforeusingthe
compressor.Avoidoverination,donotexceedthemanufacturer’s
recommended pressures. Do not leave the air compressor
unattended during use.
NOTE:Beforeyouusethecompressorforthersttime,youmustinstall
the compressor hose wrap cleats. To install: Press each cleat into its
corresponding mounting holes on the back of the jump starter until it clicks
into place. Wrap the compressor hose around these cleats when it is not being
used.
Ensure the battery clips are securely on the storage holders.1.
Remove the air compressor hose from the storage cleats on the back of the2. Instant Power™. Install adapters as necessary.
Attachtheaircompressorhosetotheproductoraccessorytobeinated3.
byippingdownthelever.
ToggletheCompressorSwitchuptotheONpositionandinatethe4. product.
Whentheproductisinatedtotheproperairpressure(usingtheair5. compressor gauge) toggle the Compressor Switch down to the OFF
position and remove the hose.
Do not run for more than 10 minutes maximum at a time. Allow the Instant6. Power™ to cool down for 10 minutes before using again.
NOTE: To prevent overheating, the compressor has built-in thermal protection
that will turn the compressor off before it overheats. If the compressor shuts
off, wait a few minutes and it will automatically restart when the compressor
cools.
NOTE: The air compressor is rated for 150 PSI.
EstimatedTimeforInating
Vehicle Tires 13” to 16” 6 to 24 minutes
Bike Tire 1 to 3 minutes
Sports Balls 30 seconds
These times are approximate, use the air compressor gauge to ensure the
properpressurehasbeenreached.Donotoverinate.
MAINTENANCE INSTRUCTIONS9.
After use and before performing maintenance, unplug and disconnect the9.1 Instant Power™ (see sections 3 and 4).
Use a dry cloth to wipe all battery corrosion and other dirt or oil from the9.2 battery clips, cords, and the Instant Power™ case.
Ensure that all of the Instant Power™ components are in place and in good9.3 working condition, for example, the plastic boots on the battery clips.
Servicing does not require opening the unit, as there are no user-serviceable9.4 parts.
Allotherservicingshouldbeperformedbyqualiedservicepersonal.9.5

•10 •
MOVING AND STORAGE INSTRUCTIONS10.
Store the Instant Power™ in an upright position.10.1
Store inside, in a cool, dry place.10.2
Do not store the clips on the handle, clipped together, on or around metal,10.3 or clipped to cables. The clips on the Instant Power™ are live and will
produce arcing or sparking if they come in contact with each other. To prevent
accidental arcing, always keep the clips on the storage holders when not using
it to jump start a vehicle.
If the Instant Power™ is moved around the shop or transported to another10.4 location, take care to avoid/prevent damage to the cords, clips and Instant
Power™. Failure to do so could result in personal injury or property damage.
Do not use and/or store the Instant Power™ in or on any
area or surface where damage could occur if the internal battery should
unexpectedly leak acid.
IMPORTANT:10.5
CHARGE IMMEDIATELY AFTER PURCHASE•
KEEP FULLY CHARGED•
Charge the Instant Power™ internal battery immediately after purchase, after
every use and every 30 days.
All batteries are affected by temperature. The ideal storage temperature is
at 70 degrees Fahrenheit. The internal battery will gradually self-discharge
(lose power) over time, especially in warm environments. Leaving the battery
in a discharged state may result in permanent battery damage. To ensure
satisfactory performance and avoid permanent damage, charge the internal
battery every month.
TROUBLESHOOTING11.
PROBLEM POSSIBLE CAUSE REASON/SOLUTION
The Instant Power™ won’t
jump start my car. Clips are not making a good connection to the battery.
Connections are reversed.
The Instant Power™ battery
is not charged.
The vehicle’s battery is
defective.
Check for poor connection
to battery and frame. Make
sure connection points are
clean. Rock clips back and
forth for a better connection.
Disconnect the Instant
Power™ and reverse the
clips.
Check the battery charge
status by pressing the
button on the front of the
Instant Power™. See LED
Indicators section of this
manual.
Have the battery checked.

•11 •
PROBLEM POSSIBLE CAUSE REASON/SOLUTION
The Instant Power™ won’t
power my 12V device. The 12V device is not turned on.
The Instant Power™ battery
is not charged.
The 12V device draws more
than 15A or has a short
circuit
Turn on the 12V device.
Check the battery charge
status by pressing the
button on the front of the
Instant Power™. See LED
Indicators section of this
manual.
Disconnect the 12V device.
The internal breaker will
automatically reset after a
minute or two. Try the 12V
device again. If it happens
again, replace the 12V
device.
The battery in the Instant
Power™ won’t hold a
charge.
The battery is bad (will not
accept a charge). Have the battery checked.
If the above solutions do not eliminate the problem or for information about troubleshooting
or replacement parts, call toll-free from anywhere in the U.S.A.
1-800-621-5485
7:00 am to 5:00 pm Central Time Monday through Friday
SPECIFICATIONS12.
Model XP400
Internal Battery Type Sealed, Maintenance Free, AGM, Lead Acid
Nominal Voltage 12V DC
Capacity 5 Ah
DC Power Output (Maximum
Continuous Load) 15A
Peak Amps 400
Cranking Amps 175
Cold Cranking Amps 116
Battery Hookup Cables with Clamps 8 gauge, AWG, 18” (45.72 cm) Long
Dimensions (H x W x D) 10 x 10.25 x 5.25 (25.4 cm x 26 cm x 13.3 cm)
Weight 7 lbs (3.18 kg)

