2.1 ACTIVE INSTALLCATION COLUMN SYSTEM
M-A2
www.se-audiotechnik.com
www.se-audiotechnik.co.kr
Designed in Germany 2014/ 12

Thank you for choosing !
We have designedthis product to operate reliably over many years. For that guarantees with its
name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new
products quickly and to the fullest.
You can find more information about audiotechnik at our Internet site WWW.SE-AUDIOTECHNIK.COM
WWW.SE-AUDIOTECHNIK.CO.KR
.
0302
POWER
PROTECT
LIMIT
SIGNAL
ON
MAIN
CHA
SUB
PROTECT
LIMIT
SIGNAL
ON
CHB
2.1 ACTIVE INSTALLCATION COLUMN SYSTEM
M-A2
www.se-audiotechnik.co.krwww.se-audiotechnik.co.kr
www.se-audiotechnik.com www.se-audiotechnik.com

0504
4
PREVENTIVE MEASURES: FEATURES & GETTING STARTED:
INTRODUCTION
M-A2 is a compact and modular active all-in-one column system.
This installation system features of full range frequency response and stereophonic sound. It is composed of one 2×6.5”
sub, two columns and one four-channel amplifier.
M-A2 generates a clear, dynamic and balanced sound throughout the frequency range of this system. The array configura-
tion ensures greater coverage with very well-balanced sound distribution even in the farthest corners of the venue.
Please read the attached safety instructions as well as the following instructions carefully.
Please keep all the instructions.
Please use the device only as intended.
Please respect the valid waste management rules. Please deliver the packaging divided into plastic and
paper / cardboard to the recycling management.
Please refer all servicing to qualified personnel only if the device is damaged, exposed to liquid / rain or if it does
not operate normally.
Please do not expose the product to any kind of heat such as ovens, radiators, or any other devices (incl. amplifiers).
Please also make sure that there is enough distance between amplifiers and walls, racks, etc. to prevent overheating.
After connection please check the wiring to prevent any kind of accident or damage.
Please never use any kind of damaged cable and wiring.
8.
9.
7.
6.
5.
1.
2.
3.
4.
Only use approved and stable stands, brackets, shelves, tables etc.. for installations. Please check for
adequate stability to avoid a collapse.
Appearance of interferences when using wireless systems.
The simultaneoususe of wireless microphones and mobile phones (if both devices are not very far away from
each other) can cause interferences in the microphone signal which can be heard in the PA system.
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage”within the product´senclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this transmission system for professional use. Therefore the commercial use of this equipment
is liable to the rules and regulations of the Accident Prevention & Insurance Association of your industry sector.
as a manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
This system is able to induce an acoustic pressure of 80 dB. 85 dB is by law the maximum audio pressure
level which your ear can be exposed to during a work day. It was set according to the technical expertise of the
occupational medicine as a basis for the noise rating level. Higher sound levels or longer exposition times could
damage your ear. The time of exposition by higher sound pressure levels should be shortened in order to prevent
from ear damages. Here are a few reliable warning signals which show that you have exposed yourself for a too
long period to excessive sound pressure levels:
- You hear bell- or whistling sounds!
- You have the impression that you can’t hear high tones anymore!
CAUTION
RISK OF ELE CTRI C SH OC K
DO NO T OPEN
www.se-audiotechnik.co.krwww.se-audiotechnik.co.kr
www.se-audiotechnik.com www.se-audiotechnik.com

M-A2 SUB M-A2 COLUMN
M-A2 AMP
6
0706
STRUCTURAL DIAGRAM:
M-A2 COLUMN 1/PC
SMB
1/PC
M-A2 COLUMN 1/PC
M-A2WB
2/PCS
SMB
Smart-Mounting-Bracket
M-A2WB
M-A2 Wall Bracket
ACCESSORIES:OPTIONAL
www.se-audiotechnik.co.krwww.se-audiotechnik.co.kr
www.se-audiotechnik.com www.se-audiotechnik.com

