HE43-1
Installation and
Operating Instructions
for Security Fireplace
Model SECURE HE43-1
This installation manual will help you obtain
a safe, efficient, dependable installation for
your fireplace and chimney system. Please
read and understand these installation
instructions before beginning your
installation.
AUTION: Do not attempt to modify or
alter the construction of the fireplace or its
components. Any modification or alteration
of construction may void the warranty,
listings and approvals of this system. In that
case, Security Fireplace will not be
responsible for damages.
WARNING: This fireplace is designed for
use as a supplemental heater. It is not
intended for continuous use as a primary heat
source.
SAVE THESE INSTRU TIONS FOR
FUTURE REFEREN E
2125 Monterey St., Laval, Qc, anada, H7L 3T6
Printed in anada Rev. 11 November 2008 PIHE43-1
• Hot! Do not touch! The glass
and surfaces of this appliance
will be hot during operation
and will retain heat for a while
after shutting off the appliance.
Severe burn may result.
• arefully supervise children in
the same room as appliance.
• If small children are present in the home, it
is recommended that this appliance be used
with a fire screen kit.
Listed to standards:
UL -S610, UL-127
Report # 192-5237

CERTIFICATION LABEL
Warnock Hersey
US
C

3
TABLE OF ONTENTS
Page
Safety rules ...................................................................................................................................... 4
Fireplace maintenance
reosote ..................................................................................................................................... 5
himney maintenance ................................................................................................................ 5
himney fires .............................................................................................................................. 5
Glass cleaning ............................................................................................................................. 6
Doors adjustment ........................................................................................................................ 6
Glass replacement ....................................................................................................................... 6
Removal of ashes ........................................................................................................................ 7
Fireplace operation
Fuel ............................................................................................................................................. 7
First fires ..................................................................................................................................... 7
Building a fire ............................................................................................................................. 7
How to use the retractable doors and firescreens ....................................................................... 8
How to use the outside air register (fireplace) ............................................................................ 8
Fireplace installation
Recommendations ...................................................................................................................... 9
Tools and building supplies ...................................................................................................... 10
Installation procedure ............................................................................................................... 11
Locating the fireplace ............................................................................................................... 11
Adjacent walls .......................................................................................................................... 11
Enclosure ............................................................................................................................. 11-12
Facing and mantel ................................................................................................................ 12-13
Hearth extension ....................................................................................................................... 13
Outside air installation ......................................................................................................... 13-14
UZY5 fan kit installation ......................................................................................................... 15
Fireplace dimensions ................................................................................................................ 16
entral forced air kit ................................................................................................................. 17
Chimney installation
General notes ............................................................................................................................ 18
Straight installation .................................................................................................. 19-19-20-21
Offset installation .......................................................................................................... 22-23-24
Angled firestop installation ...................................................................................................... 25
Roof support installation ......................................................................................................... 26
Offset support installation ....................................................................................................... 26
himney chase and multiple terminations ............................................................................... 27
Parts an components (chimney) ............................................................................................... 28
Appen ix (Specifications, Clearances, Replacement parts, Options) .......................... 28-29-30

