Foreword
4 SCHWARZE A7 TORNADO SE revised 01/22
Dear customer,
We are pleased to have you as a Schwarze customer. Your new sweeper has been carefully designed to give maximum
service with minimum downtime.
This manual is provided to give you the necessary operating and maintenance instructions for keeping your sweeper in
top operating condition. Careful use and timely service save extensive repairs and costly downtime losses. Make sure to
read this manual thoroughly and understand what each control is for and how to use it.
Safety is of primary importance to the owner/operator and the manufacturer. Observe all safety precautions decals on
the machine and noted throughout the manual for safe operation. If any assistance or additional information is needed,
contact your authorized Schwarze dealer.
In addition to having many Authorized Dealers located throughout the country, Schwarze Industries also maintains a fully
stocked factory service center in Huntsville, Alabama. In the event you need parts or service, call your nearest Authorized
Dealer. Their name and number can be found on the Sweeper Information Sheet, located in the front of this manual.
In the unlikely event that your local dealer is unable to provide the assistance you require, call us at our home ofce in
Huntsville, Alabama. We have a state-of-the-art fabrication and production facility and a complete service and refurbishing
center with an inventory of over $500,000 in spare parts. In most cases, same day shipping and overnight delivery are
available.
Schwarze dealer locator: http://www.schwarze.com/locator
Schwarze website: http://www.schwarze.com
Schwarze Customer Service: 1.800.879.7934
