Sealey GL54 User manual

INSTRUCTIONS FOR:
LAWN MOWER 1000W 300mm
MODEL No: GL54
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and properly
maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
GL54 Issue No: 1 - 15/01/13
Original Language Version
©Jack Sealey Limited 2013
1.1. ELECTRICAL SAFETY
WARNING! It is the responsibility of the owner and the operator
to read, understand and comply with the following: You must
check all electrical products, before use, to ensure that they are
safe. You must inspect power cables, plugs, sockets and any
other connectors for wear or damage. You must ensure that the
risk of electric shock is minimised by the installation of
appropriate safety devices. A Residual Current Circuit Breaker
(RCCB) should be incorporated in the main distribution board.
We also recommend that a Residual Current Device (RCD) is
used. It is particularly important to use an RCD with portable
products that are plugged into a supply which is not protected
by an RCCB. If in any doubt consult a qualified electrician. You
may obtain a Residual Current Device by contacting your
Sealey dealer. You must also read and understand the
following instructions concerning electrical safety.
1.1.1. The Electricity at Work Act 1989 requires that all portable
electrical appliances, if used on business premises, are tested
by a qualified electrician, using a Portable Appliance Tester
(PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of
electrical appliances responsible for the safe condition of those
appliances and the safety of the appliance operators. If in any
doubt about electrical safety, contact a qualified
electrician.
1.1.3. Ensure that the insulation on all cables and on the appliance is
safe before connecting it to the power supply. See 1.1.1. and
1.1.2. and use a Portable Appliance Tester.
1.1.4. Ensure that cables are always protected against short circuit
and overload.
1.1.5. Regularly inspect power supply cables and plugs for wear or
damage and check all connections to ensure that none are
loose.
1.1.6. Important: Ensure that the voltage marked on the appliance
matches the power supply to be used and that the plug is fitted
with the correct fuse - see fuse rating below.
1.1.7. DO NOT pull or carry the appliance by the power cable.
1.1.8. DO NOT pull the plug from the socket by the cable.
1.1.9. DO NOT use worn or damaged cables, plugs or connectors.
Immediately have any faulty item repaired or replaced by a
qualified electrician. When a BS 1363/A UK 3 pin plug is
damaged, cut the cable just above the plug and dispose of the
plug safely.
Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/YELLOW earth wire to the earth
terminal ‘E’.
b) Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal
‘N’.
d) After wiring, check that there are no bare wires, that
all wires have been correctly connected, that the cable
outer insulation extends beyond the cable restraint and
that the restraint is tight.
Double insulated products, which are always marked with this
symbol , are fitted with live (brown) and neutral (blue) wires
only. To rewire, connect the wires as indicated in diagram.
DO NOT connect either wire to the earth terminal.
1.1.10. Some products require more than a 13 amp electrical supply. In
such a case, NO plug will be fitted. You must contact a qualified
electrician to ensure a 30 amp fused supply is available. We
recommend you discuss the installation of a industrial round pin plug
and socket with your electrician.
1.1.11. Cable extension reels.
When a cable extension reel is used it should be fully unwound
before connection. A cable reel with an RCD fitted is
recommended since any product which is plugged into the
cable reel will be protected. The section of the cores of the
cable is important. We suggest 1.5mm² section cable as a
minimum, but to be absolutely sure that the capacity of the
cable reel is suitable for this product and for others that may be
used in the other output sockets, we recommend the use of
2.5mm² section cable.
1.2. GENERAL SAFETY
3 Familiarise yourself with the controls and limitations of the
mower. This is a portable electric appliance, use an RCD.
3 Ensure the mower is in good order and condition before use. If
in any doubt electrically do not use the unit and contact an
electrician/service agent.
WARNING! The mower must only be serviced by an
authorised agent (except for blade replacement).
3 Maintain the mower in good condition and replace any
damaged or worn parts. Use genuine parts only.
Unauthorised parts may be dangerous and will invalidate
your warranty.
3 Inspect the lawn prior to cutting, removing obstructions including
molehills.
3 Keep children and unauthorised persons away from the
working area
7 DO NOT use this product to perform a task for which it has
not been designed. Grassed lawns only.
3 Wear safety glasses, ear defenders and in dusty conditions a
face mask.
7 DO NOT operate the hover mower barefoot or wearing open
sandles, always wear substantial footwear and long trousers.
7 DO NOT carry the mower by the cable or pull the cable to
