Sealey LED100WS User manual

20W COB LED R/CHARGE WIRELESS
SPEAKER WORK LIGHT+POWER BANK
MODEL NO: LED100WS
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9Ensure the lamp is fully charged before initial use.
8DO NOT charge in damp conditions.
8DO NOT turn the lamp on when it is being charged.
8DO NOT shine directly into your, another person’s or an animal’s eyes.
8DO NOT allow children to use the lamp.
8DO NOT handle or move the lamp whilst it is being charged.
8DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8DO NOT attempt to open, disassemble, modify or service the battery pack.
8DO NOT crush, puncture, short external contacts or dispose of in re or water.
8DO NOT expose to temperatures above 60°C (140°).
9Replace only with the battery pack designated for this product.
9Recycle or dispose of used battery as stipulated by local regulation.
9If the electrolyte in the cells gets on your skin or eyes, rinse thoroughly with water.
8DO NOT connect your small devices to charge while the power bank is in the process of charging.
8DO NOT immerse in water.
8DO NOT place near a re or any other source of intense heat – battery could explode if heated.
9Battery must be recycled or disposed of according to local regulations.
2. INTRODUCTION
3-in-1 Function work light made of a strong nylon plastic with thermoplastic rubber edges for durability. Features an ultra bright 20W COB LED
light producing up to 1100 lumens with three light settings: High 1100lm, Mid 580lm, Low 350lm (working time: 3, 5 and 15 hours respectively).
Work light also includes two good quality wireless speakers which can be easily linked to your tablet or smartphone. Fixed to the rear is a
sturdy 180° adjustable stand which can also be used as a carry handle. Has four strong magnets on the back for easy mounting to metal
applications such as a tool chest. Built-in power bank with a USB output and LED charge indicator. Micro USB charging lead included.
3. SPECIFICATION
Model No: ............................................................LED100WS
Battery: ........................................................3.7V 8Ah Li-poly
Charging Time:.............................................................8-10hr
LED Qty: ........................................................ 20W COB LED
Lumen Output: ............................................................1100lm
Nett Weight: ................................................................... 790g
Running Time:..............................................................3-15hr
Speaker Output:............................................................. 85db
USB Output:............................................................... 5V / 1A
SpeakerLight
g.1
LED100WS Issue 1 20/02/19
Original Language Version
© Jack Sealey Limited
Refer to
instructions

4. OPERATION
NOTE: Charge before rst use, see section 4.5.
4.1. TO TURN ON THE LIGHT: (FIG.2)
4.1.1. Short press the main power button
to turn the light On/O󰀨.
4.1.2. There are 3 lighting modes: high, mid
and low. Keep pressing the
button until you reach the desired
setting.
4.2. TO CONNECT A WIRELESS
ENABLED DEVICE (FIG.2)
4.2.1. Press and hold the wireless activation
button for a couple of seconds until
wireless-on tone is heard.
4.2.2. You can connect and play music
from your mobile phone, tablet or other portable audio device. Keep the button pressed to turn o󰀨.
4.3. TO ADJUST VOLUME: (FIG.2)
4.3.1. Press and hold plus (+) button to increase volume. Press and hold minus (-) button to reduce volume.
4.4. TO MOVE FORWARD OR BACKWARD IN YOUR PLAYLIST: (FIG.2)
4.4.1. Short press plus (+) button to move to the next song. Short press minus (-) button to go to the previous song.
4.5. TO CHARGE THE LIGHT: (FIG.3)
4.5.1. Open the transparent cover on the back of the
device. Plug a micro USB cable into the ‘5V’ input
and connect it to a power adaptor, home
computer, laptop, etc. The indicator light will
be on to show the power capacity. 3 blue LEDs are
on when it is fully charged.
4.6. TO CHARGE YOUR SMALL DEVICES: (FIG.3)
4.6.1. Plug a USB cable into the ‘5V’ Output at the base
of the light and connect it to your mobile phone,
camera, etc.
WARNING! DO NOT connect your small devices to charge while the power bank is being charged.
Light On/Off
Wireless Activation
(Hold)Volume up
(Press) Forward Skip (+)
(Press) Backwards Skip (-)
(Hold) Volume Down
g.2
5V Charger Input
Indicator lights
USB Output Socket
g.3
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
LED100WS Issue 1 20/02/19
Original Language Version
© Jack Sealey Limited
