Seagull Models DUAL ACE User manual

Kit features.
• Factory-installedpushrods.
• Hardwarepack withwheels,tank,undercarriage.
• Photo-illustratedstep-by-stepAssemblyManual.
MadeinVietnam.
Specifications
Wingspan------------------------------------------70in-----------------------------177cm.
Wing area------------------------------------- 862sq.in---------------------- 55.6 sq.dm.
Approximate flying weight-------------------- 11lbs--------------------------------- 5kg.
Length----------------------------------------------59in---------------------------149.5cm.
Recommended engine size-----------------.46 cu.in(2pcs)-------------- 2-stroke.
Radio System required 6 channels with 7 digital servos.
Flying skill level Intermediate/advanced.
Hand-made Almost Ready to Fly R/C Model Aircraft
ASSEMBLY MANUAL
DUDU
DUDU
DUALAL
ALAL
AL AA
AA
ACECE
CECE
CE

DUAL ACE. InstructionManual.
2
INTRODUCTION.
Thank you for choosing the DUAL ACE ARTF by SEAGULL MODELS. The DUAL ACE was
designedwiththeintermediate/advancedsportflyerinmind.Itisa airplane whichiseasytoflyand
quicktoassemble.Theairframeisconventionallybuiltusingbalsa,plywood tomakeitstrongerthan
theaverageARTF,yetthedesignallowstheaeroplanetobekeptlight.Youwillfindthatmostofthe
work has been done for you already.Flying the DUAL ACE is simply a joy.
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual thoroughly before starting assembly of your DUAL ACE. Use the parts listing below to
identify all parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is
capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU
ASSUME ALL RISK & RESPONSIBILITY.
IfyouareinexperiencedwithbasicR/CflightwestronglyrecommendyoucontactyourR/Csupplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
proceduresdesignedtohelpthe newpiloton hiswaytosuccessfulR/Cflight.Theywill alsobeable
to advise on any insurance and safety regulations that may apply.
ADDITIONAL ITEMS REQUIRED.
!.46cu.in 2 - stroke engine (2pcs).
!Computer radio with seven digital
servos.
!Glow plug to suit engine.
!Propeller to suit engine.
!Protective foam rubber for radio
system.
!Siliconefuelline.
TOOLS & SUPPLIES NEEDED.
!Thick cyanoacrylate glue.
!30 minute epoxy.
!5 minute epoxy.
!Hand or electric drill.
!Assorted drill bits.
!Modellingknife.
!Straight edge ruler.
!2mm ball driver.
!Phillips head screwdriver.
!220 grit sandpaper.
!90° square or builder’s triangle.
!Wire cutters.
!Masking tape & T-pins.
!Thread-lock.
!Paper towels.
PARTS LISTING.
FUSELAGE ASSEMBLY
!(1) Fuselage.
!(1) Canopy hatch.
WING ASSEMBLY
!(1) Right wing half with pre-installed
aileron.
!(1) Left wing half with pre-installed
aileron.
!(1) Aluminium dihedral brace.
Tail section assembly
!(1) Horizontal stabilizer with pre-
installedelevator halves.
!(1) Vertical stabilizer with pre-
installed rudder halves.
Some more parts.
HARDWAREPACK
COWLING
Landinggear.....

DUAL ACE. Instruction Manual.
3
NOTE: To avoid scratching your new aero-
planewesuggestthatyoucoveryour
workbench with an old towel. Keep a
couple of jars or bowls handy to hold
the small parts after you open the
bags.
Pleasetrialfitallparts.Makesureyou
have the correct parts and that they
fit and are aligned properly before
gluing! This will ensure proper as-
sembly as the DUAL ACE is made
from natural materials and minor ad-
justments may have to be made.
The paint and plastic parts used in
this kit are fuel proof. However, they
arenottolerantofmanyharshchemi-
cals including the following: paint
thinner, cyano-acrylate glue accel-
erator,cyanoacrylategluede-bonder
andacetone. Donot letthese chemi-
calscomein contact withthe colours
onthe coveringand theplastic parts.