disconnect from mains.
7 DO NOT start the mower with blades fully exposed.
7 DO NOT put your hands or feet under the cutter deck.
3 Mow only in daylight or good artificial light.
3 Avoid mowing when grass is wet, never when raining.
3 Extra care is required when mowing slopes, be sure of your
footing. Hint-: Starting at the top of the slope, mow with a
sweeping arc action from side to side across the face, not up
and down the slope.
3 Keep the cable away from the cutter deck.
3 Switch off the mower, wait for blades to stop rotating and
remove plug from socket to carry out any user tasks such as
leaving unattended,clearing, cleaning, transporting, storing and
inspecting.
3 If used with an extension lead, seek advice from a qualified
electrician on cable insulation, sizes and lengths.
RECOMMENDED
FUSE RATING:
5 AMP
3. CONTENTS AND ASSEMBLY
3.1. Check that you have all the above details in the packaging.
In the unlikely event of any missing or damaged parts,
contact your Sealey Dealer immediately. Retain the
packaging.
3.2 Assembly:- (no tools required except cross head
screwdriver)
3.2.1 Loop the cable strain relief hook (item 3) on to the upper
handle tubular frame (item 1) in the position indicated.
3.2.2. Thread the mains cable as illustrated in fig.1 through the
cable strain relief hook (item 3). This is an important safety
feature preventing the mains cable from being accidentally
pulled from switch connections.
3.2.3. Fit the lower handle frames (item 2) into the holes of the
cutter deck (item 6) full depth. Use the supplied cross head
self tapping screws (item 8) to secure through the
pre-punched holes.
3.2.4. Fit the upper handle sub assembly (item 1) containing the
switch and cable to the lower handle (item 2) paying
attention to the cable run. There is a choice of two positions
50mm apart. Clamp the frame with (item 5) details, see fig.
2.
3.2.5 Position the three cable clips (item 4), clip to tubular frame
and finally clip the cable which runs from motor to switch.
3.2.6 Attach grass box if required (item 7) to tabs located beneath
spring loaded hinged panel, see fig.5, fig.6 and fig.7.
3.3 Blade fitting:- (spanner supplied)
3.3.1 Decide on the grass cutting length required, a choice of
3 are available, 26mm, 41mm and 56mm approximate grass
length settings. In fig.4 the wheel spindle is shown at the
26mm setting. Each wheel requires adjusting equally. A
tension spring retains the spindle into the chosen slot.
3.3.2 To remove the blade, hold the blade with a gloved hand and
undo the centre bolt with the supplied plastic spanner.
3.3.3. Refit or change the blade by the opposite approach and
tighten the centre bolt with the supplied plastic spanner, this
should avoid over torqueing.
NOTE: The blade will only fit one way, see fig.3 observing
stamped arrow. The retaining bolt has a standard RH thread.
WARNING! Never use blades other than the spares
supplied by your Sealey Dealer.
fig.1
2. INTRODUCTION & SPECIFICATION
Model No: .................................................................................... GL54
Drive Type: .................................................................. Hand Operated
Cutting Width:.................................................................. 300mm (12")
Cutting Deck Cover: ..............................Plastic Moulding (Composite)
Supply:................................................................................230V - 1ph
Power: ...................................................................................... 1000W
Three setting heights:.................. 26mm/41mm/56mm approximately
Grass Box Collection Capacity:.....................................................30ltr
Cable Length: ................................................................................10m
Cutting Blades: ......................................................Mild Steel (painted)
Ingress Protection: ....................................................................... IPX4
Weight: .........................................................................................14kg
Measured Sound Power Level: ................................................. 87dBA
Guaranteed Sound Power Level: .............................................. 96dBA
Vibration Level:.......................................................................2.13m/s²
No Load Speed: ....................................................................2800/rpm
GL54 Issue No: 1 - 15/01/13
Original Language Version
©Jack Sealey Limited 2013
Electric hand-propelled lawn mower with a 300mm (12") cutting width.
Composite deck for lightweight durability. 1000W Motor combined with
an emergency cut-out switch for safety. Cutting height can be adjusted
between 26-56mm (3 positions) and has a 30ltr rear collection box.
Supplied with 10m mains cable with BS plug. Folding handle and 14kg
weight enable easy storage.
This is a class II appliance and does not need an earth connection.
Cable strain
relief hook.
Cable clip
Power lever
Safety Button &
Switch Housing
Mains Cable
Tubular Handle
ITEM DESCRIPTION QTY
1 Upper handle sub assembly 1
