Security Camera King NVR-EL-16 User manual
16CH NVR’s - Manual
NVR-EL-16
NVR-ELC-16
NVR-ELC-16-POE16
NVR-ELM-16
NVR-ELT-16
1080p
Resolution
3yr
Warranty
Our NVR will record up to 16 individual IP based cameras up to 2 Megapixel (1080P) resolutions simultaneously. Our NVR oers you a variety of recording resolutions,
adjustable frame rates, interchangeable on all of our channels.
Our 16 channel Elite Mini NVR starts o with an innovative system designed specically for high quality IP network camera capturing and the ability to easily handle the work
load. We accomplish this by using a state-of-the-art dual core microprocessor that utilizes an embedded Linux operating system. We've found that as far as our video
recorders are concerned, the Linux OS is rock-solid. We also added an embedded digital signal processor (DSP), a dual logarithm CODEC (H.264 and MPEG-4) for recording
eciency and a built in web server. To make things convenient for you, we have also implemented an IP Search feature in the OSD to automatically discover your cameras on
the network.
Were condent you’ll be amazed with the quality and performance of our 16CH NVR’s. In fact we are so condent that you'll be satised with this Mini NVR that we back it
with 100% free lifetime technical support with a full 3 year warranty. Contact our support department with your issues or questions and we will be glad to oer our assistance
to help you resolve them. In most instances we may even be able to remotely set up your unit and/or solve your problem.
Motion
Activated
Recording
PTZ
Control
i
Table of Contents
1Features and Specifications ...............................................................................................................1
1.1 Overview........................................................................................................................................1
1.2 Features.........................................................................................................................................1
1.3 Specifications................................................................................................................................2
1.3.1 21/21-P/21-S Series..............................................................................................................2
1.3.2 21H Series..............................................................................................................................3
1.3.3 22 Series.................................................................................................................................5
1.3.4 24 Series.................................................................................................................................6
1.3.5 31H Series..............................................................................................................................8
1.3.6 NVR-ELT-16 Series..............................................................................................................9
1.3.7 NVR-ELM-16 Series .........................................................................................................11
1.3.8 32V/32V-P Series................................................................................................................12
1.3.9 34V/34V-P Series................................................................................................................14
1.3.10 38 Series...............................................................................................................................15
1.3.11 50 Series...............................................................................................................................17
1.3.12 52/52-P Series .....................................................................................................................18
1.3.13 NVR-ELC-16 Series .....................................................................................................20
1.3.14 NVR-EL-16...............................................................................................................................21
2Front Panel and Rear Panel .............................................................................................................24
2.1 Front Panel..................................................................................................................................24
2.1.1 NVR-ELT-16 Series ............................................................................................................24
2.1.2 21H Series............................................................................................................................24
2.1.3 31H Series............................................................................................................................25
2.1.4 NVR-EL Series .....................................................................................................................27
2.1.5 50 Series...............................................................................................................................29
2.1.6 22/32-8P/52/52-P Series....................................................................................................30
2.1.7 NVR-ELC-16 Series................................................................................................31
2.1.8 32V/32V-P Series ................................................................................................................33
2.1.9 34V/34V-P Series ................................................................................................................34
2.1.10 NVR-EL-16.........................................................................................................................36
2.2 Rear Panel ..................................................................................................................................38
2.2.1 21/21-P/21-S Series............................................................................................................38
2.2.2 21H/21H-P/31H/31H-P Series...........................................................................................39
2.2.3 22 Series...............................................................................................................................41
2.2.4 24 Series...............................................................................................................................41
2.2.5 NVR-ELT-16 Series............................................................................................................43
ii
2.2.6 32 Series...............................................................................................................................44
2.2.7 NVR-EL Series ...............................................................................................................45
2.2.8 32V/32V-P Series ................................................................................................................47
2.2.9 34V/34V-P Series ................................................................................................................50
2.2.10 38 Series...............................................................................................................................52
2.2.11 50 Series...............................................................................................................................54
2.2.12 52 Series...............................................................................................................................56
2.2.13 52-P Series............................................................................................................................57
2.2.14 NVR-ELC-16 Series .....................................................................................................59
2.2.15 NVR-EL-16 ...............................................................................................................................62
2.3 Alarm Connection.......................................................................................................................63
2.4 Bidirectional talk .........................................................................................................................64
2.4.1 Device-end to PC-end ........................................................................................................64
2.4.2 PC-end to the device-end ..................................................................................................64
2.5 Mouse Operation........................................................................................................................65
3HDD Installation..................................................................................................................................67