DUAL ACE. InstructionManual.
4
!4)Deflect the aileron and completely
saturate each hinge with thin C/A glue. The
aileronsfront surfaceshould lightlycontact the
wing during this procedure. Ideally, when the
hinges are glued in place, a 1/64” gap or less
will be maintained throughout the lengh of the
aileron to the wing panel hinge line.
Note:
The control surfaces, including the
ailerons, elevators, and rudder, are
prehinged with hinges installed, but the
hinges are not glued in place. It is
imperativethatyou properlyadhere the
hingesinplace perthesteps thatfollow
using a high-quality thin C/A glue.
!1) Carefully remove the aileron from one
of the wing panels. Note the position of the
hinges.
!2)Removeeach hingefrom the wingpanel
and aileron and place a T-pin in the center of
each hinge. Slide each hinge into the aileron
untiltheT-pinis snugagainstthe aileron.This
will help ensure an equal amount of hinge is
oneither sideofthe hingelinewhentheaileron
is mounted to the wing panel.
HINGING THE AILERONS.
Note:
The hinge is constructed of a special
material that allows the C/A to wick or
penetrateand distributethroughout the
hinge, securely bonding it to the wood
structureofthe wingpanel andaileron.
!7) Repeat this process with the other wing
panel, securely hinging the aileron in place.
!3) Slide the aileron on the wing panel until
there is only a slight gap. The hinge is now
centered on the wing panel and aileron.
Remove the T-pins and snug the aileron
against the wing panel.A gap of 1/64” or less
shouldbemaintained betweenthe wingpanel
andaileron.
!5) Turn the wing panel over and deflect the
aileron in the opposite direction from the
opposite side. Apply thin C/A glue to each
hinge,makingsurethattheC/Apenetratesinto
both the aileron and wing panel.
!6) Using C/A remover/debonder and a
papertowel,removeanyexcess C/Aglue that
may have accumulated on the wing or in the
aileronhingearea.
Hinge.
T-pin.
T-pin.
C/Aglue.
C/Aglue.

DUAL ACE. Instruction Manual.
5
!8)After both ailerons are securely hinged,
firmly grasp the wing panel and aileron to
make sure the hinges are securely glued and
cannot be pulled out. Do this by carefully
applying medium pressure, trying to separate
the aileron from the wing panel. Use caution
not to crush the wing structure.
Note:Work the aileron up and down several
times to “work in” the hinges and check
for proper movement.
!1) Carefully remove the elevator from one
of the horizontal stabilizer panels. Note the
position of the hinges.
!2) Remove each hinge from the horizontal
stabilizerpanelandelevator andplace aT-pin
in the center of each hinge. Slide each hinge
intotheelevator untiltheT-pin is snugagainst
the elevator. This will help ensure an equal
amount of hinge is on either side of the hinge
line when the elevator is mounted to the
horizontal stabilizer panel.
1/64”gaporlesswillbemaintainedthroughout
the lengh of the elevator to the horizontal
stabilizer panel hinge line.
Note: The hinge is constructed of a special
material that allows the C/A to wick or
penetrateand distributethroughout the
hinge, securely bonding it to the wood
structure of the horizontal stabilizer
panel and elevator.
!5) Turn the horizontal stabilizer panel over
and deflect the elevator in the opposite
directionfrom theoppositeside.Apply thinCA
glue to each hinge, making sure that the C/A
penetratesintoboththeelevatorand horizontal
stabilizer panel.
HINGING THE ELEVATORS.
!3) Slide the elevator on the horizontal
stabilizer panel until there is only a slight gap.
The hinge is now centered on the horizontal
stabilizer panel and elevator. Remove the T-
pins and snug the elevator against the
horizontal stabilizer panel. A gap of 1/64” or
less should be maintained between the
horizontal stabilizer panel and elevator.
!4)Deflect the elevator and completely
saturate each hinge with thin C/A glue. The
elevators front surface should lightly contact
thehorizontalstabilizer duringthis procedure.
Ideally, when the hinges are glued in place, a
T-pins.
Hinges.
C/Aglue.
C/Aglue.

