Network Megapixel Dome IR Camera
Technical Manual

Datascrip technical manuals
©2011 – 2012 by SECURE. All rights reserved.
2
SNDI-813V
Key Features
 Up to 1.3 megapixel (1280 × 960) resolution
 Standard video compression with high compression ratio
 Progressive scan CMOS, capture motion video without incised margin
 Support dual stream, and the sub-stream for mobile surveillance
 High-performance and long service life Infrared LED, Approx. 10 to 30 meters IR range
 IR cut filter with auto switch
 Two-way audio
 PoE (Power over Ethernet)
 Ingress Protection level: IP66
 Auto-iris, electronic shutter for different surveillance environments
 Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10
 Other functions: heartbeat, alarm, reset button, mirror, etc.
Specification
Model
Parameter
SNDI-813V
1.3 Megapixel CMOS ICR Infrared Network Bullet Camera
Camera
Image Sensor 1/3" Progressive Scan CMOS
Min. Illumination 0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
0.028 Lux @ (F2.0, AGC ON) ,0 Lux with IR

Datascrip technical manuals
©2011 – 2012 by SECURE. All rights reserved.
3
Shutter Speed 1/25 s to 1/100,000 s
Lens
6mm@ F2.0, Angle of view:45.3°
(2.8mm、4mm、12mm optional)
Lens Mount M12
Day &Night IR cut filter with auto switch
Digital Noise
Reduction 3D DNR
Angle Adjustment Pan:0° - 355°, Tilt: 0° - 65°
Compression Standard
Video Compression H.264/ MJPEG
H.264 Type Main Profile
Video Bit Rate 32 Kbps – 16 Mbps
Dual Stream Yes
Max. Resolution 1280 x 960
Frame Rate 50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720)
60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720)
Image Settings Saturation, Brightness, Contrast adjustable by client software or web
browser
Backlight
compensation Yes, zone optional
Network
Network Storage NAS (iSCSI optional)
Alarm Trigger Motion detection, Tampering alarm, Storage exception
Protocols TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,UPnP,
ICMP,IGMP,SNMP, FTP, 802.1x, QoS, HTTPS ( SIP,SRTP,IPv6 optional )
Security User Authentication
Standard ONVIF, PSIA, CGI
Interface
Communication
Interface 1 RJ45 10M/100M Ethernet interface
Reset Button Yes
General
Operating Conditions -10 °C – 60 °C (14 °F – 140 °F)
Humidity 95% or less (non-condensing)
Power Supply 12 V DC ± 10%
PoE (802.3af)
Power Consumption Max. 5 W

Datascrip technical manuals
©2011 – 2012 by SECURE. All rights reserved.
4
Ingress Protection
level IP66
IR Range Approx. 10 to 30 meters
Impact Protection IEC60068-2-75Eh, 50J; EN50102, up to IK10
Dimensions Φ111 × 82 (4.4” × 3.2”)
Weight 500g (1.1 lbs)
Order Models
SNDI-813V
Dimensions