4
SAFETY RULES FOR OPERATING
YOUR FIREPLACE MODEL SECURE HE43-1
Warning: An outsi e air kit must be installed on the fireplace model SE URE HE43-1.
Warning: Always ensure that the air inlet to the fireplace is free from debris and any other
obstructions that can block the entrance of air
Warning: The fireplace must be operated with the doors fully opened or fully closed. "If the
doors are left partly opened, gas and flame may be drawn out of the fireplace
opening, creating risks of both fire and smoke."
• Use only Security Fireplace glass doors, specifically designed for the model SE URE HE43-1
fireplace. (See Appendix for part number).
• Always keep the firescreen or the doors closed and the damper opened when using the fireplace.
Keep the damper closed when the fireplace is not in use.
• The HE43-1 fireplace is sold with a steel wood grate. If you have to replace it, we recommend
for optimum efficiency, to replace it with an identical or similar model.
• A fireplace insert heating unit may be installed in the fireplace only if this unit has been certified
with the HE43-1 fireplace.
Caution: Never use gasoline, kerosene, charcoal lighter fluid or similar liquids to start or
"freshen up" a fire in this fireplace. Keep all such liquids well away from the
fireplace at all times.
Caution: Keep combustible materials at least 48 inches away from the front of the fireplace
opening.
Caution: Never leave children unattended when there is a fire burning in the fireplace.
Caution: This appliance is designed for use with wood or certified processed solid fuel
firelogs. "Do not poke or stir the logs while they are burning. Use only firelogs that
have been evaluated for the application in fireplace and refer to firelog warnings and
caution markings on packaging prior to use".
Warning: To avoid the risk of damaging the fireplace materials and increase the risk of fire, do
not use the fireplace to cook or warm food.
Warning: Never leave your fireplace unattended while it is burning.
WARNING: THIS FIREPLA E HAS NOT BEEN TESTED WITH AN UNVENTED GAS LOG
SET. TO REDU E RISK OF FIRE OR INJURY, DO NOT INSTALL AN
UNVENTED GAS LOG SET INTO THIS FIREPLA E.

5
FIREPLACE MAINTENANCE
C REOSOTE
When wood is burned slowly, it produces tar and other organic vapors which combine with expelled
moisture to form a black deposit called creosote. The creosote vapors condense in the relatively cool
chimney flue of a slow burning fire. As a result, creosote residue accumulates on the flue lining. When
ignited, this creosote makes an extremely hot fire. If the creosote accumulation is large, a creosote fire in
the chimney can damage the chimney and overheat the surrounding wood framing. reosote formation in a
chimney can be minimized by making small hot fires rather than slow burning, smouldering fires.
C HIMNEY MAINTENANCE
Regular chimney inspection and maintenance combined with proper operation will help prevent chimney
fires. Keep your chimney clean. Do not allow more than a 1/16" (1.6 mm) build-up of creosote in your
chimney. The amount of creosote will depend on variables such as frequency of use and type of fire. We
recommend that you follow the instructions below:
1. Initially, inspect the chimney system weekly. By doing this, you will learn how often it will be necessary
to clean your chimney.
2. Have your chimney cleaned by a qualified chimney sweep. If you wish to clean it yourself, we
recommend using a stiff plastic or non-metallic brush. If a metal brush is used, its size should be slightly
smaller than the flue to avoid damaging the chimney. Do not use a brush that could scratch the stainless
steel interior of the chimney.
WARNING: The following steps must be followe to sweep the chimney. Negligence to o so coul
cause creosote accumulation on the baffle an in the air circulation area.
Sweeping steps:
1. Remove fireplace top baffle and obstruct dilution air deflector.
2. lose chimney damper and doors.
3. Sweep.
4. Open damper and then doors.
5. lean fireplace from creosote
6. put fireplace top baffle back in place
3. Do not expect chemical cleaners to keep your chimney clean.
The raincap can be removed for inspection and/or cleaning of the chimney. Unscrew the braces which
attach the raincap to the chimney. Using gloves, firmly grip the lower portion of the rain cap. Turn the cap
1/8 of a turn counterclockwise and lift it off the chimney.
C HIMNEY FIRES
If you are having a chimney fire, follow these steps:
1. lose the glass doors and the air inlet.
2. lose the chimney outside air register.
3. Alert your family of the possible danger.
4. If you require assistance, alert your fire department.
5. If possible, use a dry chemical fire extinguisher, baking soda or sand to control the fire. Do not use water
as it may cause dangerous steam explosions.
6. Watch for smouldering or fire on combustibles next to the fireplace and chimney. heck outside to
ensure that sparks and hot embers coming out of the chimney are not igniting the roof.
7. Do not use the fireplace again until your chimney and fireplace have been inspected by a qualified
chimney sweep or a fire department inspector.