DUAL ACE. InstructionManual.
6
!4)Deflect the rudder and completely
saturate each hinge with thin C/A glue. The
rudder front surface should lightly contact the
verticalfin duringthis procedure.Ideally, when
the hinges are glued in place, a 1/64” gap or
less will be maintained throughout the lengh
of the rudder to the fuselage panel hinge line.
!1) Carefully remove the rudder from the
vertical fin. Note the position of the hinges.
!2) Placing a T-pin in the center of each
hinge. Slide each hinge into the rudder until
the T-pin is snug against the rudder. This will
help ensure an equal amount of hinge is on
eithersideof thehinge linewhenthe rudderis
mounted to the fuselage panel.
Note:
!3) Slide the rudder on the vertical fin until
there is only a slight gap. The hinge is now
centered on the fuselage panel and rudder.
Remove the T-pins and snug the rudder
against the fuselage panel. A gap of 1/64” or
lessshouldbemaintainedbetween thevertical
fin panel and rudder.
!5)Turntheverticalfinpaneloveranddeflect
the rudder in the opposite direction from the
opposite side. Apply thin C/A glue to each
hinge,makingsurethattheC/Apenetratesinto
the rudder and fuselage panel.
HINGING THE RUDDER.
!8) Afterboth elevatoraresecurely hinged,
firmlygraspthehorizontalstabilizer paneland
elevatortomake surethehinges are securely
glued and cannot be pulled out. Do this by
carefully applying medium pressure, trying to
separate the elevator from the horizontal
stabilizer panel. Use caution not to crush the
horizontal stabilizer structure.
Hinges.
C/Aglue.
The hinge is constructed of a special
material that allows the C/A to wick or
penetrateand distributethroughoutthe
hinge, securely bonding it to the wood
structure of the fuselage panel and
rudder.
!6)UsingC/Aremover/debonderandapaper
towel, remove any excess C/A glue that may
have accumulated on the horizontal stabilizer
or in the elevator hinge area.
!7) Repeat this process with the other
horizontalstabilizerpanel,securelyhinging the
elevator in place. Hinges.
T-pins.
C/Aglue.

DUAL ACE. Instruction Manual.
7
!6)UsingC/Aremover/debonderandapaper
towel, remove any excess C/A glue that may
have accumulated on the fuselage or in the
rudder hinge area.
Note:Work the rudder left and right several
times to “work in” the hinges and check
for proper movement.
INSTALLING THE AILERON SERVOS.
Attach the string to the servo lead and
carefully thread it though the wing. Once you
havethreadtheleadthroughtthewing,remove
the string so it can use for the other servo
lead.Tapethe servoleadtothewingtoprevent
it from falling back into the wing.
Servo.
Small weight.
Thread.
We recommended to use long servos
arm for all servos without throttle
servo.
Because the size of servos differ, you
may need to adjust the size of the precut
opening in the mount. The notch in the
sides of the mount allow the servo lead to
pass through.
Install the rubber grommets and brass
colletsontotheaileronservo. Testfit theservo
into the aileron servo mount.
Install the servo into the servo tray.
Using a small weight (Weighted fuel pick-up
workswell)and thread, feed thestring through
the wing as indicated.
Secure the servos with the screws pro-
vided from your radio system.
Small weight.
Thread.
Small weight.
Wing bottom.
Thread.
Thread.
Electric wire.

DUAL ACE. InstructionManual.
8
AILERON LINKAGE.
INSTALLING THEAILERONLINKAGE.
!1) Using a ruler & pen to draw a straight
line as below picture.
Install the aileron servo tray into the servo
mount.
Repeat the procedure for orther wing
haft.
!!!
!!
!2) Locate the nylon control horns,nylon
control horn backplates and three machine
screws.
!!!
!!
!3)Positionthe aileronhornon thebottom
side of aileron. The clevis attachment holes
should be positioned over the hinge line.
Aileronelectric.
Plastic tape.
Wing panel bottom.
Pull.
Electric wire.
Thread.
Pen.
Servo arm.
Straighline.

DUAL ACE. Instruction Manual.
9
2mmx20mm.
3mmx30mm.
! 4) Using a 1.5mm drill bit and the control
horns as a guide, drill the mounting holes
through the aileron halves.
!
5)Mount the control horns by inserting the
bolts through the control horn bases and
aileron halves, then into the mounting
backplates. Do not overtighten the nuts or the
backplates may crush the wood.
ControlHorn.
MountingScrews.
MountingPlate.
3MM x30mm.
2MM x 20mm.
C/Aglueattach.
! 6)Threadonenylonadjustablecontrolhorn
on to each aileron control rod. Thread the
horns on until they are flush with the ends of
the control rods.
M2 lock nut. Snapkeeper.
M2clevis.
Ailerontorquerod.
Clevis.
Pen.
Cut.
M3locknut.