LINE I N
CHA LIN E O UT
LINE O U T
1+ : M +
1- : M -
2+ : H +
2- : H-
LINE I N
CH B
1+: S UB +
1- : N C. .
2+: S UB -
2- : N C. .
DSP
SE RIA L NO .
NO.
POWER
AC22 0V 5 0Hz
FUSE: T5AL 250 VAC
0908
CONNECTIONS, CONTROLS AND INDICATORS:CONNECTIONS, CONTROLS AND INDICATORS:
1
2
3
4
4
5
6
7
7
9
MAIN LEVEL CONTROL KNOB
Overall volume adjustment. The subwoofer volume is also adjusted in accordance with the preset lever on
the SUB LEVEL controller.
SUB LEVEL CONTROL KNOB
Adjusting the volume ratio of the subwoofer to the column loudspeaker.
INDICATOR LEDS
POWER SWITCH
IEC POWER INLET
LINE INPUT CHA / CHB
LINE OUTPUT CHA / CHB
SPEAKER CONNECTORS
The balanced line inputs with 2 female Neutrik XLR connectors to connect a playback device (e.g.mixer).
The balanced line outputs with 2 male Neutrik XLR connectors, it can be used to control other active speakers or amplifiers.
The output signal corresponds to the input signal.
Neutrik speakon to connect the M-A2 COLUMNS.
1+ : M+
1 - : M -
2+ : H+
2 - : H -
9
8
SPEAKER CONNECTORS
Neutrik speakon to connect the M-A2 SUBS.
1+ : SUB+
1 - : N.C.
2+ :SUB -
2 - : N.C.
6
Position - : Connects the amplifier’s current feed. (green LED on).
Position 0 : Disconnects the Power.
Before switching the active speaker on or off, always adjust the volume to zero (MAIN LEVEL all the way to the left).
An appropriate mains cord is included in the package. The M-A2 system is intended for 2 operating voltage ranges
(100 - 120 V AC and 200 - 240 V AC). The conversion is done automatically.
58
PO WE R
M- A2
PROTE CT
LIM IT
SIGNAL
ON
SU B
PROT ECT
LIMIT
SIGN AL
ON
LEVEL LE VEL
MAIN
CHA CH B
12 3
ON: Lights up once the system is properly connected to the power mains and switched on.
SIGNAL: Lights up as soon as an audio signal is present. The signal acquisition is performed before the
MAIN LEVEL controller.
LIMIT: Lights up when the limiter starts working. If the limiter LED lights up permanently or for longer periods,
PROTECT: Lights up if the amplifier is short-circuited or overheated. The amplifiers are muted automatically. Upon
reaching normal operating conditions, the device reverts to normal operating mode after a few seconds.
reduce the volume level. Failure to do so may result in a distorted sound and damage to the speaker system.
www.se-audiotechnik.co.krwww.se-audiotechnik.co.kr
www.se-audiotechnik.com www.se-audiotechnik.com

LINE IN
CHA L IN E O UT
LINE O UT
1+: M +
1- : M -
2+: H +
2- : H -
LINE IN
CH B
1+: S UB +
1- : N C. .
2+: S UB -
2- : N C. .
DSP
SERI AL NO .
NO.
POWER
AC220V 50Hz
FUSE:T5AL 25 0VAC
SPECIFICATIONS:
1110
WIRING EXAMPLE:
ONLY CON N EC T TO M- A 2 AMPL IFI ER
DESIGNE D AND ENGIN EERED IN GE RMANY
M-A 2
1+: SUB+ 2+: SUB-
4 x 1.5mm² speaker cable
2 x 1.5mm² speaker cable
Transducer MF:
Transducer HF:
8 × 2.8” Ferrite magnet, 0.75” voice coil
1 × 1” N35H Neodymium magnet phenolic diaphragm, 1” voice coil
Dimensions (W × H × D):
Weight:
M-A2 column can only be used with M-A2 AMP.
M-A2 Column
Frequency Response (-6dB):
Type:
Max. SPL (1m):
Sensitivity (1W / 1m):
Sensitivity (1W / 1m):
Cabinet / Coating: 6063 Aluminum, HD coating
Input:
Horizontal Dispersion (-6dB):
110 × 820 × 132 mm
6 kg + 6 kg
200 Hz - 20 kHz
2.8” Sealed
98 dB
121 dB
Neutrik NL- 4
120°
Dimensions (W × H × D):
Weight:
M-A2 SUB
Frequency Response (-6dB):
Power Handling (RMS):
Type:
Max. SPL (1m):
Impedance:
Transducer LF:
Cabinet / Coating:
Input:
300 × 408 × 346 mm
11.5 kg
50 Hz - 200 Hz
200 W
6.5” V construction, bassreflex
120 dB
97 dB
4 Ω
2 × 6.5” 28 OZ Ferrite magnet, 1.5” voice coil
15 mm plywood, white PU texture coating
Neutrik NL- 4
SPECIFICATIONS:WIRING EXAMPLE:
XLR balanced cable
with speakon connectors
with speakon connectors
www.se-audiotechnik.co.krwww.se-audiotechnik.co.kr
www.se-audiotechnik.com www.se-audiotechnik.com