3.1 NVR-ELT-16 Series....................................................................................................................67
3.2 NVR-ELM Series............................................................................................68
3.3 32V/32V-P/34V/34V-P Series ..................................................................................................68
3.4 50 Series......................................................................................................................................69
3.5 NVR-ELC & NVR-EL-16 Series...............................................................................................70
4Network Connection ..........................................................................................................................71
5GUI Operation.....................................................................................................................................72
5.1 Login.............................................................................................................................................72
5.2 Right Click Menu ........................................................................................................................74
5.3 Main Menu...................................................................................................................................75
5.4 Search & Playback.....................................................................................................................75
5.5 Information ..................................................................................................................................79
5.5.1 HDD Information..................................................................................................................80
5.5.2 BPS........................................................................................................................................81
iii
5.5.3 Log.........................................................................................................................................82
5.5.4 Version ..................................................................................................................................83
5.5.5 Online Users.........................................................................................................................83
5.5.6 Remote Device Information ...............................................................................................84
5.5.7 Network Info .........................................................................................................................85
5.5.7.1 Network Test................................................................................................................85
5.5.7.2 Network Load..............................................................................................................86
5.6 Setting..........................................................................................................................................86
5.6.1 General .................................................................................................................................87
5.6.2 Encode..................................................................................................................................89
5.6.3 Schedule...............................................................................................................................91
5.6.3.1 Quick Setup.................................................................................................................92
5.6.4 RS232 ...................................................................................................................................93
5.6.5 Network.................................................................................................................................93
5.6.5.1 Network Setting ..........................................................................................................95
5.6.5.2 IP Filter.........................................................................................................................95
5.6.5.3 NTP Setup...................................................................................................................96
5.6.5.4 Multicast.......................................................................................................................97
5.6.5.5 PPPoE..........................................................................................................................98
5.6.5.6 DDNS ...........................................................................................................................98
5.6.5.7 UPNP .........................................................................................................................100
5.6.5.8 WIFI Setting...............................................................................................................101
5.6.5.9 Email ..........................................................................................................................103
5.6.5.10 FTP.............................................................................................................................104
5.6.5.11 Alarm center..............................................................................................................106
5.6.5.12 SNMP.........................................................................................................................106
5.6.5.13 Auto register..............................................................................................................107
5.6.6 Alarm ...................................................................................................................................108
5.6.7 Detect..................................................................................................................................111
5.6.7.1 Motion Detect............................................................................................................112
5.6.7.2 Video Loss.................................................................................................................114
5.6.7.3 Camera Masking ......................................................................................................114
5.6.8 PTZ......................................................................................................................................115
5.6.9 Display ................................................................................................................................117
5.6.10 Default.................................................................................................................................118
5.6.11 Remote Device ..................................................................................................................119
5.6.11.1 UPNP .........................................................................................................................119
5.6.11.2 Built-in Switch Setup................................................................................................119
5.6.11.3 Remote Device .........................................................................................................119
5.6.11.4 Short-cut Menu .........................................................................................................122
5.7 Advanced...................................................................................................................................123
5.7.1 HDD Management.............................................................................................................124
5.7.2 Abnormality.........................................................................................................................126
5.7.3 Alarm Output ......................................................................................................................127
iv
5.7.4 Manual Record...................................................................................................................127
5.7.4.1 Manual record menu................................................................................................128
5.7.4.2 Basic operation.........................................................................................................128
5.7.4.3 Enable/disable record..............................................................................................128
5.7.4.4 Enable all channel recording ..................................................................................128
5.7.4.5 Stop all channel recording.......................................................................................129