6
D OOR F RAME C ARE
Use a glass cleaner and a soft cloth to polish the frame. Do not use abrasives such as steel wool or steel
pads for they may scratch the door frame finish.
G LASS CLEANING
The SE URE HE43-1 is designed to keep the glass clean under normal operating conditions. To clean the
glass there are number of specially designed cleaners. Your authorized Security Dealer can recommend a
suitable cleaner which is available in your area. Regular household glass cleaners will not clean creosote.
Do not use abrasives such as steel pads, steel wool or oven cleaner as they will scratch the glass.
DO NOT USE HEMI AL GLASS LEANERS ON PAINTED SURFA ES AS IT MAY AUSE THE
PAINT TO PEEL.
AUTION: Do not allow window cleaner to get in contact with door gasket or paint on façade or door.
Once closed, contact of glass cleaner with the fireplace facade can provoke paint peeling off.
D OORS ADJUSTMENT
Glass doors may lose their adjustment during transportation or installation of the fireplace. A wrong
adjustment may cause a loss in combustion’s efficiency and control. The glass doors must be parallel, at the
same height and must almost touch each other when closed. Maximum spacing between the doors is one
sixteenth of an inch (1/16’’).
The glass doors can be adjusted by loosening the three (3) screws of the hinges' supports (see fastening
screws in figure 1). If a minor angular adjustment is needed, you may loosen only two (2) of the three (3)
screws using the other as a pivot point.
Figure 1
G LASS REPLACEMENT
The glass used for the SE URE HE43-1 doors is a high temperature ceramic glass. If the glass breaks, it
must be replaced with a ceramic glass such as Neoceram. Tempered or ordinary glass will not withstand the
high temperatures of the SE URE HE43-1. Replacement glass should be purchased from Security
himneys International Ltd. Do not operate the unit with cracked or broken glass. To remove the glass
panel, unscrew the frame screws, remove the interior frame and the glass panel.

7
R EMOVAL OF ASHES
Remove ashes only when the fire is out and the ashes are cold. Lift the wood grate until it rests against the
rear refractory; then remove the ashes. Ashes should be placed in a metal container with a tight-fitting
lid. The closed container of ashes should be placed on a non-combustible floor or on the ground,
well away from all combustible materials, pending final disposal. If the ashes are disposed of by
burial in soil or otherwise locally dispersed, they should be retained in the closed container until all
cinders have thoroughly cooled. Do not leave the ashes in the house as they give off carbon
monoxide and other toxic gases.
OPERATING THE SECURE HE43-1
F UEL
The Secure HE43-1 is designed to work best when fueled with seasoned cordwood. Hardwoods are
preferred to softwoods since the energy content of wood is relative to its density. Hardwoods will result in a
longer burning fire and less frequent refueling. A moisture content of 15% to 20% (seasoned) is preferred.
Excessively wet wood will be difficult to burn and will result in lower efficiency and increased creosoting.
Do not burn scrap or garbage, treated wood or wood such as driftwood from the ocean which has been
exposed to salt or other chemicals. Salt or chemicals can corrode the firebox and chimney. Do not abuse
the unit by burning large amounts of paper, cardboard, hristmas tree branches or building construction
materials such as pressed wood, plywood or lumber. Intense firing with these may overheat the fireplace,
causing damage to the unit, a fire, or even possibly igniting a chimney fire, if the chimney is creosoted.
F IRST FIRES
The first 5 or 6 fires should be small fires of short duration (about 30-60 minutes). The first fire should be
especially short. This will help cure the refractory bricks. The first fires may produce slight smoking due to
drying of the paint and steel and any dust accumulated on the fireplace will be burn off at this time. For this
reason the room should be well ventilated for the first few fires.
B UILDING A FIRE
To start a fire, place several crumpled up balls of newspaper in the firebox. Place small dry pieces of
kindling on top of the paper, crisscrossing the kindling so that there are airspaces in between. Place larger
pieces of kindling on top of the pile. Keep the fuel far back enough so that air can get underneath. Open the
air control fully and light the newspaper. Once the kindling fire is well established, cordwood can be added.
The unit will burn best with a minimum of two pieces of cordwood spaced 1" to 2" apart and allowing air to
get under the fuel. risscrossing or arranging the fuel so that air can get underneath, will help the fire to get
started easily.