1312
MANUFACTURER´S DECLARATIONS:
M-A2 AMP can only be used for M-A2 Column and M-A2 SUB.
SPECIFICATIONS:SPECIFICATIONS:
Dimensions (W × H × D) :
Weight:
Power Output (RMS):
Indicators:
Input / Output:
Ampilifer Type:
Signal Processing:
Protection:
M-A2 AMP
Controls:
483 × 66 × 347 mm
6.5 kg
On, signal, limit, protect
Input Neutrik XLR / Link-output Neutrik XLR, speaker out Neutrik NL- 4
Class D amplifier, SMPS
DSP, 48 kHz, 24 bits
Multiple limiter, short circuit, overheating
On / Off switch, Main level, sub level
Sub: 400 W (200 W × 2) , Column: 400 W ((100 W + 100 W) × 2)
Input Sensitivity: - 13.2 dBV
regarding the branded product you have purchased.
In the unlikely event that your product has a recurring failure, , at its discretion, may elect to
component parts or hardware products removed under this limited warranty become the property of .
ferable to anyone who obtains ownership of the branded product from the original purchaser. During
the limited warranty period, will repair or replace the defective component parts or the product. All
does not warrant that the operation of this product will be uninterrupted or error-free. is not
provide you with a replacement unit of ’s choice that is at least equivalent to your branded
This limited warranty extends only to the original purchaser of this branded product and is not trans-
warrants that the product you have purchased from or from an authorized reseller is free
independent warranty claims towards .
LIMITED WARRANTY
This limited warranty applies to the branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies additional
from defects in materials or workmanship under normal use for a period of 1 year from the date of purchase.
The limited warranty period starts on the date of purchase. In order to receive warranty services, you are required
to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited war-
ranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
product in hardware performance.
responsible for damage that occurs as a result of your failure to follow the instructions included with the
branded product.
This limited warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defec-
tive as the result of an accident
- in case of, misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user’s documentation shipped with the product
- by use of spare parts not manufactured or sold by
- by modification or service by anyone other than
These terms and conditions constitute the complete and exclusive warranty agreement between you and
www.se-audiotechnik.co.krwww.se-audiotechnik.co.kr
www.se-audiotechnik.com www.se-audiotechnik.com

1514
MANUFACTURER´S DECLARATIONS:
MANUFACTURER´S DECLARATIONS:
of an authorized represent
16
’s maximum liability under this limited warranty is explicitly limited
of the possibility of any such damages.
is not liable for any
branded hardware product fails to work as warranted above, your sole and exclusive remedy
LIMITATION OF LIABILITY
If your
shall be repair or replacement .
to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware
components that malfunction in conditions of normal use.
damages caused by the product or the failure of the product,
profits or savings or special, incidental or consequential damages. is not liable for any claim made by
a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this limited warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limi-
tation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if
you have advised ative of
This limitation of liability however, will not apply to claims for personal injury.
This limited warranty gives you specific legal rights. You may also have other rights that may vary from state to
state or from country to country. You are advised to consult applicable state or country laws for a full determina-
tion of your rights.
REQUESTING WARRANTY-SERVICE
To request warranty service for the product, contact or the authorized reseller from which
you purchased the product.
CORRECT DISPOSAL OF THIS PRODUCT (ELECTRICAL WASTE)
(Applicable in the European Union and other European countries with separate collection systems)
This marking, shown on the product or itsliterature, indicates that it should not be disposed with other household
wastes at the end of its working life.To prevent possible harm to the environment or human health from uncon-
trolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an enviromentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal
EC DECLARATION OF CONFORMITY
These devices meet the essential requirements and further relevant specifications of Directives 2004/108/EC (EMC)
and 2006/95/EC . For more information, see www.se-audiotechnik.com.
including any lost
Your -systems product was developed and manufactured with high quality materials and components wich
WEEE-DECLARATION
can be recycled and / or reused. This symbol indicates that electrical and electronic equipment must be disposed
of separately from normal waste at the end of its operational lifetime.
Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
This will help to protect the environment in which we all live.
BATTERIES AND ACCUMULATORS
The supplied batteries or rechargeable batteries can be recycled. Please dispose of them as special waste or return
them to your specialist dealer. In order to protect the environment, only dispose exhausted batteries.
all rights reserved. The technical data and the functional product characteristics can
be subject to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the
integrality of this user’s manual is prohibited.
www.se-audiotechnik.co.krwww.se-audiotechnik.co.kr
www.se-audiotechnik.com www.se-audiotechnik.com