5.7.5 Account ...............................................................................................................................130
5.7.5.1 Modify Password ......................................................................................................131
5.7.5.2 Add/Modify Group ....................................................................................................131
5.7.5.3 Add/Modify User.......................................................................................................132
5.7.6 Auto Maintenance .............................................................................................................132
5.7.7 Config Backup....................................................................................................................133
5.8 Shutdown...................................................................................................................................133
6Quick Configuration Tool.................................................................................................................135
6.1 Overview....................................................................................................................................135
6.2 Operation...................................................................................................................................135
7Web Operation..................................................................................................................................138
7.1 General Introduction ................................................................................................................138
7.1.1 Preparation.........................................................................................................................138
7.1.2 Log in...................................................................................................................................139
7.2 LAN Mode..................................................................................................................................140
7.2.1 Monitor Channel Menu Tree............................................................................................141
7.2.2 System Menu .....................................................................................................................144
7.2.3 Monitor Window Switch ....................................................................................................144
7.2.4 PTZ Control........................................................................................................................144
7.2.5 Color and More Setup.......................................................................................................146
7.3 WAN Login ................................................................................................................................147
7.4 Configuration.............................................................................................................................149
7.4.1 System Information ...........................................................................................................149
7.4.1.1 Version Information ..................................................................................................149
7.4.1.2 HDD information.......................................................................................................150
7.4.1.3 Log..............................................................................................................................150
7.4.2 System Configuration .......................................................................................................151
7.4.2.1 General Setup...........................................................................................................151
7.4.2.2 Encode.......................................................................................................................153
7.4.2.3 Schedule....................................................................................................................154
7.4.2.4 RS232 ........................................................................................................................156
v
7.4.2.5 Network......................................................................................................................157
7.4.2.6 Alarm..........................................................................................................................165
7.4.2.1 Detect.........................................................................................................................167
7.4.2.2 PTZ.............................................................................................................................168
7.4.2.3 Default & Backup......................................................................................................169
7.4.3 Advanced............................................................................................................................170
7.4.3.1 HDD Management ...................................................................................................170
7.4.3.2 Abnormity...................................................................................................................171
7.4.3.3 Alarm I/O....................................................................................................................172
7.4.3.4 Record........................................................................................................................173
7.4.3.5 Account......................................................................................................................173
7.4.3.6 Snapshot....................................................................................................................175
7.4.3.7 Auto Maintenance ....................................................................................................175
7.4.3.8 Remote device..........................................................................................................176
7.4.3.9 Preview Control.............................................................................................................177
7.4.4 Additional Function............................................................................................................178
7.4.4.1 IPC Config .................................................................................................................178
7.4.4.2 Auto register..............................................................................................................180
7.4.4.3 Mobile Config ............................................................................................................180
7.4.4.4 WIFI Config ...............................................................................................................181
7.5 Search........................................................................................................................................182
7.6 Alarm..........................................................................................................................................185
7.7 About..........................................................................................................................................187
7.8 Log out .......................................................................................................................................187
8FAQ ....................................................................................................................................................188
9Appendix A HDD Capacity Calculation.........................................................................................193
10 Appendix B Compatible SATA HDD..........................................................................................194
11 Appendix C Compatible USB2.0 List ........................................................................................199
12 Appendix D Compatible Displayer List......................................................................................201
Appendix H Toxic or Hazardous Materials or Elements.....................................................................202
vi
Welcome
Thank you for purchasing our network video recorder!
This user’s manual is designed to be a reference tool for your system.
Please open the accessory bag to check the items one by one in accordance with the list below.
Contact your local retailer ASAP if something is missing or damaged in the bag.
vii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
We assume no liability or responsibility for all the fires or electrical shock caused by improper
handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the NVR before completing installation.