DUAL ACE. InstructionManual.
10
FUEL TANK.
!1) Using a modeling knife, carefully cut
offtherearportionofone ofthetwonylontubes
leaving 1/2” protruding from the rear of the
stopper. This will be the fuel pick up tube.
!2) Usingamodeling knife,cut onelength
ofsiliconfuel line(not included)to2-1/4” long.
Connect one end of the line to the weighted
fuelpickupand theotherend tothe nylon pick
up tube.
!4) Carefully heat the vent tube using a
heat gun or lighter to permanently set the
angle of the tube.
When the stopper assembly is installed in
the tank, the top of the vent tube should rest
justbelow thetop surfaceofthetank. Itshould
not touch the top of the tank.
INSTALLING THE STOPPER ASSEMBLY.
!3) Carefully bend the second nylon tube
up at a 45º angle. This tube is the vent tube.
Venttube.
Fuelline.
Clunk.
White glue or
epoxyglue.
Repeat the procedure for the other
aileron servo.
See pictures below.
ATTACHMENT ENGINE MOUNTING
BOX.
Push.

DUAL ACE. Instruction Manual.
11
Attach the silicone fuel and pressure pipes
tothe tank.Thelowerpipeisthe‘feed’andthe
uppertwothe ‘pressureand fill’.Thefill pipeis
the next pipe.
Blow through one of the lines to en-
sure the fuel lines have not become
kinked inside the fuel tank compartment.
Air should flow through easily.
You should mark which tube is the
vent and which is the fuel pick up when
you attach fuel tubing to the tubes in the
stopper. Once the tank is installed inside
thefuselage, itmaybe difficulttodetermine
which is which.
INSTALLING THROTTLE SERVOS.
!6) With the stopper assembly in place,
the weighted pick up should rest about 3/8”
awayfrom therear ofthe tankandmovefreely
insidethetank. Thetopof theventtubeshould
rest just below the top of the tank. It should
not touch the top of the tank.
!7) When satisfied with the alignment of
thestopperassemblytightenthe 3mmx20mm
machine screw until the rubber stopper ex-
pands and seals the tank opening. Do not
overtighten the assembly as this could cause
the tank to split.
Because the size of servos differ, you
may need to adjust the size of the
precut opening in the mount. The notch
in the sides of the mount allow the servo
lead to pass through.
Install the rubber grommets and brass
colletsontothethrottleservo. Testfittheservo
into the throttle servo mount.
Install the servo into the servo tray.
Secure the servos with the screws pro-
vided from your radio system.
Venttube.
Fuelline.
Fueltank.
!5) Test fit the stopper assembly into the
tank. It may be necessary to remove some of
the flashing around the tank opening using a
modeling knife. If flashing is present, make
sure none falls into the tank.

DUAL ACE. InstructionManual.
12
! 6) Attach theZ-Bendin thepushrod wire
to the throttle arm on the carburetor. You will
need to remove the throttle arm from the car-
buretor to be able to attach the Z-bend. When
complete, reattach the throttle arm to the car-
buretor.
!4) Remove the engine. Using an drill bit,
drill the mounting holes through the engine
mount at the four locations marked.
! 3) When you are satisfied with the align-
ment, mark the locations of the engine
mounting.
!
5) Bolttheenginetothe enginemount
using the four machine screws. Double
cheek that all the screws are tight before
proceeding.
MOUNTING THE ENGINE.
! 1) Install the pushrod housing through the
predrilledhole inthe firewallandintotheservo
compartment. The pushrod housing should
protrude 1/4" out past the front of the firewall.
Makea Z-Bend1/4" fromoneendofthe plain
wire pushrod.
! 2) Place your engine onto the engine
mount. Adjust the engine is centered of the
edges of the engine case.
Repeat the procedure for the other
servo.
4x30mm
(4pcs).
11.2cm.
4 X 30mm.

DUAL ACE. Instruction Manual.
13
Repeat the procedure for the other
engine.
MOUNTING THE NACELLE.
!1) Put the fiberglassnacelle overtheen-
gine and line up the back edge of the nacelle
withthe marksyou madeon thewing thentrim
and cut.
Because of the diameter of the na-
celle, it may be necessary to use a needle
valve extension for the high speed needle
valve. Make this out of sufficient length
1.5mm wire and install it into the end of
the needle valve. Secure the wire in place
by tightening the set screw in the side of
the needle valve.
! 2) While keeping the back edge of the
nacelle flush with the marks, align the front of
the nacelle with the crankshaft of the engine.
The front of the nacelle should be positioned
so the crankshaft is in nearly the middle of
thenacelleopening.Usethespinnerbackplate
asaguide. Holdthenacelle firmlyinplace us-
ing pieces of masking tape.
!3) Put the nacelle back over the engine
and secure it in place using thirty-two 3mm x
10mm wood screws. See picture above.
!4) Installthemufflerandmuffler extension
onto the engine and make the cutout in the
nacellefor mufflerclearance. Connect thefuel
and pressure lines to the carburetor, muffler
andfuelfiller valve.
3 x 10mm.
Pushrod wire.
Trim and cut.
Trim and cut.