8
H OW TO USE THE RETRACTABLE DOORS AND FIRESCREENS
The Security Fireplace Model HE43-1 features retractable doors and firescreens in order to allow a wider view of
the fire and save space when the doors are opened. To retract the doors, simply open them at 90° and push them
into the opening on the side of the firebox. The same procedure applies for the retractable firescreens. (see Fig. 2).
Note : Do not operate the fireplace with both firescreen an oors close at the same time.
Figure 2
H OW TO USE THE OUTSIDE AIR REGISTER ( FIREPLACE )
The outside air register is located on the upper part of the top louver. The outside air register supplies
oxygen to the fire and allows control of the fire when the doors are closed. The fresh air must come from
outside the house (the air intake must not draw air from inside the house). This will minimize the risk of
causing a negative pressure in the house. The more you slide the register to the left, the more fresh air
into the firebox and the more accelerated combustion you will get (see Figure 3). When starting a fire,
the register should always be fully opened.
Figure 3

9
FIREPLACE INSTALLATION
A DVICES TO THE INSTALLER :
1. Before beginning the installation of your fireplace, read these safety tips and installation instructions
carefully to be sure you understand them completely. Failure to follow them could cause a fireplace
malfunction resulting in serious bodily injury and/or property damage.
2. Your Security Fireplace and its instruction manual have been tested and listed to UL and UL
standards by Warnock Hersey International Inc. These instructions were written to give you an
outline for a fast and safe installation and trouble free operation.
Failure to use parts manufactured by Security himneys International Ltd. or variations in techniques
and construction materials described in this installation manual may create a serious fire hazard; it
may void the Security himneys International Ltd. warranty and will void the WHI listing.
3. Always check your local building codes. The installation must comply with their regulations.
Be ore beginning the installation, consult the local authorities and make sure your building
permit complies with their requirements.
4. This fireplace must be installed with a Security himneys International Ltd. chimney system model
ASHT+, S-2100+ or AC, or an Oliver Macleod chimney system model HT6000+, HT6103+, of 8"
insi e iameter.
5. To maintain top efficiency and to prevent build-up of soot and creosote, inspect and clean the
chimney periodically during the heating season.
6. To prevent possible hazards due to poor combustion and to avoid affecting other fuel burning
appliances (furnace, wood stove, etc.), ensure that the outside air kit is properly installed.
7. This fireplace is designed to allow the installation of a gas burner. In such a case, the installation
must conform with the National Gas ode ANSI Z223.1 and Z21.60. Warning: When using a gas
burner, it is mandatory to keep the chimney outside air register opened.
8. This fireplace has provision for the installation of a gas pipe and is intended only for connection to a
decorative gas appliance incorporating an automatic shutoff device and complying with ANSI
Z21.60-M96/ GA 2.26-M96, Standard for Decorative Gas Appliances for Installation in Solid-Fuel
Burning Fireplaces (reference lause 4.1.3 T).
9. The fireplace model SE URE HE43-1 is sold with glass doors. The outsi e combustion air kit is
man atory and is included with the fireplace. The blowers and the decorative brass trims and
panels are optional.
10. When selecting the location, the chimney outlet position and the direction of the wind are important
factor affecting the chimney performance. To allow a maximum draft and to reduce wind turbulence,
the chimney must:
• Penetrate the highest part of the roof.
• Be installed as far as possible of roof offsets, trees or any other obstructions that may cause wind
turbulence and back drafts in the chimney.
• The least amount of offsets (elbows) possible.