Do not place objects on the NVR
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
The NVR should be installed in a cool, dry place away from direct sunlight, inflammable, explosive
substances and etc.
This series product shall be transported, storage and used in the specified environments.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
7. Lithium battery
Improper battery use may result in fire, explosion, or personal injury!
When replace the battery, please make sure you are using the same model!
Before your operation please read the following instructions carefully.
z Installation environment
Keep away from extreme hot places and sources；
Avoid direct sunlight；
Keep away from extreme humid places；
Avoid violent vibration；
Do not put other devices on the top of the NVR；
Be installed in well ventilated place; do not block the vent.
z Accessories
viii
Check the following accessories after opening the box：
z Please refer to the packing list in the box *
1
1Features and Specifications
1.1 Overview
This series NVR is a high performance network video recorder. This series product support local
preview, multiple-window display, recorded file local storage, remote control and mouse shortcut
menu operation, and remote management and control function.
This series product supports centre storage, front-end storage and client-end storage. The
monitor zone in the front-end can be set in anywhere. Working with other front-end devices such
as IPC, NVS, this series product can establish a strong surveillance network via the CMS. In the
network system, there is only one network cable from the monitor centre to the monitor zone in
the whole network. There is no audio/video cable from the monitor centre to the monitor zone. The
whole project is featuring of simple connection, low-cost, low maintenance work.
This series NVR can be widely used in many areas such as public security, water conservancy,
transportation and education.
1.2 Features
User
Management
•Each group has different management powers that can be edited freely.
Every user belongs to an exclusive group.
Storage
•Via corresponding setup (such as alarm setup and schedule setup), you
can backup related audio/video data in the network video recorder.
•Support Web record and record local video and storage the file in the
client end.
Alarm
•Respond to external alarm simultaneously (within 200MS), based on
user’s pre-defined relay setup, system can process the alarm input
correctly and prompt user by screen and voice (support pre-recorded
audio).
•Support central alarm server setup, so that alarm information can
remotely notify user automatically. Alarm input can be derived from
various connected peripheral devices.
•Alert you via EMAIL.
Network
Monitor
•Through network, sending audio/video data compressed by IPC or NVS
to client-ends, then the data will be decompressed and display. If
bandwidth is big enough, latency is less than 500ms
•Support max 10 connections
•Transmit audio/video data by HTTP, TCP, UDP, MULTICAST,
RTP/RTCP and etc.
•Transmit some alarm data or alarm info by SMTP.
•Support WEB access in WAN.
Window Split •Adopt the video compression and digital process to show several
windows in one monitor. Support 1/4/8/9/16-window display.
Record
•Support schedule record function. Save the recorded files in the HDD,
client-end PC, or network storage server. You can search or playback
the saved files at the local-end or via the Web.
2
Backup
•Support network backup, USB2.0 record backup function, the recorded
files can be saved in network storage server, peripheral USB2.0
device, burner and etc.
Network
Management
•Supervise NVR configuration and control power via Ethernet.
•Support management via WEB.
Peripheral
Equipment
Management
•Support peripheral equipment management such as protocol setup and
port connection.
•Support transparent data transmission such as RS232 (RS-422), RS485
(RS-485).
Auxiliary
•Support switch between NTSC and PAL.
•Support real-time system resources information and running statistics
display.
•Support log file.
•Local GUI output. Shortcut menu operation via mouse.
•IR control function. Shortcut menu operation via remote control.
•Support IPC or NVS remote video preview and control.
1.3 Specifications
1.3.1 21/21-P/21-S Series
SpecificationsParameter
21 Series 21-S Series 21-P Series
System
Resources
Max support 8-ch standard definition with the transmission rate of 2Mbps for each
channel;
4-channel 720P, with the transmission rate of 4Mbps for each channel;
2-channel 1080P, with the transmission rate of 8Mbps for each channel;
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Video
Compression
H.264/MJPEG
Encode
Capacity
For H.264, it max supports 8-channel D1, 4-channel 720P, 2-channel 1080P.
Audio
Compression
G.711a
Video Output 1-channel VGA analog video output.