DUAL ACE. InstructionManual.
14
The propeller should not touch any
part of the spinner cone. If it does, use a
sharp modeling knife and carefully trim
away the spinner cone where the propel-
ler comes in contact with it.
Install the spinner backplate, propeller
andspinnercone. The spinnercone isheldin
place using two 3mm x 12mm wood screws
(spinner is not included).
INSTALLING THE SPINNER.
Repeat the procedure for the other
nacelle.
C/Aglue.
Carburetor.
Drill 1mm.
2mmX8mm
(10pcs).
Plywood strap.
2mmX8mm.

DUAL ACE. Instruction Manual.
15
Remove covering.
Mountingslot.
! 1)Using amodelingknife, removethe cov-
ering from over the two main gear mounting
slots located in the bottom of the wing. One
slot is located in each wing half.
! 2) Insert the 90º bend of one main gear
wire into the predrilled hole in one mounting
slot.
MAIN LANDING GEAR
INSTALLATION.
! 3) The landing gear wire is held in place
using two nylon landing gear straps and four
3mm x 10mm wood screws.
NOTE:
! 4) Using the two landing gear straps as a
guide, mark the locations of the four 3mm x
10mm mounting screws onto the wing sur-
face.
! 5) Remove the two straps and the gear
wire. Drill four 1mm pilot holes into the wing
for the wood screws.
Be careful not to drill through the top
of the wing!
INSTALLING THE MAIN GEAR WIRES.
Repeat the procedure for the other
main gear wire.
Pen.
3mm X 10mm.
3 x 10mm.
The straps should be located equal
distance from the inside and outside
ends of the wire.
Landing gear wire.

DUAL ACE. InstructionManual.
16
Installing the hard wood block.
Pushrod wire
Slide one 60mm diameter wheel collar
onto the axle and tighten. Slide the nose
wheel on and push it up against the wheel
collar. Slide the remaining wheel collar on
andpushitupagainst thewheel and tighten
the set screw. The wheels should spin free
and not bind in any way.
Adjust the nose gear steering arm until the
arm is parallel with the fire wall.
Install the pushrod wire as shown.
Installing steering arm as below.
Steering arm.
Adjustable connector.
!2) Slide one 60mm diameter wheel onto
eachaxle andpush themup againstthe wheel
collars. Slidetheremainingwheelcollars with
3mm x 6mm set screws onto the axles. Push
them up against the wheels and tighten the
set screws. The wheels should spin free and
notbind inanyway. If theydobind,loosenthe
setscrews inthe outerwheelcollarsandmove
the collars out a small amount. Retighten the
set screws.
Repeat the procedure for the other
main gear wheel.
PARTSREQUIRED
NOSE GEAR INSTALLATION.
{1} Nosegear.
{1} Steering arm.
{1} Connector.
{1} Wheel.
{2} Collar.
C/Aglue.
Adjustable
connector.
INSTALLING THE MAIN GEAR WHEELS.
!1) Slide one wheel collar with 3mm x
6mm set screw onto each axle. Push the
wheel collars on as far as they will go and
tighten the set screws.
Be careful not to overtighten the set
screws. Overtightening may cause the
threads to strip.
INSTALLING THE NOSE GEAR
WHEEL.

DUAL ACE. Instruction Manual.
17
HORIZONTALSTABILIZER.
!2)Usinga modelingknife,carefullyremove
thecovering atmountingslot ofhorizontal sta-
bilizer ( both side of fuselage).
! 1) Using a ruler and a pen, locate the
centerlineofthe horizontalstabilizer,atthetrail-
ing edge, and place a mark. Use a triangle
and extend this mark, from back to front,
across the top of the stabilizer. Also extend
thismarkdown thebackof thetrailingedge of
the stabilizer.
! 3) Slidethestabilizerintoplaceinthepre-
cut slot in the rear of the fuselage. The stabi-
lizer should be pushed firmly against the front
of the slot.
Remove covering.
INSTALLING THE COWLING.
Slide the fiberglass cowl over the engine
and line up the back edge of the cowl with the
marksyou madeon thefuselage thentrim and
cut.
Correct the cow at right possition then se-
cure it in place using four 3mm x 10mm wood
screws. See picture below.
3mm X 10mm(4pcs).
3mmX10mm.
Center line.