10
Tools an buil ing supplies normally require
Tools:
Phillips screwdriver
Slot style screwdriver
Hammer
Saw and/or Sabersaw
Level
Measuring tape
Plumb line
Electric drill and bits
Pliers
Square
If gas pipe is used:
Pipe wrench
Pipe cutter
Pipe threader
Pipe joint compound
Pipe key valve
Building supplies:
2" x 3" or heavier lumber
Drywall panel or equivalent
Silicone caulking (non-
combustible)
Overlay material for fireplace
façade
Hearth extension (non-
combustible

11
PRECAUTIONS !
The most important areas of concern dealing with the fireplace installation are clearances to combustible
materials, secure assembly of components parts, the height of the chimney system, the proper use of
accessory equipment and the techniques used in using finishing materials applied to fireplace surrounds,
hearth extensions and wall coverings. Each of these topics will be covered in greater detail throughout
this manual. Please give special attention to these instructions as you progress with your
installation.
F IREPLACE INSTALLATION PROCEDURE
1. Move the fireplace into the desired position (follow the recommendations below for enclosure).
2. Install the outside air assembly (or assemblies) - refer to page 13.
3. Install the enclosure surrounding the fireplace (refer to the sections "Enclosure" below and " Facing
and Mantel" on page 12).
4. Install the hearth extension (see page 12). Make sure the gap between the fireplace and the hearth
extension is sealed.
L OCATING THE S ECURITY F IREPLACE
Do not place the fireplace on carpeting, vinyl or other soft surface floor coverings. It may, however, be
directly placed on flat wood, plywood, particle board or other hard surface materials.
A DJACENT WALL
A wall perpendicular to and in front of the fireplace
front facing must be at least 18" (460 mm) from the
fireplace opening. A wall at 45º to the front facing
and starting at the fireplace’s outer edge is
permitted. Projections within this area are
permitted. See figure 4.
Figure 4
E NCLOSURE
1. WARNING : Do not place loose insulation or any other material in the space around the fireplace or
the chimney. Insulation placed on or around the fireplace or chimney may cause adjacent wood to
overheat and catch on fire.
2. The fireplace must be installed against a finished wall (like drywall finish). It must not be installed
against a vapor barrier or exposed insulation (see figure 5).
3. The fireplace is zero clearance. ombustible materials like wood, plywood, particle board or drywall
can be in direct contact with the fireplace reinforcements. Two inch (50 mm) clearance to
combustibles must be kept aroun the chimney.
4. WARNING : The top of the fireplace is not zero clearance. Do not place any insulating material in the
space above the fireplace for a height of 7 feet from the base of the fireplace.
5. Do not block the fireplace’s hot air vents or air inlets as this will cause the fireplace to overheat.

12
F IREPLACE F ACING
The fireplace should be framed using 2" x 3"
(50 mm x 75 mm) or heavier lumber. Figure 6
shows the general framing layout.
ombustible materials must be installed flush with
the fireplace facing. They may not project out in
front of the fireplace. Non-combustible materials
such as brick, stone or ceramic tile, may project in
front of and/or on the fireplace facing.
WARNING :
Figure 6
The header should rest on top of the metal spacers. Do not alter the spacers or notch the header to fit
around them. Do not block the air inlet or outlet as this will cause the fireplace to overheat.
Figure 5
C HASE E NCLOSURE
A chase is a vertical box-like structure constructed to
surround the fireplace and chimney. Refer to figure 5b
for a typical chase configuration. A chase should be
constructed and insulated just like any outside wal
l. In
a cold climate, we recommend the base of the chase
should also be insulated between the solid continuous
base beneath the fireplace and the outside base. hase
insulation in a cold climate installation is not required
for safety.
Insulate joists
Same as ceiling
Insulate joists
Same as ceiling
Insulation
(thermal barrier)
Firestop
Rain cap
Note : Non
-
combustible
chase flashing
must be used
to cover chase
opening
Outside
base
Solid
continuous
base
Optional
insulation
Figure 5b