•12 •
Model XP500
Internal Battery Type Sealed, Maintenance Free, AGM, Lead Acid
Nominal Voltage 12V DC
Capacity 7 Ah
DC Power Output (Maximum
Continuous Load) 15A
Peak Amps 500
Cranking Amps 195
Cold Cranking Amps 146
Battery Hookup Cables with Clamps 8 gauge, AWG, 18” (45.72 cm) Long
Dimensions (H x W x D) 10 x 10.25 x 5.25 (25.4 cm x 26 cm x 13.3 cm)
Weight 8.2 lbs (3.7 kg)
Model XP750C
Internal Battery Type Sealed, Maintenance Free, AGM, Lead Acid
Nominal Voltage 12V DC
Capacity 12 Ah
DC Power Output (Maximum
Continuous Load) 15A
Peak Amps 750
Cranking Amps 261
Cold Cranking Amps 191
Battery Hookup Cables with Clamps 8 gauge, AWG, 20.5” (52.5 cm) Long
Dimensions (H x W x D) 10.5 x 13.5 x 10.25 (26.7 cm x 34.3 cm x 26 cm)
Weight 19.85 lbs (9 kg)
REPLACEMENT PARTS/ACCESSORIES13.
Male-To-Male Accessory Cable-------------------------------------94500109
LIMITED WARRANTY14.
SCHUMACHER ELECTRIC CORPORATION, 801 BUSINESS CENTER
DRIVE, MOUNT PROSPECT, IL 60056-2179, MAKES THIS LIMITED
WARRANTY TO THE ORIGINAL RETAIL PURCHASER OF THIS PRODUCT.
THIS LIMITED WARRANTY IS NOT TRANSFERABLE OR ASSIGNABLE.
Schumacher Electric Corporation (the “Manufacturer”) warrants this Instant
Power™ for one year and the internal battery for ninety days from the date of
purchase at retail against defective material or workmanship that may occur
under normal use and care. If your unit is not free from defective material
or workmanship, Manufacturers obligation under this warranty is solely to
repair or replace your product, with a new or reconditioned unit, at the option
of the Manufacturer. It is the obligation of the purchaser to forward the unit,
along with mailing charges prepaid to the Manufacturer or its authorized
representatives in order for repair or replacement to occur.

•13 •
Manufacturer does not provide any warranty for any accessories used with this
product that are not manufactured by Schumacher Electric Corporation and
approved for use with this product. This Limited Warranty is void if the product
ismisused,subjectedtocarelesshandling,repaired,ormodiedbyanyone
other than Manufacturer or if this unit is resold through an unauthorized
retailer.
Manufacturer makes no other warranties, including, but not limited to, express,
implied or statutory warranties, including without limitation, any implied
warrantyofmerchantabilityorimpliedwarrantyoftnessforaparticular
purpose. Further, Manufacturer shall not be liable for any incidental, special
or consequential damage claims incurred by purchasers, users or others
associatedwiththisproduct,including,butnotlimitedto,lostprots,revenues,
anticipated sales, business opportunities, goodwill, business interruption
and any other injury or damage. Any and all such warranties, other than
the limited warranty included herein, are hereby expressly disclaimed and
excluded. Some states do not allow the exclusion or limitation of incidental or
consequential damages or length of implied warranty, so the above limitations
orexclusionsmaynotapplytoyou.Thiswarrantygivesyouspeciclegal
rights and it is possible you may have other rights which vary from this
warranty.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS LIMITED WARRANTY
AND THE MANUFACTURER NEITHER ASSUMES OR AUTHORIZES
ANYONE TO ASSUME OR MAKE ANY OTHER OBLIGATION TOWARDS
THE PRODUCT OTHER THAN THIS WARRANTY.
Schumacher Electric Corporation Customer Service
1-800-621-5485
Monday – Friday 7:00 a.m. to 5:00 p.m. CST
Schumacher and the Schumacher Logo are registered trademarks of
Schumacher Electric Corporation
Toactivatethewarranty,pleasellinthewarrantyregistrationcardonpage15and
mail it in, OR go to www.batterychargers.com to register your product online.
DO NOT RETURN THIS PRODUCT
TO THE STORE!
Call Customer Service for Assistance:
800-621-5485

•14 •

•15 •
1 YEAR LIMITED
WARRANTY PROGRAM
REGISTRATION
MODEL:___________________ DESCRIPTION:___________________________
This is the only express limited warranty, and the manufacturer neither assumes nor authorizes
anyone to assume or make any other obligation. There is no other warranty, other than what is
described in the product owner’s manual.
The warranty card should be submitted within 30 days of purchase. The customer must
keep the ORIGINAL receipt because it will be required for any warranty claims.
This warranty is not transferable.
Mail To: Schumacher Electric Corporation
801 Business Center Drive
Mount Prospect, IL 60056-2179
Name_______________________________________________________________
Street Address________________________________________________________
City_________________________________State__________Zip Code__________
Phone______________________Email____________________________________
Store Name Where Purchased____________________Date of Purchase__________
Store Location_____________________UPC Number_________________________
Serial Number________________________(SEE PRODUCT)
1 YEAR LIMITED
WARRANTY PROGRAM
REGISTRATION
MODEL:___________________ DESCRIPTION:___________________________
This is the only express limited warranty, and the manufacturer neither assumes nor authorizes
anyone to assume or make any other obligation. There is no other warranty, other than what is
described in the product owner’s manual.
The warranty card should be submitted within 30 days of purchase. The customer must
keep the ORIGINAL receipt because it will be required for any warranty claims.
This warranty is not transferable.
Mail To: Schumacher Electric Corporation
801 Business Center Drive
Mount Prospect, IL 60056-2179
Name_______________________________________________________________
Street Address________________________________________________________
City_________________________________State__________Zip Code__________
Phone______________________Email____________________________________
Store Name Where Purchased____________________Date of Purchase__________
Store Location_____________________UPC Number_________________________
Serial Number________________________(SEE PRODUCT)

•16 •
