Seal Shield SEAL TOUCH GLOW 2 S87P2 Operational manual

SEAL TOUCH GLOW 2™ All-In-One Waterproof Keyboard
• 100% Waterproof Guaranteed
• Limited Lifetime Warranty
• Silver Seal™ Antimicrobial Product Protection
• Quick Connect™ cable
• Seal Cap™ protects USB connector
• Built-in Seal Touch™ touch pad
• Lighter weight, improved tactile feel, smaller footprint
• Improved touchpad integration and keyboard layout
• Custom mounting solutions available for special orders
• Patent Pending
Product Datasheet
See back for specifications
87-SEAL-SHIELD (877-325-7443) | [email protected]
According to a University of North Carolina study, “25% of hospital
keyboards harbor the Super Bug MRSA, but daily disinfecting of the
keyboards could reduce the risk of cross contamination.” Now, the As-
sociation for Professionals in Infection Control and Epidemiology (APIC)
includes “cleaning and disinfection of keyboards” for C. Diff prevention.
The SEAL TOUCH GLOW 2™ washable ergo keyboard has been
developed to help prevent the spread of infections, including MRSA
and C. Diff. The SILVER WAVE™ keyboard is 100% waterproof and
can even be disinfected with bleach. As an added safeguard, it includes
antimicrobial product protection. The combination of waterproof tech-
nology and antimicrobial product protection achieves the highest level of
protection available in a true type keyboard today.
Model S87P2

S87P2 Seal Touch™ Silicone All-in-One Keyboard with Touch Pad
87 key layout
UV-Reinforced printed keys resist fading
Built-in touch pad for pointing and mouse functionality
Compatibility: Windows, Mac (USB models)
Key layout: 87 keys
Dimensions
L x W x H: 12.25 in. x 8.1 in. x 0.5 in.
Weight: 1.6 lbs.
Cable Length: 6in (15cm) Quick Connect™ with USB extension cable
Connection Types: Gold-plated USB
Key Switch: Carbon point activation with tactile feedback
Key Switch Operating Force: 160 ±15gf
Key Switch Life Cycle: Greater than 10 million keystrokes
Keycaps Type: UV Reinforced Printing
Total Key Travel: .07 ± .0196 in (1.6 ±0.5mm)
Operating Voltage: + 5VDC ± 5%
Power Consumption: ≤100mA
EMI - RFI: Conforms to FCC rules for a Class B computing device
Approvals/Certifications/Ratings: IP 68, NEMA 4X, RoHS, WEEE, CE, FCC
Waterproof and Dustproof Ratings: 100% Waterproof and Dustproof (IP 68, NEMA 4X)
Technical Specications
Product Datasheet
87-SEAL-SHIELD (877-325-7443) | [email protected]
Seal Shield, LLC
Jacksonville, FL 32205
Made in China
SSKSV104-06272013
Silver Seal™ Protection. This product is Silver Seal ™ protected. It contains an
antimicrobial, fungistatic agent which protects the product and keeps it cleaner, greener
and fresher by inhibiting the growth of microbial bacteria, mold, mildew and fungi on the
product’s surface.
Water Solvents Salt Water
Disinfectants Humidity Abrasives
Dust Corrosives Dirt
Sand Shock Alkaline
Alcohol Bleach Acid
Blood Heat Cold
Protects Against
Windows®/Mac®Compatible
Mac Compatibility requires OS X 10.5 or later. See product manual for details.
Mac®is a trademarks of Apple Inc., registered in the U.S. and other countries. Windows®is a registered trademark of Microsoft, Inc.
Copyright©2013, Seal Shield, LLC. All rights reserved. All brand and trade names are registered trademarks of their respective owners.