DUAL ACE. InstructionManual.
18
! 8) After the epoxy has fully cured, re-
move the masking tape orT-pins used to hold
the stabilizer in place. Carefully inspect the
glue joints. Use more epoxy to fill in any gaps
that may exist that were not filled previously
and clean up the excess using a paper towel
and rubbing alcohol.
Covered wood
filler piece.
Remove covering.
Wood filler piece.
surementsonce morebeforetheepoxycures.
Holdthe stabilizerinplacewithT-pins ormask-
ing tape and remove any excess epoxy using
a paper towel and rubbing alcohol.
! 6) Using a modeling knife, carefully re-
move the covering that overlaps the stabilizer
mounting platform sides in the fuselage. Re-
move the covering from both the top and the
bottom of the platform sides.
! 7) When you are sure that everything is
aligned correctly, mix up a generous amount
of 30 Minute Epoxy. Apply a thin layer to the
topandbottom ofthe stabilizermountingarea
and to the stabilizer mounting platform sides
in the fuselage. Slide the stabilizer in place
and realign. Double check all of your mea
When cutting through the covering
to remove it, cut with only enough pres-
sure to only cut through the covering it-
self. Cutting into the balsa structure may
weaken it.
! 5) Remove the stabilizer. Using thelines
youjustdrew asaguide, carefullyremove the
covering from between them using a model-
ingknife.
Pen.
Removecovering.
! 4) With the stabilizer held firmly in place,
use a pen and draw lines onto the stabilizer
where it and the fuselage sides meet. Do this
on both the right and left sides and top and
bottom of the stabilizer.

DUAL ACE. Instruction Manual.
19
VERTICAL STABILIZER INSTALLATION.
!1) Slidethevertical stabilizerinto the slot
of the fuselage. The bottom edge of the stabi-
lizer should also be firmly pushed against the
top of the horizontal stabilizer.
!2) While holding the vertical stabilizer
firmly in place, use a pen and draw a line on
each side of the vertical stabilizer where it
meets the top of the fuselage.
!3) Remove the stabilizer. Using a mod-
eling knife, remove the covering from below
the lines you drew. Also remove the covering
from the bottom edge of the stabilizer and the
bottomand topedges ofthe fillerblock. Leave
the covering in place on the sides of the filler
block.
When cutting through the covering to
remove it, cut with only enough pressure
toonly cutthrough thecovering itself. Cut-
ting into the balsa structure may weaken
it.
!4) Slide the vertical stabilizer back in
place. Using a triangle, check to ensure that
theverticalstabilizer isaligned 90º tothe hori-
zontal stabilizer.
90º
Vertical
Stabilizer.
Horizontal
Stabilizer.
!5) When you are sure that everything is
alignedcorrectly,mixup agenerousamountof
Flash30 MinuteEpoxy. Applyathinlayertothe
mounting slot in the top of the fuselage and to
the sides and bottom of the vertical stabilizer
mountingarea. Apply epoxytothebottomand
top edges of the filler block and to the lower
hinge also. Set the stabilizer in place and re-
align. Double check all of your measurements
once more before the epoxy cures. Hold the
stabilizer in place with T-pins or masking tape
and remove any excess epoxy using a paper
towel and rubbing alcohol. Allow the epoxy to
fully cure before proceeding.
Pen.
Remove covering.

DUAL ACE. InstructionManual.
20
2mmx20mm.
3mmx30mm.
2 x 8mm.
! 2) Position the elevator horn on the both
sideof elevator.The clevisattach- mentholes
should be positioned over the hinge line.
ControlHorn.
MountingScrews.
MountingPlate.
3MM x30mm.
2MM x 20mm.
C/Aglueattach.
! 3) Using a 1.5mm drill bit and the control
horns as a guide, drill the mounting holes
through the elevator halves.
!
4)Mountthe controlhornsbyinsertingthe
bolts through the control horn bases and
elevator halves, then into the mounting
backplates. Do not overtighten the nuts or the
backplates may crush the wood.
! 1) Locate the three nylon control horns,
three nylon control horn backplates and six
machine screws.
M3locknut.
TAIL FAIRING - CONTROL HORN
INSTALLATION.
See pictures below:
C/Aglue.
Remove covering.