13
M ANTEL
A wood mantel, if installed, must be at least 48"(1.2 m) above the base of the fireplace (see
Figure 7). There is no restriction regarding the length or the width of the mantel.
H EARTH EXTENSION REQUIREMENTS
A non-combustible hearth extension must be built in front of the fireplace and extend out on both sides.
Hearth extensions must be constructed according to the following guidelines:
1. A layer of sheet metal 0.018" (0.45 mm) thick or 3/8" (9 mm) thick millboard or any other material
(tiles, marble, granite) with equivalent heat resistance may be used.
heck with the local building authorities
before installing to determine what other materials are acceptable in your area.
2. The hearth extension should be secured to the floor. The gap between the fireplace and the hearth
extension must be sealed with non-combustible caulking or cement.
3. On a raised base or raised hearth, a "Z" shape piece of metal must be fabricated to join the bottom of
the fireplace to the floor.
* The supplied metal safety strip must be positioned as follows: One half under the fireplace and the
other half must extend on the floor over which the hearth extension will be built (figure 7b). The
safety metal strip must cover the entire width of the fireplace.
E LEVATED FIREPLACES ( FIGURE 7 )
Elevated fireplace installations require a special ‘Z’
Metal safety strip (field provided), in place of the safety
metal strip shown on figure 7b. The safety strip should
extend the full width of the fireplace. When more than
one safety strip is used they must overlap by a
minimum of 1 inch.
Figure 7a Figure 7b
Safety metal strip
Hearth extension
non-combustible
matreial
Floor
The crack between
the fireplace and the
hearth extension
must be sealed with
a non-combustible
material such as
sand-cement grout
Fireplace
Figure 7c ‘Z’ Safety strip

14
O UTSIDE AIR ASSEMBLY ( FIREPLACE AND AC CHIMNEY )
The outside air assemblies are mandatory or the ireplace and the AC chimney.
During operation, the fireplace requires air for combustion and draws air out of the house. It may starve
other fuel burning appliances such as gas or oil furnaces. As well, exhaust fans and fan driven appliances
may compete for air, causing a negative pressure in the home, resulting in smoke entering the home from
the fireplace. This situation is aggravated in modern airtight houses. To overcome this potential
problem, we require the installation of an outsi e air assembly to provide combustion air to the
fireplace.
O UTSIDE AIR INSTALLATION ( FIREPLACE AND AC CHIMNEY )
The outside air assembly must be installed according to the following guidelines:
1. The maximum length of 4" I.D.(100 mm) insulated flexible duct is 20 ft (6.1 m ). If a longer duct is
required, use a 6" I.D (150 mm) insulated flexible duct. The maximum length is 40 ft (12 m ). Refer
to figures 8b and 8c for connections.
2. The duct and register may be installed above or below floor level.
3. The outside air register must not be installed more than 10 feet (3.05 m) above the base of the
fireplace.
4. The outside air assembly must draw air from outside the house. It must not draw air from the attic,
the basement or a garage (see fig. 15 page 19).
5. Locate the outside register where it will be well away from automobile exhaust fumes or other vents.
6. The outside air register should be installed where it is not likely to be blocked by snow or exposed to
extreme wind
7. It is recommended to install the outside air register at floor level. However, if you must raise the air
register above the fireplace level, you will have to make a loop to the floor with the flexible pipe to
prevent from causing a draught in the outside air register (see Figure 8a).
Figure 8a
Figure 8b
Figure 8c