Video Input 4/8-ch network compression video input
HDMI 1-ch HDMI output.
Audio Input N/A
Audio Output N/A
Window Split 1/4/9-window
3
Multiple-chann
el Playback
Max 8-channel D1/4-channel 720P/2-channel 1080P playback.
Alarm Input N/A
Alarm Output N/A
Storage 1 built-in SATA ports.
RS232 Port One RS232 port to debug transparent COM data.
RS485 port N/A
USB2.0 Port 2 peripheral USB2.0 ports. One at the front panel and one at the rear panel.
Network
Connection
One RJ45 10/100Mbps self-adaptive Ethernet port.
Power Port One power port, power adapter. Input DC 12V. Two power ports, power
adapter. Input DC 12V or
DC 48V.
Power Button No on/off button. Connect to the power cable to boot up.
Power Button N/A
Clock Built-in clock.
Indication Light One power status indication light.
One network status indication light.
One HDD status indication light.
Power
Consumption
＜12W(Exclude HDD)
Working
Temperature
0℃～+50℃
Working
Humidity
10℅－90℅
Air pressure 86kpa－106kpa
Dimension 205mm×205mm×52mm
Weight 0.5~1KG（Exclude HDD）
Installation Desk installation
1.3.2 21H Series
SpecificationsParameter
210XH Series 210XH-P Series
System
Resources
Max support 8-ch standard definition with the transmission rate of 2Mbps for each
channel;
4-channel 720P, with the transmission rate of 4Mbps for each channel;
2-channel 1080P, with the transmission rate of 8Mbps for each channel;
Support 20 online users at the same time,
4
The image delay time of each channel is under 500ms.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Video
Compression
H.264/MJPEG
Encode
Capacity
For H.264, it max supports 8-channel D1, 4-channel 720P, 2-channel 1080P.
Audio
Compression
G.711a
Video Output 1-channel VGA analog video output.
Video Input 4/8-ch network compression video input
HDMI 1-ch HDMI output.
Audio Input 1-ch bidirectional talk input
Audio Output 1-ch bidirectional talk output
Window Split 1/4/9-window
Multiple-chann
el Playback
Max 8-channel D1/4-channel 720P/2-channel 1080P playback.
Alarm Input 2-ch alarm input
Alarm Output 2-ch alarm output
Storage 1 built-in SATA port.
RS232 Port N/A
RS485 port N/A
USB2.0 Port 2 peripheral USB2.0 ports. One at the front panel and one at the rear panel.
Network
Connection
One RJ45 10/100Mbps self-adaptive
Ethernet port.
4 PoE ports. Built-in Switch. Support PoE
function.
Power Port One power port, power adapter. Input DC
12V.
Two power ports, power adapter. Input DC
12V or DC 48V.
Power Button No on/off button. Connect to the power cable to boot up.
On-off Button N/A
Clock Built-in clock.
IR Remote
Control
Receiver
Support IR remote control
5
Indication Light One alarm status indication light.
One network status indication light.
One HDD status indication light.
Power
Consumption
＜12W(Exclude HDD)
Working
Temperature
0℃～+50℃
Working
Humidity
10℅－90℅
Air pressure 86kpa－106kpa
Dimension 325mm×245mm×55mm
Weight 0.5~1KG（Exclude HDD）
Installation Desk installation
1.3.3 22 Series
SpecificationsParameter
2204 Series 2208 Series 2216 Series
System
Resources
Max support 16-ch standard definition with the transmission rate of 2Mbps for each
channel;
16-channel D1,
8-channel 720P, with the transmission rate of 4Mbps for each channel;
4-channel 1080P, with the transmission rate of 8Mbps for each channel;
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Video
Compression
H.264/MJPEG
Encode
Capacity
It max supports 16-channel D1, 8-channel 720P, 4-channel 1080P.
Audio
Compression
G.711a
Video Output 1-channel VGA analog video output.
Video Input 4/8/16-ch network compression video input
HDMI 1-ch HDMI output.
