Scion-Tech SC02.7218 User manual

· PACKAGE CONTENTS
· INTRODUCTION
· IMPORTANT SAFETY INSTRUCTIONS
1. Distribute 1 HDMI source to 8 HDMI displays over network cable
simultaneously.
2. Support one HDMI Loop-out.
3. Compatible with CAT6/6a/7 network cables.
4. The transmission distance is up to 40m/131f t.
5. The highest resolution suppor ted is .1920x1080@60Hz
6. Support 20~60Hz IR pass back.
7. Support EDID Setting function.
8. Support power from transmitter to receiver unit over the CAT6 cable.
9. Plug and play.
10. Wall-mounted function, easy installation.
· INSTALLATION REQUIREMENTS
· PANEL DESCRIPTION
· INSTALLATION PROCEDURES
1. How to make a CAT5/5E/6 network cake
Transmitter unit ×1pcs
DC12V/3A ×1pcs
User Manual ×1pcs
· FEATURES
Follow the standard of IEEE-568B:
1- Orange/white 2- Orange
3- Green/white 4- Blue
5- Blue/white 6- Green
7- Brown/white 8- Brown
1
2
3
4
5
6
7
8
Power input（DC12V）
RJ45 signal output
HDMI output
Power/ signal indicator
IR blaster extension cable
EDID switch
Reset button
2. Connection
1. Do not mix up the Transmitter and Receiver, and the IR blaster and
IR receiver.
2. Do not plug-in/out the cables, when it is in using.
3. Use DC 12V power supply only. Make sure the specification matched
if using 3rd party DC adapters.
4. Support power from transmitter to receiver unit over the CAT6 cable.
This HDMI extender splitter works with 8 HDMI CAT6 extender receivers
to split and extend 1 HDMI source to 8 HDMI displays over single
CAT6/6A/7 cable up to 40m/131ft. The highest resolution supported is
1920x1080@60Hz, and it supports IR passback, EDID pass through and
only one power adapter for the transmitter is needed, the receivers are
powered by the transmitter over CAT6 cable. Ideal solution for HDMI
exhibition, video conference and show center, etc.
IR blaster extension
cable x1pcs
Receiver uni t ×8pcs
IR rece iver extension
cable ×8pcs
1. HDMI source device(computer graphics card, DVD, PS3, HD
monitoring equipment etc).
2. HDMI display device like SDT V, HDTV, and projector with HDMI por t.
3. UTP/STP CAT6/6A/7 cable, follow standard IEEE-568B.
1. Transmitter unit (TX)
2. Receiver unit (RX)
LENGTH: for adjusting to the length
of network cable
RJ45 signal input
RJ45 indicator led: it lights on all the
time when HDMI signal transmission,
flashes when no signal transmission
HDMI signal output
DV5V power input (OPTIONAL)
IR receiver extension cable
LENGTH
12 3 4 5
78
HDMI input
6
12
Receiver
power
HDMI Input HDMI extender splitter
Cable
HDMI Out
DVD
HDMI Display
HDMI Display
HDMI Display
HDMI Display
HDMI Display
HDMI Display
HDMI DisplayHDMI Display
HDMI Display
12
Remarks:
Users can press button”Length”to adjust transmittion distance of
this device automatically or manually. If users do not press this button
when power on, then the device will work like last time because of
memory function. If users press this button after power, on the first two
press will make the device adjust the distance according to the network
cable length automatically. After this two press, if users continue to press
this button, then will go to the mode of adjusting transmittion distance
manually. There is 12 levels to tally and adding one more press means a
new level. When users finish the 12 levels adjusting manually it will be
back to adjust transmittion distance automatically mode and into the
new loop. Remarks: Ple ase do not remote control two or more RX unit s' IR signal at the sa me time,
which to avoid interference.

18 HDMI Extender Splitter×
User manual
The product name and brand name may be registered trademark of
related manufacturers.TM and may be omitted on the user manual.
The pictures on the user manual are just for reference, and there may
be some slight difference with the real products.
We reserve the rights to make changes without further notice to a
product or system described herein to improve reliability, function or
design.
Disclaimer
· FAQ
Q : No image or audio output on display ?
A: 1) Please check whether display on standby mode;
2) Please make sure the HDMI Port on the HDMI display is correctly
connected with the HDMI cable.
3) Please check whether signal indicator “ LINK ” LED on RX side
keeps on, LED flash means RX does not receive signal from TX;
4) Please check whether signal indicator “ LINK ” LED on TX turns
blue, LED on red means no input signal;
5) Please check whether input resolution is suppor ted by this product.
Q : Image unstable ?
A: 1) Press the “LENGTH”button on receiver or “RESET ”button on the
transmitter to re-identify the signal;
2) Please re-connect the corresponding network cable and try again.
Q : There is only some por ts output signal ?
A : 1)Please check and make sure CAT cable or HDMI cable connected
well;
2)Press the “LENGTH”button on receiver or “RESET ”button on the
transmitter to re-identify the signal;
3)Please re-connect the corresponding network cable and tr y again.
· SPECIFICATION
Switch
Sta tus
SW1 SW2 E DID M ode
0 0 0 720P@50Hz 2.1CH
1 0 0 720P@50Hz 7.1CH
0 1 0 1080i@60Hz 2.1CH
1 1 0 1080i@60Hz 7.1CH
0 0 1 1080P@60 2.1CH
1 0 1 1080p@60Hz 7.1CH
0 1 1
1 1 1 Default 720P@50Hz 2.1CH
SW3
Read Loop-out(if not connect
the loop-out show default)

4. EDID Setting
1 ) The Transmitter will read the HDMI display's EDID information,
and then feed it back to the HDMI source device for outputing
the best matched resolution.
2 )This set is built-in 8 EDID status, switch the Dial Dip to choose one.
The detail setting information is shown as below:
Switch UP : use the arabic numeral "1" to represent
Switch DOWN : use the arabic numeral "0" to represent
3. Connection instruction:
1 ) Connect the HDMI signal source device to the transmitter HDMI
input port with HDMI cable.
2 ) Connect IR blaster to extender IR out.
3 ) Connect the transmitter RJ45 port to HDMI extender RX's RJ45
input port by network cable.
4 ) Connect HDMI extender RX's HDMI output port to HDMI display's
HDMI input por t by HDMI cable and set the HDMI display's signal
source to be HDMI port.
5 ) Supply the power(when power is on, if there is signal input, the
power light is blue, other wise, it is red), the product will work.
0℃～60℃
DC12V/3A
EDID
Working temperature
Power supply
Support EDID manual setting function
<24W
TX: 276(L) x 95.98(W) x 23(H) mm
Power Consumption
Dimension
BlackColor
RX: 71.6×66.6×22.6mm
Weight TX: 620g x1pcs RX: 80g x8pcs
Transmit distance
IR signal Support 20~60kHz IR device
Full HD resolution 1080p@60Hz up to 40 meters
via CAT6 cable
Items
480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,
720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz
1 x HDMI
8 x HDMI
HDMI signal
Input
Output
Support resolutions
HDMI1.3, Compatible with HDCP1.2
Specifications