15
I NSTALLATION OF THE FAN KIT MODEL UZY5
Note: This an kit can easily be installed when the ireplace has a pre-installed junction box.
You just have to plug them in..
Rating: 120 Volts, 60Hz, .63A.
The fans have magnetic blower mounts. The junction box (factory installed on approved fireplaces for
the use of this fan kit) must be connected to 110 VA service before permanently enclosing the fireplace.
The access hole for connecting the 110 VA is located on the lower right exterior side of the fireplace.
I NSTALLATION INSTRU TIONS :
1. Open the bottom louver of the fireplace.
2. Place each fan kit into the fireplace side opening 1" from the back of the fireplace.
3. Install the automatic fan activator on the side of the firebox (the fan activator has a magnetic mount).
4. Plug the fan kit into the junction box.
5. Ground both fans to the back panel using the green screws.
NOTE: The fireplace must be electrically connecte an groun e in accor ance with local co es
or in the absence of local co es, with the current CSA C22.1 Cana ian Electrical Co e.
For U.S.A. installations, follow local co es an the National Electrical Co e ANSI/NFPA
No 70.
CAUTION: Should this an require servicing, the power supply must be disconnected.
These fans do not need regular maintenance; however, periodic cleaning is required. heck the area in
front of the fans and wipe or vacuum at least once a month during the operating season.

16
FRAMING DIMENSIONS
Fireplace opening
A
42-1/2" 1080mm
B
43-1/4" 1099mm
C
33" 838mm
D
16-1/2" 419mm
E
85" 2159mm
F
42-1/2" 1080mm
G
27" 686mm
H
26" 660mm
J
60-1/8" 1527mm
K
8" 203mm
L
1" 25mm
Corner installation
Outsi e air kit
Rough framing face
(unfinished shown)
Rough framing face (unfinishe shown)
* Zero clearance from back spacer to wall
Back wall of chase/enclosure
Inclu ing Finishing material, if any
Notes
Due to SIL ongoing commitment to
quality, all specifications, ratings
and dimensions are subject to change
without notice.
All framing dimensions calculated
for ½’’dry wall at the fireplace face.
If sheathing the chase or finishing
with other thickness materials,
calculations will need to be made.
* The fireplace must not be in
contact with any insulation or loose
filling material. over insulation
with dry wall panels around the
fireplace.
ombustibles materials can NOT be
used in the space directly above the
fireplace. Do not fill the space above
the fireplace with any material
(except the wood framing)
Knock out
for ucting
Knock-out
ucting
Outsi e air
intake

17
CENTRAL FORCED AIR KIT
The knock-outs provided on the sides of the HE43-1 allow the connection of insulated flexible pipe which
enables you to heat adjacent rooms up to 50 feet from the fireplace.
The ducting system must be installed as described below :
1. Fix the adaptor at the side of the fireplace by twist-locking the adaptor to the fireplace. You can use
more than one outlet on the fireplace (figure 9).
2. Attach the 5" flexible pipe, using the collars provided. Important: Make sure that the plastic
wrapping aroun the flexible pipe will not be in contact with the fireplace.
3. Route the flexible pipe to the chosen location. The ducting system can be installed either in an upper
room or in a lower room.
4. Attach the flexible pipe to the fan, using the collars (figure 10a).
5. Fix the decorative grill fan adaptor to the fan.
6. Attach a standard 3" x 10" grill to the adaptor.
7. Install the blower thermostat in that part of the house to be heated by the hot air duct. Do not install the
blower thermostat in the room where the fireplace is located. A cooling thermostat can be installed in
the same room as the unit. This thermostat will turn on the blower when the room where the fireplace is
located becomes too hot.
This option requires electricity. Make sure that the connections to the fan have been made according to the
local codes and comply with their requirements
Figure 10a
Figure 9

