Card Reader Specications
Model: SCM Microsystems SCR3310v2.0 — FIPS 201 Compliant
Host USB Interface: Full speed USB 2.0 (12 Mbps)
USB Bus powered device
CCID compliant
Smart Card Contact Interface: T=0, T=1 protocol support
Memory card support through SCM MCARD API
Communication speed (PPS, Fl parameter) up to 412 kbs
Frequency up to 8 MHz (PPS, Dl parameter)
Supports ISO 7816 smart card Class A, B, C
8 contacts - ISO 7816 location
Friction contact, 100,000 insertions
Human Optical Interface: One green LED
Software API Interface: PC/SC
CT-API (thru wrapper on top of PC/SC)
Functional Approvals: (FCC Class B part 15)( cULus)(CE)(VCCI)
(ICES-003 Issue4 ClassB)(USB-IF)
(Microsoft® WHQL 2000, XP, Server2003, Vista, Win7)
(EMV 2000 Level 1)
TAA Certied
Environmental Approvals: RoHS, WEEE, REACH compliance
Seal Smart™ Keyboard
with Integrated Smart Card Reader
100% Waterproof • Spillproof • Dishwasher Safe • Guaranteed
Seal Shield, LLC
Jacksonville, FL 32205
www.SealShield.com
S103R-10192011
100% Waterproof — Guaranteed
Seal Shield™ waterproof technology (Patent Pend-
ing) products are fully submersible and manufac-
tured to meet rigorous NEMA 4X and IP68 specica-
tions. Seal Shield™ products are rugged and safe
and are backed by a 2-Year Limited Warranty.
Dishwasher Safe
Seal Shield™ products are easy to clean. Just put
them in the dishwasher to thoroughly clean and dis-
infect. Convenient product features makes it fast and
easy to go straight from use to the dishwasher
for cleaning and back again.
100% Spillproof
Accidents happen. Small spills, big spills, even
complete submersion — Seal Shield™ can handle
it. Whenever accidents happen, or just to keep the
product clean, rinse it o under the faucet, soak
it in the sink, or put it in the dishwasher. Your Seal
Shield™ product comes out clean and ready to use.
Integrated Smart Card Reader
Supports ISO/IEC 7816 smart card Class A, B, C.
Now you can enjoy easy smart card access within a
keyboard that is completely washable. Ideal for hos-
pitals, military applications and other environments.
Keyboard Specications
Compatibility: Windows
Key layout: 103 (US) 105 (International)
Dimensions
L x W x H: 15.67in x 8.62in x 1.26in (39.8cm x 21.9cm x 3.2cm)
Cable Length: 6in (15cm) Quick Connect™ with USB extension cable
Connection Types: Gold-plated USB with PS/2 adapter
Key Switch: Membrane key switch with tactile feedback
Key Switch Operating Force: 55 ± 10gf
Key Switch Life Cycle: Greater than 10 million keystrokes
Keycaps Type: Laser etched
Total Key Travel: .157 ± .019 in (4±0.5mm)
Operating Voltage: + 5VDC ± 5%
EMI - RFI: Conforms to FCC rules for a Class B computing device
Approvals/Certications/Ratings: IP 68, NEMA 4X, RoHS, WEEE, CE, FCC ,TAA
Waterproof and Dustproof Ratings: 100% Waterproof and Dustproof (IP 68, NEMA 4X)
Operating Conditions: 0-50C, 0-90% Humidity (non-condensing)
Silver Seal™ Protection
This product is Silver Seal ™ protected. It contains
an antimicrobial, fungistatic agent which protects
the product and keeps it cleaner, greener and fresh-
er by inhibiting the growth of microbial bacteria,
mold, mildew and fungi on the product’s surface.