Audio Input N/A
Audio Output N/A
Window Split 4/8/9/16-window
Multiple-chann
el Playback
Max 16-channel D1/8-channel 720P/4-channel 1080P real-time playback.
6
Alarm Input N/A
Alarm Output N/A
Storage 2 built-in SATA ports.
RS232 Port
(RS-422)
One RS232 port to debug transparent COM data.
RS485 port
(Rs-485)
One RS485 port to control PTZ. Support various protocols.
USB2.0 Port 2 peripheral USB2.0 ports.
Network
Connection
One RJ45 10/100/1000Mbps self-adaptive Ethernet port.
Power Port One power port, power adapter. Input DC 12V.
Power Button One button. At the rear panel.
Power On-off
Button
One button. At the front-panel.
IR Remote
Control
Receiver
Support IR remote control
Clock Built-in clock.
Indication Light Sixteen record status indication light.
One power status indication light.
One network status indication light.
One HDD status indication light.
Power
Consumption
＜12W(Exclude HDD)
Working
Temperature
0℃～+50℃
Working
Humidity
10℅－90℅
Air pressure 86kpa－106kpa
Dimension 375mm×287mm×52mm
Weight 1.5~2.5KG（Exclude HDD）
Installation Desk installation
1.3.4 24 Series
SpecificationsParameter
2408 Series 2416 Series
System
Resources
Max support 16-ch standard definition with the transmission rate of 2Mbps for each
channel;
16-channel D1,
7
8-channel 720P, with the transmission rate of 4Mbps for each channel;
4-channel 1080P, with the transmission rate of 8Mbps for each channel;
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Video
Compression
H.264/MJPEG
Encode
Capacity
It max supports 16-channel D1, 8-channel 720P, 4-channel 1080P.
Audio
Compression
G.711a
Video Output 1-channel VGA analog video output.
Video Input 8/16-ch network compression video input
HDMI 1-ch HDMI output.
Audio Input N/A
Audio Output N/A
Window Split 4/8/9/16-window
Multiple-chann
el Playback
Max 16-channel D1/8-channel 720P/4-channel 1080P real-time playback.
Alarm Input 8-ch alarm input
3-ch alarm output
Alarm Output
Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output））
Including one controllable DC +12V output.
Storage 4 built-in SATA ports.
1 eSATA port.
RS232 Port
(RS-422)
One RS232 port to debug transparent COM data.
RS485 port
(Rs-485)
One RS485 A/B port to control PTZ. Support various protocols.
USB2.0 Port 2 peripheral USB2.0 ports.
Network
Connection
One RJ45 10/100/1000Mbps self-adaptive Ethernet port.
Power Port One power port, AC100～240V 50+2% Hz
Power Button One button. At the rear panel.
8
Power On-off
Button
One button. At the front-panel.
IR Remote
Control
Receiver
Support IR remote control
Clock Built-in clock.
Indication Light Sixteen record status indication light.
One power status indication light.
Power
Consumption
＜12W(Exclude HDD)
Working
Temperature
0℃～+50℃
Working
Humidity
10℅－90℅
Air pressure 86kpa－106kpa
Dimension 440mm×405mm×70mm
Weight 1.5~2.5KG（Exclude HDD）
Installation Desk installation
1.3.5 31H Series
SpecificationsParameter
310XH Series 310XH-P Series
System
Resources
Max support 8-ch standard definition with the transmission rate of 2Mbps for each
channel;
4-channel 720P, with the transmission rate of 4Mbps for each channel;
2-channel 1080P, with the transmission rate of 8Mbps for each channel;
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Video
Compression
H.264/MJPEG
Encode
Capacity
For H.264, it max supports 8-channel D1, 4-channel 720P, 2-channel 1080P.
Audio
Compression
G.711a
Video Output 1-channel VGA analog video output.
Video Input 4/8-ch network compression video input
HDMI 1-ch HDMI output.