18
CHIMNEY INSTALLATION
GENERAL NOTES
1. The Security Fireplace Model SE URE HE43-1 is listed only with Security himneys International Ltd.
chimney systems. Do not connect the ireplace to a masonry chimney, chimney liner, or other brand
o actory-built chimney.
2. The Oliver Macleod chimney models HT6103+ and HT6000+ are respectively equivalent to Security
himneys International Ltd. chimney models ASHT+ and S2100+.
3. In areas with continuous temperatures below 0º F (-18º ), the use of an exterior chimney increases the
likelihood of operating problems such as low draft, high rate of creosoting and poor start up
characteristics. Exterior chimneys are also prone to down-drafting and flow reversal. Installations
located in a basement, in combination with outside chimneys, are especially prone to flow reversal. In
cold areas, air cooled chimneys should not be used in an exterior installation.
4. A chimney venting a fireplace shall not vent any other appliance.
5. The minimum system heights are indicated in Table 1.
6. In altitude, add 18" (450 mm) to the chimney for every 2000 feet (600 m) above sea level.
MINIMUM HEIGHTS
Fireplace Model SE URE HE43-1
himney Model ASHT+ / HT6103+ / S-2100+ / HT6000+ / A
Vertical Installation 15 ft (4.57 m)
One Offset (2 elbows) 18 ft (5.49 m)
Two Offsets (4 elbows) 20 ft (6.10 m)
Table 1
NOTE: A maximum of 2 offsets is allowed.
NOTE: In areas where winter temperatures are normally below freezing, the air cooled chimney may
produce condensation. This condensation may corrode the top of the fireplaces and is not covered under
warranty. For optimum performance of your fireplace, Security himneys International recommends the use
of an ASHT+ / HT6103+ or S2100+ / HT6000+ chimneys.
7. All chimney installations must include at least one support. The maximum length of chimney that can be
supported by the fireplace is 12 ft. (3.6 m) for S2100+/HT6000+, 18 ft (5.4 m) for ASHT+/ HT6103+ and
26 ft. (8 m) for A chimney.
8. The chimney must extend at least 3 ft. (915 mm)above its point of contact with the roof and at least 2 ft.
(610 mm) higher than any wall, roof or building within 10 ft. (3 m) of it (see Figure 12).
9. If the chimney extends higher than 5 ft (1500 mm) above its point of contact with the roof, it must be
secured using a roof brace or guide wires.
10. A rain cap must be installed on top of the chimney. Failure to install a rain cap may cause the fireplace
to corrode and operate inefficiently.
11. ut and frame square holes in all floors and the roof to provide a 2" (50 mm) clearance between the
chimney and any combustible materials. Do not fill this 2" (50 mm) space with any material (see Fig 13).
12. Portions of the chimney which may extend through accessible spaces must be enclosed to avoid contact
with combustible materials or damage the chimney.

19
CHIMNEY INSTALLATION INSTRUCTIONS
STRAIGHT INSTALLATION
ut and frame the holes in the ceiling, floor and roof where the chimney will pass (see Figure 13). Use a
plumb bob to line up the center of the holes. The hole sizes are indicated in Table 2 for the floor and ceiling
holes and Table 3 (page 20) for the roof holes.
Figure 12
From below, install a firestop in each ceiling/floor separation through which the chimney will pass. At the
attic level, install an attic radiation shield from above (see Figures 14a & 14b).
For ASHT+ / HT6103+ and S2100+ / HT6000+ chimneys, place the first chimney length on the fireplace.
To lock it into place, turn ¼ of a turn clockwise. With the A chimney you must use a starting section
before installing the first chimney length (see Figure 15). ontinue installing chimney lengths until you
reach the desired height.
Every time the chimney passes through a roof or a wall, install the appropriate firestop. When you reach the
desired height, install the roof support (see instructions included with the support).
Then, put the roof flashing in place and seal the joint between the roof and the flashing with roofing pitch.
For sloping roofs, place the flashing under the upper shingles and on top of the lower shingles. Nail the
flashing to the roof, using roofing nails (fig. 16a et 16b).
Place the storm collar over the flashing and tighten it with the bolt supplied. Finally, seal the joint between
the storm collar and the chimney, using silicone caulking.
Install the chimney cap.
HIMNEY MODEL SQUARE HOLE SIZE
ASHT+/HT6103+ 365 mm (14 3/8")
S2100+/HT6000+ 406 mm (16")
A 380 mm (15")
Figure 13

20
Figure 14a
Figure 14b
Figure 15
NOTE : THE OUTSIDE AIR KITS ARE MANDATORY
FOR BOTH FIREPLACE AND CHIMNEY