2 Lower handle frame 2
3 Cable strain relief hook 1
4 Cable clips 3
5 Handle clamp c/w bolt and washer 2
6 Cutter deck c/w motor, wheels and blade 1
7 Grass box 1
8 Crossheadscrews(lowerhandlexings) 2
9 Blade spanner 1
1
5
2,8
4
7
3 (see
g.1)
fig.2
50mm
Two available frame height settings (50mm).
Washer
6
See section 7
Warning symbols.
fig.3
Direction of
rotation mark
Blade orientation and direction of rotation.
Bladexingbolt(RHthread)
4. OPERATION
NOTE: This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance by a
person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
4.1 With the instructions to this stage read and the mower
assembled, plug the mains cable into an RCD protected and
isolated 230V AC supply.
4.2 With the mower cutter face down on the lawn to be cut, switch
on the supply. Nothing will happen until the safety (inhibit)
button has been depressed and the power lever gripped.
4.3 Now positioned at the mower handle and the cable clear of the
cutter deck, using the tubular handle frame, tip the whole
mower approximately 10° raising the cutter blade off the lawn.
Depress the safety button with one hand and hold, nothing will
happen until the power lever is gripped with the other hand.
4.4 With the motor running at full speed release the safety button,
maintaining grip on the power lever and lower the blade on to
the lawn.
4.5 Release grip on power lever to stop the motor. The blade
will rotate for a few seconds after the motor has stopped.
Mowing tip-: To prevent accidentally running over the lead with
cutter deck, trail the mains lead over one shoulder and hold
with the hand of the other shoulder. Alternate with operating
mower with both hands, always keeping the lead on your
shoulder.
5. MAINTENANCE
5.1 Ensureallxingsaretightandsecure.
5.2 Replace any damaged or worn parts immediately.
5.3 Check blade during and after each use, see section
3.3.2. for removal.
5.4 Check cable clips and cable runs, especially the strain relief
hook loop, mains plug and switch connections .
5.5 There are no customer serviceable parts other than the
 bladesandframexings,usequaliedservicepersonnelfor
all other aspects of maintenance.
5.6 Cleaning
5.6.1 After each use, with mower power unplugged from mains
supply, clear accumulated grass cuttings from inside cutter
deck. DO NOT allow the grass to dry on the mower.
5.6.2 Clearanyaccumulatedgrasscuttingsfromtheairwayutes
in blade hub impellor.
5.6.3 Cleananygrasscuttingsfromtheyinglead.
5.6.4 Clean the mower externally before storing with special
 attentiontograssboxslots,whichcouldaffectairowand
grass collection rate.
6. TROUBLESHOOTING
6.1 Mower fails to operate
6.1.1 Check that the power is on.
6.1.2 Check that the start up procedure has been followed, safety
button pressed and power lever operated. See section 4.
6.1.3 Check the 5amp fuse in the plug. If blown, replace. If it
 continuestoblow,themowermustbecheckedbyaqualied
electrician.
6.2 Poor grass collection.
6.2.1 Disconnect from the mains electricity supply.
6.2.2 Clean the outside of the air intakes, the discharge chute and
 theundersideofthedeck,seeg.3.
6.2.3 Clear grass box slots of solids.
6.2.4 Motor not running full speed with no load. This can only be
 checkedbyqualiedpersonnel,consultyourSealeyDealer.
6.3 Excessive vibration.
6.3.1 Disconnect from mains supply.
6.3.2 Checkthatbladeisttedcorrectly.
6.3.3 Damaged blade, replace.
6.3.4 If excessive vibration persists, discontinue use and seek
advice from your Sealey Dealer.
Grassbox location notches.
(employ either way up)
Cutting depth adjustment.
Lift spring loaded hinged stone
guardpaneltotgrassbox.
(2 tabs along top of opening)
GL54 Issue No: 1 - 15/01/13
Original Language Version
©Jack Sealey Limited 2013
fig.4 fig.5
fig.6 fig.7
GL54 Issue No: 1 - 15/01/13
Original Language Version
©Jack Sealey Limited 2013
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
sales@sealey.co.uk
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
7. MOWER WARNING SYMBOLS
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500.
Environmental Protection.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycle centre and disposed of in a manner which
is compatible with the environment.
WEEE Regulations.
Dispose of this product at the end of its working life in compliance
with the EU Directive on Waste Electrical and Electronic Equipment.
When the product is no longer required, it must be disposed of in an
environmentally protective way. Contact your local solid waste
authority for recycling information.
The mower should be used with due care. Symbols placed strategically on various parts of the machine reminds the user of the main
precautions to be taken at point of operation. Symbols and meanings are listed below. These meanings also add emphasis to the safety
regulations and safety information given in earlier sections of these instructions
Caution! Keep the mains cable
clear of cutting blade
Switch off the motor and disconnect
the mains plug before carrying out
adjustment or cleaning work or if
the mains lead has been snagged
or damaged.