9
Audio Input 1-ch bidirectional talk input
Audio Output 1-ch bidirectional talk output
Window Split 1/4/9-window
Multiple-chann
el Playback
Max 8-channel D1/4-channel 720P/2-channel 1080P playback.
Alarm Input 2-ch alarm input
Alarm Output 1-ch alarm output
Storage 1 built-in SATA port.
RS232 Port N/A
RS485 port N/A
USB2.0 Port 2 peripheral USB2.0 ports. One at the front panel and one at the rear panel.
Network
Connection
One RJ45 10/100Mbps self-adaptive
Ethernet port.
4 PoE ports. Built-in Switch. Support PoE
function.
Power Port One power port, power adapter. Input DC
12V.
Two power ports, power adapter. Input DC
12V or DC 48V.
On-off Button One button at the front panel.
Clock Built-in clock.
IR Remote
Control
Receiver
Support IR remote control
Indication Light One network status indication light.
Power
Consumption
＜12W(Exclude HDD)
Working
Temperature
0℃～+50℃
Working
Humidity
10℅－90℅
Air pressure 86kpa－106kpa
Dimension 325mm×242mm×55mm
Weight 1.25KG（Exclude HDD）
Installation Desk installation
1.3.6 NVR-ELT-16 Series
Specifications
Parameter
NVR-ELT-16 NVR-ELT-16-POE4
System
Resources
Max support 16-ch standard definition with the transmission rate of 2Mbps for each
channel;
8-channel 720P, with the transmission rate of 4Mbps for each channel;
10
4-channel 1080P, with the transmission rate of 8Mbps for each channel;
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
Operation
System Embedded Linux real-time operation system
Operation
Interface WEB/Local GUI
Video
Compression H.264/MPEG4
Encode
Capacity For H.264, it max supports 16-channel D1, 8-channel 720P, 4-channel 1080P.
Audio
Compression G.711a
Video Output 1-channel VGA analog video output.
Video Input 4/8/16-ch network compression video input
HDMI 1-ch HDMI output.
Audio Input 1-ch bidirectional audio input
Audio Output N/A
Wireless AP
antenna N/A
Window Split 1/4/9-window
Multiple-chann
el Playback Max 16-channel D1/8-channel 720P/4-channel 1080P playback.
Alarm Input N/A
Alarm Output N/A
Storage One built-in SATA port.
RS232 Port N/A
RS485 port N/A
USB2.0 Port One peripheral USB2.0 port.
Network
Connection One RJ45 10/100Mbps self-adaptive Ethernet port.
Power Port
One power port, power adapter. Input DC 12V. Two power ports, power
adapter. Input DC 12V or
DC 48V.
Power Button No on/off button. Connect to the power cable to boot up.
11
Power Button N/A
Clock Built-in clock.
Indication Light
One power status indication light.
One network status indication light.
One HDD status indication light.
Power
Consumption ＜12W(Exclude HDD)
Working
Temperature 0℃～+50℃
Working
Humidity 10℅－90℅
Air pressure 86kpa－106kpa
Dimension 270mmX205mmX41mm
Weight 600-700G（Exclude HDD）
Installation Desk installation
1.3.7 NVR-ELM-16
SpecificationsParameter
NVR-ELM-16 NVR-ELM-16-POE4
System
Resources
Max support 16-ch standard definition with the transmission rate of 2Mbps for each
channel;
8-channel 720P, with the transmission rate of 4Mbps for each channel;
4-channel 1080P, with the transmission rate of 8Mbps for each channel;
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
Operation
System Embedded Linux real-time operation system
Operation
Interface WEB/Local GUI
Video
Compression H.264/MPEG4
Encode
Capacity For H.264, it max supports 16-channel D1, 8-channel 720, 4-channel 1080P.
Audio
Compression G.711a
Video Output 1-channel VGA analog video output.
Video Input 4/8/16-ch network compression video input
HDMI 1-ch HDMI output.
Audio Input 1-ch bidirectional audio input
Audio Output 1-ch bidirectional talk output.
This manual suits for next models