Other Sealey Lawn Mower manuals

Sealey GL112 User manual

Sealey

Sealey GL112 User manual

Sealey GL109 User manual

Sealey

Sealey GL109 User manual

Sealey GL53 Firmware update

Sealey

Sealey GL53 Firmware update

Sealey GL110 User manual

Sealey

Sealey GL110 User manual

Sealey GL111 User manual

Sealey

Sealey GL111 User manual

Popular Lawn Mower manuals by other brands

MTD 600 Series Operator's manual

MTD

MTD 600 Series Operator's manual

Simplicity 1691704 parts manual

Simplicity

Simplicity 1691704 parts manual

Poulan Pro 187570 owner's manual

Poulan Pro

Poulan Pro 187570 owner's manual

Craftsman 917.272245 owner's manual

Craftsman

Craftsman 917.272245 owner's manual

Husqvarna ZTH5223 Workshop manual

Husqvarna

Husqvarna ZTH5223 Workshop manual

McCulloch PRE5553 instruction manual

McCulloch

McCulloch PRE5553 instruction manual

Makita BLM430 instruction manual

Makita

Makita BLM430 instruction manual

Toro 75746 Operator's manual

Toro

Toro 75746 Operator's manual

Swisher ZT1436B, ZT18542, ZT2250 owner's manual

Swisher

Swisher ZT1436B, ZT18542, ZT2250 owner's manual

Husqvarna LZ12597 instruction manual

Husqvarna

Husqvarna LZ12597 instruction manual

Poulan Pro PB19546LT Operator's manual

Poulan Pro

Poulan Pro PB19546LT Operator's manual

Craftsman CMXGMAM201202 user manual

Craftsman

Craftsman CMXGMAM201202 user manual

Dixon ZTR 966504101 Operator's manual

Dixon

Dixon ZTR 966504101 Operator's manual

Ariens 915213 - Zoom 42 Operator's manual

Ariens

Ariens 915213 - Zoom 42 Operator's manual

Snapper C21500KWV Safety instructions & operator's manual

Snapper

Snapper C21500KWV Safety instructions & operator's manual

FERRI TKD Maintenance and use manual

FERRI

FERRI TKD Maintenance and use manual

Murray 385011x50A Instruction book

Murray

Murray 385011x50A Instruction book

Sabo 52-S A Operator's manual

Sabo

Sabo 52-S A Operator's manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
